wiper fluid Hyundai Coupe 2003 Owner's Manual

FEATURES OF YOUR HYUNDAI 1- 35
HGK046
B350A01O-AAT Tailgate Wiper And Washer Switch
1. :The washer fluid will be sprayed onto the
rear window and the wiper operates while the rear window wiper barrel is placed inthis position.
2.OFF3.INT :To use the intermittent wiper feature,
place the rear window wiper barrel in the"INT" position.
4.ON :When the point indicates "ON", the rear
window wiper operates continuously.
To use the windshield washer, pull the wiper/ washer lever toward the steering wheel. Whenthe washer lever is operated, the wipers auto-matically make two passes across the wind-shield. The washer continues to operate until thelever is released. NOTE:
o Do not operate the washer more than 15 seconds at a time or when the fluid reser-voir is empty.
o In icy or freezing weather, be sure the wiper blades are not frozen to the glassprior to operating the wipers.
o In areas where water freezes in winter, use windshield washer antifreeze.
B350B01O-AAT Windshield Washer Operation
HGK044
B350C01S-AAT Adjustable Intermittent Wiper Opera- tion
To use the intermittent wiper feature, place the wiper switch in the "INT" position. With the switchin this position, the interval between wipes can bevaried from 2 to 10 seconds by turning theinterval adjuster barrel.
HGK043
Mist Wiper Operation
HGK045
If a single wipe is desired in mist, push the windshield wiper and washer control lever up-wards.

DO-IT-YOURSELF MAINTENANCE
6-4 G020A01A-AAT
GENERAL CHECKS Engine Compartment
The following should be checked regularly:
o Engine oil level and condition
o Transaxle fluid level and condition
o Brake fluid level
o Clutch fluid level
o Engine coolant level
o Windshield washer fluid level
o Accessory drive belt condition
o Engine Coolant hose condition
o Fluid leaks (on or below components)
o Power steering fluid level
o Battery condition
o Air filter condition
G020B01A-AAT
Vehicle Exterior The following should be checked monthly:
o Overall appearance and condition
o Wheel condition and wheel nut torque
o Exhaust system condition
o Light condition and operation
o Windshield glass condition
o Wiper blade condition
o Paint condition and body corrosion
o Fluid leaks
o Door and hood lock condition
o Tire pressure and condition (including spare tire) G020C01A-AAT
Vehicle Interior
The following should be checked each time when the vehicle is driven:
o Lights operation
o Windshield wiper operation
o Horn operation
o Defroster, heating system operation (and air conditioning, if installed)
o Steering operation and condition
o Mirror condition and operation
o Turn signal operation
o Accelerator pedal operation
o Brake operation, including parking brake
o Manual transaxle operation, including clutch operation
o Automatic transaxle operation, including "Park" mechanism operation
o Seat control condition and operation
o Seat belt condition and operation
o Sunvisor operation
If you notice anything that does not operate correctly or appears to be functioning incorrect-ly, inspect it carefully and seek assistance fromyour Hyundai dealer if service is needed. G030A01A-AAT
CHECKING THE ENGINE OIL
Engine oil is essential to the performance andservice of the engine. It is suggested that youcheck the oil level at least once a week innormal use and more often if you are on a tripor driving in severe conditions. G030B02GK-GAT
Recommended Oil SH, SG or SG/CD (API) multi-grade and fuel efficient oil is recommended.
SSA6030B°C °F -25-13 20W-40 20W-50
15W-40 15W-50
10W-30
10W-40 10W-50
5W-40
5W-30
5W-2040
104
20 68
1050
032
-15 5 -10-14
1.6L (DOHC), 2.7 L (V6)

DO-IT-YOURSELF MAINTENANCE
6-10
G090A01A-GAT FILLING THE WASHER RESERVOIR The washer fluid reservoir supplies fluid to the windshield washer system. A good quality washer fluid should be used to fill the washer reservoir. The fluid level should bechecked more frequently during inclementweather or whenever the washer system is inmore frequent use. The capacity of the washer reservoir is 3.0 liters (3.2 U.S. quarts). CAUTION:
o Radiator antifreeze (engine coolant) should not be used in the washer system because it will damage the car's finish.
o The washer should not be operated if the washer reservoir is empty. This can dam-age the washer fluid pump.
HGK217
G080A02A-AAT
WINDSHIELD WIPER BLADES
The wiper blades should be carefully inspected from time to time and cleaned to remove accu-mulations of road film or other debris. To cleanthe wiper blades and arms, use a clean spongeor cloth with a mild soap or detergent and water.If the wipers continue to streak or smear theglass, replace them with Genuine HyundaiReplacement Parts or their equivalent. CAUTION:
o Do not operate the wipers on dry glass. This can result in more rapid wear of the wiper blades and may scratch the glass.
o Keep the blade rubber out of contact with petroleum products such as engineoil, gasoline etc.
G070A02GK-AAT
CHANGING THE AIR CLEANER FIL- TER
To change the filter, unsnap the clips around
the cover. When this is done, the cover can be lifted off, the old filter removed and the new filterput in its place. Genuine Hyundai ReplacementParts are recommended.
CAUTION:
o Operating your vehicle without a proper air cleaner filter in place can result inexcessive engine wear.
o Be careful that dust or dirt does not enter the air intake, or damage may result.
o When removing the air cleaner filter, be careful that dust or dirt does not enterthe air intake. These may result in dam-age to the air cleaner filter.HGK213HEF119
