A050A04A-AATHYUNDAI MOTOR COMPANY
Note: Because future owners will also need the information included in this manual, if you sell this Hyundai, please leave
the manual in the vehicle for their use. Thank you. CAUTION: Severe engine and transaxle damage may result from the use of poor quality fuels and lubricants that do not meet Hyundai specifications. You must always use high quality fuels and lubricants that meet thespecifications listed on Page 9-3 in the Vehicle Specifications section of the Owner's Manual. Copyright 2004 Hyundai Motor Company. All rights reserved. No part of this publication may be reproduced, stored in any retrieval system or transmitted in any form or by any means without the prior written permission of Hyundai Motor Company.
A040A01A-AAT
FOREWORD
Thank you for choosing Hyundai. We are pleased to welcome you to the growing number of discriminating people who drive Hyundais. The advanced engineering and high-quality construction of each Hyundai we build is something of which we'revery proud. Your Owner's Manual will introduce you to the features and operation of your new Hyundai. It is suggested that you read it carefully because the information it contains can contribute greatly to the satisfaction you receive from your new car. The manufacturer also recommends that all service and maintenance on your car be performed by an authorized Hyundai dealer. Hyundai dealers are prepared to provide high-quality service, maintenance and any other assistance that may berequired.
Page 8 of 389
A100A01LA100A02LA100A04L
A100A03L
A100A01L-GAT GUIDE TO HYUNDAI GENUINE PARTS
1. What are Hyundai Genuine Parts?
Hyundai Genuine Parts are the same parts used by Hyundai Motor Companyto manufacture vehicles. They are de-signed and tested for the optimum safe-ty, performance, and reliability to ourcustomers.
2. Why should you use genuine parts? Hyundai Genuine Parts are engineeredand built to meet rigid manufacturingrequirements. Using imitation, counter-feit or used salvage parts are not cov-ered under the Hyundai New Vehicle Limited Warranty or any other Hyundaiwarranty. In addition, any damage to orfailure of Genuine Hyundai Partscaused by the installation or failure ofan imitation, counterfeit or used sal-vage part is not covered by Hyundai
Motor Company.
3. How can you tell if you are purchas- ing Hyundai Genuine Parts?Look for the Hyundai Genuine PartsLogo on the package (see below). The export specifications are written in English only. Hyundai Genuine Parts are only soldthrough authorized Hyundai Dealer-ship and Service Center.
Page 9 of 389
FEATURES OF YOUR HYUNDAI 1- 1
1. FEATURES OF
YOUR HYUNDAI
B010A01GK
B010A02A-GAT FUEL RECOMMENDATIONS Use Unleaded Gasoline Unleaded gasoline with a Pump Octane Rating of 87 (Research Octane Number 91) or highermust be used in Hyundai vehicle. If leaded gaso-line is used, it will cause the catalytic converter tobecome ineffective and the emission controlsystem to malfunction.This can also result in increased maintenanceexpense. To avoid accidental use of leaded fuel,the large nozzle used with leaded gasoline atservice stations can not be inserted into fuel tankopening of Hyundai vehicle. NOTE:
o For some countries, Hyundai vehicles are
designed to use leaded gasoline. Whenyou are going to use leaded gasoline, askto Hyundai dealer whether leaded gaso-line in your vehicle is available or not.
o Octane Rating of leaded gasoline is same with unleaded one.
B010B01A-AAT What About Gasohol? Gasohol (a mixture of 90% unleaded gasoline and 10% ethanol or grain alcohol) may be usedin your Hyundai. However, if your engine devel-ops driveability problems, the use of 100% un-leaded gasoline is recommended. Fuels withunspecified quantities of alcohol, or alcoholsother than ethanol, should not be used. B010D01S-AAT Do not Use Methanol Fuels containing methanol (wood alcohol) should
not be used in your Hyundai. This type of fuel canreduce vehicle performance and damage com-ponents of the fuel system. CAUTION: Your Hyundai's New Vehicle Limited War-ranty may not cover damage to the fuel sys-tem and performance problems that arecaused by the use of methanol or fuels con-taining methanol. B010E01A-AAT Gasolines for Cleaner AirTo help contribute to cleaner air, Hyundai recom- mends that you use gasolines treated with deter-gent additives, which help prevent deposit for-mation in the engine. These gasolines will helpthe engine run cleaner and enhance performanceof the Emission Control System. B010F01A-AAT Operation in Foreign Countries If you are going to drive your Hyundai in another country, be sure to:
o Observe all regulations regarding registra-
tion and insurance.
o Determine that acceptable fuel is available. B020A01S-GAT BREAKING IN YOUR NEW HYUNDAI During the First 2,000 Km (1,200 Miles) No formal "break-in" procedure is required with your new Hyundai. However, you can contributeto the economical operation and durability of yourHyundai by observing the following recommen-dations during the first 2,000 km (1,200 miles).
o Don't drive faster than 88 km/h (55 mph).
o While driving, keep your engine speed (rpm, or revolutions per minute) between 2,000 rpmand 4,000 rpm.
o Use moderate acceleration. Don't start, de- press the accelerator pedal fully.
1
Page 10 of 389
FEATURES OF YOUR HYUNDAI
1- 2
o For the first 300 km (200 miles), try to avoid
hard stops.
o Don't lug the engine (in other words, don't drive so slowly. In too high a gear that the engine "bucks" shift to a lower gear).
o Whether going fast or slow, vary your speed from time to time.
o Don't let the engine idle longer than 3 minutes at one time.
o Don't tow a trailer during the first 2,000 km (1,200 miles) of operation.
SSA1030A
B030A01A-AAT KEYS For greater convenience, the same key operates all the locks in your Hyundai. However, becausethe doors can be locked without a key, carryinga spare key is recommended in case you acci-dentally lock one key inside the car. B030B01S-AAT Record Your Key NumberSSA1030B
A code number is stamped on the key number plate that came with the keys to your Hyundai.This key number plate should be kept in a safeplace, not in the vehicle. The key number shouldalso be recorded in a place where it can be foundin an emergency. If you need additional keys, or if you should lose your keys, your authorized Hyundai dealer canmake new keys if you can supply the key num-ber.
B880A01A-GAT IMMOBILIZER SYSTEM (If Installed) The immobilizer system is an anti-theft device, designed to deter automobile theft. B880B03A-GAT Keys
All of the locks fitted to the vehicle are operated by the same key. However, since it is possible tolock the doors without the use of the key, careshould be exercised to ensure that the key doesnot become locked inside the vehicle by mistake. NOTE: If you make your own duplicate key, you willnot be able to cancel the system or start theengine.
AX10020A-1
Page 11 of 389
FEATURES OF YOUR HYUNDAI 1- 3
B040A02Y-AAT DOOR LOCKS WARNING:
o Unlocked doors can be dangerous. Be-
fore you drive away (especially if there are children in the car), be sure that all thedoors are securely closed and locked sothat the doors cannot be inadvertentlyopened from the inside. This helps ensurethat the doors will not be opened acciden- tally. Also, when combined with the proper use of seat belts, locking the doors helpskeep occupants from being ejected fromthe car in case of an accident.
o Before opening the door, always look for and avoid oncoming traffic.
o In case of accident, the door is unlocked automatically (If installed).
B880C02A-GAT Key Numbers
AX10030A-1
The vehicle key number is recorded upon a metal tag attached to the keys when the vehicleis first delivered to you.The key number should be recorded and kept ina safe place in case the need to order furtherkeys arises. New keys are available from anyHyundai dealer by quoting the relevant key num-ber.In the interest of security, the metal tag attachedto the keys which bears the key number shouldbe removed from the key ring after you receiveyour new vehicle. In addition, key numbers can-not be provided by Hyundai for security reasons.If you need additional keys or if you should loseyour keys, your authorized Hyundai dealer canmake new keys. B880D01GK-GAT Limp Home Procedures In case the immobilizer system is out of order, you cannot start the engine without the limphome procedures with ignition key.The following procedure is how to start the en-gine with the function of the limp home. (0, 1, 2,3 as a sample password). NOTE: You can get the limp home password whenthe vehicle is first delivered to you. If you donot have the password, consult your autho-rized Hyundai dealer.
1. To set the password, you may turn the ignition
key "ON" and then turn it "OFF" according to the digit numbers. For example, turn the igni- tion key once for digit number "1", and twice for "2", and so on. However, for the digitnumber "0", you must turn the ignition key for10 times.
2. Wait for 3~10 seconds.
3. You may set the remaining number of digits by following the same procedures 1 and 2.
4. If all of four digits have been tried success- fully, from this time, you have to start yourengine within 30 seconds. If you start yourengine after 30 seconds, your engine will notstart.
After doing the limp home procedure, you have toconsult with your authorized Hyundai dealer assoon as possible.
CAUTION: If you cannot start your engine in spite of limphome procedure, have your vehicle towed byan authorized Hyundai dealer.
Page 13 of 389
FEATURES OF YOUR HYUNDAI 1- 5
B070A01A-AAT THEFT-ALARM SYSTEM (If Installed)This system is designed to provide protection from unauthorized entry into the car. This systemis operated in three stages: the first is the "Armed"stage, the second is the "Alarm" stage, and thethird is the "Disarmed" stage. If triggered, thesystem provides an audible alarm with blinkingof the turn signal light.
B070C01GK-GAT Alarm StageThe alarm will be activated if any of the following occur while the car is parked and the system isarmed.
1) A front door is unlocked and opened without
using the transmitter.
2) The tail gate is opened without using the key.
3) The engine hood is opened. The siren will sound and the turn signal lights will blink continuously for 30 seconds. (E.C only/Except E.C : This happens 3 times). To turn offthe system, unlock the door with the transmitter. CAUTION: Avoid trying to start the engine while thesystem is armed.
B070B02GK-AAT Armed Stage Park the car and stop the engine. Arm the system as described below.
1) Remove the ignition key from the ignition
switch.
2) Make sure that the engine hood and tail gate are closed and latched.
3) Lock the doors using the transmitter of the keyless entry system.
After completion of the steps above, the turn signal light will blink once to indicate that thesystem is armed. NOTE:
1) If any door, tail gate or engine hood re- mains open, the system will not be armed.
2) If this happens, rearm the system as de- scribed above.
3) Once the system is armed, only the tail gate may be unlocked using the key with-out disarming the system. CAUTION:Do not arm the system until all passengershave left the car. If the system is armed whilea passenger(s) remains in the car, the alarmmay be activated when the remainingpassenger(s) leaves the car.
B070D03GK-AAT Disarmed Stage The system will be disarmed when either of the following steps are taken:
1) The driver's or passenger's door is unlocked
by depressing the "UNLOCK" button on the transmitter.
2) In the middle of alarming or after alarming, it disarms after 30 seconds if the key is turnedto and kept in the "ON" position.
3) If after disarming the system with the trans- mitter the doors are not opened within 30seconds, the system will automatically re-arm.
After completing one of steps above, the turnsignal light will blink twice to indicate that thesystem is disarmed. HGK102
UNLOCK
LOCK
Page 29 of 389
FEATURES OF YOUR HYUNDAI 1- 21
B240B01GK-GAT SRS Components and Functions The SRS consists of the following components: - Driver's Airbag Module - Passenger's Airbag Module- SRS Service Reminder Indicator (SRI)- SRS Control Module (SRSCM) The SRSCM continually monitors all elements while the ignition is "ON" to determine if a frontalor near-frontal impact is severe enough to re-quire airbag deployment. The SRS service reminder indicator (SRI) on the instrument panel will blink for about 6 secondsafter the ignition key is turned to the "ON" positionor after the engine is started, after which the SRIshould go out.
o Do not tamper with or disconnect SRS
wiring, or other components of the SRSsystem. Doing so could result in injury,due to accidental firing of the airbags orby rendering the SRS inoperative.
o Do not install a child restraint system in the front passenger seat position. A childrestraint system must never be placed inthe front seat. The infant or child could beseverely injured or killed by an airbagdeployment in case of an accident.
o Do not allow children to ride in the front passenger seat. If older children (teenag-ers and older) must ride in the front seat,make sure they are always properly beltedand that the seat is moved back as far aspossible.
o For maximum safety protection in all types of crashes, all occupants including thedriver should always wear their seat beltswhether or not an airbag is also providedat their seating position to minimize therisk of severe injury or death in the eventof a crash. Do not sit or lean unnecessarilyclose to the airbag while the vehicle is inmotion.
o The SRS airbag system must deploy very rapidly to provide protection in a crash. Ifan occupant is out of position because ofnot wearing a seat belt, the airbag mayforcefully contact the occupant causingserious or fatal injuries.
B240B01L
The airbag modules are located both in the center of the steering wheel and in the frontpassenger's panel above the glove box. Whenthe SRSCM detects a considerable impact to thefront of the vehicle, it will automatically deploy theairbags. CAUTION: Do not install or place any accessories (drinkholder, cassette holder, sticker, etc) on thefront passenger's panel above the glove boxin a vehicle with a passenger's air bag. Suchobjects may become dangerous projectilesand cause injury if the passenger's air baginflates.
B240B02L
Upon deployment, tear seams molded directly into the pad covers will separate under pressurefrom the expansion of the airbags. Further open-ing of the covers then allows full inflation of theairbags.
Page 30 of 389
FEATURES OF YOUR HYUNDAI
1- 22
A fully inflated airbag in combination with a prop- erly worn seat belt slows the driver's or thepassenger's forward motion, thus reducing therisk of head and chest injury.After complete inflation, the airbag immediatelystarts deflating, enabling the driver to maintainforward visibility.
Passanger's Airbag
B240B01GK
FUA1115A
CAUTION: When installing a container of liquid air fresh-ener inside a vehicle, do not place it near theinstrument cluster nor on the instrument panelpad surface. If there is any leakage from theair freshener onto these areas (instrumentcluster, instrument panel pad or air ventila-tor), it may damage these parts. If the liquidfrom the air freshener does leak onto theseareas, wash them with water immediately.
B240B03L
o The SRS can function only when the igni- tion key is in the "ON" position. If the SRS SRI does not come on or illuminatescontinuously when the ignition key isturned to "ON", or continuously remainson after flashing for about 6 seconds whenthe ignition key is turned to the "ON"position, or after the engine is started,comes on while driving, the SRS is notworking properly. If this occurs, have yourvehicle immediately inspected by yourHyundai dealer.
o Before you replace a fuse or disconnect a battery terminal, turn the ignition key tothe "LOCK" position or remove the igni-tion key. Never remove or replace the airbag related fuse(s) when the ignition keyis in the "ON" position. Failure to heed thiswarning will cause the SRS SRI to illumi-nate.
WARNING:
o When the SRS is activated, there may be a loud noise and fine dust will be releasedthroughout the vehicle. These conditionsare normal and are not hazardous. How-ever, the fine dust generated during airbagdeployment may cause skin irritation.Wash your hands and face thoroughlywith lukewarm water and a mild soap afteran accident in which the airbags weredeployed.
Page 32 of 389
FEATURES OF YOUR HYUNDAI
1- 24 o Do not tamper with or disconnect SRS
wiring, or other components of the SRS system. Doing so could result in injury,due to accidental firing of the airbags orby rendering the SRS inoperative.
o If components of the airbag system must be discarded, or if the vehicle must be
scrapped, certain safety preca utions must
be observed. Your Hyundai dealer knowsthese precautions and can give you the
necessary information. Failure to followthese precautions and procedures could
increase the risk of personal injury.
o If you sell your vehicle, be sure to inform the new owner of these important pointsand make certain that this manual is trans-ferred to the new owner.
o If your car was flooded and has soaked carpeting or water on flooring, youshouldn't try to start engine; have the car
towed to authorized Hyundai dealer.
WARNING:
o Do not install a child restraint system in
the front passenger seat position.
A child restraint system must never be placed in the front seat. The infant or childcould be severely injured by an airbagdeployment in case of an accident.
o Extreme Hazard! Do not use a reward facing restraint on a seat protected by anairbag in front of it!
o Modification to SRS components or wir- ing, including the addition of any kind ofbadges to the pad covers or modifications
to the body structure, can adversely affectSRS performance and lead to possibleinjury.
o For cleaning the airbag pad covers, use only a soft, dry cloth or one which hasbeen moistened with plain water. Solventsor cleaners could adversely affect theairbag covers and proper deployment ofthe system.
o No objects should be placed over or near the airbag modules on the steering wheel,instrument panel, and the frontpassenger's panel above the glove box,because any such object could cause harmif the vehicle is in a crash severe enoughto cause the airbags to inflate.
o If the airbags inflate, they must be re- placed by an authorized Hyundai dealer.
Page 35 of 389
FEATURES OF YOUR HYUNDAI 1- 27
B260B01GK-GAT
SRS (Airbag) Service Reminder Indicator (SRI)
The SRS service reminder indicator (SRI) comes on and flashes for about 6 seconds after theignition key is turned to the "ON" position or afterthe engine is started, after which it will go out. This light also comes on when the SRS is not working properly. If the SRI does not come on orilluminates continuously when the ignition key isturned to "ON", or continuously remains on afterflashing for about 6 seconds when you turned theignition key to the "ON" position or started theengine, or if it comes on while driving, have theSRS inspected by an authorized Hyundai Dealer. B260P02Y-GAT
ABS Service Reminder Indicator (SRI)(If installed)
When the key is turned to the "ON" position, the Anti-Lock Brake System will come on and thengo off in a few seconds. If the ABS SRI remainson, comes on while driving, or does not come onwhen the key is turned to the "ON" position, thisindicates that there may be a problem with theABS.If this occurs, have your vehicle checked by yourHyundai dealer as soon as possible. The normalbraking system will still be operational, but with-out the assistance of the anti-lock brake system. B260F01A-AAT
High Beam Indicator Light
The high beam indicator light comes on when-ever the headlights are switched to the highbeam or flash position.
B260D01A-AAT
Turn Signal Indicator Lights
The blinking green arrows on the instrumentpanel show the direction indicated by the turnsignals. If the arrow comes on but does not blink,blinks more rapidly than normal, or does notilluminate at all, a malfunction in the turn signalsystem is indicated. Your dealer should be con-sulted for repairs. B260G01A-AAT
Low Oil Pressure Warning Light
CAUTION:If the oil pressure warning light stays onwhile the engine is running, serious enginedamage may result. The oil pressure warninglight comes on whenever there is insufficientoil pressure. In normal operation, it shouldcome on when the ignition switch is turnedon, then go out when the engine is started. Ifthe oil pressure warning light stays on whilethe engine is running, there may be a seriousmalfunction.If this happens, stop the car as soon as it issafe to do so, turn off the engine and checkthe oil level. If the oil level is low, fill the engineoil to the proper level and start the engineagain. If the light stays on with the enginerunning, turn the engine off immediately. Inany instance where the oil light stays onwhen the engine is running, the engine shouldbe checked by an authorized Hyundai dealerbefore the car is driven again.
WARNING:If the both ABS SRI and Parking Brake/Brakefluid level warning lights remain "ON" orcome on while driving, there may be a prob-
lem with E.B.D (Electronic Brake Force Dis-tribution).If this occurs, avoid sudden stops and haveyour vehicle checked by your Hyundai dealeras soon as possible.
AIR
BAG
