Hyundai Coupe 2006 Owners Manual

1
FEATURES OF YOUR HYUNDAI
79CRUISE CONTROL
!
!
CAUTION:
To prevent damage to the goods or the vehicle, care should be taken when carrying fragile or bulky ob- jects in the luggage compartment.
WARNING:
Avoid eye injury. DO NOT over-stretch. ALWAYS keep face and body out of recoil path. DO NOT use when strap has visible signs ofwear or damage. B660A02S-GAT (If Installed) The cruise control system provides automatic speed control for your com- fort when driving on freeways, tollroads,or other noncongested highways. This is designed to function above approxi- mately 40 km/h (25 mph).
Main switch
OGK016660
B660B01GK-GAT To Set the Cruise Speed
1. Push in the cruise control mainswitch on the end of the barrel. The "CRUISE" indicator light in the in-strument cluster will be illuminated. This turns the system on.
2. Accelerate to the desired cruising speed above 40 km/h (25 mph).
3. Push the control switch downward
to "SET (COAST)" and release it. The "SET" indicator light in the in- strument cluster will illuminate.
4. Remove your foot from the accel- erator pedal and the desired speedwill automatically be maintained. OGK016661
!WARNING:
Pay particular attention during the down-hill driving with cruise controlsystem as the vehicle speed can be increased gradually.

1FEATURES OF YOUR HYUNDAI
80
o Decrease the vehicle speed to lessthan 40 km/h (25 mph).
o Release the main switch. B660D01E-GAT To Resume the Preset Speed The vehicle will automatically resume the speed set prior to cancellation when you push the control switch upward to"RESUME (ACCEL)" position and re- lease it, providing the vehicle speed is above 40 km/h (25 mph).
OGK016663
!
5. To increase speed, depress the accelerator pedal enough for the vehicle to exceed the preset speed. When you remove your foot from the accelerator pedal, the vehiclewill return to the speed you have set.
WARNING:
To avoid accidental cruise controlengagement, keep the cruise con- trol main switch off when not using the cruise control. B660C01GK-GAT To Cancel the Cruise Speed To disengage the cruise control sys- tem, pull the control switch toward the steering wheel to "CANCEL" position.Additionally, the following actions will disengage the system :
o Depress the brake pedal.
o Depress the clutch pedal (Manual
transaxle).
o Shift the selector lever to "N" posi- tion (Automatic transaxle).
o Decrease the vehicle speed lower than the memorized speed by 15km/h (9 mph). OGK016662

1
FEATURES OF YOUR HYUNDAI
81
B660E01E-AAT To Reset at a Faster Speed
1. Push the control switch upward to
"RESUME (ACCEL)" position and hold it.
2. Accelerate to desired speed and
release the control switch. Whilethe control switch is held, the ve- hicle will gradually gain speed. B660F01GK-AAT To Reset at a Slower Speed
1. Push the control switch downward
to "SET (COAST)" and hold it. The "SET" indicator light in the instru-ment cluster will illuminate. The ve- hicle will decelerate.
2. When the desired speed is obtained, release the control switch. The"SET" indicator light in the instru- ment cluster will turn off. While thecontrol switch is pushed, the vehicle speed will gradually decrease. OGK016661
!WARNING:
o Keep the main switch off when not using the cruise control.
o Use the cruise control system only when traveling on open high- ways in good weather.
o Do not use the cruise control when it may not be safe to keepthe car at a constant speed, for instance, driving in heavy or vary-ing traffic, or on slippery (rainy, icy or snow-covered) or winding roads or over 6% up-hill or down-hill roads.
o Pay particular attention to the
driving conditions whenever us-ing the cruise control system.
o During cruise-control driving
with a manual transaxle vehicle,do not shift into neutral without depressing the clutch pedal, or the engine will be overrevved. Ifthis happens, depress the clutch pedal or release the main switch.

1FEATURES OF YOUR HYUNDAI
82
SEEK UP ( ) Switch Press the SEEK UP ( ) switch 1 sec. or more.
1. RADIO mode When the SEEK UP ( ) switch is pressed, the unit will automatically tune to the next higher frequency.
2. TAPE mode Pressing the SEEK UP ( ) switch will play the beginning of the next music segment.
3. CD (compact disc)/CDC(compact disc changer) mode
Press the SEEK UP ( ) switch once to skip forward to the beginning of the next track.
VOL ( / ) Switch
o Press the VOL ( ) button to in- crease volume.
o Press the VOL ( ) button to de- cease volume.AUDIO REMOTE CONTROL SWITCH
o With the cruise control engaged,
when the brake pedal is applied, it is normal to hear the cruise control system deactivate. This is an indication of normal systemoperation.
o During normal cruise control
operation, when the"SET(COAST)" is activated or reactivated after applying the brakes, the cruise control willenergize after approximately 3 seconds. This delay is normal. B610A01GK-GAT (If installed) The steering wheel audio remote con- trol switch is installed to promote safe driving. POWER ON/OFF Switch Press the POWER ON/OFF switch to select Radio, Tape, CD (compact disc) and CDC (compact disc changer). Press the POWER ON/OFF switch once again to cancel Radio, Tape, CD (compact disc) and CDC (compactdisc changer).OGK046086L

1
FEATURES OF YOUR HYUNDAI
83HEATING AND AIRCONDITIONING CONTROL
B710A02GK-GAT
1. Side defrost nozzle
2. Side Ventilator
3. Windshield Defrost ventilator
4. Center Ventilator
OGK016003 B710B02O-AAT Center Ventilator The center ventilators are located in the middle of the dashboard. To change thedirection of the air flow, move the knob in the center of the vent up-and-down and side-to-side. The vents are openedwhen the vent knob is moved to " " position. The vents are closed when the vent knob is moved to " ". Keep thesevents clear of any obstructions. B710C02HP-AAT Side Ventilator The side ventilators are located on each side of the dash board. To changethe direction of the air flow, move the knob in the center of the vent up-and- down and side-to-side. The vents areopened when the vent knob is moved to " " position. The vents are closed when the vent knob is moved to " ".Keep these vents clear of any obstruc- tions.

1FEATURES OF YOUR HYUNDAI
84HEATING AND VENTILATION
B670A02GK-GAT Rotary Type
1. Temperature control switch
2. Air intake control switch
3. Air flow control switch
4. Air Conditioning switch
5. Fan speed control switch
6. Rear window defroster switch OGK046038L
B670B01A-AAT Fan Speed Control (Blower Control) This is used to turn the blower fan on or off and to select the fan speed. This blower fan speed, and therefore the volume of air delivered from thesystem, may be controlled manually by setting the blower control between the "1" and "4" positions. B670E02A-AAT Temperature Control This control is used to adjust the degree of heating or cooling desired.
Cool
OGK046045 OGK046043
Warm

1
FEATURES OF YOUR HYUNDAI
85
B670C02Y-AAT Air Intake Control This is used to select fresh outside air or recirculation of inside air.
FreshRecirculation
With the "
" mode selected, air
enters the vehicle from outside and is heated or cooled according to the otherfunctions selected. With the "
" mode selected, air from
within the passenger compartment is drawn through the heating system and heated or cooled according to the other functions selected. NOTE: It should be noted that prolonged operation of the heating system in "
" mode will give rise to fogging
of the windshield and side windows and the air within the passenger com- partment will become stale. In addi-tion prolonged use of the air condi- tioning with the "
" mode selected
may result in the air within the pas- senger compartment becoming ex- cessively dry.
OGK046044
B670D01MC-AAT Air Flow Control This is used to direct the flow of air. Air can be directed to the floor, instrument panel outlets, or windshield. Five sym-bols are used to represent Face, Bi- Level, Floor, Floor-Defrost and Defrost air position.The MAX A/C mode is used to cool the inside of the vehicle faster (If installed). OGK046039

1FEATURES OF YOUR HYUNDAI
86
Face-Level
Selecting the "Face" mode will cause air to be discharged through the face level vents. Bi-Level
Air is discharged through the face ventsand the floor vents. This makes it pos- sible to have cooler air from the dash-board vents and warmer air from the floor outlets at the same time. Floor-Level
Air is discharged through the floor vents,windshield defroster nozzle, side de- froster nozzle, side ventilator.
OGK016095 OGK016096 OGK016097

1
FEATURES OF YOUR HYUNDAI
87
Floor-Defrost Level
Air is discharged through the wind- shield defroster nozzle, the floor vents, side defroster nozzle, side ventilator. If the "Floor-Defrost" mode is selected,the A/C will turn on automatically and "Fresh" mode will be activated. Defrost-Level
Air is discharged through the wind- shield defroster nozzle, side defroster nozzle, side ventilator. If the "Defrost" mode is selected, the A/C will turn on automatically and "Fresh" mode will be activated.
OGK016098
OGK016099
MAX A/C-Level (If Installed)
Air is discharged through the face level vents. If the "MAX A/C" mode is selected, theA/C will turn on automatically and "Re- circulation" mode will be activated.
OGK016103
MAX A/C

1FEATURES OF YOUR HYUNDAI
88BI-LEVEL HEATING
B700A02A-AAT Your Hyundai is equipped with bi-level heating controls. This makes it pos- sible to have cooler air from the dash- board vents and warmer air from thefloor outlets at the same time. To use this feature:
o Set the air intake control switch to the fresh air (
) position.
o Set the air flow control at the bi-level (
) position.
o Adjust the fan speed control to the
desired speed.
o Set the temperature control between "Cool" and "Warm". OGK016700
HEATING CONTROLS
B690A02S-AAT For normal heating operation, set the air intake control to the fresh air (
)
position and the air flow control to the floor (
) position.
For faster heating, the air intake control switch should be set in the recirculate (
) position.
If the windows fog up, set the air flow control to the defrost (
) position.
(The A/C will turn on automatically and "Fresh" mode will be activated.) For maximum heat, move the tempera- ture control to "Warm". OGK046038
* The A/C or the air intake control switch returns to its former setting.
A/C
ON
ON or OFF * ON or OFF *
ONON Air Intake
Control Switch
or *
NOTE:
o The air intake control switch will change to "
" mode when the
ignition switch is turned "ON" with the MAX A/C mode selected.
o When you change to another mode
from MAX A/C, the A/C and the airintake control switch are set as shown in the following chart.
