Hyundai Getz 2006 Owner's Manual

1- 4 FEATURES OF YOUR HYUNDAI
B880A01A-EAT IMMOBILISER SYSTEM The immobiliser system is an anti-theft device, designed to deter vehicle theft. B885B02O-EAT Keys
5) Avoid rapid acceleration and maxi-
mum throttle openings.
6) Avoid harsh braking during the first 100 miles of urban motoring or 1,000 miles of motorway driving to allow the friction facings of the brake padsand shoes to bed against the discs and drums properly.
7) No trailer towing should be under- taken during the running-in period.
B020B01FC-EAT (Diesel Engine) The longevity and performance of the vehicle are greatly affected by the care exercised during the first 1,000 miles ofmotoring. Because of modern manu- facturing techniques, rigid guidelines regarding maximum road speeds havebecome unnecessary. However, cer- tain precautions should be observed in order to obtain the best possible perfor-mance and useful life from the vehicle. 1) Do not race the engine without a load
(i.e revving the engine in neutral).
2) During the first 600 miles the maxi- mum engine speed should be re- stricted to 3,000 rpm and gradually increased thereafter. And while driv-ing, keep under three quarters of maximum vehicle speed.
3) Avoid prolonged constant speed op- eration. The internal components ofthe engine will become more quickly run in if the operation speed is variedduring the running in period.
4) Never allow the engine to labour. Use
the gearbox freely and avoid largethrottle openings when the engine speed is below 1,500 rpm.
5) Avoid rapid acceleration and maxi- mum throttle openings.
6) Avoid harsh braking during the first
100 miles of urban motoring or 1,000 miles of motorway driving to allow the friction facings of the brake pads and shoes to bed against the discsand drums properly.
7) No trailer towing should be under
taken during the running in period. All of the locks fitted to the vehicle areoperated by the same key. However,since it is possible to lock the doors without the use of the key, care should be exercised to ensure that the keydoes not become locked inside the vehicle by mistake.
AX10020A-1
tbuk-1a.p65
3/6/2007, 10:21 AM
4

FEATURES OF YOUR HYUNDAI 1- 5
B880C02A-EAT Key Numbers The vehicle key number is recorded on a metal tag attached to the keys when the vehicle is first delivered to you.The key number should be recorded and kept in a safe place in case the need to order further keys arises. Newkeys are available from any Hyundai authorised repairer by quoting the rel- evant key number.In the interest of security, the metal tag attached to the keys which bears the key number should be removed fromthe key ring after you receive your new vehicle. In addition, key numbers cannot beprovided by Hyundai for security rea- sons.
AX10030A-1 If you need additional keys or if you should lose your keys, your Hyundai authorised repairer can make new keys.
NOTE: A non-genuine duplicate key will not start the engine.
!
CAUTION:
When starting the engine, do not use the key with other immobiliser keysaround. Otherwise the engine may not start or may stop soon after it starts.Keep each keys separately not to have any malfunction after you re- ceive your new vehicle. B040A02Y-EAT DOOR LOCKS
!WARNING:
o Unlocked doors can be danger- ous. Before you drive away (espe- cially if there are children in the car), be sure that all the doors are securely closed and locked so that the doors cannot be inadvert- ently opened from the inside. Thishelps ensure that doors will not be opened accidentally. Also, when combined with the proper use ofseat belts, locking the doors helps keep occupants from being ejected from the car in case of an accident.
o Before opening the door, always look for and avoid oncoming traf-fic.
o In case of accident the door is unlocked automatically (Not allmodels).
tbuk-1a.p65 3/6/2007, 10:21 AM
5

1- 6 FEATURES OF YOUR HYUNDAI
o To help prevent theft, always re-
move the ignition key, close all windows, and lock all doors andhatchback door when leaving your vehicle unattended.
B040B01A-EAT Locking and Unlocking Front Doors With a Key
o The door can be locked or unlocked
with a key.
o Lock the door by turning the key clockwise and unlock it by turning the key counterclockwise. B040C01FC-GAT Locking From the Outside The doors can be locked without a key. To lock the doors from the outside, first push the inside lock switch to the"LOCK" position, so that the red mark on the switch is not visible, then close the door.The door will not lock if the key is left in the ignition switch when the front doors close. This is normal. (Not all models) NOTE:
o When locking the door this way,
be careful not to lock the door with the ignition key left in thevehicle.
LOCK
HTB056-D
UNLOCK
HTB062-D
tbuk-1a.p65
3/6/2007, 10:21 AM
6

FEATURES OF YOUR HYUNDAI 1- 7
SB040G2-E CENTRAL DOOR LOCKING (Not all models)
SB040D1-F Locking from the Inside To lock the doors from inside, simply close the door and push the lock switch to the "LOCK" position.When this is done, the door cannot be opened using either the inside or the outside door handle. NOTE: When the door is locked, the red mark on the switch is not visible and the character "LOCK" on the switchis visible. SB040F2-E CHILD-PROOF REAR DOOR LOCK The rear doors are fitted with child proof locks to prevent accidental opening of the doors using the inside door handle, whilst allowing access by means of the outside handle (such as is required in the event of an acccident for example) provided that the door lock button is at the unlocked position. Use of the child proof lock mechanism is recommended when children are carried in the vehicle. The child proof lock mechanism may be activated by opening the door and moving the lever located by the door latch to the "
" locked position. Move
the lever to the opposite direction of "
" unlocked position when normal
door operation is desired.
HTB057-D
UNLOCK
LOCK
HTB058-D
HTB212-D
The central door locking is operated by pushing the driver's door lock switch toward the front or rear of the vehicle. Ifthe passenger and rear doors are open when the switch is pushed, the door will remain locked when closed. NOTE:
o When pushing the switch toward the rear, all doors and tail gate will unlock.When pushing the switch toward the front, all doors and tail gate will lock.
tbuk-1a.p65 3/6/2007, 10:21 AM
7

1- 8 FEATURES OF YOUR HYUNDAI
B070A01A-EAT ANTI-THEFT ALARM SYSTEM (Not all models) This system is designed to provide protection from unauthorized entry intothe car. This system is operated in three stages: the first is the "Armed" stage, the second is the "Alarm" stage,and the third is the "Disarmed" stage. If triggered, the system provides an au- dible alarm with blinking of the turnsignal lights. Park the car and stop the engine. Arm the system as described below.
1) Remove the ignition key from the
ignition switch.
2) Make sure that the engine bonnet ,
doors and hatchback door are closed.
3) Lock the doors using the transmitter
of the keyless entry system.
After completion of the steps above, the turn signal lights will blink once toindicate that the system is armed.
B070B01TB-D
B070B01O-EAT Armed Stage
o When the door is unlocked, the
red mark on the switch is visible and the character "LOCK" on theswitch is visible.
o The central door locking is oper-
ated by turning the key (with theft-alarm system: driver's door and passenger's door, without theft- alarm system: driver's door only)toward the front or rear of the vehicle.
o If the door is locked/unlocked mul- tiple times in rapid successionwith either the vehicle key or door lock switch, the system may stopoperating temporarily in order to protect the circuit and prevent damage to system components. NOTE:
1) If any door, hatchback door or
engine bonnet remains open, the system will not be armed.
2) If this happens, rearm the system as described above.
! CAUTION:
Do not arm the system until all pas- sengers have left the car. If the sys- tem is armed while a passenger(s)remains in the car, the alarm may be activated when the remaining passenger(s) leaves the car.
tbuk-1a.p65 3/6/2007, 10:21 AM
8

FEATURES OF YOUR HYUNDAI 1- 9
HTB202
B070D02TB-EAT Disarmed Stage
B070C02FC-EATAlarm Stage The alarm will be activated if any of the following occurs while the car is parkedand the system is armed.
1) A front or rear door is unlocked and
opened without using the transmit- ter.
2) The hatchback door is opened with-
out using the transmitter.
3) The engine bonnet is opened. The alarming horn will sound and the turn signal lights will blink continuously for approximately 27 seconds. To turnoff the system, unlock the door or hatchback door with the transmitter. The system will be disarmed when thedriver's or passenger's door is un- locked by depressing the button on thetransmitter. After completion of the step above, the turn signal lights will blink twice to indicate that the system is disarmed. NOTE: When the vehicle is unlocked using the unlock button on the remote, but the doors, bonnet or boot are not opened within 30 seconds, the doorswill relock and the system will re- arm. CAUTION:
Only the transmitter can disarm thearmed stage. If the transmitter does not disarm the system, it is neces-sary to take the following steps;
1. Unlock the door with the key, which will cause, the alarm to be activated.
2. Insert the key in the ignition key cylinder and turn the ignition keyto "ON" position.
3. Wait for 30 seconds. After completing the step above, the system will be disarmed.
!
tbuk-1a.p65 3/6/2007, 10:21 AM
9

1- 10 FEATURES OF YOUR HYUNDAI
HTB053
B070E01TB-EAT Replacing the battery When the transmitter's battery begins to get weak, it may take several pusheson the button to lock or unlock the doors, and the LED will not light. Re- place the battery as soon as possible. Battery type : CR1220 Replacement instructions:
1. Remove the screw with a (+) screw-
driver.
2. Separate the case with a (-) screw- driver as shown in the illustration.
- Other vehicles or objects may be
blocking the signal.
- The weather is extremely cold.
- The transmitter is close to a radio transmitter such as a radio stationor an airport which can interferewith normal operation of the trans- mitter.
When the transmitter does not workcorrectly, open and close the door with the ignition key. If you have aproblem with the transmitter, con- tact an authorized Hyundai Dealer. NOTE: Keep the transmitter away from wa- ter or any liquid. If the keyless entry system is inoperative due to expo-sure to water or liquids, it will not be covered by your manufacturer ve- hicle warranty.
B070F02TB-EAT Keyless Entry System (Not all models)Locking doors
1. Close all doors.
2. Push the button on the transmitter.
3. At the same time all doors lock, the
turn signal light will blink once to indicate that the system is armed.
Unlocking doors
1. Push the button on the transmitter.
2. At the same time all doors unlock, the turn signal light will blink twice to indicate that the system is disarmed.
NOTE: The transmitter will not work if any of following occur:
- The ignition key is in ignition switch.
- You exceed the operating distance limit (10 m).
- The battery in the transmitter is
weak.
tbuk-1a.p65 3/6/2007, 10:21 AM
10

FEATURES OF YOUR HYUNDAI 1- 11
!
HTB257-D
SB060A1-E MANUAL WINDOWS
The front door windows may be opened or closed by turning the window regula- tor handle. Ensure that when the win-dows are closed, nothing may become trapped between the glass and the door frame. HTB064-D
(1)
B060A02E-EAT POWER WINDOWS (Not all models)
The power windows operate when the ignition key is in the "ON" position. The main switches are located on the driver's armrest and control the front and rearwindows on both sides of the vehicle. The windows may be opened by de- pressing the appropriate window switchand closed by pulling up the switch. To open the window on the driver's side, press the switch(1) down. The windowmoves as long as the switch is oper- ated.
WARNING:
When opening or closing the win- dows, make sure your passenger's head, hair, arms and hands are safely out of the way.
3. Remove the four screws on the rear face of the built-in circuit. HTB054
HTB055
Battery
4. Before removing the battery note its position and ensure the new battery is fitted the same + side (positive) facing upwards, then insert it into the transmitter.
tbuk-1a.p65 3/6/2007, 10:21 AM
11

1- 12 FEATURES OF YOUR HYUNDAI
!
HTB024-D
B080A01FC-EAT SEAT ADJUSTMENT B080B02FC-EAT FRONT SEATS Front Seat Rake Adjustment
The front seat rake adjustment is per- formed by raising the lever at the frontof the seat base and sliding the seat to the desired position. At this position the lever should be released and the seatrocked to and fro to ensure that the mechanism has locked.
WARNING:
Front seat adjustments must not be undertaken whilst the vehicle is inmotion. Loss of control of the ve- hicle may result if seat adjustments are made whilst the vehicle is inmotion. WARNING:
1) Be careful that someone's head, hands and body are not trappedby a closing window.
2) Never try to operate the main switch on the driver's door andthe individual door window switchin opposing directions at the same time. If this is done, the window will stop and cannot be opened orclosed.
3) Always remove the ignition key
prior to exiting the car.
4) Do not leave children alone in the car.
!
!WARNING:
To ensure the seat is locked se- curely, attempt to move the seat for- ward or rearward without using thelever.
In order to prevent operation of the passenger front and rear windows, a window lock switch is provided on thearmrest of the driver's door. To disable the power windows, press the window lock switch.To revert to normal operation, press the window lock switch a second time. Auto-Down Window (Driver's Side) The Auto-Down window is moved to its fully open position by pushing the switch. To stop at the desired positionpush the switch again. HTB066-D
tbuk-1a.p65
3/6/2007, 10:21 AM
12

FEATURES OF YOUR HYUNDAI 1- 13
SB070C1-E Front Seat Recline Adjustment
HTB026-D
The front seat back recline angle may be adjusted by leaning forward slightly and raising the recline adjustment leverat the side of the seat. When the seatback is at the desired angle, the lever should be released. Ensure thatthe seatback is locked before driving the vehicle.
!WARNING:
To minimize risk of severe injury in the event of a collision or a sudden stop, both the driver and passenger seatbacks should always be in anupright position while the vehicle is in motion. The protection provided by the seat belts and airbags in afrontal collision may be reduced sig- nificantly when the seatbacks are reclined. There is greater risk thatthe driver and passenger will slide under the seat belt which may result in serious injury if a crash occurswhen the seatbacks are reclined. The seat belt cannot provide full protec- tion to an occupant if the seatback isreclined.
B080D02JM-EAT Adjustable Head restraints Head restraints are designed to help reduce the risk of neck injuries.To raise the head restraint, pull it up. To lower it, push it down whilst pressing the lock knob. To remove the headrestraint, raise it as far as it can go then press the lock knob whilst pulling up- ward. HFC2028
Lock knob
tbuk-1a.p65
3/6/2007, 10:22 AM
