FEATURES OF YOUR HYUNDAI 1- 45
1. Hatch back door Open Warning Light
2. Immobiliser Warning Indicator Light
3. Tachometer
4. Turn Signal Indicator Light
5. Automatic Transaxle Position Indicator Light
(Not all models)
6. Odometer/Trip Odometer
7. Fuel Gauge
8. Trip Computer (Not all models)
9. Speedometer
10. Malfunction Indicator Light (MIL)
11. Diesel Pre-heat Indicator Light (Diesel only)
12. High Beam Indicator Light
13. Engine Coolant Temperature Indicator Light 14. Parking Brake/Brake Fluid Level Warning Light
15. Door Open (Ajar) Warning Light
16. Passenger' s Front Airbag OFF Indicator Light
(Not all models)
17. SRS (Airbag) Warning Light (Not all models)
18. Low Fuel Warning Light
19. Electronic Stability Program (ESP) Indicator Light (Not all models)
20. ABS Warning Light
21. Fuel Filter Warning Light (Diesel only)
22. Seat Belt Warning Light
23. Oil Pressure Warning Light
24. Charging System Warning Light
25. Overdrive Off Indcator Light (Auto T/A only)

1- 52 FEATURES OF YOUR HYUNDAI
If the red indicator illuminates, pull over and stop as soon as possible and turn off the engine. Then open the bonnetand check the coolant level (See "If the engine overheats" on the page 3-4.) and the water pump drive belt. If you sus-pect cooling system trouble, have your cooling system checked by a Hyundai dealer as soon as possible. NOTE: If the red engine temperature indica- tor illuminates, it indicates overheat-ing that may damage the engine.
B265A01FC-EAT
FUEL FILTER WARNING LIGHT-RED(Diesel Engine)
This light illuminates when the engine has started and go off after a approimately seconds. If it lights upwhile the engine is running, it indicates that water has accumulated inside the fuel filter. If this happens, remove thewater from the fuel filter. (Refer to "6-24 page")B290A01TB-EAT ENGINE COOLANT TEM-
PERATURE INDICATOR
WARNING:
Never remove the radiator cap when the engine is hot. The engine coolantis under pressure and could erupt and cause severe burns. Wait until the engine is cool before removingthe radiator cap.
!
These indicators show the temperature of the engine coolant when the ignition switch is ON. Red indicator illuminatesif the temperature of the engine coolant is above 120±3°C (248±37.4°F). Blue indicator Illuminates if the tem-perature of the engine coolant is below 60±3°C (140±37.4°F).

FEATURES OF YOUR HYUNDAI 1- 53
B300A01A-EAT SPEEDOMETER
B300A01TB-E
Your Hyundai's speedometer is cali- brated in miles per hour or kilometers per hour.
A Type B Type
SB210S1-E BRAKE PAD WEAR INDICATOR The front brake disc pads are fitted with an audible wear indicator which will cause a high pitched noise to be emit- ted when the remaining amount of fric-tion lining is below the specified value. When the wear indicator is heard, the brake pads should be replaced withoutdelay to avoid damage occurring to the brake discs and a severe reduction in braking efficiency.
B900A01A-EAT ACOUSTIC WARNING SOUND (Not all models) The acoustic warning chime sounds when the tail lights are on and the door in driver side is open. This prevents thebattery from discharging when the car is left with the tail lights on. The chime sounds until the tail lights are turned off.
The needle on the gauge indicates the approximate fuel level in the fuel tank.The fuel capacity is given in Section 9.
B280A01A-AAT FUEL GAUGE
HTB2019

INDEX 10- 3
ENGINE COMPARTMENT . ......................................... 6-2
ENGINE COOLANT CHE CKING.................................. 6-9
ENGINE OIL CONS UMPTION ..................................... 6-9
ENGINE OIL REPLENISHMENT ................................. 6-8
ENGINE OIL ................................................................ 6-6 F FRONT ASHTRAY ...................................................... 1-64
FRONT SEAT ............................................................. 1-12
FRONT FOG LIGHT SWITCH ..................................... 1-61
FUEL ECONO MY ........................................................ 2-7
FUEL GAUGE ............................................................. 1-53
FUEL RECOMMENDATIONS ...................................... 1-2
FUSE PANEL DESCRI PTION .................................... 6-31
FUSIBLE LINKS ......................................................... 6-21
G
GLOVE BOX ............................................................... 1-69
HHATCHBACK DOOR .................................................. 1-76
HAZARD WARNING SYSTEM ................................... 1-60
HEADLIGHT AIMING ADJUSTEMENT.......................6-24
HEADLIGHT BULB ..................................................... 6-26
HEADLIGHT LEVELING DEVICE SYSTEM ...............1-65
HEATED REAR WINDOW .......................................... 1-61
HEATING AND COOLING CONTROL .........................1-83HEATING AND VENTILATION
...................................1-84
HEIGHT ADJUSTABLE FRONT SEAT SHOULDER BELT .................................................. 1-21
HORN ......................................................................... 1-81
HOW TO USE LUGGAGE ROOM ............................... 1-77
I
IF THE ENGINE CANNOT BE CRANKED ................... 3-2
IF THE ENGINE OVERHEATS .................................... 3-4
IF THE ENGINE WILL NOT START ............................ 3-2
IF THE EVENT OF A PUNCTURE ............................... 3-7
IMMOBILISER SYSTEM ............................................. 1-5
INDIVIDUAL CIRCUIT FUSES .................................... 6-21
INSTRUMENT CLUSTER AND INDICATORS............1-42
INTERIOR LIGHT ....................................................... 1-68
INTERIOR REAR VIEW MIRROR ............................... 1-72
JJUMP STARTING ....................................................... 3-3
KKEY POSITI ONS ......................................................... 2-4
