1- 50 FEATURES OF YOUR HYUNDAI
B370A01A-AAT HAZARD WARNING SYSTEM The hazard warning system should be used whenever you find it necessary to stop the car in a hazardous location.When you must make such an emer- gency stop, always pull off the road as far as possible.The hazard warning lights are turned on by pushing in on the hazard switch. This causes all turn signal lights toblink. The hazard warning lights will operate even though the key is not in the ignition.To turn the hazard warning lights off, push in on the switch a second time. B380A01HP-DAT REAR WINDOW DEMISTER SWITCH The rear window demister is turned on by pushing in on the switch. To turn the demister off, push in on the switch asecond time. The rear window demister automatically turns itself off after about 20 minutes. To restart the demistercycle, push in on the switch again after it has turned itself off.
HTB039
B350A01TB-AAT Tail Gate Wiper And Washer Switch
1. : The washer fluid will be sprayed onto the rear window and the wiper operates while the rear win-dow wiper barrel is placed in this position.
2.ON : When the point indicates "ON",
the rear window wiper oper-ates continuously.
3.OFF
B370A01TB-D
OMC048916R

FEATURES OF YOUR HYUNDAI 1- 51
B360B01FC-GAT FRONT FOG LIGHT SWITCH (If Installed)
To turn on the front fog lights, push the switch in the "ON" position. They will come on when the headlight switch isin the first or second position.
CAUTION:
Do not clean the inner side of therear window glass with an abrasive type of glass cleaner or use a scraper to remove foreign deposits fromthe inner surface of the glass as this may cause damage to the demister elements. NOTE: The engine must be running for the rear window demister to operate.
!
HTB2030-D
B400A01E-AAT DIGITAL CLOCK
HTB2033-D
There are three control buttons for the digital clock. Their functions are: HOUR -Push "H" to advance the hour
indicated.
MIN -Push "M" to advance the
minute indicated.
RESET - Push "R" to reset minutes to
":00" to facilitate resetting the clock to the correct time. When this is done:
Pressing "R" between 10 : 30 and 11 :29 changes the readout to 11 : 00. Pressing "R" between 11 : 30 and 12 :29 changes the readout to 12 : 00.

1- 52 FEATURES OF YOUR HYUNDAI
CAUTION:
Do not use electric accessories or equipment other than the Hyundai genuine parts in the socket.!
B420A02A-AAT CIGARETTE LIGHTER (If installed) For the cigarette lighter to work, the key must be in the "ACC" position or the "ON" position. To use the cigarette lighter, push it allthe way into its socket. When the ele- ment has heated, the lighter will pop out to the "ready" position.Do not hold the cigarette lighter pressed in. This can damage the heating ele- ment and create a fire hazard.If it is necessary to replace the ciga- rette lighter, use only a genuine Hyundai replacement or its approved equiva-lent.
HHR2098A
The instrument panel lights can be made brighter or dimmer by turning the instrument panel light control knob. HTB182-D
B410A01A-AAT INSTRUMENT PANEL LIGHT CONTROL (RHEOSTAT)

FEATURES OF YOUR HYUNDAI 1- 53
B500D01TG-DAT POWER OUTLET (If installed)
These supply 12V electric power to operate electric accessories or equip- ment only when the key is in the "ON" or "ACC" position.
!
CAUTION:
o Only use the power outlet when the engine is running. The use of this outlet with the engine not running may cause the battery to be discharged.
o Do not use the power outlet to connect electric accessories orequipment other than those de-signed to operate on 12 volts.
o Some electronic devices can cause
electronic interference whenplugged into the power outlet. These devices may cause exces- sive audio noise and malfunctionsin other electronic systems or de- vices used in your vehicle.
OHTB029040R
B430A01TB-GAT FRONT ASHTRAY (If installed) The front ashtray may be opened by pulling it up by its top edge. To closethe ashtray cover firmly, let the lid grip protrude outside. To remove the ash- tray to empty or clean it, pull the coverup all the way out. Either holder can be a drink holder or a ashtray holder. HTB100-D

1- 54 FEATURES OF YOUR HYUNDAI
B460A01Y-AAT SUNROOF (If installed) Sun Shade
Your HYUNDAI is equipped with a sliding sunshade which you can manu- ally adjust to let in light with the sunroof closed, or to block sunlight. B470A01FC
WARNING:
Never adjust the sunshade whiledriving.
!
Front side
B450A01TB-GAT DRINK HOLDER (If Installed) The drink holder is used for holding cups or cans. Either holder can be a drink holder or aashtray holder. HTB105-D
Rear side
B455A01TB-GAT CONSOLE TRAY There is a multipurpose compartment to accept pens or CD case in the console tray.
HTB307

FEATURES OF YOUR HYUNDAI 1- 55
!
B460B01GK-GAT Opening the Sunroof System The sunroof can be electrically opened or closed with the ignition key in the "ON" position. The sunroof is moved toits fully open position by pushing the "Open" switch, and to stop at the de- sired position, push in any switches(Open, Close, Up, Down). To close, press and hold the "CLOSE" button. Release the button when the sunroofreaches the desired position. HFC2021WARNING:
o Do not close a sunroof if anyone’s hands, arms or body are betweenthe sliding glass and the sunroofsash, as this could result in in- jury.
o Do not place your head or arms
out of the sunroof opening at anytime.
CAUTION:
o Do not open the sunroof in se- verely cold temperature or when it is covered with ice or snow.
o Periodically remove any dirt that
may have accumulated on theguide rails.
!
HFC2022
B460C01GK-GAT Tilting the Sunroof System The sunroof is moved to its fully tilt up position by pushing the "UP" switch, and to stop at the desired position,push in any switches (Open, Close, Up, Down). To tilt down, press and hold the"DOWN" button. Release the button when the sunroof reaches the desired position. NOTE: After washing the car or after there is rain, be sure to wipe off any water that is on the sunroof before oper-ating it.

1- 56 FEATURES OF YOUR HYUNDAI
HTB050
With Sunroof Without unroof
B480A01E-AAT FRONT INTERIOR LIGHT Map Light The two map light switches are located on both sides of the front overhead console. Push in the map light switchto turn the light on or off. This light produces a spot beam for convenient use as a map light at night or as apersonal light for the driver and the passenger.
B460E02TB-GAT Resetting the Sunroof System If the battery has been recharged, disconnected, or if the sunroof opera- tion is stopped by that ignition key isturned to the "OFF" position while it is moving, you may need to reset the sunroof. To do this;
1. Turn the ignition switch "OFF".
2. With pressing "open" "up" button at
the same time, turn the ignitionswitch "ON".
3. If the sunroof is set like this, the sunroof is reset with tilting up/downautomatically once for all.
! CAUTION:
If the sunroof is not reset, it may not be operated properly.
With SunroofWithout Sunroof
HTB303
The interior courtesy light has a button of three positions. The three positions are:
oDR Type A In the "DR" position, the interior cour- tesy light comes on when any door isopened regardless of the ignition key position. The light goes out when the door is closed.
B490A01TB-AAT INTERIOR LIGHT

FEATURES OF YOUR HYUNDAI 1- 57
Type B In the "DR" position, the interior cour- tesy light comes on when any door isopened regardless of the ignition key position. The light goes out gradually 6 seconds after the door is closed.
oON In the "ON" position, the light stays on at all times.
o OFF In the "OFF" position, the light stays off at all times even though a door is open.
!
!
WARNING:
To avoid the possibility of injury in case of an accident or a sudden stop, the glove box door should bekept closed when the car is in mo- tion.
o To open the glove box, pull on the glove box release lever.
B500A01A-AAT GLOVE BOX
HTB101-D
HTB102
B491A01TB-GAT SPECTACLE CASE (If Installed) The spectacle case is located on the driver side of roof trim.Pull the end of the cover to open the spectacle case.
WARNING:
Do not keep objects such as sharp or unsuitable things inside the spec- tacle case. Such objects can be thrown out in the event of a suddenstop or an accident, possibly injur- ing the passengers in the vehicle.

1- 58 FEATURES OF YOUR HYUNDAI
B510B01FC-GAT Electric Type (If installed) The outside rearview mirrors can be adjusted to your preferred rear vision, both directly behind the vehicle, and tothe rear of the left and right sides. The remote control outside rearview mirror switch controls the adjustmentsfor both right and left outside mirrors. HTB104-D
B510A01A-AAT OUTSIDE REAR VIEW MIRROR Manual Type (If installed) The outside rearview mirrors are equipped with a remote control for your convenience. It is operated by thecontrol lever in the bottom front corner of the window.
HTB306
CAUTION:
If the mirror control is jammed withice, do not attempt to break it free using the control handle or by ma- nipulating the face of the mirror. Use an approved spray de-icer (notradiator antifreeze) to release the frozen mechanism or move the ve- hicle to a warm place and allow theice to melt.
!
Before driving away, always check that your mirrors are positioned so you can see behind you, both to the left and rightsides, as well as directly behind your vehicle. When using the mirror, always exercise caution when attempting tojudge the distance of vehicles behind or along side of you.

FEATURES OF YOUR HYUNDAI 1- 59
HTB213
To adjust the position of either mirror:
1. Move the selecting switch to the
right or left to activate the adjustable mechanism for the correspondingdoor mirror.
2. Now, adjust mirror angle by de-
pressing the appropriate perimeterswitch as illustrated.
!
CAUTION:
o Do not operate the switch con- tinuously for an unnecessary length of time.
o Scraping ice from the mirror face could cause permanent damage.To remove any ice, use a sponge,soft cloth or approved de-icer.!
B510D01HP-DAT OUTSIDE REARVIEW MIRROR
HEATER (If Installed) The outside rearview mirror heater is actuated in connection with the rear window demister. To heat the outsiderearview mirror glass, push in the switch for the rear window demister. The rear- view mirror glass will be heated fordemisting or defogging and will give you improved rear vision in inclement weather conditions. Push the switch again toturn the heater off. The outside rearview mirror heater automatically turns itself off after 20 minutes. HTB039
WARNING:
Be careful when judging the size ordistance of any object seen in the passenger side rear view mirror. It is a convex mirror with a curvedsurface. Any objects seen in this mirror are closer than they appear.
