Hyundai H-100 Truck 2010 s Service Manual

1FEATURES OF YOUR HYUNDAI
40
CAUTION:
Do not use electric accessories or equipment other than the Hyundai genuine parts in the socket.
!
Reset: Press the switch for more than 1 sec- ond to reset minutes to ":00" or to facilitate resetting the clock to the cor-rect time. When this is done: Pressing the switch between 9 : 01 and 9 : 29 changes the readout to 9 : 00. Pressing the switch between 9 : 30 and 9 : 59 changes the readout to 10 : 00.
!
CIGARETTE LIGHTER
B420A02A-AAT For the cigarette lighter to work, the key must be in the "ACC" position or the "ON" position. To use the cigarette lighter, push it allthe way into its socket. When the ele- ment has heated, the lighter will pop out to the "ready" position.Do not hold the cigarette lighter pressed in. This can damage the heating ele- ment and create a fire hazard.If it is necessary to replace the cigarette lighter, use only a genuine Hyundai replacement or its approved equivalent. B420A01HR
CAUTION:
Don't turn the switch excessively toprevent switch damage.

1
FEATURES OF YOUR HYUNDAI
41ENGINE ILDE RPM ADJUST- MENT KNOBASHTRAY
B430A01HR-GAT The front ashtray may be opened by pulling it out by its grip. To remove the ashtray to empty or clean it, press downon the spring-loaded tab inside the ash- tray and pull it all the way out. B430A01HR
B420B01HR-GAT (If Installed) When the outside air temperature is very low or it is necessary to warm up the engine, turn the knob clockwise to that point at which the engine runssmoothly. Once the warming up is com- pleted, fully turn the knob counterclock- wise. B420B01HR
CAUTION:
Never attempt to adjust the controlknob during driving. This can cause severe engine dam- age.
!
DRINK HOLDER
!
B450A01HR-GAT (If Installed)
WARNING:
o Use caution when using the drink holders. A spilled beverage that is very hot can injure you or your passengers. Spilled liquids can damage interior trim and electri-cal components.
o Do not place anything except
drinks in the drink holder. Suchobjects can be thrown out, possi- bly injuring persons in the vehicle during sudden braking or in theevent of an accident. B450A01HR

1FEATURES OF YOUR HYUNDAI
42
The interior courtesy light switch has three positions. The three positions are: o "DOOR"
In the "DOOR" position, the interior courtesy light comes on when any door is opened regardless of theignition key position. The light goes out gradually 6 seconds after the door is closed.
B490A01HR-GAT Interior Light
(If installed, Without Spectacle Case)
HHR2070
o"ON"
In the "ON" position, the light stays on at all times.
CAUTION:
Do not leave the switch in this posi- tion for an extended period of timewhen the vehicle is not running.
o "OFF" In the "OFF" position, the light stays off at all times even though a door isopen.
!
INTERIOR LIGHT
B480A01HR-GAT Map Light (If installed, With Spectacle Case) The map light has two kinds button. The two buttons are as follow: o " " Push in this button to turn on or off the map light.This light produces a spot beam for convenient use as a map light at night or as a personal light for the driver andthe passenger. o " " With this button pressed, both map lights come on when any door is opened regardless of the ignition key position. The light goes out gradually 6 secondsafter the door is closed. HHR2072

1
FEATURES OF YOUR HYUNDAI
43SPECTACLE CASE
B491A02O-GAT (If Installed)
HHR2108
!
The spectacle case is located on the front overhead console. Push the end of the cover to open the spectacle case.WARNING:
Do not keep objects such as sharp orunsuitable things inside the spec-tacle case. Such objects can be thrown out in the event of a sudden stop or an accident, possibly injur-ing the passengers in the vehicle.!
GLOVE BOX
WARNING:
To avoid the possibility of injury in case of an accident or a sudden stop, the glove box door should be keptclosed when the car is in motion. B500A01A-AAT
OHR028105
o To open the glove box, pull on the glove box release lever.
B500C01HR-GAT Pen, Card and Tissue Holder For your convenience, a pen holder (1), a card holder (2) and a tissue holder (3) are located in the glove box cover. B500C01HR
(1)
(2)
(3)

1FEATURES OF YOUR HYUNDAI
44CENTER SEATBACK CON- SOLE COMPARTMENT
WARNING:
o Use caution when using the drink holders. A spilled beverage that is very hot can injure you or your passengers. Spilled liquids candamage interior trim and electri- cal components.
o Do not place anything except drinks in the drink holder. Suchobjects can be thrown out, possi- bly injuring persons in the vehicleduring sudden braking or in the event of an accident.!
B505A01HR-GAT (If Installed) Your vehicle is equipped with a console compartment on the backside of front center seat. To use console compartment, pushdown the lever and tilt the seatback forward. B500B01HRB505B01HR-GAT Multi Tray The multi tray is used for storing cas- sette tapes or small articles. To open the multi tray lid, press the hook in the lid's grip and pull up the lid.
HHR2107
B505C01HR-GAT Auxiliary Drink Holder (If Installed) The auxiliary drink holder is used for holding cups or cans.
B500B02HR
Lever

1
FEATURES OF YOUR HYUNDAI
45
B510A01HR-GAT Manual Type
Before driving away, always check that your mirrors are positioned so you can see behind you, both to the left and rightsides, as well as directly behind your vehicle. When using the mirror, always exercise caution when attempting tojudge the distance of vehicles behind or along side of you. NOTE: There is the assist convex mirror at the under side of driver's outside rearview mirror. You can take a bet-ter look at the dead zone. But, the object seems to be distorted. HHR2134
OUTSIDE REARVIEW MIRROR
CAUTION:
If the mirror control is jammed with ice, do not attempt to break it free using the control handle or by ma- nipulating the face of the mirror. Usean approved spray de-icer (not radia- tor antifreeze) to release the frozen mechanism or move the vehicle to awarm place and allow the ice to melt.
!
!WARNING:
Be careful when judging the size or distance of any object seen in the rearview mirror. It is a convex mirror with a curved surface. Any objectsseen in this mirror are closer than they appear. Check your inside rearview mirror orglance over your shoulder before changing lanes.
B505D01HR-GAT Coin Holder The coin holder is used to store coins.
HHR2114

1FEATURES OF YOUR HYUNDAI
46PARKING BRAKE
HHR3033DAY/NIGHT INSIDE REARVIEW MIRROR
B520A01A-AAT
Your Hyundai is equipped with a day/ night inside rearview mirror. The "night" position is selected by flipping the tab at the bottom of the mirror toward you.In the "night" position, the glare of headlights of cars behind you is re- duced. HHR2057
!
B510C01A-AAT Folding the Outside Rearview Mirrors To fold the outside rearview mirrors, push them towards the rear. The outside rearview mirrors can be folded rearward for parking in narrowareas.
WARNING:
Do not adjust or fold the outsiderearview mirrors while the vehicleis moving. This could result in loss of control, and an accident which could cause death, serious injuryor property damage. HHR2136
B530A02A-AAT Applying the parking brake To engage the parking brake, first apply the foot brake and then without press-ing the release button in, pull the park- ing brake lever up as far as possible. In addition it is recommended that whenparking the vehicle on a gradient, the shift lever should be positioned in the appropriate low gear on manual transaxlevehicles or in the P (Park) position on automatic transaxle vehicles.

1
FEATURES OF YOUR HYUNDAI
47
2. Push the secondary latch lever to the left and lower the hood.
To close the hood, lift up it and hit the center of the hood with your hand. Makesure that it locks into place. NOTE: If the hood will not open because ice has formed around it, tap lightly orpush on the hood to break the ice and release the hood. Do not pry on the hood. If necessary, spray aroundthe hood with an approved de-icer fluid (do not use radiator anti-freeze) or move the vehicle to a warm placeand allow the ice to melt.
!WARNING:
o Always double check to be sure that the hood is firmly latched before driving away.
o Do not press excessively or step
on the hood. This can cause thehood to fall and result in serious injury.
HOOD RELEASE
B570A01HR-GAT
1. Pull the release knob to unlatch the hood.
B570B01HR
B570A01HR
Releasing the parking brake To release the parking brake, first apply the foot brake and pull the parking brake lever slightly. Secondly, depress therelease button and lower the parking brake lever while holding the button. CAUTION:
Driving with the parking brake ap- plied will cause excessive brake pad(or lining) and brake rotor wear.
!

1FEATURES OF YOUR HYUNDAI
48
!WARNING:
o Make sure to refuel your vehicle according to the "Fuel require- ments" suggested in section 1.
o Fuel vapors are dangerous. Be-
fore refueling, always stop theengine and never allow sparks or open flames near the tank area. If you need to replace the tank cap,use a genuine Hyundai replace- ment part. If you open the fuel tank cap dur-ing high ambient temperatures, a slight "pressure sound" may be heard. This is normal and not acause for concern. Whenever you open the fuel tank cap, turn it slowly.
o Automotive fuels are flammable/ explosive materials. When refuel-ing, please note the followingguidelines carefully.
- Before touching the fuel nozzle or
fuel tank cap, have one's hands incontact with metal parts away from the tank neck to discharge static electricity.
FUEL TANK CAP
B560A03HR-GAT
The fuel tank cap is located at the left side of the vehicle body. The fuel tank cap can be unlocked by turning the key counterclockwise.To lock the fuel tank cap, turn it clock- wise until it locks into place. NOTE: If the fuel tank cap will not open because ice has formed around it, tap lightly on the cap to break the iceand release the cap. If necessary, spray around the cap with an ap- proved de-icer fluid (do not use ra-diator anti-freeze) or move the ve- hicle to a warm place and allow the ice to melt. HHR2036
- Do not get back in the vehicle
while refueling. Do not operateanything that can produce static electricity. Static electricity dis- charge can ignite fuel vapors re-sulting in an explosion.
- When using a portable fuel con-
tainer, be sure to place the con-tainer on the ground while refuel- ing. Static electricity discharge from the container can ignite fuelvapors causing a fire. While start- ing refueling, contact should be maintained until the filling is com-plete.
- Do not use cellular phones around
a gas station. The electric currentor electronic interference from cel- lular phones can ignite fuel va- pors causing a fire.
- When refueling, always turn the engine off. Sparks by engine com-partment electrical equipment canignite fuel vapors causing a fire. After refueling, check to make sure the fuel tank cap is securely closed,and then start the engine.
- Do not smoke or try to light ciga-
rettes around a gas station. Auto-motive fuels are flammable.

1
FEATURES OF YOUR HYUNDAI
49SIDE GATE
B191B01HR-GAT To open the side gate
1. With the rear gate opened, pull up the knob to release the support bar down. HHR2026
Support bar
!WARNING:
When the rear combination lamps are hidden, other road users shouldbe warned by means of warning tri- angle or other devices. To close the rear gate
Lift the rear gate up and lock the rear gate handle in place. HHR2031
2. Lower the rear gate slowly with it
received on both arms.
REAR GATE
B191A01HR-GAT To open the rear gate
HHR2025
1. Lift up the rear gate handle, push it inside and pull it toward you.
OHR028106
