9 VEHICLE SPECIFICATIONS
4LUBRICATION CHART
Oil & Grease Standard
API SJ, SL SAE 5W-20, 5W-30
or ABOVE, SAE 10W-30 (ABOVE -18°C)
ILSAC GF-3 SAE 15W-40 (ABOVE -13°C)
or ABOVE SAE 20W-50 (ABOVE -7°C)
API CH-4 SAE 30 (0°C ~ 40°C)
or ABOVE, SAE 20W-40 (ABOVE -10°C)
ACEA B4 SAE 15W-40 (ABOVE -15°C)
or ABOVE SAE 10W-30 (-20°C ~ 40°C) SAE 5W-30 (-25°C ~ 40°C) SAE 0W-30 (BELOW 10°C) *1, *2
*1. Restricted to driving condition and area*2. Not recommended for sustained high speed vehicle operation Normal driving condition Severe driving condition HYUNDAI GENUINE PARTS MTF 75W/85 (API GL-4) HYUNDAI GENUINE ATF SP III, DIAMOND ATF SP III, SK ATF SP III or other brands approved by Hyundai Motor Co., PSF-3 DOT 3, DOT 4 or equivalent Ethylene glycol base for aluminum radiator Q'ty (liter)
1.6 DOHC - 3.3 (with oil filter) (3.5 us.qts., 2.9 Imp.qts)
1.8 DOHC - 4.0 (with oil filter) (4.2 us.qts., 3.5 Imp.qts)
1.5 CRDi - 5.3 (with oil filter)
(5.6 us.qts., 4.7 Imp.qts)
MAX. 1L / 1,500 Km MAX. 1L / 1,000 Km2.15 (2.3 us. qts., 1.86 Imp. qts) 2.0 (2.11 us. qts., 1.76 Imp. qts) (1.5 CRDi) 6.1 (6.4 us. qts., 5.3 Imp.qts) (1.6 DOHC)6.7 (7.0 us. qts., 5.8 Imp.qts) (1.8 DOHC) As required As requiredGasoline : 6.2(1.6 DOHC), 6.5(1.8 DOHC) Diesel : 6.3
J080A07FC-GAT
Item
Engine Oil Gasoline Diesel
Recommends Engine oil consumption Transaxle Manual Automatic
Power steering Brake fluid Coolant
