wheel Hyundai Santa Fe 2009 Owner's Manual - RHD (UK, Australia)

F9
1. Passenger's
Airbag............................................... 1-36
2. Rear Air Conditioning Sw itch (If installed) ............1-116
3. Front Window Demister Switch........................... 1-115
4. Digital Clock .......................................................... 1-68
5. Rear Window Demi ster Switch .............................. 1-67
6. Hazard Warning Light Switch................................ 1-67
7. Windshield W iper/Washer Switch ..........................1-63
8. Instrument Cluster ................................................ 1-54
9. Horn and Driver' s Airbag ............................... 1-92, 1-36
10. Steering Wheel ..................................................... 1-93
11. Audio System (If installed) .................................. 1-120
12. Glove Box ............................................................. 1-78
CAUTION:
When installing a container of liquid air freshener inside the vehicle, do not place it near the instrument cluster nor on the instrument panel surface. If there is any leakagefrom the air freshener onto these areas (Instrument cluster, instrument panel or airventilator), it may damage these parts. If the liquid from the air freshener does leakonto these areas, wash them with water immediately.
! 13. Ashtray
............................................................. 1-71
14. Power Outlet ..................................................... 1-70
15. Shift Lever (If installed) ...................................... 2-9
16. Centre Console Box .......................................... 1-78
17. Cigarette Lighter ................................................ 1-69
18 Parking Brake Pedal (If installed) ...................... 1-83
19. Heating/Air Conditioning Control Panel (If installed)
....................................................................... 1-107
20. Ignition Switch ................................................... 1-6
21. Bonnet Release Lever ....................................... 1-90
22. Multi-Function Light Switch ............................... 1-60
CM-aust-00.p65 5/19/2008, 6:25 PM
9

1FEATURES OF YOUR HYUNDAI
18
!
!
B090A01TG-DAT FRONT POWER SEATS (If Installed) The front seats can be adjusted appro- priately by using the control knob of theseat. Before driving away, adjust the seat to the proper position so as to easily control the steering wheel, ped-als and switches on the instrument panel.
CAUTION:
Do not operate two knobs at the same time.
WARNING:
o Never attempt to adjust the seat while the vehicle is moving. This could result in loss of control, and an accident causing death, seri-ous injury, or property damage.
o Sitting or leaning unnecessarily
close to the front airbags mayresult in reduced protection in case of airbag deployment during a vehicle accident.
B080F01NF-EAT Seat Cushion Height Adjustment (Driver's Seat Only) To adjust the height of the seat cush- ion, raise or lower the control lever in theappropriate position.
HNF2034-E
B090B01NF-GAT Adjusting Seat Forward and Rearward Pull the control knob forward or rear- ward to move the seat forward or rear-ward to the desired position. Release the control knob and the seat will re- main at that position.OCM052026R
CM-aust-1a.p65
5/21/2008, 2:05 PM
18

1FEATURES OF YOUR HYUNDAI
36
!
OCM051008L
Driver's Front Airbag
B240A03NF-DAT Driver's and Passenger's Front Airbag Your vehicle is equipped with a Supple- mental Restraint (Air Bag) System andlap/shoulder belts at both the driver and passenger seating positions. The indi- cations of the system's presence arethe letters "SRS AIR BAG" embossed on the airbag pad cover in the steering wheel and the front passenger's panelpad above the glove box. The Hyundai SRS consists of airbagsinstalled under the pad covers in thecentre of the steering wheel and the front passenger's panel above the glove box.The purpose of the SRS is to provide the vehicle's driver or the front passen- ger with additional protection than thatoffered by the seat belt system alone, in case of a frontal impact of sufficient severity. NOTE: Be sure to read information about the SRS on the labels provided on the sun visor.
WARNING:
o As its name implies, the SRS is designed to work with, and besupplemental to, the driver's andthe passenger's three point seat belt systems and is not a substi- tute for them. Therefore your seatbelts must be worn at all times while the vehicle is in motion. The airbags deploy only in certain fron-tal impact conditions severe enough to likely cause significant injury to the vehicle occupants.
o The SRS is designed to deploy the airbags only when the impact issufficiently severe and when theimpact is in the front or frontal angle of the vehicle, and will not deploy in side, rear or rolloverimpacts. Additionally, the airbags will only deploy once. Thus, seat belts must be worn at all times.
CM-aust-1a.p65 5/21/2008, 2:06 PM
36

1FEATURES OF YOUR HYUNDAI
38
OCM051009R
The SRS service reminder indicator (SRI) on the instrument panel will illumi-nate for about 6 seconds after the ignition key is turned to the "ON" posi- tion or after the engine is started, afterwhich the SRI should go out.
B240B02L-R B240B03L-R
Upon deployment, tear seams moldeddirectly into the pad covers will sepa- rate under pressure from the expansion of the airbags. Further opening of the covers then allows full inflation of the airbags. A fully inflated airbag in combination with a properly worn seat belt slows thedriver's or the passenger's forward mo- tion, thus reducing the risk of head or chest injury. After complete inflation, the airbag im- mediately starts deflating, enabling thedriver to maintain forward visibility. CAUTION:
When installing a container of liquidair freshener inside the vehicle, donot place it near the instrument clus- ter nor on the instrument panel pad surface. If there is any leakage fromthe air freshener onto these areas (Instrument cluster, instrument panel pad or air ventilator), it may damagethese parts. If the liquid from the air freshener does leak onto these ar- eas, wash them with water immedi-ately.
!
Passenger's Airbag
The airbag modules are located both in the centre of the steering wheel and in the front passenger's panel above the glove box. When the SRSCM detects aconsiderable impact to the front of the vehicle, it will automatically deploy the airbags.
CM-aust-1a.p65 5/21/2008, 2:06 PM
38

1FEATURES OF YOUR HYUNDAI
40
!
OCM052212L
Side airbag sensor
Important Safety Notes on the Side Airbag System Following is a number of safety points concerning this system which shouldalways be observed to ensure risk of injury is reduced in an accident. WARNING:
o The side impact airbag is supple- mental to the driver's and the passenger's seat belt systems andis not a substitute for them. There- fore your seat belts must be worn at all times while the vehicle is inmotion. The airbags deploy only in certain side impact conditions severe enough to cause signifi-cant injury to the vehicle occu- pants.
o For best protection from the side impact airbag system and to avoidbeing injured by the deploying side impact airbag, both front seatoccupants should sit in an upright position with the seat belt prop- erly fastened. The driver's handsshould be placed on the steering wheel at the 9:00 and 3:00 o'clock positions. The passenger's armsand hands should be placed on their laps.
o Do not use any accessory seat covers. o Use of seat covers could reduce or
prevent the effectiveness of the system.
o Do not install any accessories on
the side or near the side impactairbag.
o Do not use excessive force on the
side of the seat.
o Do not place any objects over the airbag or between the airbag andyourself.
o Do not place any objects (an um- brella, bag, etc.) between the frontdoor and the front seat. Such ob- jects may become dangerous pro- jectiles and cause injury if thesupplemental side impact air bag inflates.
o To prevent unexpected deploy-
ment of the side impact air bagthat may result in personal injury,avoid impact to the sideairbag sensor when the ignition key is on.
CM-aust-1a.p65 5/21/2008, 2:06 PM
40

1FEATURES OF YOUR HYUNDAI
42
!
B240C01JM-DAT SRS Care The SRS is virtually maintenance-free and so there are no parts you can safelyservice by yourself. If the SRS SRI (Service Reminder Indicator) does not come on, or continuously remains on,have your vehicle immediately in- spected by your authorised Hyundai dealer. Any work on the SRS system, such as removing, installing, repairing, or anywork on the steering wheel must be performed by a qualified Hyundai tech- nician. Improper handling of the SRSsystem may result in serious personal injury.
o Do not install any accessories or
children’s toys in the Curtain Airbag deployment zones, as this may impair the operation of the system or throw parts of them intothe vehicle cabin causing injury to occupants if the system is de- ployed.
o To maintain the integrity of the Curtain Airbag system, any work,removal or installation of theairbag and associated compo- nents (such as roof lining and side trims) should always be performed by a qualified vehicle repairer.
1JBH3051L
WARNING:
o Extreme Hazard! Do not use a rear- ward facing child restraint on a seat protected by an airbag in frontof it!
o Do not install a child restraint sys-
tem in the front passenger seatposition. A child restraint system must never be placed in the front seat. The infant or baby could beseverely injured by an airbag de- ployment in case of an accident.
CM-aust-1a.p65 5/21/2008, 2:06 PM
42

1
FEATURES OF YOUR HYUNDAI
43
o Do not tamper with or disconnect
SRS wiring, or other components of the SRS system. Doing so could result in injury, due to acci- dental firing of the airbags or byrendering the SRS inoperative.
o If components of the air bag sys-
tem must be discarded, or if thevehicle must be scrapped, certain safety precautions must be ob- served. Your Hyundai dealerknows these precautions and can give you the necessary informa- tion. Failure to follow these precautions and procedures could increase therisk of personal injury.
o If you sell your vehicle, make cer-
tain that this manual is trans-ferred to the new owner.
o If your car was flooded and has
soaked carpeting or water on floor-ing, you shouldn't try to start the engine; have the car towed to an authorised Hyundai dealer.
o Modification to SRS components
or wiring, including the addition of any kind of badges to the pad cover or modifications to the bodystructure, can adversely affect SRS performance and lead to possible injury.
o For cleaning the horn pad, use only a soft, dry cloth or one whichhas been moistened with plainwater. Solvents or cleaners could adversely affect the airbag cover and proper deployment of the sys-tem.
o No objects should be placed over
or near the label identifying the airbag on the steering wheel and instrument panel, because any such object could cause harm ifthe vehicle is in a crash severe enough to cause the air bag to inflate.
o If the air bag inflates, it must be replaced by an authorised Hyundaidealer. o Do not replace the bumper or the
bumper guard with the one otherthan the Hyundai genuine parts.Otherwise, it can adversely affect SRS performance and lead to un- expected injury.
CM-aust-1a.p65 5/21/2008, 2:06 PM
43

1
FEATURES OF YOUR HYUNDAI
49
!
B260G01A-AAT
Low Oil Pressure Warn- ing Light
CAUTION:
If the low oil pressure warning light stays on while the engine is running,serious engine damage may result. The oil pressure warning light comes on whenever there is insufficient oilpressure. In normal operation, it should come on when the ignition switch is turned on, then go outwhen the engine is started. If the oil pressure warning light stays on while the engine is running, there is aserious malfunction. If this happens, stop the car as soon as it is safe to do so, turn off theengine and check the oil level. If the oil level is low, fill the engine oil to the proper level and start the engineagain. If the light stays on with the engine running, turn the engine off immediately. In any instance wherethe oil light stays on when the engine is running, the engine should be checked by a Hyundai dealer beforethe car is driven again.
!
B260H02A-GAT Parking Brake/Low Brake Fluid Level Warning Light
WARNING:
If you suspect brake trouble, have your brakes checked by a Hyundai dealer as soon as possible. Driving your car with a problem in either thebrake electrical system or brake hy- draulic system is dangerous, and could result in a serious injury or death.
Warning Light Operation The parking brake/low brake fluid level warning light should come on when theparking brake is applied and the ignition switch is turned to "ON" or "START". After the engine is started, the lightshould go out when the parking brake is released. If the parking brake is not applied, the warning light should comeon when the ignition switch is turned to "ON" or "START", then go out when the engine starts. If the light comes on atany other time, you should slow the vehicle and bring it to a complete stop in a safe location off the roadway. The brake fluid level warning light indi-cates that the brake fluid level in thebrake master cylinder is low and hy- draulic brake fluid conforming to DOT 3 or DOT 4 specifications should be added.After adding fluid, if no other trouble is found, the car should be immediately and carefully driven to a Hyundai dealerfor inspection. If further trouble is expe- rienced, the vehicle should not be driven at all but taken to a dealer by aprofessional towing service or some other safe method. Your Hyundai is equipped with dual-diagonal braking systems. This means you still have braking on two wheels even if one of the dual systems shouldfail. With only one of the dual systems working, more than normal pedal travel and greater pedal pressure are requiredto stop the car. Also, the car will not stop in as short a distance with only half of the brake system working. If thebrakes fail while you are driving, shift to a lower gear for additional engine brak- ing and stop the car as soon as it is safeto do so.
CM-aust-1a.p65
5/21/2008, 2:06 PM
49

1
FEATURES OF YOUR HYUNDAI
51
B260B01JM-DAT SRS (Airbag) Service Reminder Indicator (SRI)
The SRS service reminder indicator (SRI) comes on for about 6 secondsafter the ignition key is turned to the "ON" position or after the engine is started, after which it will go out. This light also comes on when the SRS is not working properly. If the SRI doesnot come on, or continuously remains on after operating for about 6 seconds when you turned the ignition key to the"ON" position or started the engine, or if it comes on while driving, have the SRS inspected by an authorised Hyundaidealer.
B260N02A-DAT Malfunction Indicator Light
This light illuminates when there is a malfunction of an exhaust gas relatedcomponent, and the system is not func- tioning properly so that the exhaust gas regulation values are not satisfied. Thislight will also illuminate when the igni- tion key is turned to the "ON" position, and then it will go out in a few secondsafter the engine is started. If it illumi- nates while driving, or does not illumi- nate when the ignition key is turned tothe "ON" position, take your car to your nearest authorised Hyundai dealer and have the system checked. B260Q01NF-DAT
CRUISE Indicator Light (If Installed)
The cruise indicator light in the instru- ment cluster is illuminated when thecruise control ON/OFF switch is pushed on the steering wheel. The indicator light does not illuminatewhen the cruise control ON/OFF switch is pushed again. Information about the use of cruise control begins on page 1-94.
B260R01NF-DAT CRUISE SET Indicator Light (If Installed)
The Cruise SET indicator light in the instrument cluster is illuminated whenthe cruise control "COAST/SET" or "RES/ACCEL" switch is pushed. The Cruise SET indicator light does notilluminate when the cruise control "CAN- CEL" switch is pushed or the system is disengaged. Refer to page 1-95 in "Tocancel the cruise speed".
CM-aust-1a.p65 5/21/2008, 2:06 PM
51

1FEATURES OF YOUR HYUNDAI
52
B260T01O-DAT 4WD System Warning Light
When the key is turned to the "ON" position, the 4WD(Four Wheel Drive)system warning light will come on and then go off in a few seconds.
CAUTION:
If the 4WD system warning light ( ) blinks while driving, this indicates that there is a malfunction in the 4WD system. If this occurs, have your vehicle checked by an authorised Hyundai dealer as soonas possible.! B260V01JM-GAT
4WD Lock Indicator Light
4WD (Four Wheel Drive) lock indicator light in the instrument cluster is illumi-nated when the 4WD lock switch is pushed. The purpose of this switch is to in-crease the drive power when driving on dry road surface, wet pavement snow- covered roads and/or off-road.4WD lock indicator light is turned off by pushing the switch once again.
CAUTION:
Do not use 4WD lock switch on dry paved roads or highway, it can cause noise, vibration or damage of 4WD related parts.
!
B260U01CM-DAT Immobiliser Warning Light
This indicator light comes on for some seconds after the ignition key is turnedto the "ON" position. The light goes out after the engine is running. In case this light blinks for five seconds when theignition key is turned to "ON" position, this indicates that the immobiliser sys- tem is out of order. Should theimmobiliser system become out of or- der, have the system inspected with a Hyundai dealer.
CM-aust-1a.p65 5/21/2008, 2:06 PM
52
