ECO mode INFINITI FX 2013 Quick Reference Guide

table of contents
new system features Around view Monitor with Moving Object Detection (MOD)
(if so equipped) ................................................ 2
Power Liftgate Switch ............................................ 3
Power Liftgate Main Switch ....................................... 4
Garage Mode System (if so equipped) .............................. 4

essential information
Loose Fuel Cap ................................................. 5
Tire Pressure Monitoring System (TPMS) ............................ 5
Front Armrest/Center Console Storage Box ..........................6

first drive features
INFINITI Intelligent Key™ System .................................. 7
Power Liftgate .................................................. 8
Power Seat Adjustments ......................................... 8
Automatic Drive Positioner (if so equipped) ..........................9
Outside Mirror Control Switch ..................................... 9
Starting/Stopping the Engine .................................... 10
Headlight Control Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . 10
Windshield Wiper/Washer Switch ................................. 11
Automatic Climate Control (if so equipped) . . . . . . . . . . . . . . . . . . . . . . . . .12
FM/AM/SiriusXM
™ Satellite Radio with CD/D vD Player
(with Navigation System – if so equipped) ..........................14
USB/iPod
® Interface ........................................... 15
Conventional (Fixed Speed) Cruise Control ......................... 15
Intelligent Cruise Control (ICC) System (if so equipped) ...............16
Power Outlets ................................................. 17
Fuel-Filler Door ................................................ 17

system guide
Trip Computer ................................................ 18
Bluetooth® Hands-free Phone System ........................... . .18
System Operating Tips ....................................... 19
Bluetooth
® System with Navigation (if so equipped) ...............19
Bluetooth® System without Navigation (if so equipped) . . . . . . . . . . . .21
Navigation System (if so equipped) ............................... 23
DvD Player (if so equipped) ...................................... 24
HomeLink
® Universal Transceiver ................................. 25
Additional information about your vehicle is also available in your Owner’s Manual,
Navigation System Owner’s Manual and at www.InfinitiUSA.com.
• A cellular telephone should not be used for any purpose while driving so full attention
may be given to vehicle operation.
• Always wear your seat belt.
• Supplemental air bags do not replace proper seat belt usage.
• Children 12 and under should always ride in the rear seat properly secured in child
restraints or seat belts according to their age and weight.
• Do not drink and drive.
For more information, refer to the “Safety –– Seats, seat belts and supplemental
restraint system (section 1)”, “Monitor, climate, audio, phone and voice recognition
systems (section 4)” and the “Starting and driving (section 5)” of your Owner’s Manual.

10
first drive features
Starting/Stopping the Engine
NOTE: It is important to make sure the INFINITI Intelligent
Key™ is with you (that is, in your pocket or purse).

Depress the brake pedal.
• If the brake pedal is not depressed, pushing the
ignition switch once enters the ACC mode.
• If the ignition switch is pushed a second time, the
vehicle will enter the ON mode.

Move the shift lever to P (PARK).

Push the ignition switch to start the engine.
TURNING THE ENGINE OFF

Move the shift lever to the P (PARK) position and apply the parking brake.

Press the ignition switch START/STOP button to turn the engine off.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
Headlight Control Switch
Turn the headlight control switch to the position

01 to turn on the front parking, side marker, tail,

license plate and instrument panel lights. Turn the
switch to the

position
02 to turn on the

headlights.
AUTOLIGHT SYSTEM

The autolight system will automatically turn the headlights on when it is dark and off when it is
light. The system will keep the headlights on for a period of time after you turn the ignition off
and all doors are closed.

To activate the autolight system, turn the headlight control switch to the AUTO position
03
then push the ignition switch to ON. To deactivate the autolight system, turn the headlight

control switch to the Off,

01 or
position
02 .

HIGH BEAM SELECT

Push the headlight control switch forward
04 to
select the high beam function. The blue indicator
light
illuminates in the instrument panel. Pull
the headlight switch back to the original position to
select the low beam. The blue indicator light goes off.

Pull and release the headlight control switch
05 to
flash the headlight high beams on and off.
03
04
05
01
02

13
07 INTAKE AIR CONTROL BUTTON (if so equipped)
AIR RECIRCULATION


Press the intake air control button
to recirculate interior air inside the vehicle. The indicator

light on the
side will come on. This system is used to avoid outside odors and helps to
adjust the inside vehicle temperature more effectively.

The air recirculation mode cannot be activated when the air conditioner is in the front
defrosting mode

.
OUTSIDE AIR CIRCULATION


Press the intake air control button again
to draw outside air into the passenger
compartment. The indicator light on the
side will come on.
AUTOMATIC INTAKE AIR CONTROL

In the auto mode, the intake air will be controlled automatically. To manually control the
intake air, press the intake air control button. To return to the automatic control mode,
press the intake air control button
for about 2 seconds.
08
A/C BUTTON

Press the A/C button to turn the air conditioner system on or off. This system helps cool
and dehumidify the air inside the cabin and defog the windows.
09 Off
BUTTON

Press the Off button to turn the climate control system off.
For more information, refer to the “Instruments and controls (section 2)” and the “Monitor, climate, audio, phone and voice recognition
systems (section 4)” of your Owner’s Manual.

Intelligent Cruise Control (ICC) System (if so equipped)
vEHICLE-TO-vEHICLE DISTANCE CONTROL MODE

To set vehicle-To- vehicle Distance Control mode,
press the CRUISE ON/Off button

01 for less than
1.5 seconds. The CRUISE indicator light
02 will

illuminate.

Accelerate to the desired speed.

Push down on the COAST/SET switch
03 and release
it. Cruise control will be set to the desired speed.

Press the distance button
04 repeatedly to change
the set distance between long, middle, and short.

When a vehicle is not detected ahead of you in the
lane, the set distance and set vehicle speed indicator
lights will illuminate

05 in set mode.

When a vehicle is detected ahead of you in the lane,
the vehicle ahead detection, set distance, and set
vehicle speed indicator lights will illuminate

06 in set mode.

To reset at a faster cruising speed, push and hold the ACCEL/RES
switch

07 . When the vehicle attains the desired speed, release
the switch.

To reset at a slower cruising speed, push and hold the COAST/SET switch
03 . Release

the switch when the vehicle slows to the desired speed.


To cancel the preset speed, push the CANCEL switch
08 or tap the brake pedal. The set
vehicle speed indicator 05 will go out.

To turn off cruise control, press the CRUISE ON/Off button
01 . The
CRUISE indicator light

02 , in the instrument panel, will turn off.
To set conventional (fixed speed) cruise control mode:

While cruise control is off, press the CRUISE ON/Off
button
01 and hold it down for more
than 1.5 seconds. The CRUISE indicator light will illuminate.

Accelerate to the desired speed.

Push down on the COAST/SET switch and release it. The SET indicator light will illuminate.
Cruise control should be set to the desired speed.
To switch between the two cruise control modes:

When one of the two cruise modes is in use, you must turn the system off, and then turn it on
again to select the other cruise control mode.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
16
first drive features
0807
0304
01
0205
06

18
system guide
Trip Computer
When the
button
01 is pressed, the following
modes will appear on the dot matrix liquid crystal
display

02 :
• MPG – Displays the current fuel consumption.
• MPG/MPh – Displays the average fuel consumption
and speed since the last reset.
• TIME/MILES – Displays the elapsed time and total
distance the vehicle has been driven since the
last reset.
• RANGE – Displays the estimated distance to empty
(dte) the vehicle can be driven before refueling.
• OUTSIDE TEMP – Displays the exterior air
temperature including a low temperature
warning feature.
• SETTING – Allows you to set reminders for alerts and maintenance intervals or change the
language and units used in the system.
— Press the

button
03 to cycle through the various setting modes.

— Press the

button
01 to choose the selected menu.

• WARNING – If there are any.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
Bluetooth® Hands-free Phone System

With an overhead microphone and sound
transmitted through the audio system speakers,
the Bluetooth
® Hands-free Phone System utilizes
Bluetooth wireless technology and voice recognition
to provide hands-free cellular phone communication.

Bluetooth Streaming Audio (available with Navigation
System only) allows you to use a compatible Bluetooth
phone to play audio files on your device. Your
compatible cellular phone can be connected to the
vehicle’s audio system allowing audio files to play
through the vehicle’s speakers.

A cellular telephone should not be used while driving so full attention may be given to vehicle
operation.*
01
03
02
Bluetooth® Controls
*Some jurisdictions prohibit the use of cellular telephones while driving.

SYSTEM OPERATING TIPS

Close all windows. Surrounding noises may interfere with system operation and performance.

Press the or
button on the steering wheel to

activate voice recognition.

Wait for the tone before speaking.

Begin speaking a command within 5 seconds of the tone.

Speak in a clear and natural voice without pausing
between words.

Look straight ahead and avoid speaking too loudly or too softly.

To go back to the previous command, say “Go back”.

To cancel a voice recognition session, say “Exit” or press and hold the or
button.

To interrupt the system voice and give a command quickly, press the
or
button.

When speaking Phonebook names, please be aware some phones require the last name to be
spoken before the first name. For example, “Michael Smith” may be spoken as “Smith Michael”.

To increase or decrease the volume of the voice prompts, push the volume control switches

or
+ on the steering wheel or turn the VOL/ON•OFF control knob on the audio system while

the system is responding.

If the voice Recognition system does not recognize your voice commands, train the system
using the Speaker Adaptation Mode. See your Owner’s Manual for detailed information.

Some commands are not available while the vehicle is in motion.

The “Help” command can be used to hear a list of available commands at any time.

Please refer to the cellular phone manufacturer’s Owner’s Manual for detailed information
regarding your Bluetooth phone.
Bluetooth® System with Navigation* (if so equipped)
CONNECTING PROCEDURE
NOTE: The vehicle must be stationary when connecting
the phone.

1. Press the

button
and select the “Connect Phone” key.
19
Microphone
*Some jurisdictions prohibit the use of cellular telephones while driving.

20
system guide
2. Initiate connecting from the phone.
• The connecting procedure varies according to each
cellular phone model. For detailed connecting
instructions and a list of compatible phones,
please visit www.InfinitiUSA.com/bluetooth.
• When prompted for a PIN code, enter “1234”
from the handset. (The PIN code is assigned
by INFINITI and cannot be changed.)
3. When the connecting is complete, the screen will return to the Phone menu display.
PHONEBOOK SETUP

Depending on your cell phone, the system may automatically download your cell phone’s entire
phonebook to the vehicle’s Bluetooth system.

If the phonebook does not download to “Handset Phonebook”, 40 entries may be created in
the “v ehicle Phonebook”. This phonebook allows a custom recording for each entry to be
spoken while using the voice recognition system. To create the “v ehicle Phonebook”:
1. Push the

button on the steering wheel
2. Select “v ehicle Phonebook”.
3. Select “Add New” at the top of the screen.
4. Choose the method for entering the phonebook entry.
For this example, select “Enter Number by Keypad”.
5. Enter the digits and select “OK”.
6. Select “v oicetag” to record a custom name to speak
when using the voice Recognition system.
7. Select “Store” and speak the custom name after
the tone.
8. When the voicetag is successfully stored, select
“OK” to save the phonebook entry.
9. After the phonebook entry is saved, it will show a
screen that is ready to call the number. Select “BACK” to return to the vehicle Phonebook.
CALLING A PHONEBOOK ENTRY:
1. Press the

button.
2. After waiting for the tone, say “Phone”.
3. After the tone, say “Handset Phonebook” or “v ehicle Phonebook” to select the desired
phonebook.

21

4. After the tone, say the name of the person as shown on the vehicle’s display of the phonebook.
Depending on the phone, the last name of the contact may need to be spoken before the
first name.
MAKING A CALL:
1. Press the

button.
2. After waiting for the tone, say “Phone”.
3. After the next tone, say “Dial Number”.
4. After the next tone, say “123-456-7891”. You may also say the digits in groups of 3, 3 and
4, respectively. To use this group dialing method, say only the first 3 digits of the phone number
instead of all 10 digits. After the system recognizes the number, it will request the next 3 digits
and finally the last 4 digits.
5. After the system speaks the correct number and sounds the tone, say “Dial.”
RECEIvING/ENDING A CALL

To accept the call, press the button on the steering
wheel or touch the “Answer” key. To reject the call,
touch the “Reject Call” key.

To hang-up, press the button or touch the
“Hang-Up” key.
Bluetooth® System without Navigation* (if so equipped)
PAIRING PROCEDURE
1. Press the

button on the steering wheel. The

system announces the available commands.
2. Say “Connect Phone”. The system acknowledges
the command and announces the next set of
available commands.
3. Say “Add Phone”. The system acknowledges the
command and asks you to initiate connecting
from the phone handset.
4. Initiate pairing from the phone.
• The connecting procedure varies according to each cellular phone model. For detailed
connecting instructions and a list of compatible phones, please visit
www.InfinitiUSA.com/bluetooth.
•
When prompted for a PIN code, enter “1234” from the handset. (The PIN code is assigned
by INFINITI and cannot be changed.)
*Some jurisdictions prohibit the use of cellular telephones while driving.
