ad blue INFINITI FX35 2004 Service Manual

ATC-16
PRECAUTIONS
Revision: 2004 November 2004 FX35/FX45
Precautions for Leak Detection DyeAJS00141

The A/C system contains a fluorescent leak detection dye used for locating refrigerant leaks. An ultraviolet
(UV) lamp is required to illuminate the dye when inspecting for leaks.

Always wear fluorescence enhancing UV safety goggles to protect your eyes and enhance the visibility of
the fluorescent dye.

The fluorescent dye leak detector is not a replacement for an electronic refrigerant leak detector. The fluo-
rescent dye leak detector should be used in conjunction with an electronic refrigerant leak detector to (J-
41995) pin-point refrigerant leaks.

For your safety and your customer′s satisfaction, read and follow all manufacture′s operating instructions
and precautions prior to performing the work.

A compressor shaft seal should not be repaired because of dye seepage. The compressor shaft seal
should only be repaired after confirming the leak with an electronic refrigerant leak detector (J-41995).

Always remove any remaining dye from the leak area after repairs are complete to avoid a misdiagnosis
during a future service.

Do not allow dye to come into contact with painted body panels or interior components. If dye is spilled,
clean immediately with the approved dye cleaner. Fluorescent dye left on a surface for an extended period
of time cannot be removed.

Do not spray the fluorescent dye cleaning agent on hot surfaces (engine exhaust manifold, etc.).

Do not use more than one refrigerant dye bottle (1/4 ounce /7.4 cc) per A/C system.

Leak detection dyes for HFC-134a (R-134a) and CFC-12 (R-12) A/C systems are different. Do not use
HFC-134a (R-134a) leak detection dye in CFC-12 (R-12) A/C system or CFC-12 (R-12) leak detector dye
in HFC-134a (R-134a) A/C system or A/C system damage may result.

The fluorescent properties of the dye will remain for over three (3) years unless a compressor malfunction
occurs.
IDENTIFICATION
NOTE:
Vehicles with factory installed fluorescent dye have a green label.
Vehicles without factory installed fluorescent dye have a blue label.
IDENTIFICATION LABEL FOR VEHICLE
Vehicles with factory installed fluorescent dye have this identification
label on the front side of hood.
Wiring Diagrams and Trouble DiagnosisAJS00142
When you read wiring diagrams, refer to the following:

GI-15, "How to Read Wiring Diagrams" in GI section.

PG-4, "Wiring Diagram - POWER -" in PG section.
When you perform trouble diagnosis, refer to the following:

GI-11, "How to Follow Trouble Diagnoses" in GI section.

GI-27, "How to Perform Efficient Diagnosis for an Electrical Incident" in GI section.
SHA436FA

ATC-18
PREPARATION
Revision: 2004 November 2004 FX35/FX45
HFC-134a (R-134a) Service Tools and EquipmentAJS00144
Never mix HFC-134a (R-134a) refrigerant and/or its specified lubricant with CFC-12 (R-12) refrigerant and/or
its lubricant.
Separate and non-interchangeable service equipment must be used for handling each type of refrigerant/lubri-
cant.
Refrigerant container fittings, service hose fittings and service equipment fittings (equipment which handles
refrigerant and/or lubricant) are different between CFC-12 (R-12) and HFC-134a (R-134a). This is to avoid
mixed use of the refrigerants/lubricant.
Adapters that convert one size fitting to another must never be used: refrigerant/lubricant contamination will
occur and compressor malfunction will result.
Tool number
(Kent-Moore No.)
Tool name Description
HFC-134a (R-134a) refrigerantContainer color: Light blue
Container marking: HFC-134a (R-
134a)
Fitting size: Thread size

Large container 1/2″ -16 ACME
KLH00-PAGS0
( - )
Nissan A/C System Oil Type S
(DH-PS)Type: Poly alkylene glycol oil (PAG),
type S (DH-PS)
Application: HFC-134a (R-134a)
wabble (swash) plate compressors
(Nissan only)
Lubricity: 40 m (1.4 US fl oz., 1.4
Imp fl oz.)
(J-43600)
Recovery/Recycling/
Recharging equipment
(ACR2000)Function: Refrigerant recovery and
recycling and recharging
(J-41995)
Electrical leak detectorPower supply:

DC 12V (Cigarette lighter)
S-NT196
S-NT197
WJIA0293E
AHA281A

ATC-20
PREPARATION
Revision: 2004 November 2004 FX35/FX45
Commercial Service ToolsAJS00145
Service hoses

High-pressure side hose
(J-39501-72)

Low-pressure side hose
(J-39502-72)

Utility hose
(J-39476-72)Hose color:

Low hose: Blue with black stripe

High hose: Red with black stripe

Utility hose: Yellow with black stripe
or green with black stripe
Hose fitting to gauge:

1/2″ -16 ACME
Service couplers

High-pressure side coupler
(J-39500-20)

Low-pressure side coupler
(J-39500-24)Hose fitting to service hose:

M14 x 1.5 fitting is optional or
permanently attached.
(J-39650)
Refrigerant weight scaleFor measuring of refrigerant
Fitting size: Thread size

1/2″ -16 ACME
(J-39649)
Vacuum pump
(Including the isolator valve)Capacity:

Air displacement: 4 CFM

Micron rating: 20 microns

Oil capacity: 482 g (17 oz.)
Fitting size: Thread size

1/2″ -16 ACME Tool number
(Kent-Moore No.)
Tool name Description
S-NT201
S-NT202
S-NT200
S-NT203
Tool nameDescription
Refrigerant identifier equipmentChecking for refrigerant purity and
system contamination
Power toolFor loosening bolts and nuts
RJIA0197E
PBIC0190E

NAVIGATION SYSTEM
AV-121
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2004 November 2004 FX35/FX45
Terminals and Reference Value for NAVI Control UnitAKS00BMY
Terminal
(Wire color)
ItemSignal
input/
outputCondition
Reference valueExample of
symptom
+–Igni-
tion
switchOperation
1 (B) Ground Ground – ON – Approx. 0V –
2 (Y)
GroundBattery
power supplyInput OFF – Battery voltageSystem does not
work properly.
3 (Y)
4 (B) Ground Ground – ON – Approx. 0V –
6 (LG) GroundACC power
supplyInput ACC – Battery voltageSystem does not
work properly.
7 (LG) 8 (PU)Voice guide
signalOutput ONPress the “GUIDE/
VOICE”button.Only route guide
and operation
guide are not
heard.
9–Shield
ground–– – – –
14 –Shield
ground–– – – –
15 (B) 17RGB signal
(B: blue)Output ONSelect “Display
Diagnosis (NAVI)” of
CONFIRMATION/
ADJUSTMENT
function.NAVI screen
looks yellowish.
16 (G) 14RGB syn-
chronizing
signalOutput ONPress the “MAP”
button.NAVI screen is
rolling.
17 –Shield
ground–– – – –
18 (R) 17RGB signal
(R: red)Output ONSelect “Display
Diagnosis (NAVI)” of
CONFIRMATION/
ADJUSTMENT
function.NAVI screen
looks bluish.
21 (W) 17RGB signal
(G: green)Output ONSelect “Display
Diagnosis (NAVI)” of
CONFIRMATION/
ADJUSTMENT
function.NAVI screen
looks reddish.
SKIA0171J
SKIA4979E
SKIA0164E
SKIA4977E
SKIA4978E

NAVIGATION SYSTEM
AV-125
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2004 November 2004 FX35/FX45
41 –Shield
ground–– – – –
42 (B/Y) GroundAudio TX
communica-
tion signalOutput ONOperate audio
volume.Audio dose not
operate properly.
43 (G/B) 41RGB syn-
chronizing
signalInput ONPress the “MAP”
button.NAVI screen is
rolling.
44 (R/W) 45RGB signal
(R: red)Input ONSelect “Display
Diagnosis (NAVI)” of
CONFIRMATION/
ADJUSTMENT
function.NAVI screen
looks bluish.
45 –Shield
ground–– – – –
46 (R/L) 45RGB signal
(G: green)Input ONSelect “Display
Diagnosis (NAVI)” of
CONFIRMATION/
ADJUSTMENT
function.NAVI screen
looks reddish.
47 –Shield
ground–– – – –
48 (B) 45RGB signal
(B: blue)Input ONSelect “Display
Diagnosis (NAVI)” of
CONFIRMATION/
ADJUSTMENT
function.NAVI screen
looks yellowish.
49 –Shield
ground–– – – –
50 (L/R) 47RGB signal
(R: red)Output ONSelect “Display
Diagnosis (DCU)” of
CONFIRMATION/
ADJUSTMENT
function.RGB screen
looks bluish. Terminal
(Wire color)
ItemSignal
input/
outputCondition
Reference valueExample of
symptom
+–Igni-
tion
switchOperation
SKIA4402E
SKIA0164E
SKIA4977E
SKIA4978E
SKIA4979E
SKIA4980E

AV-126
NAVIGATION SYSTEM
Revision: 2004 November 2004 FX35/FX45
51 (B) 49RGB area
(YS) signalOutput ONPress the“TRIP”
button.RGB screen is
not shown.
52 (L/W) 47RGB signal
(G: green)Output ONSelect “Display
Diagnosis (DCU)” of
CONFIRMATION/
ADJUSTMENT
function.RGB screen
looks reddish.
53 (W) 49Vertical syn-
chronizing
(VP) signalInput ONSelector lever in
R position.Audio and A/C
does not operate
properly.
54 (L) 47RGB signal
(B: blue)Output ONSelect “Display
Diagnosis (DCU)” of
CONFIRMATION/
ADJUSTMENT
function.RGB screen
looks yellowish.
55 (R) 49Horizontal
synchroniz-
ing (HP) sig-
nalInput ON –Audio and A/C
does not operate
properly.
56 (G) 49RGB syn-
chronizing
signalOutput ONPress the “TRIP”
button.NAVI screen is
rolling. Terminal
(Wire color)
ItemSignal
input/
outputCondition
Reference valueExample of
symptom
+–Igni-
tion
switchOperation
SKIA0162E
SKIA4981E
SKIA0161E
SKIA4982E
SKIA4983E
SKIA0164E

AV-128
NAVIGATION SYSTEM
Revision: 2004 November 2004 FX35/FX45
18 (L) 7RGB signal (B:
blue)Input ONSelect “Display
Diagnosis (DCU)”
of CONFIRMA-
TION/ADJUST-
MENT function.RGB screen
looks yellow-
ish.
19 (G) 21RGB synchroniz-
ing signalInput ONPress the “TRIP”
button.NAVI screen
is rolling.
20 (W) 21Vertical synchro-
nizing (VP) signalOutput ONSelector lever in
R position.Rear view
monitor
screen is roll-
ing.
21 – Shield ground – – – – –
22 (LG) 23Display communi-
cation signal
(DSP-DCU)Output ON –Though a
screen is dis-
played, it is
impossible to
adjust bright-
ness.
23 – Shield ground – – – – –Terminal
(Wire color)
ItemSignal
input/
outputCondition
Reference valueExample of
symptom
+–Ignition
switchOperation
SKIA4982E
SKIA0164E
SKIA0161E
SKIA4363E

NAVIGATION SYSTEM
AV-137
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2004 November 2004 FX35/FX45

When RGB signal error occurred in the RGB system, tone of the color bar will change as follows.

When the color of the screen looks unusual, refer to AV- 1 6 2 , "Color of RGB Image is Not Proper (All
screens Looks Bluish)" ,AV- 1 6 3 , "Color of RGB Image is Not Proper (All Screens Looks Reddish)" and
AV- 1 6 4 , "
Color of RGB Image is Not Proper (All Screens Looks Yellowish)" .
VEHICLE SIGNALS

A comparison check can be made of each actual vehicle signal
and the signals recognized by the system.
CAUTION:
In case of confirming light signal, set D/N mode to ON/OFF
of lighting switch (normal setting).

OFF: D (Day mode)

ON: N (Night mode)
Unless above setting, light signal (ON/OFF) may not be
accurately displayed.

If vehicle speed is NG, refer to AV- 1 5 0 , "Vehicle Speed Signal Check for Display Control Unit" .

If light is NG, refer to AV- 1 5 2 , "Illumination Signal Check for Display Control Unit" .

If IGN is NG, refer to AV- 1 5 2 , "Ignition Signal Check for Display Control Unit" .

If reverse is NG, refer to AV- 1 5 3 , "Reverse Signal Check for Display Control Unit" .
AUTO CLIMATE CONTROL

Refer to ATC Automatic Air Conditioner AT C - 5 3 , "Self-diagnosis Function" for details. R (red) signal error : Screen looks bluish
G (green) signal error : Screen looks reddish
B (blue) signal error : Screen looks yellowish
SKIA5628E
Diagnosis item Display Condition Remarks
Vehicle speedON Vehicle speed > 0 MPH (0 km/h)
Changes in indication may be delayed by
approx. 1.5 seconds. This is normal. OFF Vehicle speed = 0 MPH (0 km/h)
– Ignition switch in ACC position
IGNON Ignition switch ON
–
OFF Ignition switch ACC
ReverseON Selector lever in R position
Changes in indication may be delayed by
approx. 1.5 seconds. This is normal. OFF Selector lever except R position
– Ignition switch in ACC position
LightON Lighting switch ON
–
OFF Lighting switch OFF

AV-138
NAVIGATION SYSTEM
Revision: 2004 November 2004 FX35/FX45
NAVIGATION
1. The initial trouble diagnosis screen will be shown, and items
“Display Diagnosis”, “Vehicle Signals”, “History of Errors” and
“Navigation” will become selective.
2. Select each switch on “CONFIRMATION/ADJUSTMENT”
screen to display the relevant diagnosis screen.
DISPLAY DIAGNOSIS

When RGB signal error occurred in the RGB system, tone of the color bar will change as follows.

When the color of the screen looks unusual, refer to AV- 1 5 9 , "Color of RGB Image is Not Proper (NAVI
Screen Looks Bluish)" ,AV- 1 6 0 , "Color of RGB Image is Not Proper (NAVI Screen Looks Reddish)" and
AV- 1 6 1 , "
Color of RGB Image is Not Proper (NAVI Screen Looks Yellowish)" .
SKIA4226E
SKIA0362E
R (red) signal error : Screen looks bluish
G (green) signal error : Screen looks reddish
B (blue) signal error : Screen looks yellowish

FUEL INJECTOR AND FUEL TUBE
EM-45
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: 2004 November 2004 FX35/FX45
FUEL INJECTOR AND FUEL TUBEPFP:16600
Removal and InstallationABS004U8
CAUTION:
Do not remove or disassemble parts unless instructed as shown in the figure.
1. Fuel damper 2. O-ring 3. Fuel sub-tube
4. EVAP hose 5. Intake manifold collector (lower) 6. Fuel feed hose (with damper)
7. Fuel tube 8. Spacer 9. Clip
10. O-ring (blue) 11. Fuel injector 12. O-ring (brown)
13. Hose clamp 14. Bracket 15. Quick connector cap
16. Centralized under-floor piping
SBIA0580E
