ON-VEHICLE SERVICE
Revision: 2004 November 2004 FX35/FX45
11. Disconnect A/T fluid temperature sensor 2 connector.
CAUTION:
Be careful not to damage connector.
12. Straighten terminal clip to free A/T fluid temperature sensor 2
harness.
13. Disconnect revolution sensor connector.
CAUTION:
Be careful not to damage connector.
14. Straighten terminal clips to free revolution sensor harness.
15. Remove bolts A, B and C from control valve with TCM.
SCIA5023E
SCIA5146E
SCIA5024E
SCIA3969E
Bolt symbol Length mm (in) Number of bolts
A 42 (1.65) 5
B 55 (2.17) 6
C 40 (1.57) 1
SCIA5139E

ON-VEHICLE SERVICE
AT-247
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2004 November 2004 FX35/FX45

Assemble it so that manual valve cutout is engaged with
manual plate projection.
5. Install bolts A, B and C in control valve with TCM.
6. Tighten bolt 1, 2 and 3 temporarily to prevent dislocation. After
that tighten them in order (1 → 2 → 3), and then tighten other
bolts.
7. Connect A/T fluid temperature sensor 2 connector.
8. Securely fasten A/T fluid temperature sensor 2 harness with ter-
minal clip.
SCIA5142E
Bolt symbol Length mm (in) Number of bolts
A 42 (1.65) 5
B 55 (2.17) 6
C 40 (1.57) 1
SCIA5139E
: 7.9 N·m (0.81 kg-m, 70 in-lb)
SCIA5140E
SCIA5023E
SCIA5146E

AT-268
TRANSMISSION ASSEMBLY
Revision: 2004 November 2004 FX35/FX45
INSTALLATION
Install the removed parts in the reverse order of the removal, while paying attention to the following work.

When installing transmission assembly to the engine, attach the
fixing bolts in accordance with the following standard.

Align the positions of tightening bolts for drive plate with those of
the torque converter, and temporarily tighten the bolts. Then,
tighten the bolts with the specified torque.
CAUTION:

When turning crankshaft, turn it clockwise as viewed
from the front of the engine.

When tightening the tightening bolts for the torque con-
verter after fixing the crankshaft pulley bolts, be sure to
confirm the tightening torque of the crankshaft pulley
mounting bolts.

After converter is installed to drive plate, rotate crankshaft several turns and check to be sure
that transmission rotates freely without binding.

Install crankshaft position sensor (POS). Refer to EM-30, "Removal and Installation" .

After completing installation, check fluid leakage, fluid level, and the A/T positions of A/T. Refer to AT- 1 2 ,
"Changing A/T Fluid" , AT- 2 3 4 , "Adjustment of A/T Position" , AT- 2 3 4 , "Checking of A/T Position" .
Bolt No. 1 2 3 4
Number of bolts 1 5 2 2
Bolt length
“ ”mm (in)55 (2.17) 65 (2.56) 65 (2.56) 35 (1.38)
Tightening torque
N·m (kg-m, ft-lb)75
(7.7, 55)55
(5.6, 41)47
(4.8, 35)
: 51 N·m (5.2 kg-m, 38 ft-lb)
SCIA3949E
SCIA2288E

AT-272
TRANSMISSION ASSEMBLY
Revision: 2004 November 2004 FX35/FX45
24. Remove transmission assembly with transfer from vehicle.

Secure torque converter to prevent it from dropping.

Secure transmission assembly to a jack.
25. Remove transfer from transmission assembly. Refer to TF-43,
"Removal and Installation" .
INSPECTION
Installation and Inspection of Torque Converter

After inserting a torque converter to a transmission, be sure to
check distance “A” to ensure it is within the reference value limit.
INSTALLATION
Install the removed parts in the reverse order of the removal, while paying attention to the following work.

When installing transmission assembly to the engine, attach the fixing bolts in accordance with the follow-
ing standard.
For VQ35DE models
For VK45DE models
*: No.2 bolt also secures A/T fluid charging pipe.
SCIA2203E
Distance “A”
VQ35DE models: 25.0 mm (0.98 in) or more
VK45DE models: 22.0 mm (0.87 in) or more
SAT017B
Bolt No. 1 2 3 4
Number of bolts 1 5 2 1
Bolt length
“ ”mm (in)55 (2.17) 65 (2.56) 35 (1.38) 65 (2.56)
Tightening torque
N·m (kg-m, ft-lb)75
(7.7, 55)47
(4.8, 35)34
(3.5, 25)
SCIA4600E
Bolt No. 1 2* 3
Number of bolts 5 1 4
Bolt length
“ ”mm (in)70 (2.76) 65 (2.56)
Tightening torque
N·m (kg-m, ft-lb)11 3
(12, 83)74.0
(7.5, 55)
SCIA4601E

DISASSEMBLY
AT-293
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2004 November 2004 FX35/FX45
33. Disconnect revolution sensor connector.
CAUTION:
Be careful not to damage connector.
34. Straighten terminal clips to free revolution sensor harness.
35. Remove bolts A, B and C from control valve with TCM.
36. Remove control valve with TCM from transmission case.
CAUTION:
When removing, be careful with the manual valve notch and
manual plate height.Remove it vertically.
37. Remove A/T fluid temperature sensor 2 with bracket from con-
trol valve with TCM.
SCIA5024E
SCIA5293E
Bolt symbol Length mm (in) Number of bolts
A 42 (1.65) 5
B 55 (2.17) 6
C 40 (1.57) 1
SCIA5025E
SCIA5260E
SCIA5301E

AT-344
ASSEMBLY
Revision: 2004 November 2004 FX35/FX45
f. Tighten bolt 1, 2 and 3 temporarily to prevent dislocation. After
that tighten them in order (1 → 2 → 3), and then tighten other
bolts.
10. Connect A/T fluid temperature sensor 2 connector.
11. Securely fasten A/T fluid temperature sensor 2 harness with ter-
minal clip.
12. Connect revolution sensor connector.
Bolt symbol Length mm (in) Number of bolts
A 42 (1.65) 5
B 55 (2.17) 6
C 40 (1.57) 1
SCIA5025E
: 7.9 N·m (0.81 kg-m, 70 in-lb)
SCIA5037E
SCIA5023E
SCIA5146E
SCIA5024E

AV-58
INTEGRATED DISPLAY SYSTEM
Revision: 2004 November 2004 FX35/FX45
SETTING SCREEN

Setting of electric status can be changed by A/C and AV switch. The signal is sent to BCM through display
unit to change vehicle electric system setting.

Display unit is communicating with driver seat control unit.

Pressing “SETTING” switch once cycles display from DISPLAY→LANGUAGE→BEEP SET→SERVICE
ALERT→PERSONALIZED SETTINGS MENU→DISPLAY OFF→DISPLAY.

Using the joystick, setting of each item will become possible.
Adjustable Vehicle Status
NOTE:
Setting in factory shipment is ON.
Setting itemsSetting varia-
tionsInitial
settingOperation
DISPLAY ON/OFF ON It switches displayed/Non-displayed of the screen.
LANGUAGEENGLISH/
FRANCAIS– It switches displayed language.
BEEP SET ON/OFF ONIt selects beep sound ON/OFF during switch operation. How-
ever, even if beep is set OFF, beep for NO OPERATION and
for screen interception are not reset.
SERVICE ALERT ON/OFF OFFIt switches displayed/Non-displayed of alert indication.

When the setting is ON, if engine oil or tire rotation will be
replace distance, alert is displayed.

When the setting is OFF, alert is not displayed.
PERSONALIZED
SETTING MENUSLIDE BACK DR
SEAT ON EXITON/OFF
ON
NoteThe driver’s seat automatically moves back and returns to
the original position for exceptional ease of exit and entry.
(Models with automatic drive positioner.)
LIFT STEERING
WHEEL ON EXITON/OFF
ON
NoteThe steering column automatically tilts up and returns to the
original position for exceptional ease of entry and exit. (Mod-
els with automatic drive positioner.)
REMOTE UNLOCK
DOOR LOGICDR-1ST/ALL DR-1STThis key can switch the unlock doors of the 1st unlocking
operation as follows:

Only the driver side door⇔All the doors
HORN CHIRP WITH
REMOTEON/OFF ONThis key changes the horn chirp mode occurring when press-
ing the LOCK button on the keyfob.
LAMPS FLASH
WITH REMOTEALL/LOCK/
UNLOCK/OFFALLThis key changes the hazard indicator flash mode occurring
when pressing the LOCK or UNLOCK button on the keyfob.
AUTO RE-LOCK
TIME5m/1m/OFF 1mThe length of auto door re-lock time can be set. Select the
“Auto Re-Lock timer” key, then move the joystick to adjust the
time.
AUTO HEADLAMP
SENSITIVITYLEVEL 1/2/3/4LEVEL
2Automatic light illumination can be set as desired. Select the
“Auto Headlamp Sensitivity” key, then move the joystick to
the left (lower) or right (higher).
AUTO HEADLAMP
OFF DELAYOFF/30/45/60/
90/120/150/
180 SEC45 SECThis key can control how long it takes the automatic turn off
timer to extinguish the headlamps in “AUTO” position. Select
the “Auto Headlamp Off Delay” key, then move the joystick to
the left or right to adjust the timer.
SPEED SENSING
WIPER INTERVALON/OFF ONThis key turns on and off the driving speed dependent inter-
mittent wiper function.
CONFIRM RESET
SETTINGSYES/NO NOWhen this key is selected and turned on using the “ENTER”
button, all settings mode by PERSONALIZED SETTINGS will
return to the initial conditions.

NAVIGATION SYSTEM
AV-95
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2004 November 2004 FX35/FX45
Vehicle Electronic Systems
How To Perform Vehicle Electronic Systems
1. Start the engine.
2. Push “SETTING” button.
3. Select “Vehicle Electronic Systems”.
4. Push “Enter” switch.
Application Items
Adjust Driver Seat When Exiting Vehicle
1. Select “Adjust Driver Seat When Exiting Vehicle”.
2. Push “Enter” switch.

The indicator light alternately turns on and off each time the “Enter” switch is pressed.
Lift Steering Column When Exiting Vehicle
1. Select “Lift Steering Column When Exiting Vehicle”.
2. Push “Enter” switch.

The indicator light alternately turns on and off each time the “Enter” switch is pressed.
SKIA5987E
Icon DescriptionReference
page
Adjust Driver Seat When Exiting Vehicle The driver's seat automatically moves back and returns to the original
position.AV- 9 5
Lift Steering Column When Exiting Vehicle This function can be performed to On or Off.AV- 9 5
Selective Door UnlockThis key can switch the unlock doors of the 1st unlocking operation as
follows.

Only the driver side door (On)⇔All the doors (Off)AV- 9 6
Keyless Remote Response-HornThis key changes the horn chirp mode occurring when pressing the
Lock button on the Intelligent Key or keyfob. AV- 9 6
Keyless Remote Response-LightsThis key changes the hazard indicator flash mode occurring when
pressing the Lock or Unlock button on the Intelligent Key or keyfob. AV- 9 6
Auto Re-Lock TimeThe length of auto door relock time can be set.
(Setting value: OFF, 1min or 5min)AV- 9 6
Sensitivity of Automatic Headlights Sensitivity of automatic light can be set as desired.AV- 9 6
Automatic Headlights Off DelayYou can control how long it takes the automatic turn off timer to extin-
guish the headlights in AUTO position.
(Setting value: OFF, 30sec, 45sec, 60sec, 90sec, 120sec, 150sec or
180sec)AV- 9 6
Speed Dependent wiper This function can be performed to On or Off.AV- 9 6
Intelligent Key Lock Response-SoundThe sound pattern of the Intelligent Key operation can be set as
desired. (Setting value:OFF, Beeper or Horn chirp)AV- 9 6
Intelligent Key Unlock Response-Beep SoundThe beep sound when unlocking door with the intelligent key operation
can be turned On or Off.AV- 9 6
Intelligent Key Engine Start Function This function can be performed to On or Off.AV- 9 6
Intelligent Key Lock/Unlock FunctionThe door handle request switch lock/unlock operation with the Intelli-
gent Key can be canceled or activated.AV- 9 6
Return All Settings to DefaultThe all settings made by VEHICLE ELECTRONICS will return to
default.AV- 9 6

BL-246
BODY REPAIR
Revision: 2004 November2004 FX35/FX45
DESCRIPTION
lAll dimensions indicated in the figures are actual.
lWhen using a tracking gauge, adjust both pointers to equal length. Then check the pointers and gauge
itself to make sure there is no free play.
lWhen a measuring tape is used, check to be sure there is no elongation, twisting or bending.
lMeasurements should be taken at the center of the mounting holes.
lAn asterisk (*) following the value at the measuring point indicates that the measuring point on the other
side is symmetrically the same value.
lThe coordinates of the measurement points are the distances measured from the standard line of²X²,²Y²
and²Z².
PIIA0104E

BR-16
BRAKE BOOSTER
Revision: 2004 November 2004 FX35/FX45
Removal and InstallationAFS001N7
REMOVAL
CAUTION:

Be careful not to deform or bend brake piping while removing and installing brake booster.

Replace clevis pin if it is damaged.

Be careful not to damage brake booster stud bolt threads. If brake booster is tilted or inclined dur-
ing installation, dash panel may damage the threads.

Attach the check valve in the correct direction.
1. Remove brake piping from brake master cylinder.
2. Remove brake master cylinder. Refer to BR-13, "
Removal and Installation" .
3. Remove vacuum hose from brake booster. Refer to BR-18, "
VACUUM LINES" .
4. Disconnect harness connector from brake booster assembly. (ICC model)
5. Remove brake pedal attachment snap pin and clevis pin from inside the vehicle.
6. Remove nuts on brake booster and brake pedal assembly.
7. Remove brake booster assembly from dash panel.
INSPECTION AFTER REMOVAL
Output Rod Length Inspection
1. Using a handy vacuum pump, apply a vacuum of – 66.7 kPa (–
500 mmHg, –19.69 inHg) to brake booster.
2. Check output rod length.
1. Reservoir tank 2. Master cylinder 3. Gasket
4. Brake pedal 5. Lock nut 6. Brake booster
SFIA1033E
Standard dimension when vacuum
-66.7kpa (500mmHg, -19.69inHg):
15.6 − 15.9 mm (0.614 − 0.626 in)
SFIA2146E
