Page 1312 of 4731
WARNING LAMPS DI-51
C
D E
F
G H
I
J
L
M A
B
DI
Revision: 2005 July 2005 FX
Oil Pressure Warning Lamp Stays Off (Ignition Switch ON)AKS005NF
1. CHECK SELF-DIAGNOSTIC RESULTS OF UNIFIED METER AND A/C AMP.
Select “METER A/C AMP” on CONSULT-II, and perform self-diagnosis of unified meter and A/C amp. Refer to
DI-31, "
CONSULT-II Function (METER A/C AMP)" .
Self-diagnostic results content
No malfunction detected>> GO TO 2.
Malfunction detected>> Go to DI-17, "
Symptom Chart 2" in “COMBINATION METER”.
2. CHECK IPDM E/R OUTPUT SIGNAL
Activate IPDM E/R auto active test. Refer to PG-24, "
Auto Active Test" .
Does oil pressure warning lamp is blinking?
YES >> GO TO 5.
NO >> GO TO 3.
3. CHECK BCM INPUT SIGNAL
Select “DATA MONITOR” of “SIGNAL BUFFER”. Refer to BCS-13,
"CONSULT-II Function (BCM)" . Operate ignition switch with “OIL
PRESS SW” of “DATA MONITOR” and check operate status.
OK or NG
OK >> GO TO 4.
NG >> Replace IPDM E/R. Refer to PG-30, "
Removal and
Installation of IPDM E/R" .
4. CHECK UNIFIED METER AND A/C AMP. INPUT SIGNAL
Select “METER A/C AMP” on CONSULT-II. Operate ignition switch
with “OIL W/L” of “DATA MONITOR” and check operation status.
OK or NG
OK >> Replace combination meter.
NG >> Replace BCM. Refer to BCS-16, "
Removal and Installa-
tion of BCM" .
“OIL PRESS SW”
When ignition switch is in ON
position (Engine stopped) : ON
When engine running : OFF
SKIA8709E
“OIL W/L”
When ignition switch is in ON
position (Engine stopped) : ON
When engine running : OFF
PKIA2064E
Page 1314 of 4731
WARNING LAMPS DI-53
C
D E
F
G H
I
J
L
M A
B
DI
Revision: 2005 July 2005 FX
3. CHECK OIL PRESSURE SWITCH CIRCUIT
1. Disconnect IPDM E/R connector.
2. Check continuity between IPDM E/R harness connector E9 ter- minal 57 (BR) and ground.
OK or NG
OK >> Replace IPDM E/R. Refer to PG-30, "Removal and
Installation of IPDM E/R" .
NG >> Repair harness or connector.
Component InspectionAKS005NH
OIL PRESSURE SWITCH
Check continuity between oil pressure switch and ground. 57 (BR) – Ground : Continuity should not exist.
SKIA5013E
Condition
Oil pressure kPa (kg/cm2 , psi) Continuity
Engine stopped Less than 29 (0.3, 4) Yes Engine running More than 29 (0.3, 4) No
ELF0044D
Page 1317 of 4731
DI-56
A/T INDICATOR
Revision: 2005 July 2005 FX
A/T Indicator Is MalfunctionAKS005NJ
1. CHECK SELF-DIAGNOSIS OF COMBINATION METER
Perform combination meter self-diagnosis. Refer to DI-14, "
OPERA-
TION PROCEDURE" .
Are all segments displayed?
YES >> GO TO 2.
NO >> Replace combination meter.
2. CHECK SELF-DIAGNOSIS RESULTS OF UNIFIED METER AND A/C AMP.
Select “METER A/C AMP” on CONSULT-II, and perform self-diagnosis of unified meter and A/C amp. Refer to
DI-31, "
CONSULT-II Function (METER A/C AMP)" .
Self-diagnostic results content
No malfunction detected>> GO TO 3.
Malfunction detected>> Go to DI-17, "
Symptom Chart 2" in “COMBINATION METER”.
3. CHECK UNIFIED METER AND A/C AMP. INPUT SIGNAL
1. Connect CONSULT-II and start engine.
2. Use “DATA MONITOR” of “METER A/C AMP” on CONSULT-II. Confirm each indication on the monitor when operating the shift
lever.
OK or NG
OK >> Replace combination meter.
NG >> GO TO 4.
4. CHECK A/T DEVICE
Perform A/T device inspection. Refer to AT- 1 7 0 , "
DTC P1815 MANUAL MODE SWITCH" .
OK or NG
OK >> GO TO 5.
NG >> Repair or replace applicable parts.
EL-3828D
CONSULT-II display Switch operation Operation
status
AT - M I N D Manual mode range ON
Except for manual mode range OFF
AT - M G E A R Manual mode range (shift- up or down) 5 - 1
Except for manual mode range 1
P RANGE IND P range position ON
Except for P range position OFF
R RANGE IND R range position ON
Except for R range position OFF
N RANGE IND N range position ON
Except for N range position OFF
D RANGE IND D range position ON
Except for D range position OFF
SKIA6259E
Page 1347 of 4731
DI-86
LANE DEPARTURE WARNING SYSTEM
Revision: 2005 July 2005 FX
Camera Aiming AdjustmentAKS00C7J
OUTLINE
Adjust the camera aiming every time the LDW camera unit is removed or installed.
CAUTION:
Place the vehicle on the level ground when the camera aiming adjustment is operated.
Follow the CONSULT-II when adjusting the camera aiming. (Camera aiming adjustment cannot be
operated without CONSULT-II.)
PREPARATION
Keep all tires inflated to correct pressures. Adjust the tire pressure to the specified pressure value.
There is no-load in vehicle. Check if coolant, engine oil are filled up to correct level and fuel tank is full.
Shift the gear into “P” position and release the parking brake.
Clean the windshield.
NOTE:
Do not place anything reflective on the upper surface of instrument panel.
TARGET SETTING
Preparation Aiming Adjustment Jig
For aiming adjustment, prepare the following jigs and targets.
PKIB4693E
Page 1350 of 4731
LANE DEPARTURE WARNING SYSTEM DI-89
C
D E
F
G H
I
J
L
M A
B
DI
Revision: 2005 July 2005 FX
7. Mark point at the center of the point “E” and “F”, on the line
“FW”.
CAUTION:
Make sure that “E” through “X” is equal to “F” through “X”.
8. Position the center of the right target to the point of “X”.
VEHICLE HEIGHT CHECK
Measure the wheel arch height. And calculate “Dh”.
NOTE:
“Dh” may be calculated as a minus value.
AIMING ADJUSTMENT
Operation Procedure
CAUTION:
Perform the adjustment under unloaded vehicle condition.
LDW indicator is turned off after the removal/installation, and blinks after replacement.
1. Turn ignition switch OFF.
2. Connect CONSULT-II and CONSULT-II CONVERTER on the data link connector.
3. Start the engine, wait for at least 10 seconds, and touch “START (NISSAN BASED VHCL)”.
PKIB5331E
Dh [mm] = (Hfl + Hfr) ÷ 2 − 840
where, Hfl: Front left wheel arch height [mm]
Hfr: Front right wheel arch height [mm]
SKIB3164E
PBIB1503E
SAIA0450E
Page 1394 of 4731
EC-1
ENGINE CONTROL SYSTEM
B ENGINE
CONTENTS
C
D E
F
G H
I
J
K L
M
SECTION EC
A
EC
Revision: 2005 July 2005 FX
ENGINE CONTROL SYSTEM
VQ35DE
INDEX FOR DTC ...................................................... 15
DTC No. Index .................................................... ... 15
Alphabetical Index ............................................... ... 19
PRECAUTIONS ..................................................... ... 23
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ............................................................. ... 23
On Board Diagnostic (OBD) System of Engine and
A/T ....................................................................... ... 23
Precaution ........................................................... ... 23
PREPARATION ...................................................... ... 27
Special Service Tools .......................................... ... 27
Commercial Service Tools ................................... ... 29
ENGINE CONTROL SYSTEM ............................... ... 30
System Diagram .................................................. ... 30
Multiport Fuel Injection (MFI) System ................. ... 31
Electronic Ignition (EI) System ............................ ... 33
Fuel Cut Control (at No Load and High Engine
Speed) ................................................................. ... 34
AIR CONDITIONING CUT CONTROL .................. ... 35
Input/Output Signal Chart .................................... ... 35
System Description ............................................. ... 35
AUTOMATIC SPEED CONTROL DEVICE (ASCD) ... 36
System Description ............................................. ... 36
Component Description ....................................... ... 37
CAN COMMUNICATION ....................................... ... 38
System Description ............................................. ... 38
EVAPORATIVE EMISSION SYSTEM .................... ... 39
Description .......................................................... ... 39
Component Inspection ........................................ ... 42
Removal and Installation ..................................... ... 43
How to Detect Fuel Vapor Leakage .................... ... 43
ON BOARD REFUELING VAPOR RECOVERY
(ORVR) ................................................................... ... 46
System Description ............................................. ... 46
Diagnostic Procedure .......................................... ... 47
Component Inspection ........................................ ... 49 POSITIVE CRANKCASE VENTILATION ..............
... 51
Description ........................................................... ... 51
Component Inspection ......................................... ... 51
IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-
NATS) ..................................................................... ... 53
Description ........................................................... ... 53
ON BOARD DIAGNOSTIC (OBD) SYSTEM ......... ... 54
Introduction .......................................................... ... 54
Two Trip Detection Logic ..................................... ... 54
Emission-Related Diagnostic Information ............ ... 55
Malfunction Indicator Lamp (MIL) ........................ ... 69
OBD System Operation Chart ............................. ... 72
BASIC SERVICE PROCEDURE ............................ ... 78
Basic Inspection .................................................. ... 78
Idle Speed and Ignition Timing Check ................. ... 83
Idle Mixture Ratio Adjustment .............................. ... 85
VIN Registration .................................................. ... 96
Accelerator Pedal Released Position Learning ... ... 96
Throttle Valve Closed Position Learning .............. ... 96
Idle Air Volume Learning ..................................... ... 97
Fuel Pressure Check ........................................... ... 99
TROUBLE DIAGNOSIS ......................................... .101
Trouble Diagnosis Introduction ............................ .101
DTC Inspection Priority Chart .............................. .107
Fail-Safe Chart .................................................... .109
Symptom Matrix Chart ......................................... .110
Engine Control Component Parts Location ......... .114
Vacuum Hose Drawing ........................................ .120
Circuit Diagram .................................................... .121
ECM Harness Connector Terminal Layout .......... .123
ECM Terminals and Reference Value .................. .123
CONSULT-II Function (ENGINE) ......................... .132
Generic Scan Tool (GST) Function ...................... .144
CONSULT-II Reference Value in Data Monitor .... .147
Major Sensor Reference Graph in Data Monitor
Mode .................................................................... .151
TROUBLE DIAGNOSIS - SPECIFICATION VALUE .153
Description ........................................................... .153
Testing Condition ................................................. .153
Page 1398 of 4731
EC-5
C
D E
F
G H
I
J
K L
M
EC A
Revision: 2005 July 2005 FX
FUNCTION .............................................................
. 426
Description .......................................................... . 426
On Board Diagnosis Logic .................................. . 426
DTC Confirmation Procedure .............................. . 426
Wiring Diagram ................................................... . 427
Diagnostic Procedure .......................................... . 428
Component Inspection ........................................ . 431
Remove and Installation ...................................... . 431
DTC P1124, P1126 THROTTLE CONTROL MOTOR
RELAY ................................................................... . 432
Component Description ....................................... . 432
CONSULT-II Reference Value in Data Monitor Mode . 432
On Board Diagnosis Logic .................................. . 432
DTC Confirmation Procedure .............................. . 432
Wiring Diagram ................................................... . 434
Diagnostic Procedure .......................................... . 435
DTC P1128 THROTTLE CONTROL MOTOR ....... . 437
Component Description ....................................... . 437
On Board Diagnosis Logic .................................. . 437
DTC Confirmation Procedure .............................. . 437
Wiring Diagram ................................................... . 438
Diagnostic Procedure .......................................... . 439
Component Inspection ........................................ . 440
Removal and Installation ..................................... . 441
DTC P1146, P1166 HO2S2 .................................... . 442
Component Description ....................................... . 442
CONSULT-II Reference Value in Data Monitor Mode . 442
On Board Diagnosis Logic .................................. . 442
DTC Confirmation Procedure .............................. . 443
Overall Function Check ....................................... . 443
Wiring Diagram ................................................... . 445
Diagnostic Procedure .......................................... . 448
Component Inspection ........................................ . 450
Removal and Installation ..................................... . 452
DTC P1147, P1167 HO2S2 .................................... . 453
Component Description ....................................... . 453
CONSULT-II Reference Value in Data Monitor Mode . 453
On Board Diagnosis Logic .................................. . 453
DTC Confirmation Procedure .............................. . 454
Overall Function Check ....................................... . 454
Wiring Diagram ................................................... . 456
Diagnostic Procedure .......................................... . 459
Component Inspection ........................................ . 461
Removal and Installation ..................................... . 463
DTC P1148, P1168 CLOSED LOOP CONTROL ... . 464
On Board Diagnosis Logic .................................. . 464
DTC P1211 TCS CONTROL UNIT ........................ . 465
Description .......................................................... . 465
On Board Diagnosis Logic .................................. . 465
DTC Confirmation Procedure .............................. . 465
Diagnostic Procedure .......................................... . 465
DTC P1212 TCS COMMUNICATION LINE ........... . 466
Description .......................................................... . 466
On Board Diagnosis Logic .................................. . 466
DTC Confirmation Procedure .............................. . 466
Diagnostic Procedure .......................................... . 466 DTC P1217 ENGINE OVER TEMPERATURE .......
.467
Description ........................................................... .467
CONSULT-II Reference Value in Data Monitor Mode .469
On Board Diagnosis Logic ................................... .469
Overall Function Check ....................................... .469
Wiring Diagram .................................................... .471
Diagnostic Procedure .......................................... .473
Main 12 Causes of Overheating .......................... .478
Component Inspection ......................................... .478
DTC P1225 TP SENSOR ....................................... .479
Component Description ....................................... .479
On Board Diagnosis Logic ................................... .479
DTC Confirmation Procedure .............................. .479
Diagnostic Procedure .......................................... .480
Removal and Installation ..................................... .480
DTC P1226 TP SENSOR ....................................... .481
Component Description ....................................... .481
On Board Diagnosis Logic ................................... .481
DTC Confirmation Procedure .............................. .481
Diagnostic Procedure .......................................... .482
Removal and Installation ..................................... .482
DTC P1229 SENSOR POWER SUPPLY ............... .483
On Board Diagnosis Logic ................................... .483
DTC Confirmation Procedure .............................. .483
Wiring Diagram .................................................... .484
Diagnostic Procedure .......................................... .485
DTC P1271, P1281 A/F SENSOR 1 ...................... .488
Component Description ....................................... .488
CONSULT-II Reference Value in Data Monitor Mode .488
On Board Diagnosis Logic ................................... .488
DTC Confirmation Procedure .............................. .488
Wiring Diagram .................................................... .490
Diagnostic Procedure .......................................... .493
Removal and Installation ..................................... .496
DTC P1272, P1282 A/F SENSOR 1 ...................... .497
Component Description ....................................... .497
CONSULT-II Reference Value in Data Monitor Mode .497
On Board Diagnosis Logic ................................... .497
DTC Confirmation Procedure .............................. .497
Wiring Diagram .................................................... .499
Diagnostic Procedure .......................................... .502
Removal and Installation ..................................... .505
DTC P1273, P1283 A/F SENSOR 1 ...................... .506
Component Description ....................................... .506
CONSULT-II Reference Value in Data Monitor Mode .506
On Board Diagnosis Logic ................................... .506
DTC Confirmation Procedure .............................. .506
Wiring Diagram .................................................... .508
Diagnostic Procedure .......................................... .511
Removal and Installation ..................................... .515
DTC P1274, P1284 A/F SENSOR 1 ...................... .516
Component Description ....................................... .516
CONSULT-II Reference Value in Data Monitor Mode .516
On Board Diagnosis Logic ................................... .516
Page 1401 of 4731
EC-8Revision: 2005 July 2005 FX
VK45DE
INDEX FOR DTC .....................................................707
DTC No. Index ..................................................... .707
Alphabetical Index ............................................... .711
PRECAUTIONS ...................................................... .715
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .............................................................. .715
On Board Diagnostic (OBD) System of Engine and
A/T ....................................................................... .715
Precaution ........................................................... .715
PREPARATION ...................................................... .719
Special Service Tools .......................................... .719
Commercial Service Tools ................................... .720
ENGINE CONTROL SYSTEM ............................... .721
System Diagram .................................................. .721
Multiport Fuel Injection (MFI) System .................. .722
Electronic Ignition (EI) System ............................ .724
Fuel Cut Control (at No Load and High Engine
Speed) ................................................................. .725
AIR CONDITIONING CUT CONTROL ................... .726
Input/Output Signal Chart .................................... .726
System Description .............................................. .726
AUTOMATIC SPEED CONTROL DEVICE (ASCD) .727
System Description .............................................. .727
Component Description ....................................... .728
CAN COMMUNICATION ........................................ .729
System Description .............................................. .729
EVAPORATIVE EMISSION SYSTEM .................... .730
Description ........................................................... .730
Component Inspection ......................................... .733
Removal and Installation ..................................... .734
How to Detect Fuel Vapor Leakage ..................... .734
ON BOARD REFUELING VAPOR RECOVERY
(ORVR) ................................................................... .737
System Description .............................................. .737
Diagnostic Procedure .......................................... .738
Component Inspection ......................................... .740
POSITIVE CRANKCASE VENTILATION .............. .742
Description ........................................................... .742
Component Inspection ......................................... .742
IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-
NATS) ..................................................................... .744
Description ........................................................... .744
ON BOARD DIAGNOSTIC (OBD) SYSTEM ......... .745
Introduction .......................................................... .745
Two Trip Detection Logic ..................................... .745
Emission-Related Diagnostic Information ............ .746
Malfunction Indicator Lamp (MIL) ........................ .760
OBD System Operation Chart ............................. .764
BASIC SERVICE PROCEDURE ............................ .769
Basic Inspection .................................................. .769
Idle Speed and Ignition Timing Check ................. .774
Idle Mixture Ratio Adjustment .............................. .775
VIN Registration .................................................. .786
Accelerator Pedal Released Position Learning ... .786
Throttle Valve Closed Position Learning .............. .786 Idle Air Volume Learning ......................................
.787
Fuel Pressure Check ........................................... .789
TROUBLE DIAGNOSIS ......................................... .791
Trouble Diagnosis Introduction ............................ .791
DTC Inspection Priority Chart .............................. .797
Fail-Safe Chart ..................................................... .799
Symptom Matrix Chart ......................................... .800
Engine Control Component Parts Location .......... .804
Vacuum Hose Drawing ........................................ .810
Circuit Diagram .................................................... .811
ECM Harness Connector Terminal Layout ........... .813
ECM Terminals and Reference Value .................. .813
CONSULT-II Function (ENGINE) ......................... .822
Generic Scan Tool (GST) Function ...................... .835
CONSULT-II Reference Value in Data Monitor .... .838
Major Sensor Reference Graph in Data Monitor
Mode .................................................................... .842
TROUBLE DIAGNOSIS - SPECIFICATION VALUE .844
Description ........................................................... .844
Testing Condition ................................................. .844
Inspection Procedure ........................................... .844
Diagnostic Procedure ........................................... .845
TROUBLE DIAGNOSIS FOR INTERMITTENT INCI-
DENT ...................................................................... .854
Description ........................................................... .854
Diagnostic Procedure ........................................... .854
POWER SUPPLY AND GROUND CIRCUIT .......... .855
Wiring Diagram .................................................... .855
Diagnostic Procedure ........................................... .856
Ground Inspection ................................................ .861
DTC U1000, U1001 CAN COMMUNICATION LINE .862
Description ........................................................... .862
On Board Diagnosis Logic ................................... .862
DTC Confirmation Procedure ............................... .862
Wiring Diagram .................................................... .863
Diagnostic Procedure ........................................... .864
DTC P0011, P0021 IVT CONTROL ........................ .865
Description ........................................................... .865
CONSULT-II Reference Value in Data Monitor Mode .866
On Board Diagnosis Logic ................................... .866
DTC Confirmation Procedure ............................... .867
Wiring Diagram .................................................... .868
Diagnostic Procedure ........................................... .871
Component Inspection ......................................... .875
Removal and Installation ...................................... .876
DTC P0031, P0032, P0051, P0052 HO2S1 HEATER .877
Description ........................................................... .877
CONSULT-II Reference Value in Data Monitor Mode .877
On Board Diagnosis Logic ................................... .877
DTC Confirmation Procedure ............................... .878
Wiring Diagram .................................................... .879
Diagnostic Procedure ........................................... .882
Component Inspection ......................................... .884
Removal and Installation ...................................... .884
DTC P0037, P0038, P0057, P0058 HO2S2 HEATER .885
Description ........................................................... .885
CONSULT-II Reference Value in Data Monitor Mode
Page 1405 of 4731
EC-12Revision: 2005 July 2005 FX
Component Inspection .........................................
11 5 5
Removal and Installation ..................................... 11 5 5
DTC P1124, P1126 THROTTLE CONTROL MOTOR
RELAY .................................................................... 115 6
Component Description ....................................... 11 5 6
CONSULT-II Reference Value in Data Monitor Mode 11 5 6
On Board Diagnosis Logic ................................... 11 5 6
DTC Confirmation Procedure .............................. 11 5 6
Wiring Diagram .................................................... 11 5 8
Diagnostic Procedure .......................................... 11 5 9
DTC P1128 THROTTLE CONTROL MOTOR ........ 116 1
Component Description ....................................... 11 6 1
On Board Diagnosis Logic ................................... 11 6 1
DTC Confirmation Procedure .............................. 11 6 1
Wiring Diagram .................................................... 11 6 2
Diagnostic Procedure .......................................... 11 6 3
Component Inspection ......................................... 11 6 4
Removal and Installation ..................................... 11 6 5
DTC P1140, P1145 IVT CONTROL POSITION SEN-
SOR ........................................................................ 116 6
Component Description ....................................... 11 6 6
CONSULT-II Reference Value in Data Monitor Mode 11 6 6
On Board Diagnosis Logic ................................... 11 6 6
DTC Confirmation Procedure .............................. 11 6 6
Wiring Diagram .................................................... 11 6 7
Diagnostic Procedure .......................................... 11 7 0
Component Inspection ......................................... 11 7 3
Removal and Installation ..................................... 11 7 3
DTC P1143, P1163 HO2S1 .................................... 117 4
Component Description ....................................... 11 7 4
CONSULT-II Reference Value in Data Monitor Mode 11 7 4
On Board Diagnosis Logic ................................... 11 7 4
DTC Confirmation Procedure .............................. 11 7 5
Overall Function Check ....................................... 11 7 6
Diagnostic Procedure .......................................... 11 7 6
Component Inspection ......................................... 11 7 8
Removal and Installation ..................................... 11 7 9
DTC P1144, P1164 HO2S1 .................................... 118 0
Component Description ....................................... 11 8 0
CONSULT-II Reference Value in Data Monitor Mode 11 8 0
On Board Diagnosis Logic ................................... 11 8 0
DTC Confirmation Procedure .............................. 11 8 1
Overall Function Check ....................................... 11 8 2
Diagnostic Procedure .......................................... 11 8 2
Component Inspection ......................................... 11 8 4
Removal and Installation ..................................... 11 8 6
DTC P1146, P1166 HO2S2 .................................... 118 7
Component Description ....................................... 11 8 7
CONSULT-II Reference Value in Data Monitor Mode 11 8 7
On Board Diagnosis Logic ................................... 11 8 7
DTC Confirmation Procedure .............................. 11 8 8
Overall Function Check ....................................... 11 8 8
Wiring Diagram .................................................... 11 9 0
Diagnostic Procedure .......................................... 11 9 3 Component Inspection .........................................
11 9 6
Removal and Installation ...................................... 11 9 7
DTC P1147, P1167 HO2S2 .................................... 11 98
Component Description ....................................... 11 9 8
CONSULT-II Reference Value in Data Monitor Mode 11 9 8
On Board Diagnosis Logic ................................... 11 9 8
DTC Confirmation Procedure ............................... 11 9 9
Overall Function Check ........................................ 11 9 9
Wiring Diagram .................................................... 1201
Diagnostic Procedure ........................................... 1204
Component Inspection ......................................... 1207
Removal and Installation ...................................... 1208
DTC P1148, P1168 CLOSED LOOP CONTROL ... 1209
On Board Diagnosis Logic ................................... 1209
DTC Confirmation Procedure (Up To Serial 400595
Except for Serial 400590) .................................... 1209
DTC Confirmation Procedure (For Serial 400590
and From Serial 400596) ..................................... 1210
Overall Function Check (Up To Serial 400595
Except for Serial 400590) .................................... 1210
Diagnostic Procedure ........................................... 1210
DTC P1211 TCS CONTROL UNIT ......................... 1211
Description ........................................................... 1211
On Board Diagnosis Logic ................................... 1211
DTC Confirmation Procedure ............................... 1211
Diagnostic Procedure ........................................... 1211
DTC P1212 TCS COMMUNICATION LINE ............ 1212
Description ........................................................... 1212
On Board Diagnosis Logic ................................... 1212
DTC Confirmation Procedure ............................... 1212
Diagnostic Procedure ........................................... 1212
DTC P1217 ENGINE OVER TEMPERATURE ....... 1213
Description ........................................................... 1213
CONSULT-II Reference Value in Data Monitor Mode 1214
On Board Diagnosis Logic ................................... 1214
Overall Function Check ........................................ 1215
Wiring Diagram .................................................... 1217
Diagnostic Procedure ........................................... 1219
Main 13 Causes of Overheating .......................... 1223
Component Inspection ......................................... 1224
DTC P1225 TP SENSOR ....................................... 1225
Component Description ....................................... 1225
On Board Diagnosis Logic ................................... 1225
DTC Confirmation Procedure ............................... 1225
Diagnostic Procedure ........................................... 1226
Removal and Installation ...................................... 1226
DTC P1226 TP SENSOR ....................................... 1227
Component Description ....................................... 1227
On Board Diagnosis Logic ................................... 1227
DTC Confirmation Procedure ............................... 1227
Diagnostic Procedure ........................................... 1228
Removal and Installation ...................................... 1228
DTC P1229 SENSOR POWER SUPPLY ............... 1229
On Board Diagnosis Logic ................................... 1229
DTC Confirmation Procedure ............................... 1229
Wiring Diagram .................................................... 1230
Diagnostic Procedure ........................................... 1231
Page 1420 of 4731
![INFINITI FX35 2005 Service Manual PREPARATION EC-27
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2005 July 2005 FX
PREPARATIONPFP:00002
Special Service ToolsABS006K2
The actual shapes of Kent-Moore tools may differ from](/img/42/57020/w960_57020-1419.png "INFINITI FX35 2005 Service Manual PREPARATION EC-27
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2005 July 2005 FX
PREPARATIONPFP:00002
Special Service ToolsABS006K2
The actual shapes of Kent-Moore tools may differ from")
PREPARATION EC-27
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2005 July 2005 FX
PREPARATIONPFP:00002
Special Service ToolsABS006K2
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
(Kent-Moore No.)
Tool name Description
EG17650301
(J-33984-A)
Radiator cap tester
adapter Adapting radiator cap tester to radiator cap and
radiator filler neck
a: 28 (1.10) dia.
b: 31.4 (1.236) dia.
c: 41.3 (1.626) dia.
Unit: mm (in)
KV10117100
(J-36471-A)
Heated oxygen
sensor wrench Loosening or tightening heated oxygen sensor
with 22 mm (0.87 in) hexagon nut
KV10114400
(J-38365)
Heated oxygen
sensor wrench Loosening or tightening air fuel ratio (A/F) sensor
a: 22 mm (0.87 in)
(J-44321)
Fuel pressure gauge
kit Checking fuel pressure
(J-44321-6)
Fuel pressure adapter Connecting fuel pressure gauge to quick
connector type fuel lines.
(J-44626)
Air fuel ratio (A/F)
sensor wrench Loosening or tightening air fuel ratio (A/F) sensor
1
(J-45488)
Quick connector
release Remove fuel tube quick connectors in engine
room.
S-NT564
S-NT379
S-NT636
LEC642
LBIA0376E
LEM054
PBIC0198E
