TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2005 July 2005 FX
4. CHECK RELEASE SWITCH
1. Turn ignition switch OFF.
2. Check release switch. Refer to ACS-72, "
Release Switch" .
OK or NG
OK >> 1. Replace ICC unit. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NG >> Release switch malfunction 1. Replace brake booster.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
DTC 65 PRESSURE CONTROLAKS00C8X
1. OPERATION CHECK
Check foot brake pedal operates normally.
OK or NG
OK >> GO TO 2.
NG >> 1. Check brake circuit.
2. After repairing, erase DTC and perform active test (BOOSTER SOL/V3) with CONSULT-II. Then perform self-diagnosis of ICC system again.
2. CHECK BOOST SOLENOID
Check boost solenoid. Refer to ACS-71, "
Boost Solenoid" .
OK or NG
OK >> GO TO 3.
NG >> Boost solenoid malfunction
1. Replace brake booster.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS ACS-53
[ICC]
C
D E
F
G H
I
J
L
M A
B
ACS
Revision: 2005 July 2005 FX
3. CHECK HARNESS BETWEEN SOLENOID/RELEASE SWITCH AND ICC UNIT
1. Turn ignition switch OFF.
2. Disconnect ICC unit connector and brake booster connector.
3. Check continuity between ICC unit harness connector M88 ter- minals 10 (B/R), 12 (L/W) and brake booster harness connector
E54 terminals 4 (B), 6 (L).
4. Check continuity between ICC unit harness connector M88 ter- minals 10 (B/R), 12 (L/W) and ground.
OK or NG
OK >> 1. Replace ICC unit. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NG >> 1. Repair harness between brake booster and ICC unit. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
DTC 74 LASER BEAM OFF CNTRAKS00C8Y
1. DIAGNOSTIC CHECK
1. Adjust laser beam aiming. Then erase DTC, and perform ICC system running test.
2. Perform self-diagnosis of ICC system.
3. Check if “DTC 74 LASER BEAM OFF CNTR” is indicated.
Is it indicated?
YES >> 1. Replace ICC sensor, and adjust laser beam aiming.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NO >> INSPECTION END
DTC 90 STOP LAMP RLY FIXAKS00CAT
1. CHECK CONNECTOR ICC UNIT
1. Turn ignition switch OFF.
2. Disconnect ICC unit connector, and connect it securely again.
3. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
Is malfunction indicated?
YES >> GO TO 2.
NO >> Poor connector connection
1. Check connector (Check connector housing for disconnected, loose, bent, and collapsed termi- nals. If any malfunction is detected, repair applicable part).
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
10 (B/R) – 4 (B) : Continuity should exist.
12 (L/W) – 6 (L) : Continuity should exist.
PKIB4147E
10 (B/R) – Ground : Continuity should not exist.
12 (L/W) – Ground : Continuity should not exist.
PKIB4148E

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS ACS-55
[ICC]
C
D E
F
G H
I
J
L
M A
B
ACS
Revision: 2005 July 2005 FX
6. CHECK HARNESS BETWEEN ICC UNIT AND ICC BRAKE HOLD RELAY
1. Disconnect ICC brake switch connector, ECM connector and ICC unit connector.
2. Check continuity between ICC unit harness connector M89 ter- minal 29 (SB) and ICC brake hold relay harness connector E14
terminal 4 (SB).
3. Check continuity between ICC unit harness connector M89 ter- minal 29 (SB) and ground.
OK or NG
OK >> GO TO 7.
NG >> 1. Repair harness between ICC unit and ICC brake hold relay.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
7. CHECK HARNESS BETWEEN ICC BRAKE HOLD RELAY AND ICC BRAKE SWITCH
1. Check continuity between ICC brake hold relay harness connec- tor E14 terminal 3 (L) and ICC brake switch harness connector
E209 terminal 2 (L).
2. Check continuity between ICC brake hold relay harness connec- tor E14 terminal 3 (L) and ground.
OK or NG
OK >> GO TO 8.
NG >> 1. Repair harness between ICC brake hold relay and ICC brake switch.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
8. CHECK ICC BRAKE SWITCH POWER SUPPLY CIRCUIT
1. Turn ignition switch ON.
2. Check voltage between ICC brake switch harness connector E209 terminal 1 (Y) and ground.
OK or NG
OK >> 1. Replace ICC unit. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NG >> 1. Repair or replace harness or fuse. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
29 (SB) – 4 (SB) : Continuity should exist.
29 (SB) – Ground : Continuity should not exist.
SKIA5980E
3 (L) – 2 (L) : Continuity should exist.
3 (L) – Ground : Continuity should not exist.
PKIB4167E
1 (Y) – Ground : Battery voltage
PKIB4168E

ACS-56
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2005 July 2005 FX
9. CHECK STOP LAMP ILLUMINATION
1. Turn ignition switch OFF.
2. Disconnect ICC brake hold relay.
3. Check stop lamp circuit.
OK or NG
OK >> GO TO 10.
NG >> After repairing, erase DTC and perform ICC system running test. Then perform self-diagnosis of
ICC system again.
10. CHECK ICC BRAKE HOLD RELAY CIRCUIT
1. Connect ICC brake hold relay connector.
2. Disconnect stop lamp switch connector.
3. When brake pedal is not depressed, make sure that stop lamp does not illuminate.
OK or NG
OK >> 1. Replace ICC unit. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NG >> GO TO 11.
11 . CHECK ICC BRAKE HOLD RELAY
1. Disconnect ICC brake hold relay.
2. Check continuity between ICC brake hold relay terminal 6 and terminal 7.
OK or NG
OK >> 1. Replace ICC unit. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NG >> 1. Replace ICC brake hold relay. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
6 – 7 : Continuity should not exist.
SKIA6659E

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS ACS-57
[ICC]
C
D E
F
G H
I
J
L
M A
B
ACS
Revision: 2005 July 2005 FX
12. CHECK HARNESS BETWEEN ICC UNIT ICC BRAKE HOLD RELAY AND GROUND
1. Disconnect ICC unit connector and ICC brake hold relay.
2. Check continuity between ICC unit harness connector M89 ter- minal 47 (W/R) and ICC brake hold relay harness connector E14
terminal 1 (W).
3. Check continuity between ICC unit harness connector M89 ter- minal 47 (W/R) and ground.
4. Check continuity between ICC brake hold relay harness connec- tor E14 terminal 2 (B) and ground.
OK or NG
OK >> GO TO 13.
NG >> 1. Repair harness between ICC unit, ICC brake hold
relay, and ground.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
13. CHECK ICC BRAKE HOLD RELAY
Check continuity between ICC brake hold relay terminal 1 and termi-
nal 2.
OK or NG
OK >> GO TO 14.
NG >> 1. Replace ICC brake hold relay.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
14. CHECK ICC UNIT STANDARD VOLTAGE
With CONSULT-II
1. Connect ICC unit connector and stop lamp switch connector.
2. Active test (“STOP LAMP”:“STP LMP DRIVE ON”) with CON- SULT-II, check voltage between ICC unit harness connector
M89 terminal 47 (W/R) and ground.
OK or NG
OK >> GO TO 15.
NG >> 1. Replace ICC unit.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
47 (W/R) – 1 (W) : Continuity should exist.
47 (W/R) – Ground : Continuity should not exist.
SKIA6660E
2 (B) – Ground : Continuity should exist.
SKIA6661E
1 – 2 : Continuity should exist.
SKIA6662E
47 (W/R) – Ground : Approx. 12 V (during active test)
SKIA3075E

ACS-58
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2005 July 2005 FX
15. CHECK ICC BRAKE HOLD RELAY POWER SUPPLY CIRCUIT
Check voltage between ICC brake hold relay harness connector E14
terminal 6 (G/Y) and ground.
OK or NG
OK >> GO TO 16.
NG >> 1. Repair or replace harness or fuse.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
16. CHECK HARNESS BETWEEN ICC UNIT AND ICC BRAKE HOLD RELAY
1. Turn ignition switch OFF.
2. Disconnect ICC unit and ICC brake hold relay connector.
3. Check continuity between ICC unit harness connector M89 ter- minal 38 (P/B) and ICC brake hold relay harness connector E14
terminal 7 (P).
4. Check continuity between ICC unit harness connector M89 ter- minal 38 (P/B) and ground.
OK or NG
OK >> GO TO 17.
NG >> 1. Repair harness between ICC unit and ICC brake hold relay.
2. Erase DTC and perform ICC system running test. Then, perform self-diagnosis of ICC system again.
17. CHECK ICC BRAKE HOLD RELAY
With CONSULT-II
1. Connect ICC unit connector and ICC brake hold relay.
2. Disconnect stop lamp switch connector.
3. Perform “ACTIVE TEST” (“STOP LAMP”) with CONSULT-II, and make sure that stop lamp is illuminated.
OK or NG
OK >> GO TO 18.
NG >> 1. Replace ICC brake hold relay.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
6 (G/Y) – Ground : Battery voltage
SKIA1198E
38 (P/B) – 7 (P) : Continuity should exist.
38 (P/B) – Ground : Continuity should not exist.
SKIA6663E

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS ACS-59
[ICC]
C
D E
F
G H
I
J
L
M A
B
ACS
Revision: 2005 July 2005 FX
18. CHECK ICC UNIT STANDARD VOLTAGE
1. Connect stop lamp switch connector.
2. Perform “ACTIVE TEST” (“STOP LAMP”:“STP LMP DRIVE ON”) with CONSULT-II, check voltage between ICC unit harness
connector M89 terminal 29 (SB) and ground.
OK or NG
OK >> 1. Replace ICC unit. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NG >> 1. Replace stop lamp switch. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
DTC 92 ECM CIRCUITAKS00C90
1. CHECK ICC UNIT SELF-DIAGNOSIS
With CONSULT-II
1. Perform self-diagnosis with CONSULT-II.
2. Check if “DTC 20 CAN COMM CIRCUIT” other than “DTC 92 ECM CIRCUIT” is indicated in self-diagnosis item in the display.
Is it indicated?
YES >> 1. Repair or replace applicable item.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NO >> GO TO 2.
2. CHECK ECM SELF-DIAGNOSIS
With CONSULT-II
1. Perform ECM self-diagnosis with CONSULT-II.
2. Check if malfunction is indicated.
Is malfunction indicated?
YES >> 1. Repair or replace applicable item. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NO >> 1. Replace ICC unit.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
29 (SB) – Ground : Approx. 0 V (during active test)
SKIA1200E

ACS-60
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2005 July 2005 FX
DTC 96 NP RANGEAKS00C91
1. CHECK CONNECTOR ICC UNIT
1. Turn ignition switch OFF.
2. Disconnect ICC unit connector, and connect them securely again.
3. Erase DTC and then perform ICC system running test. Then perform self-diagnosis of ICC system again.
Is malfunction indicated?
YES >> GO TO 2.
NO >> Poor connector connection
1. Check connector. (Check connector housing for disconnected, loose, bent, and collapsed ter- minals. If any malfunction is detected, repair applicable part.)
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
2. CHECK NP RANGE SWITCH SIGNAL
With CONSULT-II
With “DATA MONITOR”, check that “NP RANGE SW” operates normally. Refer to ACS-32, "
DATA MONITOR"
.
OK or NG
OK >> GO TO 5.
NG >> GO TO 3.
3. CHECK HARNESS BETWEEN ICC UNIT AND TCM
1. Turn ignition switch OFF.
2. Disconnect ICC unit harness connector and A/T assembly har- ness connector.
3. Check continuity between ICC unit harness connector M88 ter- minal 7 (GY/R) and A/T assembly harness connector F44 termi-
nal 9 (GY).
4. Check continuity between ICC unit harness connector M88 ter- minal 7 (GY/R) and ground.
OK or NG
OK >> GO TO 4.
NG >> 1. Repair harness between ICC unit and A/T assembly.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
4. CHECK TCM START SIGNAL CIRCUIT
Check TCM start signal. Refer to AT- 1 0 9 , "
DTC P0615 START SIGNAL CIRCUIT" .
OK or NG
OK >> 1. Replace ICC unit. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NG >> 1. Repair or replace damaged parts. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
7 (GY/R) – 9 (GY) : Continuity should exist.
7 (GY/R) – Ground : Continuity should not exist.
PKIB1447E

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS ACS-61
[ICC]
C
D E
F
G H
I
J
L
M A
B
ACS
Revision: 2005 July 2005 FX
5. CHECK SHIFT POSITION SIGNAL
With CONSULT-II
With TCM diagnosis, check that shift operates normally. Refer to AT- 11 4 , "
DTC P0705 PARK/NEUTRAL
POSITION SWITCH" .
OK or NG
OK >> 1. Replace ICC unit. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NG >> 1. Perform TCM self-diagnosis. 2. After repairing or replacing applicable item, erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
DTC 97 AT CIRCUITAKS00C92
1. CHECK AT CIRCUIT
With CONSULT-II
With TCM diagnosis, check that shift operates normally. Refer to AT- 11 4 , "
DTC P0705 PARK/NEUTRAL
POSITION SWITCH" .
OK or NG
OK >> 1. Replace ICC unit. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NG >> 1. Perform TCM self-diagnosis. 2. After repairing or replacing applicable item, erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
DTC 98 GEAR POSITIONAKS00C93
1. CHECK ICC UNIT SELF-DIAGNOSIS
With CONSULT-II
1. Perform self-diagnosis.
2. Check if “DTC 43 ABS/TCS/VDC CIRC” or “DTC 41 VHCL SPEED SE CIRC” other than “DTC 98 GEAR POSITION” is indicated in self-diagnosis item in the display.
Is any indicated?
YES >> 1. Repair or replace applicable item. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NO >> GO TO 2.
2. CHECK VEHICLE SPEED SIGNAL
With CONSULT-II
With “DATA MONITOR”, check that “VHCL SPEED SE” is normal.
OK or NG
OK >> GO TO 3.
NG >> 1. Replace ICC unit.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.

ACS-62
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2005 July 2005 FX
3. CHECK SHIFT GEAR POSITION
Check that gear positions are correct in A/T.
OK or NG
OK >> GO TO 5.
NG >> GO TO 4.
4. CHECK TCM GEAR POSITION SIGNAL
With CONSULT-II
With TCM “DATA MONITOR” with CONSULT-II, check that gear positions are correct.
OK or NG
OK >> 1. Replace ICC unit. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NG >> 1. Perform TCM self-diagnosis. 2. After repairing or replacing applicable item, erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
5. CHECK TCM TURBINE ROTATION
With CONSULT-II
With TCM diagnosis, check that turbine rpm is normal. Refer to AT- 1 4 1 , "
DTC P1716 TURBINE REVOLU-
TION SENSOR" .
OK or NG
OK >> 1. Replace ICC unit. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NG >> 1. Perform TCM self-diagnosis. 2. After repairing or replacing applicable item, erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
DTC 102 RADAR STAINAKS00C94
1. VISUAL INSPECTION 1
Check that there is no contamination and foreign material on ICC sensor body window.
OK or NG
OK >> GO TO 2.
NG >> 1. If any, remove them.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
2. VISUAL INSPECTION 2
Check ICC sensor body window for cracks.
OK or NG
OK >> GO TO 3.
NG >> 1. Replace ICC sensor, and adjust laser beam aiming.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
