TROUBLE DIAGNOSISPFP:00004
DTC Inspection Priority ChartACS002LS
If some DTCs are displayed at the same time, perform inspections one by one based on the following priority
chart.
NOTE:
If DTC U1000 is displayed with other DTCs, first perform the trouble diagnosis for DTC U1000. Refer to
AT- 1 0 6
.
Fail-safeACS002LT
The TCM has an electrical fail-safe mode. This mode makes it possible to operate even if there is a an error in
a main electronic control input/output signal circuit.
In fail-safe mode, even if the selector lever is “D” or “M” mode, the transmission is fixed in 2nd, 4th or 5th
(depending on the breakdown position), so the customer should feel “slipping” or “poor acceleration”. When
fail-safe mode is triggered, when the ignition switch is switched “ON”, the A/T CHECK indicator lamp flashes
for about 8 seconds. (Refer to AT- 1 0 3 , "
TCM SELF-DIAGNOSTIC PROCEDURE (NO TOOLS)" ).
Even when the electronic circuits are normal, under special conditions (for example, when slamming on the
brake with the wheels spinning drastically and stopping the tire rotation), the transmission can go into fail-safe
mode. If this happens, switch OFF the ignition switch for 10 seconds, then switch it ON again to return to the
normal shift pattern. Also, the A/T CHECK indicator lamp flashes for about 8 seconds once, then is cleared.
Therefore, the customer's vehicle has returned to normal, so handle according to the “WORK FLOW” (Refer to
AT- 4 6
).
FAIL-SAFE FUNCTION
If any malfunction occurs in a sensor or solenoid, this function controls the A/T to mark driving possible.
Vehicle Speed Sensor

Signals are input from two systems - from vehicle speed sensor A/T (revolution sensor) installed on the
transmission and from combination meter so normal driving is possible even if there is a malfunction in
one of the systems. And if vehicle speed sensor A/T (revolution sensor) has unusual cases, 5th gear and
manual mode are prohibited.
Accelerator Pedal Position Sensor

If there is a malfunction in one of the systems, the accelerator opening angle is controlled by ECM accord-
ing to a pre-determined accelerator angle to make driving possible. And if there are malfunctions in tow
systems, the engine speed is fixed by ECM to a pre-determined engine speed to make driving possible.
Throttle Position Sensor

If there is a malfunction in one of the systems, the accelerator opening angle is controlled by ECM accord-
ing to a pre-determined accelerator angle to make driving possible. And if there are malfunctions in tow
systems, the accelerator opening angle is controlled by the idle signal sent from the ECM which is based
on input indicating either idle condition or off-idle condition (pre-determined accelerator opening) in order
to make driving possible.
PNP Switch

In the unlikely event that a malfunction signal enters the TCM, the position indicator is switched OFF, the
starter relay is switched OFF (starter starting is disabled), the back-up lamp relay switched OFF (back-up
lamp is OFF) and the position is fixed to the “D” position to make driving possible.
Starter Relay

The starter relay is switched OFF. (Starter starting is disabled.)
Priority Detected items (DTC)
1 U1000 CAN communication line
2 Except above

AT-44
TROUBLE DIAGNOSIS
Revision: 2005 July 2005 FX
A/T Interlock

If there is an A/T interlock judgment malfunction, the transmission is fixed in 2nd gear to make driving pos-
sible.
NOTE:
When the vehicle is driven fixed in 2nd gear, a turbine revolution sensor malfunction is displayed,
but this is not a turbine revolution sensor malfunction.

When the coupling pattern below is detected, the fail-safe action corresponding to the pattern is per-
formed.
A/T INTERLOCK COUPLING PATTERN TABLE

: NG X: OK
A/T 1st Engine Braking

When there is an A/T first gear engine brake judgment malfunction, the low coast brake solenoid is
switched OFF to avoid the engine brake operation.
Line Pressure Solenoid

The solenoid is switched OFF and the line pressure is set to the maximum hydraulic pressure to make
driving possible.
Torque Converter Clutch Solenoid

The solenoid is switched OFF to release the lock-up.
Low Coast Brake Solenoid

When a (electrical or functional) malfunction occurs, in order to make driving possible, if the solenoid is
ON, the transmission is held in 2nd gear; if the solenoid is OFF, the transmission is held in 4th gear.
(Engine brake is not applied in 1st and 2nd gear.)
Input Clutch Solenoid

If a (electrical or functional) malfunction occurs with the solenoid either ON or OFF, the transmission is
held in 4th gear to make driving possible.
Direct Clutch Solenoid

If a (electrical or functional) malfunction occurs with the solenoid either ON or OFF, the transmission is
held in 4th gear to make driving possible.
Front Brake Solenoid

If a (electrical or functional) malfunction occurs with the solenoid ON, in order to make driving possible,
the A/T is held in 5th gear; if the solenoid is OFF, 4th gear.
High and Low Reverse Clutch Solenoid

If a (electrical or functional) malfunction occurs with the solenoid either ON or OFF, the transmission is
held in 4th gear to make driving possible.
Turbine Revolution Sensor 1 or 2

The control is the same as if there were no turbine revolution sensors, 5th gear and manual mode are pro-
hibited.
Gear position ATF pressure switch output
Fail-safe function Clutch pressure output pattern after fail-safe func-
tion
SW3 (I/C) SW6
(HLR/ C) SW5
(D/C) SW1
(FR/B) SW2
(LC/B) I/C HLR/C D/C FR/B LC/B L/U
A/T inter-
lock cou-
pling pattern 3rd – X X –

Held in
2nd gear OFF OFF ON OFF OFF OFF
4th – X X –
Held in
2nd gear OFF OFF ON OFF OFF OFF
5th X X – X
Held in
2nd gear OFF OFF ON OFF OFF OFF

AT-48
TROUBLE DIAGNOSIS
Revision: 2005 July 2005 FX
4 ❏
Perform all road tests and enter checks in required inspection items. AT- 5 6
4-1. Check before engine is started
AT- 5 6
❏ The A/T CHECK Indicator Lamp does come on. AT- 1 9 3 .
❏ Perform self-diagnostics. Enter checks for detected items. AT- 9 3
,AT- 1 0 3
❏ AT-106, "DTC U1000 CAN COMMUNICATION LINE" .
❏ AT-109, "
DTC P0615 START SIGNAL CIRCUIT" .
❏ AT- 11 3 , "
DTC P0700 TCM"
❏ AT- 11 4 , "DTC P0705 PARK/NEUTRAL POSITION SWITCH" .
❏ AT- 11 8 , "
DTC P0720 VEHICLE SPEED SENSOR A/T (REVOLUTION SENSOR)" .
❏ AT-123, "
DTC P0725 ENGINE SPEED SIGNAL" .
❏ AT-125, "
DTC P0740 TORQUE CONVERTER CLUTCH SOLENOID VALVE" .
❏ AT-127, "
DTC P0744 A/T TCC S/V FUNCTION (LOCK-UP)" .
❏ AT-129, "
DTC P0745 LINE PRESSURE SOLENOID VALVE" .
❏ AT-131, "
DTC P1702 TRANSMISSION CONTROL MODULE (RAM)" .
❏ AT-132, "
DTC P1703 TRANSMISSION CONTROL MODULE (ROM)" .
❏ AT-133, "
DTC P1705 THROTTLE POSITION SENSOR" .
❏ AT-136, "
DTC P1710 A/T FLUID TEMPERATURE SENSOR CIRCUIT" .
❏ AT-141, "
DTC P1716 TURBINE REVOLUTION SENSOR" .
❏ AT-143, "
DTC P1721 VEHICLE SPEED SENSOR MTR" .
❏ AT-145, "
DTC P1730 A/T INTERLOCK" .
❏ AT-148, "
DTC P1731 A/T 1ST ENGINE BRAKING" .
❏ AT-150, "
DTC P1752 INPUT CLUTCH SOLENOID VALVE" .
❏ AT-152, "
DTC P1754 INPUT CLUTCH SOLENOID VALVE FUNCTION" .
❏ AT-154, "
DTC P1757 FRONT BRAKE SOLENOID VALVE" .
❏ AT-156, "
DTC P1759 FRONT BRAKE SOLENOID VALVE FUNCTION" .
❏ AT-158, "
DTC P1762 DIRECT CLUTCH SOLENOID VALVE" .
❏ AT-160, "
DTC P1764 DIRECT CLUTCH SOLENOID VALVE FUNCTION" .
❏ AT-162, "
DTC P1767 HIGH AND LOW REVERSE CLUTCH SOLENOID VALVE" .
❏ AT-164, "
DTC P1769 HIGH AND LOW REVERSE CLUTCH SOLENOID VALVE
FUNCTION" .
❏ AT-166, "
DTC P1772 LOW COAST BRAKE SOLENOID VALVE" .
❏ AT-168, "
DTC P1774 LOW COAST BRAKE SOLENOID VALVE FUNCTION" .
❏ AT-170, "
DTC P1815 MANUAL MODE SWITCH" .
❏ AT-175, "
DTC P1841 ATF PRESSURE SWITCH 1" .
❏ AT-177, "
DTC P1843 ATF PRESSURE SWITCH 3" .
❏ AT-179, "
DTC P1845 ATF PRESSURE SWITCH 5" .
❏ AT-181, "
DTC P1846 ATF PRESSURE SWITCH 6" .
4-2. Check at Idle
AT- 5 7
❏ AT-194, "Engine Cannot Be Started in “P” or “N” Position" .
❏ AT-195, "
In “P” Position, Vehicle Moves When Pushed"
❏ AT-196, "In “N” Position, Vehicle Moves" .
❏ AT-197, "
Large Shock (“N” to “D” Position)" .
❏ AT-200, "
Vehicle Does Not Creep Backward in “R” Position" .
❏ AT-203, "
Vehicle Does Not Creep Forward in “D” Position" .
4-3. Cruise Test
AT- 5 8
Part 1
❏ AT-205, "
Vehicle Cannot Be Started from D1" .
❏ AT-208, "
A/T Does Not Shift: D1 → D2" .
❏ AT-210, "
A/T Does Not Shift: D2 → D3" .
❏ AT-212, "
A/T Does Not Shift: D3 → D4" .
❏ AT-215, "
A/T Does Not Shift: D4 → D5" .
❏ AT-217, "
A/T Does Not Perform Lock-up"
❏ AT-219, "A/T Does Not Hold Lock-up Condition" .
❏ AT-221, "
Lock-up Is Not Released" .
❏ AT-221, "
Engine Speed Does Not Return to Idle" .

TROUBLE DIAGNOSIS AT-49
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2005 July 2005 FX
44-3 Part 2
AT- 6 0
❏ AT- 2 0 5 , "Vehicle Cannot Be Started from D1" .
❏ AT- 2 0 8 , "
A/T Does Not Shift: D1 → D2" .
❏ AT- 2 1 0 , "
A/T Does Not Shift: D2 → D3" .
❏ AT- 2 1 2 , "
A/T Does Not Shift: D3 → D4" .
Part 3 AT- 6 1
❏ AT- 2 2 3 , "Cannot Be Changed to Manual Mode" .
❏ AT- 2 2 3 , "
A/T Does Not Shift: 5th Gear → 4th Gear" .
❏ AT- 2 2 5 , "
A/T Does Not Shift: 4th Gear → 3rd Gear" .
❏ AT- 2 2 7 , "
A/T Does Not Shift: 3rd Gear → 2nd Gear" .
❏ AT- 2 2 9 , "
A/T Does Not Shift: 2nd Gear → 1st Gear" .
❏ AT- 2 3 1 , "
Vehicle Does Not Decelerate by Engine Brake" .
❏ Perform self-diagnostics. Enter checks for detected items. AT- 9 3
,AT- 1 0 3
❏ AT-106, "DTC U1000 CAN COMMUNICATION LINE" .
❏ AT-109, "
DTC P0615 START SIGNAL CIRCUIT" .
❏ AT-113, "
DTC P0700 TCM"
❏ AT-114, "DTC P0705 PARK/NEUTRAL POSITION SWITCH" .
❏ AT-118, "
DTC P0720 VEHICLE SPEED SENSOR A/T (REVOLUTION SENSOR)" .
❏ AT-123, "
DTC P0725 ENGINE SPEED SIGNAL" .
❏ AT-125, "
DTC P0740 TORQUE CONVERTER CLUTCH SOLENOID VALVE" .
❏ AT-127, "
DTC P0744 A/T TCC S/V FUNCTION (LOCK-UP)" .
❏ AT-129, "
DTC P0745 LINE PRESSURE SOLENOID VALVE" .
❏ AT-131, "
DTC P1702 TRANSMISSION CONTROL MODULE (RAM)" .
❏ AT-132, "
DTC P1703 TRANSMISSION CONTROL MODULE (ROM)" .
❏ AT-133, "
DTC P1705 THROTTLE POSITION SENSOR" .
❏ AT-136, "
DTC P1710 A/T FLUID TEMPERATURE SENSOR CIRCUIT" .
❏ AT-141, "
DTC P1716 TURBINE REVOLUTION SENSOR" .
❏ AT-143, "
DTC P1721 VEHICLE SPEED SENSOR MTR" .
❏ AT-145, "
DTC P1730 A/T INTERLOCK" .
❏ AT-148, "
DTC P1731 A/T 1ST ENGINE BRAKING" .
❏ AT-150, "
DTC P1752 INPUT CLUTCH SOLENOID VALVE" .
❏ AT-152, "
DTC P1754 INPUT CLUTCH SOLENOID VALVE FUNCTION" .
❏ AT-154, "
DTC P1757 FRONT BRAKE SOLENOID VALVE" .
❏ AT-156, "
DTC P1759 FRONT BRAKE SOLENOID VALVE FUNCTION" .
❏ AT-158, "
DTC P1762 DIRECT CLUTCH SOLENOID VALVE" .
❏ AT-160, "
DTC P1764 DIRECT CLUTCH SOLENOID VALVE FUNCTION" .
❏ AT-162, "
DTC P1767 HIGH AND LOW REVERSE CLUTCH SOLENOID VALVE" .
❏ AT-164, "
DTC P1769 HIGH AND LOW REVERSE CLUTCH SOLENOID VALVE
FUNCTION" .
❏ AT-166, "
DTC P1772 LOW COAST BRAKE SOLENOID VALVE" .
❏ AT-168, "
DTC P1774 LOW COAST BRAKE SOLENOID VALVE FUNCTION" .
❏ AT-170, "
DTC P1815 MANUAL MODE SWITCH" .
❏ AT-175, "
DTC P1841 ATF PRESSURE SWITCH 1" .
❏ AT-177, "
DTC P1843 ATF PRESSURE SWITCH 3" .
❏ AT-179, "
DTC P1845 ATF PRESSURE SWITCH 5" .
❏ AT-181, "
DTC P1846 ATF PRESSURE SWITCH 6" .
5 ❏ Inspect each system for items found to be NG in the self-diagnostics and repair or replace the malfunctioning parts.
6 ❏ Perform all road tests and enter the checks again for the required items. AT- 5 6
7 ❏
For any remaining NG items, perform the “diagnostics procedure” and repair or replace the malfunctioning
parts. See the chart for diagnostics by symptoms. (This chart also contains other symptoms and inspection pro-
cedures.) AT- 6 4
8
❏ Erase the results of the self-diagnostics from the TCM. AT- 4 1,
AT-
103

TROUBLE DIAGNOSIS AT-55
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2005 July 2005 FX
6. Start the engine, then measure the line pressure at both idle and
the stall speed.
CAUTION:

Keep the brake pedal pressed all the way down during
measurement.

When measuring the line pressure at the stall speed,
refer to AT- 5 2 , "
STALL TEST" .
7. After the measurements are complete, install the oil pressure detection plug and tighten to the specified torque.
CAUTION:

Do not reuse the O-ring.

Apply ATF to the O-ring.
Line Pressure
Judgement of Line Pressure Test
:7.3 N·m (0.74 kg-m, 65 in-lb)SAT493G
Engine speed Line pressure [kPa (kg/cm
2 , psi)]
“R” position “D”, “M” positions
At idle speed 425 - 465 (4.3 - 4.8, 62 - 67) 379 - 428 (3.9 - 4.4, 55 - 62)
At stall speed 1,605 - 1,950 (16.4 - 19.9, 233 - 283) 1,310 - 1,500 (13.4 - 15.3, 190 - 218)
Judgement Possible cause
Idle speed Low for all positions
(“P”, “R”, “N”, “D”,
“M”) Possible causes include malfunctions in the pressure supply system and low oil pump output.
For example

Oil pump wear

Pressure regulator valve or plug sticking or spring fatigue

Oil strainer
oil pump
pressure regulator valve passage oil leak

Engine idle speed too low
Only low for a spe-
cific position Possible causes include an oil pressure leak in a passage or device related to the position after
the pressure is distributed by the manual valve.
High Possible causes include a sensor malfunction or malfunction in the line pressure adjustment func-
tion.
For example

Accelerator pedal position signal malfunction

ATF temperature sensor malfunction

Line pressure solenoid malfunction (sticking in OFF state, filter clog, cut line)

Pressure regulator valve or plug sticking

AT-64
TROUBLE DIAGNOSIS
Revision: 2005 July 2005 FX
Symptom ChartACS0080Q

The diagnostics item numbers show the sequence for inspection. Check in order from Item 1.

Overhaul and check inside the A/T only if A/T fluid condition is NG. Refer to AT- 5 2 , "A/T Fluid Condition
Check" .
No. Items Symptom Condition Diagnostic Item Reference
page
1 Shift
Shock Large shock. (“N”
→
“D” position)
Refer to AT-197,
"Large Shock (“N” to
“D” Position)" . ON vehicle 1. Engine idle speed
EC-83
(for
VQ35DE)
or EC-774

(for
VK45DE)
2. Engine speed signal AT- 1 2 3
3. Accelerator pedal position sensorAT- 1 3 3
4. Control linkage adjustmentAT- 2 3 5
5. A/T fluid temperature sensorAT- 1 3 6
6. ATF pressure switch 1 and front brake solenoid valve AT- 1 7 5,
AT- 1 5 4
7. CAN communication line AT- 1 0 6
8. A/T fluid level and state AT- 5 2
9. Line pressure testAT- 5 4
10. Control valve with TCMAT- 2 4 3
OFF vehicle 11. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-18, "Cross-Sectional View (2WD Models)" or AT- 1 9 , "Cross-
Sectional View (AWD Models)" ) AT- 2 9 0
2
Shock is too large
when changing D1 →
D
2 or M1 → M2 . ON vehicle 1. Accelerator pedal position sensor
AT- 1 3 3
2. Control linkage adjustmentAT- 2 3 5
3. ATF pressure switch 5 and direct clutch solenoid valve AT- 1 7 9,
AT- 1 5 8
4. CAN communication line AT- 1 0 6
5. Engine speed signalAT- 1 2 3
6. Turbine revolution sensorAT- 1 4 1
7. Vehicle speed sensor A/T and vehicle speed sensor MTR AT- 11 8,
AT- 1 4 3
8. A/T fluid level and state AT- 5 2
9. Control valve with TCMAT- 2 4 3
OFF vehicle 10. Direct clutch AT- 3 2 6

TROUBLE DIAGNOSIS AT-65
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2005 July 2005 FX
3
Shift
Shock Shock is too large
when changing D2 →
D
3 or M2 → M3 . ON vehicle 1. Accelerator pedal position sensor
AT-133
2. Control linkage adjustmentAT-235
3. ATF pressure switch 6, high and low reverse clutch sole-
noid valve AT-181,
AT-162
4. CAN communication line AT-106
5. Engine speed signalAT-123
6. Turbine revolution sensorAT-141
7. Vehicle speed sensor A/T and vehicle speed sensor MTR AT- 11 8,
AT-143
8. A/T fluid level and state AT- 5 2
9. Control valve with TCMAT-243
OFF vehicle 10. High and low reverse clutch AT-323
4 Shock is too large
when changing D3 →
D
4 or M3 → M4 . ON vehicle 1. Accelerator pedal position sensor
AT-133
2. Control linkage adjustmentAT-235
3. ATF pressure switch 3 and input clutch solenoid valve AT-177,
AT-150
4. CAN communication line AT-106
5. Engine speed signalAT-123
6. Turbine revolution sensorAT-141
7. Vehicle speed sensor A/T and vehicle speed sensor MTR AT- 11 8,
AT-143
8. A/T fluid level and state AT- 5 2
9. Control valve with TCMAT-243
OFF vehicle 10. Input clutch AT-313
5 Shock is too large
when changing D4 →
D
5 or M4 → M5 . ON vehicle 1. Accelerator pedal position sensor
AT-133
2. Control linkage adjustmentAT-235
3. ATF pressure switch 1 and front brake solenoid valve AT-175,
AT-154

4. CAN communication line AT-106
5. Engine speed signalAT-123
6. Turbine revolution sensorAT-141
7. Vehicle speed sensor A/T and vehicle speed sensor MTR AT- 11 8,
AT-143
8. A/T fluid level and state AT- 5 2
9. Control valve with TCMAT-243
OFF vehicle 10. Front brake (brake band)
AT-27811. Input clutchAT-313
No. Items Symptom Condition Diagnostic Item Reference
page

AT-66
TROUBLE DIAGNOSIS
Revision: 2005 July 2005 FX
6
Shift
Shock Shock is too large for
downshift when accel-
erator pedal is
pressed. ON vehicle 1. Accelerator pedal position sensor
AT- 1 3 3
2. Control linkage adjustmentAT- 2 3 5
3. CAN communication lineAT- 1 0 6
4. Engine speed signalAT- 1 2 3
5. Turbine revolution sensorAT- 1 4 1
6. Vehicle speed sensor A/T and vehicle speed sensor MTR AT- 11 8,
AT- 1 4 3
7. A/T fluid level and state AT- 5 2
8. Control valve with TCMAT- 2 4 3
OFF vehicle 9. Front brake (brake band)
AT- 2 7 810. Input clutch AT- 3 1 3
11. High and low reverse clutchAT- 3 2 3
12. Direct clutchAT- 3 2 6
7 Shock is too large for
upshift when acceler-
ator pedal is released. ON vehicle 1. Accelerator pedal position sensor
AT- 1 3 3
2. Control linkage adjustmentAT- 2 3 5
3. Engine speed signalAT- 1 2 3
4. CAN communication lineAT- 1 0 6
5. Turbine revolution sensorAT- 1 4 1
6. Vehicle speed sensor A/T and vehicle speed sensor MTR AT- 11 8,
AT- 1 4 3
7. A/T fluid level and state AT- 5 2
8. Control valve with TCMAT- 2 4 3
OFF vehicle 9. Front brake (brake band)
AT- 2 7 810. Input clutch AT- 3 1 3
11. High and low reverse clutch AT- 3 2 3
12. Direct clutch AT- 3 2 6
8 Shock is too large for
lock-up. ON vehicle 1. Accelerator pedal position sensor
AT- 1 3 3
2. Control linkage adjustmentAT- 2 3 5
3. Engine speed signalAT- 1 2 3
4. CAN communication lineAT- 1 0 6
5. Turbine revolution sensorAT- 1 4 1
6. Vehicle speed sensor A/T and vehicle speed sensor MTR AT- 11 8,
AT- 1 4 3
7. Torque converter clutch solenoid valve AT- 1 2 5
8. A/T fluid level and state AT- 5 2
9. Control valve with TCMAT- 2 4 3
OFF vehicle 10. Torque converter AT- 2 9 0
No. Items Symptom Condition Diagnostic Item Reference
page

TROUBLE DIAGNOSIS AT-67
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2005 July 2005 FX9 Shift
Shock Shock is too large
during engine brake. ON vehicle
1. Accelerator pedal position sensor
AT-133
2. Control linkage adjustmentAT-235
3. CAN communication lineAT-106
4. A/T fluid level and state AT- 5 2
5. Control valve with TCMAT-243
OFF vehicle 6. Front brake (brake band)
AT-2787. Input clutch AT-313
8. High and low reverse clutchAT-323
9. Direct clutch AT-326
10
No Up
Shift Gear does not change
from D
1 → D2 or from
M
1 → M2 .
Refer to AT-208, "
A/T
Does Not Shift: D1 →
D2" . ON vehicle 1. A/T fluid level and state
AT- 5 2
2. Vehicle speed sensor A/T and vehicle speed sensor MTR AT- 11 8,
AT-143
3. ATF pressure switch 5 and direct clutch solenoid valve AT-179,
AT-158
4. Line pressure test AT- 5 4
5. CAN communication lineAT-106
6. Control valve with TCMAT-243
OFF vehicle 7. Direct clutch AT-326
11 Gear does not change
from D
2 → D3 or from
M
2 → M3 .
Refer to AT-210, "
A/T
Does Not Shift: D2 →
D3" . ON vehicle 1. A/T fluid level and state
AT- 5 2
2. Vehicle speed sensor A/T and vehicle speed sensor MTR AT- 11 8,
AT-143
3. ATF pressure switch 6, high and low reverse clutch sole-
noid valve AT-181,
AT-162
4. Line pressure test AT- 5 4
5. CAN communication lineAT-106
6. Control valve with TCMAT-243
OFF vehicle 7. High and low reverse clutch AT-323
12 Gear does not change
from D
3 → D4 or from
M
3 → M4 .
Refer to AT-212, "
A/T
Does Not Shift: D3 →
D4" . ON vehicle 1. A/T fluid level and state
AT- 5 2
2. Vehicle speed sensor A/T and vehicle speed sensor MTR AT- 11 8,
AT-143
3. ATF pressure switch 3 and input clutch solenoid valve AT-177,
AT-150
4. ATF pressure switch 1 and front brake solenoid valve AT-175,
AT-154
5. Line pressure test AT- 5 4
6. CAN communication lineAT-106
7. Control valve with TCMAT-243
OFF vehicle 8. Input clutch AT-313
No. Items Symptom Condition Diagnostic Item Reference
page

AT-68
TROUBLE DIAGNOSIS
Revision: 2005 July 2005 FX
13 No Up
Shift Gear does not change
from D
4 → D5 or from
M
4 → M5 .
Refer to AT-215, "
A/T
Does Not Shift: D4 →
D5" . ON vehicle 1. A/T fluid level and state
AT- 5 2
2. Vehicle speed sensor A/T and vehicle speed sensor MTR AT- 11 8,
AT- 1 4 3
3. ATF pressure switch 1 and front brake solenoid valve AT- 1 7 5,
AT- 1 5 4
4. ATF pressure switch 5 and direct clutch solenoid valve AT- 1 7 9,
AT- 1 5 8
5. Turbine revolution sensor AT- 1 4 1
6. Line pressure test AT- 5 4
7. CAN communication lineAT- 1 0 6
8. Control valve with TCMAT- 2 4 3
OFF vehicle 9. Front brake (brake band)
AT- 2 9 010. Input clutchAT- 3 1 3
14
No Down
Shift In “D” or “M” position,
does not downshift to
4th gear. ON vehicle 1. A/T fluid level and state
AT- 5 2
2. Vehicle speed sensor A/T and vehicle speed sensor MTR AT- 11 8,
AT- 1 4 3

3. ATF pressure switch 1 and front brake solenoid valve AT- 1 7 5
,
AT- 1 5 4
4. ATF pressure switch 5 and direct clutch solenoid valve AT- 1 7 9,
AT- 1 5 8
5. CAN communication line AT- 1 0 6
6. Line pressure test AT- 5 4
7. Control valve with TCMAT- 2 4 3
OFF vehicle 8. Front brake (brake band)
AT- 2 9 09. Input clutchAT- 3 1 3
15 In “D” or “M” position,
does not downshift to
3rd gear. ON vehicle 1. A/T fluid level and state
AT- 5 2
2. Vehicle speed sensor A/T and vehicle speed sensor MTR AT- 11 8,
AT- 1 4 3
3. ATF pressure switch 3 and input clutch solenoid valve AT- 1 7 7,
AT- 1 5 0
4. ATF pressure switch 1 and front brake solenoid valve AT- 1 7 5,
AT- 1 5 4
5. CAN communication line AT- 1 0 6
6. Line pressure test AT- 5 4
7. Control valve with TCMAT- 2 4 3
OFF vehicle 8. Input clutch AT- 3 1 3
No. Items Symptom Condition Diagnostic Item Reference
page
