TROUBLE DIAGNOSIS AT-69
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2005 July 2005 FX16
No Down
Shift In “D” or “M” position,
does not downshift to
2nd gear. ON vehicle 1. A/T fluid level and state
AT- 5 2
2. Vehicle speed sensor A/T and vehicle speed sensor MTR AT- 11 8,
AT-143

3. ATF pressure switch 6, high and low reverse clutch sole-
noid valve AT-181
,
AT-162
4. CAN communication line AT-106
5. Line pressure test AT- 5 4
6. Control valve with TCMAT-243
OFF vehicle 7. High and low reverse clutch AT-323
17 In “D” or “M” position,
does not downshift to
1st gear. ON vehicle 1. A/T fluid level and state
AT- 5 2
2. Vehicle speed sensor A/T and vehicle speed sensor MTR AT- 11 8,
AT-143
3. ATF pressure switch 5 and direct clutch solenoid valve AT-179,
AT-158
4. CAN communication line AT-106
5. Line pressure test AT- 5 4
6. Control valve with TCMAT-243
OFF vehicle 7. Direct clutch AT-326
18 Slips/Will
Not
Engage When “D” or “M” posi-
tion, remains in 1st
gear. ON vehicle
1. A/T fluid level and state
AT- 5 2
2. Vehicle speed sensor A/T and vehicle speed sensor MTR AT- 11 8,
AT-143
3. Direct clutch solenoid valve AT-158
4. Line pressure test AT- 5 4
5. CAN communication lineAT-106
6. Control valve with TCMAT-243
OFF vehicle 7. 3rd one-way clutch
AT- 3 11
8. 1st one-way clutchAT-318
9. Gear systemAT-278
10. Reverse brakeAT-290
11. Forward one-way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT- 1 8 , "
Cross-Sectional View (2WD Models)" or AT- 1 9 ,
"Cross-Sectional View (AWD Models)" ) AT-290
12. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-18,
"Cross-Sectional View (2WD Models)" or AT-19, "Cross-
Sectional View (AWD Models)" ) AT-290
No. Items Symptom Condition Diagnostic Item
Reference
page

AT-70
TROUBLE DIAGNOSIS
Revision: 2005 July 2005 FX
19
Slips/Will
Not
Engage When “D” or “M” posi-
tion, remains in 2nd
gear. ON vehicle
1. A/T fluid level and state
AT- 5 2
2. Vehicle speed sensor A/T and vehicle speed sensor MTR AT- 11 8,
AT- 1 4 3
3. Low coast brake solenoid valve AT- 1 6 6
4. Line pressure test AT- 5 4
5. CAN communication lineAT- 1 0 6
6. Control valve with TCMAT- 2 4 3
OFF vehicle 7. 3rd one-way clutch
AT- 3 11
8. Gear systemAT- 2 7 8
9. Direct clutchAT- 3 2 6
10. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-18,
"Cross-Sectional View (2WD Models)" or AT- 1 9 , "Cross-
Sectional View (AWD Models)" ) AT- 2 9 0
20When “D” or “M” posi-
tion, remains in 3rd
gear. ON vehicle
1. A/T fluid level and state
AT- 5 2
2. Vehicle speed sensor A/T and vehicle speed sensor MTR AT- 11 8,
AT- 1 4 3
3. Line pressure test AT- 5 4
4. CAN communication lineAT- 1 0 6
5. Control valve with TCMAT- 2 4 3
OFF vehicle 6. 3rd one-way clutch
AT- 3 11
7. Gear systemAT- 2 7 8
8. High and low reverse clutchAT- 3 2 3
9. Forward one-way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT-18, "
Cross-Sectional View (2WD Models)" or AT-19,
"Cross-Sectional View (AWD Models)" ) AT- 2 9 0
10. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-18,
"Cross-Sectional View (2WD Models)" or AT- 1 9 , "Cross-
Sectional View (AWD Models)" ) AT- 2 9 0
No. Items Symptom Condition Diagnostic Item
Reference
page

TROUBLE DIAGNOSIS AT-71
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2005 July 2005 FX
21
Slips/Will
Not
Engage When “D” or “M” posi-
tion, remains in 4th
gear. ON vehicle 1. A/T fluid level and state
AT- 5 2
2. Vehicle speed sensor A/T and vehicle speed sensor MTR AT- 11 8,
AT-143
3. ATF pressure switch 3 and input clutch solenoid valve AT-177,
AT-150
4. ATF pressure switch 5 and direct clutch solenoid valve AT-179,
AT-158
5. ATF pressure switch 6, high and low reverse clutch sole-
noid valve AT-181,
AT-162
6. Low coast brake solenoid valve AT-166
7. Front brake solenoid valveAT-154
8. Line pressure test AT- 5 4
9. CAN communication lineAT-106
10. Control valve with TCMAT-243
OFF vehicle 11. Input clutch
AT-31312. Gear systemAT-278
13. High and low reverse clutchAT-323
14. Direct clutchAT-326
22 When “D” or “M” posi-
tion, remains in 5th
gear. ON vehicle 1. A/T fluid level and state
AT- 5 2
2. Vehicle speed sensor A/T and vehicle speed sensor MTR AT- 11 8,
AT-143

3. ATF pressure switch 1 and front brake solenoid valve AT-175
,
AT-154
4. Line pressure test AT- 5 4
5. CAN communication lineAT-106
6. Control valve with TCMAT-243
OFF vehicle 7. Front brake (brake band)
AT-2908. Input clutchAT-313
9. Gear systemAT-278
10. High and low reverse clutchAT-323
No. Items Symptom Condition Diagnostic Item Reference
page

AT-72
TROUBLE DIAGNOSIS
Revision: 2005 July 2005 FX
23
Slips/Will
Not
Engage Vehicle cannot be
started from D
1 .
Refer to AT-205,
"Vehicle Cannot Be
Started from D1" . ON vehicle
1. A/T fluid level and state
AT- 5 2
2. Accelerator pedal position sensorAT- 1 3 3
3. Line pressure test AT- 5 4
4. CAN communication lineAT- 1 0 6
5. Control valve with TCMAT- 2 4 3
OFF vehicle 6. Torque converter
AT- 2 9 0
7. Oil pump assemblyAT- 3 0 8
8. 3rd one-way clutch AT- 3 11
9. 1st one-way clutch AT- 3 1 8
10. Gear systemAT- 2 7 8
11. Reverse brakeAT- 2 9 0
12. Forward one-way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT-18, "
Cross-Sectional View (2WD Models)" or AT-19,
"Cross-Sectional View (AWD Models)" ) AT- 2 9 0
13. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-18,
"Cross-Sectional View (2WD Models)" or AT- 1 9 , "Cross-
Sectional View (AWD Models)" ) AT- 2 9 0
24Does not lock-up.
Refer to AT-217, "A/T
Does Not Perform
Lock-up" . ON vehicle 1. A/T fluid level and state
AT- 5 2
2. Line pressure testAT- 5 4
3. Engine speed signalAT- 1 2 3
4. Turbine revolution sensorAT- 1 4 1
5. Torque converter clutch solenoid valveAT- 1 2 5
6. CAN communication lineAT- 1 0 6
7. Control valve with TCMAT- 2 4 3
OFF vehicle 8. Torque converter
AT- 2 9 09. Oil pump assemblyAT- 3 0 8
25 Does not hold lock-up
condition.
Refer to AT-219, "A/T
Does Not Hold Lock-
up Condition" . ON vehicle 1. A/T fluid level and state
AT- 5 2
2. Line pressure testAT- 5 4
3. Engine speed signalAT- 1 2 3
4. Turbine revolution sensorAT- 1 4 1
5. Torque converter clutch solenoid valveAT- 1 2 5
6. CAN communication lineAT- 1 0 6
7. Control valve with TCMAT- 2 4 3
OFF vehicle 8. Torque converter
AT- 2 9 09. Oil pump assemblyAT- 3 0 8
No. Items Symptom Condition Diagnostic Item Reference
page

TROUBLE DIAGNOSIS AT-73
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2005 July 2005 FX26
Slips/Will
Not
Engage Lock-up is not
released.
Refer to AT-221,
"Lock-up Is Not
Released" . ON vehicle 1. A/T fluid level and state
AT- 5 2
2. Line pressure testAT- 5 4
3. Engine speed signalAT-123
4. Turbine revolution sensorAT-141
5. Torque converter clutch solenoid valveAT-125
6. CAN communication lineAT-106
7. Control valve with TCMAT-243
OFF vehicle 8. Torque converter
AT-2909. Oil pump assemblyAT-308
27 No shock at all or the
clutch slips when
vehicle changes
speed D
1 → D2 or
M
1 → M2 . ON vehicle
1. A/T fluid level and state
AT- 5 2
2. Vehicle speed sensor A/T and vehicle speed sensor MTR AT- 11 8,
AT-143
3. ATF pressure switch 5 and direct clutch solenoid valve AT-179,
AT-158
4. CAN communication line AT-106
5. Line pressure test AT- 5 4
6. Control valve with TCMAT-243
OFF vehicle 7. Torque converter
AT-290
8. Oil pump assemblyAT-308
9. 3rd one-way clutch AT- 3 11
10. Gear systemAT-278
11. Direct clutchAT-326
12. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-18,
"Cross-Sectional View (2WD Models)" or AT-19, "Cross-
Sectional View (AWD Models)" ) AT-290
No. Items Symptom Condition Diagnostic Item
Reference
page

AT-74
TROUBLE DIAGNOSIS
Revision: 2005 July 2005 FX
28
Slips/Will
Not
Engage No shock at all or the
clutch slips when
vehicle changes
speed D
2 → D3 or
M
2 → M3 . ON vehicle
1. A/T fluid level and state
AT- 5 2
2. Vehicle speed sensor A/T and vehicle speed sensor MTR AT- 11 8,
AT- 1 4 3
3. ATF pressure switch 6, high and low reverse clutch sole-
noid valve AT- 1 8 1,
AT- 1 6 2
4. CAN communication line AT- 1 0 6
5. Line pressure test AT- 5 4
6. Control valve with TCMAT- 2 4 3
OFF vehicle 7. Torque converter
AT- 2 9 0
8. Oil pump assemblyAT- 3 0 8
9. 3rd one-way clutch AT- 3 11
10. Gear systemAT- 2 7 8
11. High and low reverse clutchAT- 3 2 3
12. Forward one-way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT-18, "
Cross-Sectional View (2WD Models)" or AT-19,
"Cross-Sectional View (AWD Models)" ) AT- 2 9 0
13. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-18,
"Cross-Sectional View (2WD Models)" or AT- 1 9 , "Cross-
Sectional View (AWD Models)" ) AT- 2 9 0
29 No shock at all or the
clutch slips when
vehicle changes
speed D
3 → D4 or
M
3 → M4 . ON vehicle
1. A/T fluid level and state
AT- 5 2
2. Vehicle speed sensor A/T and vehicle speed sensor MTR AT- 11 8,
AT- 1 4 3
3. ATF pressure switch 3 and input clutch solenoid valve AT- 1 7 7,
AT- 1 5 0

4. ATF pressure switch 1 and front brake solenoid valve AT- 1 7 5
,
AT- 1 5 4
5. CAN communication line AT- 1 0 6
6. Line pressure test AT- 5 4
7. Control valve with TCMAT- 2 4 3
OFF vehicle 8. Torque converter
AT- 2 9 0
9. Oil pump assemblyAT- 3 0 8
10. Input clutchAT- 3 1 3
11. Gear systemAT- 2 7 8
12. High and low reverse clutchAT- 3 2 3
13. Direct clutchAT- 3 2 6
No. Items Symptom Condition Diagnostic Item Reference
page

TROUBLE DIAGNOSIS AT-75
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2005 July 2005 FX
30
Slips/Will
Not
Engage No shock at all or the
clutch slips when
vehicle changes
speed D
4 → D5 or
M
4 → M5 . ON vehicle
1. A/T fluid level and state
AT- 5 2
2. Vehicle speed sensor A/T and vehicle speed sensor MTR AT- 11 8,
AT-143
3. ATF pressure switch 1 and front brake solenoid valve AT-175,
AT-154
4. ATF pressure switch 5 and direct clutch solenoid valve AT-179,
AT-158
5. CAN communication line AT-106
6. Line pressure test AT- 5 4
7. Control valve with TCMAT-243
OFF vehicle 8. Torque converter
AT-290
9. Oil pump assemblyAT-308
10. Front brake (brake band)AT-290
11. Input clutchAT-313
12. Gear systemAT-278
13. High and low reverse clutchAT-323
31 When you press the
accelerator pedal and
shift speed D5 → D4
or M
5 → M4 the
engine idles or the
transmission slips. ON vehicle
1. A/T fluid level and state
AT- 5 2
2. Vehicle speed sensor A/T and vehicle speed sensor MTR AT- 11 8,
AT-143
3. ATF pressure switch 1 and front brake solenoid valve AT-175,
AT-154
4. ATF pressure switch 5 and direct clutch solenoid valve AT-179,
AT-158
5. CAN communication line AT-106
6. Line pressure test AT- 5 4
7. Control valve with TCMAT-243
OFF vehicle 8. Torque converter
AT-290
9. Oil pump assemblyAT-308
10. Input clutchAT-313
11. Gear systemAT-278
12. High and low reverse clutchAT-323
13. Direct clutchAT-326
No. Items Symptom Condition Diagnostic Item Reference
page

AT-76
TROUBLE DIAGNOSIS
Revision: 2005 July 2005 FX
32
Slips/Will
Not
Engage When pressing the
accelerator pedal and
shifting speed D4 →
D
3 or M4 → M3 the
engine idles or the
transmission slips. ON vehicle
1. A/T fluid level and state
AT- 5 2
2. Vehicle speed sensor A/T and vehicle speed sensor MTR AT- 11 8,
AT- 1 4 3
3. ATF pressure switch 3 and input clutch solenoid valve AT- 1 7 7,
AT- 1 5 0
4. ATF pressure switch 1 and front brake solenoid valve AT- 1 7 5,
AT- 1 5 4
5. CAN communication line AT- 1 0 6
6. Line pressure test AT- 5 4
7. Control valve with TCMAT- 2 4 3
OFF vehicle 8. Torque converter
AT- 2 9 0
9. Oil pump assemblyAT- 3 0 8
10. 3rd one-way clutch AT- 3 11
11. Gear systemAT- 2 7 8
12. High and low reverse clutchAT- 3 2 3
13. Forward one-way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT-18, "
Cross-Sectional View (2WD Models)" or AT-19,
"Cross-Sectional View (AWD Models)" ) AT- 2 9 0
14. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-18,
"Cross-Sectional View (2WD Models)" or AT- 1 9 , "Cross-
Sectional View (AWD Models)" ) AT- 2 9 0
33 When pressing the
accelerator pedal and
shifting speed D3 →
D
2 or M3 → M2 the
engine idles or the
transmission slips. ON vehicle
1. A/T fluid level and state
AT- 5 2
2. Vehicle speed sensor A/T and vehicle speed sensor MTR AT- 11 8,
AT- 1 4 3
3. ATF pressure switch 6, high and low reverse clutch sole-
noid valve AT- 1 8 1,
AT- 1 6 2
4. ATF pressure switch 5 and direct clutch solenoid valve AT- 1 7 9,
AT- 1 5 8
5. CAN communication line AT- 1 0 6
6. Line pressure test AT- 5 4
7. Control valve with TCMAT- 2 4 3
OFF vehicle 8. Torque converter
AT- 2 9 0
9. Oil pump assemblyAT- 3 0 8
10. 3rd one-way clutch AT- 3 11
11. Gear systemAT- 2 7 8
12. Direct clutchAT- 3 2 6
13. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-18,
"Cross-Sectional View (2WD Models)" or AT- 1 9 , "Cross-
Sectional View (AWD Models)" ) AT- 2 9 0
No. Items Symptom Condition Diagnostic Item
Reference
page

TROUBLE DIAGNOSIS AT-77
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2005 July 2005 FX
34
Slips/Will
Not
Engage When pressing the
accelerator pedal and
shifting speed D2 →
D
1 or M2 → M1 the
engine idles or the
transmission slips. ON vehicle
1. A/T fluid level and state
AT- 5 2
2. Vehicle speed sensor A/T and vehicle speed sensor MTR AT- 11 8,
AT-143
3. ATF pressure switch 5 and direct clutch solenoid valve AT-179,
AT-158
4. CAN communication line AT-106
5. Line pressure test AT- 5 4
6. Control valve with TCMAT-243
OFF vehicle 7. Torque converter
AT-290
8. Oil pump assemblyAT-308
9. 3rd one-way clutch AT- 3 11
10. 1st one-way clutchAT-318
11. Gear systemAT-278
12. Reverse brakeAT-290
13. Forward one-way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT- 1 8 , "
Cross-Sectional View (2WD Models)" or AT- 1 9 ,
"Cross-Sectional View (AWD Models)" ) AT-290
14. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-18,
"Cross-Sectional View (2WD Models)" or AT-19, "Cross-
Sectional View (AWD Models)" ) AT-290
35
With selector lever in
“D” position, accelera-
tion is extremely poor. ON vehicle
1. A/T fluid level and state
AT- 5 2
2. Line pressure testAT- 5 4
3. Accelerator pedal position sensorAT-133
4. CAN communication lineAT-106
5. PNP switch AT- 11 4
6. Control linkage adjustmentAT-235
7. Control valve with TCMAT-243
OFF vehicle 8. Torque converter
AT-290
9. Oil pump assemblyAT-308
10. 1st one-way clutchAT-318
11. Gear systemAT-278
12. Reverse brakeAT-290
13. Forward one-way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT- 1 8 , "
Cross-Sectional View (2WD Models)" or AT- 1 9 ,
"Cross-Sectional View (AWD Models)" ) AT-290
14. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-18,
"Cross-Sectional View (2WD Models)" or AT-19, "Cross-
Sectional View (AWD Models)" ) AT-290
No. Items Symptom Condition Diagnostic Item
Reference
page

AT-78
TROUBLE DIAGNOSIS
Revision: 2005 July 2005 FX
36
Slips/Will
Not
Engage With selector lever in
“R” position, accelera-
tion is extremely poor. ON vehicle 1. A/T fluid level and state
AT- 5 2
2. Line pressure testAT- 5 4
3. Accelerator pedal position sensorAT- 1 3 3
4. ATF pressure switch 6, high and low reverse clutch sole-
noid valve AT- 1 8 1,
AT- 1 6 2
5. CAN communication line AT- 1 0 6
6. PNP switch AT- 11 4
7. Control linkage adjustmentAT- 2 3 5
8. Control valve with TCMAT- 2 4 3
OFF vehicle 9. Gear system
AT- 2 7 810. Output shaft AT- 2 9 0
11. Reverse brakeAT- 2 9 0
37 While starting off by
accelerating in 1st,
engine races or slip-
page occurs. ON vehicle
1. A/T fluid level and state
AT- 5 2
2. Line pressure testAT- 5 4
3. Accelerator pedal position sensorAT- 1 3 3
4. CAN communication lineAT- 1 0 6
5. Control valve with TCMAT- 2 4 3
OFF vehicle 6. Torque converter
AT- 2 9 0
7. Oil pump assemblyAT- 3 0 8
8. 3rd one-way clutch AT- 3 11
9. 1st one-way clutchAT- 3 1 8
10. Gear systemAT- 2 7 8
11. Reverse brakeAT- 2 9 0
12. Forward one-way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT-18, "
Cross-Sectional View (2WD Models)" or AT-19,
"Cross-Sectional View (AWD Models)" ) AT- 2 9 0
13. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-18,
"Cross-Sectional View (2WD Models)" or AT- 1 9 , "Cross-
Sectional View (AWD Models)" ) AT- 2 9 0
No. Items Symptom Condition Diagnostic Item
Reference
page
