Page 3291 of 4731
GW-14
BACK DOOR WINDOW GLASS
Revision: 2005 July 2005 FX
CAUTION:
Be careful not to scratch the glass when removing.
Do not set or stand the glass on its edge. Small chips may develop into cracks.
4. Remove the back door window glass, using suction liter.
INSTALLATION
Use a genuine Nissan Urethane Adhesive Kit (if available) or equivalent and follow the instructions fur-
nished with it.
While the urethane adhesive is curing, open a door window. This will prevent the glass from being forced
out by passenger room air pressure when a door is closed.
The molding must be installed securely so that it is in position and leaves no gap.
Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely
cured (preferably 24 hours). Curing time varies with temperature and humidity.
WARNING:
Keep heat and open flames away as primers and adhesive are flammable.
The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Avoid
contact with the skin and eyes.
Use in an open, well ventilated location. Avoid breathing the vapors. They can be harmful if
inhaled. If affected by vapor inhalation, immediately move to an area with fresh air.
Driving the vehicle before the urethane adhesive has completely cured may affect the perfor-
mance of the back door window glass in case of an accident.
CAUTION:
Do not use an adhesive which is past its usable term. Shelf life of this product is limited to six
months after the date of manufacture. Carefully adhere to the expiration or manufacture date
printed on the box.
Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator.
Do not leave primers or adhesive cartridge unattended with their caps open or off.
The vehicle should not be driven for at least 24 hours or until the urethane adhesive has com-
pletely cured. Curing time varies depending on temperature and humidity. The curing time will
increase under lower temperature and lower humidity.
PIIB0908E
Page 3351 of 4731
GW-74
SIDE WINDOW GLASS
Revision: 2005 July 2005 FX
SIDE WINDOW GLASSPFP:83300
Removal and InstallationAIS003A5
REMOVAL
1. Remove the roof rear garnish. Refer to EI-43, "Removal and Installation" .
2. Remove the luggage side finisher. Refer to EI-43, "
Removal and Installation" .
3. Remove the rear pillar upper garnish. Refer to EI-43, "
Removal and Installation" .
4. Apply a protective tape around the side window glass to protect the painted surface from damage.
Remove side window glass using piano wire or power cutting tool and an inflatable pump bag.
WARNING:
When cutting the glass from the vehicle, always wear safety glasses and heavy gloves to help prevent
glass splinters from entering your eyes or cutting your hands.
CAUTION:
Be careful not to scratch the glass when removing.
PIIA9192E
1. Side window glass molding (upper) 2. Side window glass 3. Clip
4. Side window glass molding (lower) 5. Fastener 6. Adhesive
7. Body side outer panel 8. Side window glass molding (pillar) 9. Dam rubber
Page 3395 of 4731
IDX-2
ALPHABETICAL INDEX
A
A/C air flow ...................................................... ATC-37
A/C component layout ..................................... ATC-26
A/C compressor clutch removal and installation ...........
ATC-144
A/C compressor mounting ........... ATC-141, ATC-144,
ATC-148
, ATC-149, ATC-150, ATC-151, ATC-152,
ATC-154
, ATC-155, ATC-156, ATC-157
A/C compressor precaution ............................. ATC-13
A/C compressor special service tool ................ ATC-17
A/C control operation (auto A/C) ...................... ATC-34
A/C diagnostic work flow (auto A/C) .............. ATC-102
A/C evaporator ............................................... ATC-156
A/C HFC134a (R134a) system precaution ........ ATC-6
A/C HFC134a (R134a) system service procedure .......
ATC-138
A/C HFC134a (R134a) system service tools ... ATC-18
A/C HFC134a system service equipment precaution ...
ATC-13
A/C lubricant (R134a) ...................................... ATC-27
A/C lubrication oil ........................................... ATC-162
A/C operational check ...................................... ATC-61
A/C self-diagnoses (auto A/C) ........ ATC-53, ATC-102
A/C service data specification ........................ ATC-162
A/C system description (auto A/C) ................... ATC-30
A/C trouble diagnoses (auto A/C) .................... ATC-40
A/C, A - Wiring diagram ................................... ATC-46
A/T fluid checking ...................... AT-13, AT-52, MA-29
A/T fluid cooler cleaning .................................... AT-15
A/T fluid replacement ............................. AT-12, MA-31
A/T fluid temperature sensor ........................... AT-136
A/T IND - Wiring diagram .................................... DI-54
A/T self-diagnoses ........................................... AT-103
A/T shift lock system ........................................ AT-236
A/T shift lock system - Wiring diagram ............ AT-237
A/T trouble diagnoses ........................................ AT-43
A/T Wiring diagram AT - CAN .......................... AT-107
A/T Wiring diagram AT - FTS .......................... AT-137
A/T Wiring diagram AT - MAIN ........................ AT-183
A/T Wiring diagram AT - MMSW ..................... AT-171
A/T Wiring diagram AT - NONDTC .................. AT-190
A/T Wiring diagram AT - PNP/SW ................... AT-115
A/T Wiring diagram AT - STSIG ...................... AT-110
A/T Wiring diagram AT - VSS A/T ................... AT-120
Accelerator pedal position (APP) sensor ........ EC-619,
EC-626
, EC-640, EC-1302, EC-1309, EC-1323
Accelerator pedal released position learning .... EC-96,
EC-786
AF1B1-Wiring diagram ...... EC-490, EC-499, EC-508,
EC-518
, EC-529, EC-539, EC-551
AF1B2-Wiring diagram ...... EC-492, EC-501, EC-510,
EC-520
, EC-531, EC-541, EC-553
AF1HB1-Wiring diagram .................................. EC-407
AF1HB2-Wiring diagram .................................. EC-409
Air bag .............................................................. SRS-3
Air bag precautions ........................................... SRS-3
Air cleaner and air duct(VK45DE) ................... EM-176
Air cleaner and air duct(VQ35DE) .................... EM-17
Air cleaner filter replacement ............................ MA-25
Air cleaner filter replacement(VQ35DE) ............ MA-18
Air cleaner filter(VQ35DE) ................................ EM-18
Air conditioner cut control ................... EC-35, EC-726
Air flow meter - See Mass air flow sensor ....... EC-186,
EC-195
, EC-893, EC-902
Air fuel ratio sensor 1 ......... EC-488, EC-497, EC-506,
EC-516
, EC-526, EC-536, EC-548
Air fuel ratio sensor 1 heater ............................ EC-405
Air mix. door motor ......................... ATC-73, ATC-132
Ambient sensor ............................. ATC-104, ATC-117
Angular tightening application ............................. EM-6
Angular tightening application(VK45DE) ........ EM-164
APPS1 - Wiring diagram ................. EC-621, EC-1304
APPS2 - Wiring diagram ................. EC-628, EC-1311
APPS3 - Wiring diagram ................. EC-642, EC-1325
ASC/BS - Wiring diagram ............... EC-599, EC-1273
ASC/SW - Wiring diagram .............. EC-583, EC-1256
ASCBOF - Wiring diagram .............. EC-689, EC-1379
ASCD .................................................. EC-36, EC-727
ASCD (automatic speed control device) ........... ACS-3
ASCIND - Wiring diagram ............... EC-696, EC-1386
Ashtray illumination .......................................... LT-157
AT indicator lamp ................................................ DI-54
Auto air conditioner - Wiring diagram ............. ATC-46
Auto amp ...................................................... ATC-116
Auto anti-dazzling inside mirror ....................... GW-84
Automatic amplifier ........... ATC-51, ATC-63, ATC-116
Automatic transmission fluid replacement ........ MA-32
AV and NAVI control unit ................................... AV-89
AV communication line .................................... AV-114
AWD - Wiring diagram ....................................... TF-17
Axle ................................................................... MA-37
Axle housing (rear) ........................................... RAX-7
B
Back Door ........................................................ BL-164
Back door ......................................................... BL-164
Back door opener - See Back door .................. BL-168
BACK/L - Wiring diagram ................................. LT-127
Back-up lamp ................................................... LT-127
Basic inspection ............................................... EC-769
Battery ................................................................. SC-4
Battery/Starting/Charging System Tester SC-6, SC-13,
SC-26
BCM (Body control module) .............................. BCS-3
Block heater(VK45DE) .................................... EM-245
Block heater(VQ35DE) ................................... EM-122
Blower motor ................................... ATC-79, ATC-123
Blower unit .................................................... ATC-121
Board computer ................................................. AV-58
Brake booster .................................................... BR-15
Brake fluid level ................................................ MA-35
Brake hydraulic line ........................................... BR-11
Brake inspection ............................................... MA-36
Brake lines and cables inspection .................... MA-35
Brake master cylinder ........................................ BR-13
Brake switch ................................... EC-614, EC-1297
