INFINITI FX35 2005 Service Manual

SE-28
AUTOMATIC DRIVE POSITIONER
Revision: 2005 July 2005 FX
TIWM0319E

AUTOMATIC DRIVE POSITIONER SE-29
C
D E
F
G H
J
K L
M A
B
SE
Revision: 2005 July 2005 FX
TIWM0320E

SE-30
AUTOMATIC DRIVE POSITIONER
Revision: 2005 July 2005 FX
Terminals and Reference Values for BCMAIS002XG
Terminals and Reference Values for Automatic Drive Positioner Control UnitAIS002XH
TERMINAL WIRE
COLOR ITEM CONDITION
VOLTAGE (V)
(Approx.)
11 LG/R Ignition switch (ACC) Ignition switch
(ACC or ON position) Battery voltage
37 B/W Key switch signal Key switch ON (key is inserted in
ignition key cylinder) Battery voltage
Key switch OFF (key is removed
from ignition key cylinder) 0
38 W/L Ignition switch (ON) Ignition switch
(ON or START position) Battery voltage
39 L CAN-H — —
40 R CAN-L — —
42 L/R Power source (Fuse) — Battery voltage
49 B Ground (signal) — 0
52 B Ground (power) — 0
55 G Power supply (Fusible link) — Battery voltage
62 W Front door switch (driver side) ON (Open) → OFF (Closed) 0 → Battery voltage
TERMI-
NAL WIRE
COLOR ITEM CONDITION VOLTAGE (V)
(Approx.)
1 LG/R Tilt switch UP signal Tilt switch turned to upward 0
Other than above 5
2 G/W Changeover switch RH signal When changeover switch in RH posi-
tion 0
Other than above 5
3 GY Mirror switch UP signal When mirror switch in turned to
upward position 0
Other than above 5
4 Y Mirror switch LEFT signal When mirror switch in turned to left-
ward position 0
Other than above 5
5OR Passenger side mirror sensor
(vertical) signal When passenger side mirror motor is
UP or DOWN operation Changes between 3 (close to perk)
- 1 (close to valley)
6P/L Driver side mirror sensor
(vertical) signal When driver side mirror motor is UP
or DOWN operation Changes between 3 (close to perk)
- 1 (close to valley)
7 Y/R Tilt sensor signal Tilt position, top 2
Tilt position, bottom 4
10 B UART LINE (TX) Memory switch 1 or 2 operated
11 B R Telescopic switch
FORWARD signal Telescopic switch turned to forward 0
Other than above 5
PIIA4813E

AUTOMATIC DRIVE POSITIONER SE-31
C
D E
F
G H
J
K L
M A
B
SE
Revision: 2005 July 2005 FX
14 L/W Passenger side mirror motor
UP signal When passenger side mirror motor
UP operation 1.5 - Battery voltage
Other than above 0
15 L/B Passenger side mirror motor
LEFT signal When passenger side mirror motor
LEFT operation 1.5 - Battery voltage
Other than above 0
16 P Driver side mirror motor
DOWN signal When driver side mirror motor DOWN
operation 1.5 - Battery voltage
Other than above 0
Driver side mirror motor
RIGTH signal When driver side mirror motor RIGHT
operation 1.5 - Battery voltage
Other than above 0
17 R/B Tilt switch DOWN signal Tilt switch turned to downward 0
Other than above 5
18 L/OR Changeover switch LH signal When changeover switch in LH posi-
tion 0
Other than above 5
19 GY/L Mirror switch DOWN signal When mirror switch in turned to down-
ward position 0
Other than above 5
20 PU Mirror switch RIGHT signal When mirror switch in turned to right-
ward position 0
Other than above 5
21 G/Y Passenger side mirror sensor
(horizontal) signal When passenger side mirror motor is
LEFT or RIGHT operation Changes between 1 (close to left
edge) - 3 (close to right edge)
22 L/Y Driver side mirror sensor
(horizontal) signal When driver side mirror motor is LEFT
or RIGHT operation Changes between 1 (close to right
edge) - 3 (close to left edge)
23 Y/B Telescopic sensor input Telescopic position, top 1
Telescopic position, bottom 4
26 W UART LINE (RX) Memory switch 1 or 2 operated
27 LG Telescopic switch
BACKWARD signal Telescopic switch turned to backward 0
Other than above 5
28 SB Ignition switch (START) Ignition switch
(START position) Battery voltage
30 W/R Passenger side mirror motor
DOWN signal When passenger side mirror motor
downward 1.5 - Battery voltage
Other than above 0
Passenger side mirror motor
RIGTH signal When passenger side mirror motor
RIGHT operation 1.5 - Battery voltage
Other than above 0
31 R/W Driver side mirror motor
UP signal When driver side mirror motor upward 1.5 - Battery voltage
Other than above 0
TERMI-
NAL WIRE
COLOR ITEM CONDITION VOLTAGE (V)
(Approx.)
PIIA4814E

SE-32
AUTOMATIC DRIVE POSITIONER
Revision: 2005 July 2005 FX
Terminals and Reference Values for Driver Seat Control UnitAIS002XI
32 G/B Driver side mirror motor
LEFT signal When driver side mirror motor LEFT
operation 1.5 - Battery voltage
Other than above 0
33 G/W Sensor power supply — 5
34 L/R Battery power supply — Battery voltage
35 R/L Tilt motor UP signal Tilt switch turned to upward Battery voltage
Other than above 0
36 L/R Telescopic motor
FORWARD signal Telescopic switch turned to forward Battery voltage
OFF 0
39 W/R Battery power supply — Battery voltage
40 B Ground (signal) — 0
41 B/Y Sensor ground — 0
42 R/B Tilt motor DOWN signal Tilt switch turned to downward Battery voltage
Other than above 0
44 L/W Telescopic motor
BACKWARD signal Telescopic switch turned to backward Battery voltage
Other than above 0
48 B Ground (power) — 0
TERMI-
NAL WIRE
COLOR ITEM CONDITION VOLTAGE (V)
(Approx.)
TERMI-NAL WIRE
COLOR ITEM CONDITION VOLTAGE (V)
(Approx.)
1A R Power source (Fusible link) — Battery voltage
2 P UART LINE (TX) Memory switch 1 or 2 operated
3G Sliding motor
FORWARD signal When sliding motor
FORWARD operation Battery voltage
Other than above 0
4 G/L Reclining motor
FORWARD signal When reclining motor
FORWARD operation Battery voltage
Other than above 0
5LG Front lifting motor
DOWN signal When front lifting motor
DOWN operation Battery voltage
Other than above 0
6 G/W Rear lifting motor
UP signal When rear lifting motor
UP operation Battery voltage
Other than above 0
7 G/B Rear lifting motor
DOWN signal When rear lifting motor
DOWN operation Battery voltage
Other than above 0
PIIA4814E

AUTOMATIC DRIVE POSITIONER SE-33
C
D E
F
G H
J
K L
M A
B
SE
Revision: 2005 July 2005 FX
8 G/Y UART LINE (RX) Memory switch 1 or 2 switch operated
9 BR Ignition switch (START) Ignition switch
(START position) Battery voltage
10 G/R Sliding motor
BACKWARD signal When sliding motor
BACKWARD operation Battery voltage
Other than above 0
11A R/W Power source (Fuse) — Battery voltage
12 G/Y Reclining motor
BACKWARD signal When reclining motor
BACKWARD operation Battery voltage
Other than above 0
13 Y Front lifting motor
UP output signal When front lifting motor
UP operation Battery voltage
Other than above 0
14 OR CAN-H — —
15 SB CAN-L — —
16A B Ground (power) — 0
17 PU Detention switch signal Selector lever other than P position Battery voltage
Selector lever is sifted to P position 0
18 G Seat sliding sensor signal ON (sliding motor operation)
Other than above 0 or 5
19 G/Y Front lifting sensor signal ON (front lifting motor operation)
Other than above 0 or 5
22 L/G Power seat memory switch
1 signal Memory switch 1: ON 0
Memory switch 1: OFF 5
23 Y/W Power seat memory switch
indictor 1 signal Memory switch 1: ON 1
Memory switch 1: OFF Battery voltage
24 L/R Seat sliding switch
FORWARD signal When seat sliding switch
FORWARD operation 0
Other than above Battery voltage
TERMI-
NAL WIRE
COLOR ITEM CONDITION VOLTAGE (V)
(Approx.)
PIIA4813E
PIIA3277E
SIIA0691J

SE-34
AUTOMATIC DRIVE POSITIONER
Revision: 2005 July 2005 FX
25 L/OR Seat reclining switch
FORWARD signal When seat reclining switch
FORWARD operation 0
Other than above Battery voltage
26 L/P Front lifting switch UP signal When front lifting switch
UP operation 0
Other than above Battery voltage
27 L Rear lifting switch UP signal When rear lifting switch
UP operation 0
Other than above Battery voltage
28C B/W Sensor ground — 0
29 G/L Reclining sensor signal ON (reclining motor operation)
Other than above 0 or 5
30 G/W Rear lifting sensor signal ON (rear lifting motor operation)
Other than above 0 or 5
34 L/W Set switch signal Set witch: ON 0
Set witch: OFF 5
35 L/B Power seat memory switch
2 signal Memory switch 2: ON 0
Memory switch 2: OFF 5
36 Y/G Power seat memory switch
indictor 2 signal Memory switch 2: ON 1
Memory switch 2: OFF Battery voltage
37 L/P Seat sliding switch
BACKWARD signal When seat sliding switch
BACKWARD operation 0
Other than above Battery voltage
38 LG/B Seat reclining switch
BACKWARD signal When seat reclining switch
BACKWARD operation 0
Other than above Battery voltage
39 L/G Front lifting switch
DOWN signal When front lifting switch
DOWN operation 0
Other than above Battery voltage
40 L/Y Rear lifting switch
DOWN signal When rear lifting switch
DOWN operation 0
Other than above Battery voltage
61E B/Y Ground (signal) — 0
TERMI-
NAL WIRE
COLOR ITEM CONDITION VOLTAGE (V)
(Approx.)
SIIA0692J
SIIA0693J

AUTOMATIC DRIVE POSITIONER SE-35
C
D E
F
G H
J
K L
M A
B
SE
Revision: 2005 July 2005 FX
Work Flow AIS002XJ
1. Check the symptom and customer's requests.
2. Understand the system description. Refer to SE-11, "
System Description" .
3. Perform the preliminary check, refer to SE-35, "
Preliminary Check" .
4. Perform the CAN communication inspection using CONSULT-II, refer to SE-38, "
CONSULT-II Function
(AUTO DRIVE POS.)" .
5. Perform the self-diagnosis. Refer to SE-42, "
Check CAN Communication System Inspection" .
6. Repair or replace depending on the self-diagnostic results.
7. Based on the trouble diagnosis chart, repair or replace the cause of the malfunction. Refer to SE-42,
"Symptom Chart" .
8. Does the automatic drive positioner system operate normally? If it is normal, GO TO 8.
If it is not normal, GO TO 3.
9. INSPECTION END
Preliminary CheckAIS002XK
SETTING CHANGE FUNCTION
The settings of the automatic driving positioner system can be changed, using CONSULT-II and the display
unit in the center of the instrument panel.
× : Applicable –: Not applicable
It is possible to set sliding driver seat for entry/exit of vehicle by pressing set switch.
NOTE:
After the setting is registered, the new setting is effective, even if the battery is disconnected.
Setting item Content CONSULT–II
(WORK SUPPORT) Display unitFactory
setting
Change seat sliding volume
setting The distance at retain operation
can be selected from the following
3 modes. 40 mm
— ×
80 mm —
150 mm —
Change the Entry/Exit seat
slide function setting The seat sliding turnout and return
at entry/exit can be selected: ON
(operated) – OFF (not operated) ON ON: Indicator lamp ON
×
OFF OFF: Indicator lamp OFF —
Change the Entry/Exit tilt
steering wheel function setting Lift up and backward steering
wheel at entry and exit can be
selected: ON (operated) - OFF (not
operated) ON ON: Indicator lamp ON
×
OFF OFF: Indicator lamp OFF —
Reset custom settings All settings to default. — Default: Setting button
OFF —
Content Setting change operation Indicator LED
The seat sliding turnout and
steering wheel up/backward at
entry/exit can be operated. Press the set switch for more than 10 seconds Blinking twice
The seat sliding turnout and
steering wheel up/backward at
entry/exit can be not operated. Blinking ones

SE-36
AUTOMATIC DRIVE POSITIONER
Revision: 2005 July 2005 FX
CHECK POWER SUPPLY AND GROUND
1. CHECK FUSE
Check if any of the following fuses in the BCM are blown.

Check 50A fusible link (letter M , located in the fuse and fusible link box.)

Check 15A fuse [No.22, located in the fuse block (J/B)]

Check 10A fuse [No.1, located in the fuse block (J/B)]

Check 10A fuse [No.6, located in the fuse block (J/B)]
NOTE:
Refer to SE-15, "
Component Parts and Harness Connector Location" .
OK or NG
OK >> GO TO 2.
NG >> If fuse is blown out, be sure to eliminate cause of malfunction before installing new fuse. Refer to
SE-15, "
Component Parts and Harness Connector Location" .
2. CHECK POWER SUPPLY CIRCUIT (BCM)
1. Turn ignition switch OFF.
2. Disconnect BCM connector.
3. Check voltage between BCM connector and ground.
OK or NG
OK >> GO TO 3.
NG >> Check harness for open and short between BCM and fuse or fusible link.
3. CHECK GROUND CIRCUIT (BCM)
1. Turn ignition switch OFF.
2. Check continuity between BCM connector B14 terminal 49, 52 and ground.
OK or NG
OK >> BCM circuit is OK. Check the driver seat control unit. GO TO 4.
NG >> Repair or replace the harness between BCM and ground.
Connector Terminals (Wire color)
Ignition
switch Voltage (V)
(Approx.)
(+) (–)
M3 11 (LG/R)
Ground ACC
Battery voltage
38 (W/L) ON
B14 42 (L/R)
OFF
55 (G)
PIIA5083E
49 (B) – Ground : Continuity should exist.
52 (B) – Ground : Continuity should exist.
PIIA5084E

AUTOMATIC DRIVE POSITIONER SE-37
C
D E
F
G H
J
K L
M A
B
SE
Revision: 2005 July 2005 FX
4. CHECK FUSE

Check 10A fuse [No.9, located in fuse block (J/B)].
NOTE:
Refer to SE-15, "
Component Parts and Harness Connector Location" .
OK or NG
OK >> GO TO 5.
NG >> If fuse is blown out, be sure to eliminate cause of malfunction before installing new fuse. Refer to
SE-15, "
Component Parts and Harness Connector Location" .
5. CHECK POWER SUPPLY CIRCUIT (DRIVER SEAT CONTROL UNIT)
1. Disconnect driver seat control unit connector.
2. Check voltage between driver seat control unit and ground.
OK or NG
OK >> GO TO 6.
NG >> Repair or replace harness between driver seat control
unit and fuse block (J/B).
6. CHECK GROUND CIRCUIT (DRIVER SEAT CONTROL UNIT)
1. Turn ignition switch OFF.
2. Check continuity between the driver seat control unit connector B152, B153 terminal16A, 61E and ground.
OK or NG
OK >> GO TO 7.
NG >> Repair or replace harness between driver seat control unit and ground.
7. CHECK POWER SUPPLY CIRCUIT (AUTOMATIC DRIVE POSITIONER CONTROL UNIT)
1. Disconnect automatic drive positioner control unit connector.
2. Check voltage between automatic drive positioner control unit and ground.
OK or NG
OK >> GO TO 8.
NG >> Repair or replace harness between automatic drive positioner control unit and fuse block (J/B).
Connector Terminals (Wire color)
Ignition
switch Voltage (V)
(Approx.)
(+) (–)
B152 9 (BR)
Ground START
Battery voltage
B153 1A (R)
OFF
11 A ( R / W )
PIIA5085E
16A (B) – Ground : Continuity should exist.
61E (B/Y) – Ground : Continuity should exist.
PIIA5087E
Connector Terminals (Wire color)
Ignition
switch Voltage (V)
(Approx.)
(+) (–)
M49 28 (SB) Ground START
Battery voltage
M50 34 (L/R)
M50 39 (W/R) OFF
PIIA5086E
