INFINITI FX35 2005 Workshop Manual

ACS-42
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2005 July 2005 FX
DTC 11 CONTROL UNITAKS00C8O
1. CHECK ICC UNIT SELF-DIAGNOSIS
1. Perform self-diagnosis.
2. Check if any item other than “DTC 11 CONTROL UNIT” is indicated on self-diagnosis display.
Is any indicated?
YES >> 1. Repair or replace applicable item. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NO >> 1. Replace ICC unit. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
90 STOP LAMP RLY FIX ×× ×
Normally open terminal of stop
lamp relay is stuck. ACS-53
92 ECM CIRCUIT
××××

ECM malfunction

Accelerator pedal position sensor
malfunction

ICC unit malfunction ACS-59
96 NP RANGE
×××

Park/neutral position switch har-
ness is open or shorted.

Park/neutral position switch mal-
function.

TCM malfunction ACS-60
97 AT CIRCUIT
×××
TCM malfunctionACS-61
98 GEAR POSITION ×××

TCM malfunction

AT turbine revolution sensor mal-
function

AT vehicle speed sensor malfunc-
tion ACS-61
102 RADAR STAIN
×× ×
ICC sensor body window has con-
tamination. ACS-62
103 LASER SENSOR FAIL
×× ×
ICC sensor internal malfunctionACS-63
104 LASER AIMING INCMP ×× ×
Laser beam aiming of ICC sensor
is not adjusted. ACS-63
107 LASER COMM FAIL
×× ×

CAN data received by ICC sensor
is strange (from ICC unit, combi-
nation meter or ECM). ACS-63
109 LASER HIGH TEMP
×× ×
Temperature around ICC sensor
is excessively high. ACS-64
DTC
No. CONSULT-II
screen terms ICC
system
warning
lamp Fail-safe
Malfunctions detected where... Refer-
ence
page
Vehicle-
to-
vehicle
distance control
mode Conven-
tional
(fixed
speed)
cruise
control mode Brake
assist (with
preview
function)

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS ACS-43
[ICC]
C
D E
F
G H
I
J
L
M A
B
ACS
Revision: 2005 July 2005 FX
DTC 20 CAN COMM CIRCUITAKS00C8P
1. CHECK CAN COMMUNICATION
With CONSULT-II
1. Perform self-diagnosis.
2. Print self-diagnostic result.
>> After printing self-diagnostic result, go to “CAN system”. Refer to LAN-5, "
Precautions When
Using CONSULT-II" .
DTC 31 POWER SUPPLY CIR, DTC 34 POWER SUPPLY CIR 2AKS00C8Q
1. CHECK CONNECTOR ICC UNIT
1. Turn ignition switch OFF.
2. Disconnect ICC unit connector, and connect it securely again.
3. Erase DTC and perform ICC running test. Then perform self-diagnosis of ICC system again.
Is malfunction indicated?
YES >> GO TO 2.
NO >> Poor connector connection
1. Check connector. (Check connector housing for disconnected, loose, bent, and collapsed ter- minals. If any malfunction is detected, repair applicable part.)
2. Erase DTC and perform ICC running test. Then perform self-diagnosis of ICC system again.
2. CHECK POWER SUPPLY CIRCUIT FOR ICC UNIT
1. Turn ignition switch ON.
2. Check voltage between ICC unit harness connector M89 termi- nals 33 (G/R), 42 (G/R) and ground.
OK or NG
OK >> GO TO 3.
NG >> 1. Repair ICC unit power supply harness.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
33 (G/R) – Ground : Battery voltage
42 (G/R) – Ground : Battery voltage
SKIA1173E

ACS-44
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2005 July 2005 FX
3. CHECK GROUND CIRCUIT FOR ICC UNIT
1. Turn ignition switch OFF.
2. Disconnect ICC unit connector.
3. Check continuity between ICC unit harness connector M88 ter- minals 19 (B), 20 (B) and ground.
4. Check continuity between ICC unit harness connector M89 ter- minal 46 (B) and ground.
OK or NG
OK >> 1. Replace ICC unit. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NG >> 1. Repair ICC unit ground harness. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
DTC 41 VHCL SPEED SE CIRCAKS00C8R
1. CHECK ICC UNIT SELF-DIAGNOSIS
1. Perform self-diagnosis.
2. Check if “DTC 43 ABS/TCS/VDC CIRC” or “DTC 20 CAN COMM CIRCUIT” other than “DTC 41 VHCL SPEED SE CIRC” is indicated in self-diagnosis item in the display.
Is any indicated?
YES >> 1. Repair or replace applicable item.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NO >> GO TO 2.
2. CHECK AT VEHICLE SPEED SENSOR
With CONSULT-II
With “DATA MONITOR”, check “VHCL SPD AT” operates normally. Refer to ACS-32, "
DATA MONITOR" .
OK or NG
OK >> 1. Replace ICC unit. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NG >> 1. Perform TCM self-diagnosis. 2. After repairing or replacing applicable item, erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
19 (B) – Ground : Continuity should exist.
20 (B) – Ground : Continuity should exist.
46 (B) – Ground : Continuity should exist.
SKIA6650E

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS ACS-45
[ICC]
C
D E
F
G H
I
J
L
M A
B
ACS
Revision: 2005 July 2005 FX
DTC 43 ABS/TCS/VDC CIRCAKS00C8S
1. CHECK ICC UNIT SELF-DIAGNOSIS
With CONSULT-II
1. Perform self-diagnosis.
2. Check if “DTC 20 CAN COMM CIRCUIT” other than “DTC 43 ABS/TCS/VDC CIRC” is indicated in self- diagnosis item in the display.
Is it indicated?
YES >> 1. Repair or replace applicable item. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NO >> GO TO 2.
2. CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF-DIAGNOSIS
With CONSULT-II
1. Perform self-diagnosis of ABS actuator and electric unit (control unit). Refer to BRC-12, "
TROUBLE
DIAGNOSIS" .
2. Check if malfunction is indicated.
Is malfunction indicated?
YES >> 1. Repair or replace applicable item. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NO >> 1. Replace ICC unit. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
DTC 45 BRAKE SW/STOP L SWAKS00C8T
1. CHECK CONNECTOR FOR ICC UNIT
1. Turn ignition switch OFF.
2. Disconnect ICC unit connector, and connect it securely again.
3. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
Is malfunction indicated?
YES >> GO TO 2.
NO >> Poor connector connection
1. Check connector. (Check connector housing for disconnected, loose, bent, and collapsed ter- minals. If any malfunction is detected, repair applicable part.)
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
2. CHECK STOP LAMP SWITCH AND ICC BRAKE SWITCH
With CONSULT-II
With “DATA MONITOR”, check if “STOP LAMP SW” and “BRAKE SW” are operated normally. Refer to ACS-
32, "DATA MONITOR" .
OK or NG
OK >> 1. Replace ICC unit. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NG >>

BRAKE SW: GO TO 3.

STOP LAMP SW: GO TO 5.

ACS-46
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2005 July 2005 FX
3. BRAKE SWITCH INSTALLATION AND ADJUSTMENT INSPECTION
Check brake switch for proper installation, and adjust the switch if necessary. Refer to BR-6, "
BRAKE PEDAL"
.
OK or NG
OK >> GO TO 4.
NG >> After adjustment, erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
4. CHECK ICC BRAKE SWITCH
Check ICC brake switch. Refer to ACS-71, "
ICC Brake Switch and Stop Lamp Switch" .
OK or NG
OK >> 1. Replace ICC unit. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NG >> 1. Replace ICC brake switch. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
5. CHECK STOP LAMP ILLUMINATION
Check stop lamp illumination.
OK or NG
OK >> GO TO 6.
NG >> 1. Check stop lamp circuit.
2. After repairing, erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
6. CHECK ICC BRAKE HOLD RELAY
1. Turn ignition switch OFF.
2. Remove ICC brake hold relay.
3. Check continuity of ICC brake hold relay.
OK or NG
OK >> GO TO 7.
NG >> 1. Replace brake hold relay.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
6 – 7 : Continuity should not exist.
3 – 4 : Continuity should exist.
SKIA6651E

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS ACS-47
[ICC]
C
D E
F
G H
I
J
L
M A
B
ACS
Revision: 2005 July 2005 FX
7. CHECK ICC BRAKE HOLD RELAY CIRCUIT
1. Disconnect ICC unit connector and stop lamp switch connector.
2. Check continuity between ICC unit harness connector M89 ter- minal 38 (P/B) and ICC brake hold relay harness connector E14
terminal 7 (P).
3. Check continuity between ICC unit harness connector M89 ter- minal 38 (P/B) and ground.
OK or NG
OK >> GO TO 8.
NG >> 1. Repair harness between ICC unit and ICC brake hold relay.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
8. CHECK STOP LAMP SWITCH CIRCUIT
Check continuity between ICC unit harness connector M89 terminal
38 (P/B) and stop lamp switch harness connector E210 terminal 2
(P).
OK or NG
OK >> 1. Replace ICC unit. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NG >> 1. Repair harness between ICC unit and stop lamp switch.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
DTC 46 OPERATION SW CIRCAKS007I0
1. CHECK CONNECTOR FOR ECM
1. Turn ignition switch OFF.
2. Disconnect ECM connector, and connect it securely again.
3. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
Is malfunction indicated?
YES >> GO TO 2.
NO >> Poor connector connection
1. Check connector. (Check connector housing for disconnected, loose, bent, and collapsed ter- minals. If any malfunction is detected, repair applicable part.)
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
2. CHECK ICC STEERING SWITCH
Check ICC steering switch. Refer to ACS-71, "
ICC Steering Switch" .
OK or NG
OK >> GO TO 3.
NG >> 1. Replace ICC steering switch.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
38 (P/B) – 7 (P) : Continuity should exist.
38 (P/B) – Ground : Continuity should not exist.
PKIA9907E
38 (P/B) – 2 (P) : Continuity should exist.
PKIB4163E

ACS-48
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2005 July 2005 FX
3. CHECK ICC STEERING SWITCH SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM connector and spiral cable connector.
3. Check continuity between spiral cable harness connector M15 terminals 33 (B/W), 34 (G/Y) and ECM harness connector M90
terminals 82 (B/W), 99 (G/Y).
4. Check continuity between spiral cable harness connector M15 terminals 33 (B/W), 34 (G/Y) and ground.
OK or NG
OK >> GO TO 4.
NG >> 1. Repair harness between ECM and spiral cable.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
4. CHECK SPIRAL CABLE
Check continuity between spiral cable (on vehicle) M15 terminals 33,
34 and spiral cable (on switch) M203 terminals 14, 15.
OK or NG
OK >> 1. Perform ECM self-diagnosis. 2. After repairing or replacing applicable item, erase DTC and perform ICC system running test. Then per-
form self-diagnosis of ICC system again.
NG >> 1. Replace spiral cable. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
DTC 61 PRESS SEN CIRCUITAKS00C8U
1. CHECK CONNECTOR BRAKE PRESSURE SENSOR AND ICC UNIT
1. Turn ignition switch OFF.
2. Disconnect brake pressure sensor connector and ICC unit connector, and connect them securely again.
3. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
Is malfunction indicated?
YES >> GO TO 2.
NO >> Poor connector connection
1. Check connector. (Check connector housing for disconnected, loose, bent, and collapsed ter- minals. If any malfunction is detected, repair applicable part.)
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
33 (B/W) – 82 (B/W) : Continuity should exist.
34 (G/Y) – 99 (G/Y) : Continuity should exist.
PKIB4164E
33 (B/W) – Ground : Continuity should not exist.
34 (G/Y) – Ground : Continuity should not exist.
PKIB4165E
33 – 15 : Continuity should exist.
34 – 14 : Continuity should exist.
PKIB4166E

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS ACS-49
[ICC]
C
D E
F
G H
I
J
L
M A
B
ACS
Revision: 2005 July 2005 FX
2. CHECK HARNESS BETWEEN BRAKE PRESSURE SENSOR AND ICC UNIT
1. Turn ignition switch OFF.
2. Disconnect ICC unit connector and brake pressure sensor con- nector.
3. Check continuity between brake pressure sensor harness con- nector E142 terminals 1 (Y/R), 2 (OR), 3 (Y/G) and ICC unit har-
ness connector M88 terminals 24 (Y/R), 17 (BR), 8 (Y/G).
4. Check continuity between ICC unit harness connector M88 ter- minals 8 (Y/G), 17 (BR), 24 (Y/R) and ground.
OK or NG
OK >> GO TO 3.
NG >> 1. Repair harness between brake pressure sensor and ICC unit.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
3. CHECK POWER SUPPLY CIRCUIT FOR BRAKE PRESSURE SENSOR
1. Connect ICC unit connector.
2. Turn ignition switch ON.
3. Check voltage between ICC unit harness connector M88 termi- nals 8 (Y/G) and 24 (Y/R).
OK or NG
OK >> 1. Replace brake pressure sensor. Refer to BR-13,
"BRAKE MASTER CYLINDER" .
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NG >> 1. Replace ICC unit. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
1 (Y/R) – 24 (Y/R) : Continuity should exist.
2 (OR) – 17 (BR) : Continuity should exist.
3 (Y/G) – 8 (Y/G) : Continuity should exist.
SKIA6652E
8 (Y/G) – Ground : Continuity should not exist.
17 (BR) – Ground : Continuity should not exist.
24 (Y/R) – Ground : Continuity should not exist.
PKIB1444E
Terminal (wire color) Voltage (V)
(+) (–)
8 (Y/G) 24 (Y/R) Approx. 5
SKIA6653E

ACS-50
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2005 July 2005 FX
DTC 62 BOOSTER SOL/V CIRCUITAKS00C8V
1. CHECK SOLENOID/RELEASE SWITCH AND ICC UNIT CONNECTOR
1. Turn ignition switch OFF.
2. Disconnect brake booster connector and ICC unit connector, and connect them securely again.
3. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
Is malfunction indicated?
YES >> GO TO 2.
NO >> Poor connector connection
1. Check connector. (Check connector housing for disconnected, loose, bent, and collapsed ter- minals. If any malfunction is detected, repair applicable part.)
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
2. CHECK HARNESS BETWEEN SOLENOID/RELEASE SWITCH AND ICC UNIT
1. Turn ignition switch OFF.
2. Disconnect ICC unit connector and brake booster connector.
3. Check continuity between ICC unit harness connector M88 ter- minals 10 (B/R), 12 (L/W) and brake booster harness connector
E54 terminals 4 (B), 6 (L).
4. Check continuity between ICC unit harness connector M88 ter- minals 10 (B/R), 12 (L/W) and ground.
OK or NG
OK >> GO TO 3.
NG >> 1. Repair harness between brake booster and ICC unit.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
3. CHECK BOOST SOLENOID
Check boost solenoid. Refer to ACS-71, "
Boost Solenoid" .
OK or NG
OK >> 1. Replace ICC unit. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NG >> Boost solenoid malfunction 1. Replace brake booster.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
10 (B/R) – 4 (B) : Continuity should exist.
12 (L/W) – 6 (L) : Continuity should exist.
PKIB4147E
10 (B/R) – Ground : Continuity should not exist.
12 (L/W) – Ground : Continuity should not exist.
PKIB4148E

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS ACS-51
[ICC]
C
D E
F
G H
I
J
L
M A
B
ACS
Revision: 2005 July 2005 FX
DTC 63 RELEASE SW CIRCUITAKS00C8W
1. CHECK SOLENOID/RELEASE SWITCH AND ICC UNIT CONNECTOR
1. Turn ignition switch OFF.
2. Disconnect brake booster connector and ICC unit connector, and connect them securely again.
3. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
Is malfunction indicated?
YES >> GO TO 2.
NO >> Poor connector connection
1. Check connector. (Check connector housing for disconnected, loose, bent, and collapsed ter- minals. If any malfunction is detected, repair applicable part.)
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
2. CHECK HARNESS SOLENOID/RELEASE SWITCH AND ICC UNIT
1. Turn ignition switch OFF.
2. Disconnect brake booster connector and ICC unit connector.
3. Check continuity between ICC unit harness connector M88 ter- minals 6 (GY/L), 15 (LG/R), 22 (G/Y) and brake booster harness
connector E54 terminals 1 (R), 3 (LG), 2 (G).
4. Check continuity between ICC unit harness connector M88 ter- minals 6 (GY/L), 15 (LG/R), 22 (G/Y) and ground.
OK or NG
OK >> GO TO 3.
NG >> 1. Repair harness between brake booster and ICC unit.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
3. CHECK RELEASE SWITCH POWER SUPPLY CIRCUIT
1. Connect ICC unit connector.
2. Turn ignition switch ON.
3. Check voltage between ICC unit harness connector M88 termi- nal 6 (GY/L) and ground.
OK or NG
OK >> GO TO 4.
NG >> 1. Replace ICC unit.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
6 (GY/L) – 1 (R) : Continuity should exist.
15 (LG/R) – 3 (LG) : Continuity should exist.
22 (G/Y) – 2 (G) : Continuity should exist.
SKIA6655E
6 (GY/L) – Ground : Continuity should not exist.
15 (LG/R) – Ground : Continuity should not exist.
22 (G/Y) – Ground : Continuity should not exist.
PKIB1446E
6 (GY/L) – Ground : Approx. 10 V
SKIA6656E
