TIRE PRESSURE

Pressure indication in psi on the screen indicates that the
pressure is being measured. After a few driving trips, the pres-
sures for all four tires will be displayed.

The order of tire pressure figures displayed on the screen does
not correspond with the actual order of the tire position.

Tire pressure rises and falls depending on the heat caused by
the vehicle's traveling condition and the temperature.

FLAT TIRE–very low tire air pressure.
NOTE:

In a case of FLAT TIRE pressure, interrupt screen is not shown
on the display.

On the screen of TIRE PRESSURE, “FLAT TIRE”, “Check”, “All tire” is displayed.
WARNING INDICATIONS
Warning signal (door switch signal) is received from BCM through
CAN communication line.
SKIA5994E
SKIA5995E
Warning
indicators Warning lamps in
instrument panel Warning detection and cancel conditions
Cases of
malfunction
DOOR OPEN Door Detection condition
Vehicle is running [approx. 5km/h (3 MPH) or faster]
and door ajar of any of the doors is detected. Door is open.
Cancel condition Vehicle is stopped and all the doors lock.

AV-178
NAVIGATION SYSTEM
Revision: 2005 July 2005 FX
CURRENT LOCATION MARK IS IN A RIVER OR SEA
The navigation system moves the current-location mark with no distinction between land and rivers or sea. If
the location mark is somehow out of place, it may appear that the vehicle is driving in a river or the sea.
WHEN DRIVING ON SAME ROAD, SOMETIMES CURRENT-LOCATION MARK IS IN RIGHT
PLACE AND SOMETIMES IT IS WRONG PLACE
The conditions of the GPS antenna (GPS data) and gyroscope (angular speed sensor) change gradually.
Depending on the road traveled and the operation of the steering wheel, the location detection results will be
different. Therefore, even on a road on which the location has never been wrong, conditions may cause the
vehicle mark to deviate.
LOCATION CORRECTION BY MAP-MATCHING IS SLOW

The map matching function needs to refer to the data of the surrounding area. It is necessary to drive
some distance for the function to work.

Because map matching operates on this principle, when there are many roads running in similar direc-
tions in the surrounding area, no matching determination may be made. The location may not be cor-
rected until some special feature is found.
ALTHOUGH GPS RECEIVING DISPLAY IS GREEN, VEHICLE MARK DOES NOT RETURN TO
CORRECT LOCATION

The GPS accuracy has an error of approximately 10 m (30 ft). In some cases the current-location mark
may not be on the correct street, even when GPS location-correction is done.

The navigation system compares the results of GPS location detection with the results from map-match-
ing location detection. The one which is determined to have higher accuracy is used.

GPS location correction may not be performed when the vehicle is stopped.
NAME OF CURRENT PLACE IS NOT DISPLAYED
The current place name may not be displayed if there are no place names displayed on the map screen.
CONTENTS OF DISPLAY DIFFER FOR BIRDVIEW™ AND THE (FLAT) MAP SCREEN
Difference of the BIRDVIEW™ screen from the Flat Map Screen are as Follows.

The current place name displays names which are primarily in the direction of vehicle travel.

The amount of time before the vehicle travel or turn angle is updated on the screen is longer than for the
(flat) map display.

The conditions for display of place names, roads, and other data are different for nearby areas and for
more distant areas.

Some thinning of the character data is done to prevent the display becoming to complex. In some cases
and in some locations, the display contents may differ.

The same place name, street name, etc. may be displayed multiple times.

ON-VEHICLE SERVICE BRC-7
