ENGINE COOLING SYSTEM
VQ35DE
PRECAUTIONS .......................................................... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ............................................................. ..... 3
Precautions for Liquid Gasket ............................. ..... 3
REMOVAL OF LIQUID GASKET SEALING ..... ..... 3
LIQUID GASKET APPLICATION PROCEDURE ..... 3
PREPARATION ...................................................... ..... 5
Special Service Tools .......................................... ..... 5
Commercial Service Tools ................................... ..... 6
OVERHEATING CAUSE ANALYSIS ..................... ..... 7
Troubleshooting Chart ......................................... ..... 7
COOLING SYSTEM ............................................... ..... 9
Cooling Circuit ..................................................... ..... 9
System Chart ...................................................... ... 10
ENGINE COOLANT ............................................... ....11
Inspection ............................................................ .... 11
LEVEL CHECK ................................................ .... 11
LEAK CHECK .................................................. .... 11
Changing Engine Coolant ................................... .... 11
DRAINING ENGINE COOLANT ...................... .... 11
REFILLING ENGINE COOLANT ..................... ... 12
FLUSHING COOLING SYSTEM ...................... ... 13
RADIATOR ............................................................. ... 14
Components ........................................................ ... 14
Removal and Installation ..................................... ... 14
REMOVAL ........................................................ ... 14
INSTALLATION ................................................ ... 15
INSPECTION AFTER INSTALLATION ............ ... 15
Checking Radiator Cap ....................................... ... 15
Checking Radiator ............................................... ... 16
RADIATOR (ALUMINUM TYPE) ........................... ... 17
Components ........................................................ ... 17
Disassembly and Assembly ................................ ... 17
PREPARATION ................................................ ... 17
DISASSEMBLY ................................................ ... 17
ASSEMBLY ...................................................... ... 18
INSPECTION ................................................... ... 20 COOLING FAN .......................................................
... 21
Components ........................................................ ... 21
Removal and Installation ..................................... ... 21
REMOVAL ........................................................ ... 21
INSTALLATION ................................................ ... 21
INSPECTION AFTER INSTALLATION ............. ... 21
Disassembly and Assembly ................................. ... 21
DISASSEMBLY ................................................ ... 21
INSPECTION AFTER DISASSEMBLY ............. ... 21
ASSEMBLY ...................................................... ... 21
WATER PUMP ....................................................... ... 22
Components ........................................................ ... 22
Removal and Installation ..................................... ... 22
REMOVAL ........................................................ ... 22
INSPECTION AFTER REMOVAL .................... ... 24
INSTALLATION ................................................ ... 24
INSPECTION AFTER INSTALLATION ............. ... 26
WATER INLET AND THERMOSTAT ASSEMBLY . ... 27
Components ........................................................ ... 27
Removal and Installation ..................................... ... 27
REMOVAL ........................................................ ... 27
INSPECTION AFTER REMOVAL .................... ... 28
INSTALLATION ................................................ ... 28
INSPECTION AFTER INSTALLATION ............. ... 28
WATER OUTLET AND WATER PIPING ................ ... 29
Components ........................................................ ... 29
Removal and Installation ..................................... ... 29
REMOVAL ........................................................ ... 29
INSTALLATION ................................................ ... 30
INSPECTION AFTER INSTALLATION ............. ... 30
SERVICE DATA AND SPECIFICATIONS (SDS) ... ... 31
Standard and Limit ............................................... ... 31
ENGINE COOLANT CAPACITY (APPROXI-
MATE) ............................................................... ... 31
RADIATOR ....................................................... ... 31
THERMOSTAT ................................................. ... 31

CO-2Revision: 2006 July 2007 FX35/FX45
VK45DE
PRECAUTIONS ......................................................... 32
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .............................................................. ... 32
PREPARATION ...................................................... ... 33
Special Service Tools .......................................... ... 33
Commercial Service Tools ................................... ... 33
OVERHEATING CAUSE ANALYSIS ..................... ... 34
Troubleshooting Chart ......................................... ... 34
COOLING SYSTEM ............................................... ... 36
Cooling Circuit ..................................................... ... 36
System Chart ....................................................... ... 37
ENGINE COOLANT ............................................... ... 38
Inspection ............................................................ ... 38
LEVEL CHECK ................................................. ... 38
LEAK CHECK ................................................... ... 38
Changing Engine Coolant .................................... ... 38
DRAINING ENGINE COOLANT ....................... ... 38
REFILLING ENGINE COOLANT ...................... ... 39
FLUSHING COOLING SYSTEM ...................... ... 40
RADIATOR ............................................................. ... 41
Components ........................................................ ... 41
Removal and Installation ..................................... ... 41
REMOVAL ........................................................ ... 41
INSTALLATION ................................................. ... 43
INSPECTION AFTER INSTALLATION ............. ... 43
Checking Radiator Cap ....................................... ... 43
Checking Radiator ............................................... ... 44
RADIATOR (ALUMINUM TYPE) ............................ ... 45
Components ........................................................ ... 45
Disassembly and Assembly ................................. ... 45
PREPARATION ................................................ ... 45
DISASSEMBLY ................................................ ... 45
ASSEMBLY ...................................................... ... 46
INSPECTION .................................................... ... 48 COOLING FAN .......................................................
... 49
Components (Crankshaft Driven type) ................. ... 49
Removal and Installation ...................................... ... 49
REMOVAL ......................................................... ... 49
INSPECTION AFTER REMOVAL ..................... ... 49
INSTALLATION ................................................. ... 49
Components (Motor Driven Type) ........................ ... 50
Removal and Installation ...................................... ... 50
REMOVAL ......................................................... ... 50
INSTALLATION ................................................. ... 50
Disassembly and Assembly (Motor Driven Type) ... 50 DISASSEMBLY ................................................. ... 50
INSPECTION AFTER DISASSEMBLY ............. ... 50
ASSEMBLY ....................................................... ... 50
WATER PUMP ........................................................ ... 51
Components ......................................................... ... 51
Removal and Installation ...................................... ... 51
REMOVAL ......................................................... ... 51
INSPECTION AFTER REMOVAL ..................... ... 52
INSTALLATION ................................................. ... 52
INSPECTION AFTER INSTALLATION ............. ... 52
THERMOSTAT AND WATER CONTROL VALVE .. ... 53
Components ......................................................... ... 53
Removal and Installation ...................................... ... 54
REMOVAL ......................................................... ... 54
INSPECTION AFTER REMOVAL ..................... ... 54
INSTALLATION ................................................. ... 54
INSPECTION AFTER INSTALLATION ............. ... 55
SERVICE DATA AND SPECIFICATIONS (SDS) ... ... 56
Standard and Limit ............................................... ... 56
ENGINE COOLANT CAPACITY (APPROXI-
MATE) ............................................................... ... 56
RADIATOR ........................................................ ... 56
THERMOSTAT .................................................. ... 56
WATER CONTROL VALVE ............................... ... 56

PRECAUTIONS CO-3
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
CO
Revision: 2006 July 2007 FX35/FX45
[VQ35DE]PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
NBS003JN
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:

To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.

Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.

Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions for Liquid GasketNBS003JO
REMOVAL OF LIQUID GASKET SEALING

After removing mounting nuts and bolts, separate the mating
surface using the seal cutter (SST) and remove old liquid gasket
sealing.
CAUTION:
Be careful not to damage the mating surfaces.

Tap the seal cutter to insert it, and then slide it by tapping on the
side as shown in the figure.

In areas where seal cutter is difficult to use, use a plastic ham-
mer to lightly tap the parts, to remove it.
CAUTION:
If for some unavoidable reason tool such as a screwdriver
is used, be careful not to damage the mating surfaces.
LIQUID GASKET APPLICATION PROCEDURE
1. Using a scraper, remove old liquid gasket adhering to the liquid
gasket application surface and the mating surface.

Remove liquid gasket completely from the groove of the liquid
gasket application surface, mounting bolts, and bolt holes.
2. Wipe the liquid gasket application surface and the mating sur- face with white gasoline (lighting and heating use) to remove
adhering moisture, grease and foreign materials.
PBIC0002E
PBIC0003E

CO-4
[VQ35DE]
PRECAUTIONS
Revision: 2006 July 2007 FX35/FX45
3. Attach liquid gasket tube to the tube presser [SST: WS39930000
(—)].
Use Genuine RTV Silicone Sealant or equivalent. Refer to
GI-48, "
RECOMMENDED CHEMICAL PRODUCTS AND
SEALANTS" .
4. Apply liquid gasket without breaks to the specified location with the specified dimensions.

If there is a groove for the liquid gasket application, apply liq-
uid gasket to the groove.

As for the bolt holes, normally apply liquid gasket inside the
holes. Occasionally, it should be applied outside the holes.
Make sure to read the text of service manual.

Within five minutes of liquid gasket application, install the mat-
ing component.

If liquid gasket protrudes, wipe it off immediately.

Do not retighten after mounting bolts and nuts the installation.

After 30 minutes or more have passed from the installation, fill
engine oil and engine coolant.
CAUTION:
If there are specific instructions in this manual, observe them.
EMA0622D
SEM159F

PREPARATION CO-5
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
CO
Revision: 2006 July 2007 FX35/FX45
PREPARATIONPFP:00002
Special Service ToolsNBS003JP
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
(Kent-Moore No.)
Tool name Description
EG17650301
(J33984-A)
Radiator cap tester adapter Adapting radiator cap tester to radiator cap
and radiator filler neck
a: 28 (1.10) dia.
b: 31.4 (1.236) dia.
c: 41.3 (1.626) dia.
Unit: mm (in)
KV99103510
(—)
Radiator plate pliers A Installing radiator upper and lower tanks
KV99103520
(—)
Radiator plate pliers B Removing radiator upper and lower tanks
KV10111100
(J37228)
Seal cutter Removing chain tensioner cover and water
pump cover
WS39930000
(—)
Tube presser Pressing the tube of liquid gasket
S-NT564
S-NT224
S-NT225
NT046
S-NT052

CO-6
[VQ35DE]
PREPARATION
Revision: 2006 July 2007 FX35/FX45
Commercial Service ToolsNBS003JQ
Tool nameDescription
Power tool Loosening nuts and bolts
Radiator cap tester Checking radiator and radiator cap
PBIC0190E
PBIC1982E

OVERHEATING CAUSE ANALYSIS CO-7
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
CO
Revision: 2006 July 2007 FX35/FX45
OVERHEATING CAUSE ANALYSISPFP:00012
Troubleshooting ChartNBS003JR
Symptom Check items
Cooling sys-
tem parts
malfunction Poor heat transfer
Water pump malfunction Worn or loose drive belt
—
Thermostat stuck closed —
Damaged fins Dust contamination or
paper clogging
Physical damage
Clogged radiator cooling
tube Excess foreign material
(rust, dirt, sand, etc.)
Reduced air flow Cooling fan does not oper-
ate
Fan assembly —
High resistance to fan rota-
tion
Damaged fan blades
Damaged radiator shroud — — —
Improper engine coolant
mixture ratio —— —
Poor engine coolant quality — Engine coolant density —
Insufficient engine coolant Engine coolant leaks Cooling hose
Loose clamp
Cracked hose
Water pump Poor sealing
Radiator cap Loose
Poor sealing
Radiator O-ring for damage, deterio-
ration or improper fitting
Cracked radiator tank
Cracked radiator core
Reservoir tank Cracked reservoir tank
Overflowing reservoir tank Exhaust gas leaks into
cooling system Cylinder head deterioration
Cylinder head gasket dete-
rioration

CO-8
[VQ35DE]
OVERHEATING CAUSE ANALYSIS
Revision: 2006 July 2007 FX35/FX45
Except cool-
ing system
parts mal-
function — Overload on engine
Abusive driving
High engine rpm under no
load
Driving in low gear for
extended time
Driving at extremely high
speed
Powertrain system mal-
function
—
Installed improper size
wheels and tires
Dragging brakes
Improper ignition timing
Blocked or restricted air
flow Blocked bumper —
—
Blocked radiator grille
Installed car brassiere
Mud contamination or
paper clogging
Blocked radiator —
Blocked condenser Blocked air flow
Installed large fog lamp
Symptom Check items

COOLING SYSTEM CO-9
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
CO
Revision: 2006 July 2007 FX35/FX45
COOLING SYSTEMPFP:21020
Cooling CircuitNBS003JS
PBIC2073E

CO-10
[VQ35DE]
COOLING SYSTEM
Revision: 2006 July 2007 FX35/FX45
System ChartNBS003JT
PBIC0847E
