AV-1
AUDIO VISUAL, NAVIGATION & TELEPHONE SYS- TEM
K ELECTRICAL
CONTENTS
C
D E
F
G H
I
J
L
M
SECTION
A
B
AV
Revision: 2006 July 2007 FX35/FX45
AUDIO VISUAL, NAVIGATION & TELEPHONE SYSTEM
PRECAUTIONS .......................................................... 4
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ............................................................. ..... 4
PREPARATION ...................................................... ..... 5
Commercial Service Tools ................................... ..... 5
AUDIO .................................................................... ..... 6
System Description ............................................. ..... 6
AUDIO SYSTEM .............................................. ..... 6
SPEED SENSITIVE VOLUME SYSTEM ......... ..... 7
Component Parts Location .................................. ..... 7
Schematic — AUDIO — / With Navigation System ..... 8
Wiring Diagram — AUDIO — / With Navigation Sys-
tem ...................................................................... ..... 9
Schematic — AUDIO — Without Navigation System ... 19
Wiring Diagram — AUDIO — / Without Navigation
System ................................................................ ... 20
Terminals and Reference Value for Audio Unit .... ... 29
Terminals and Reference Value for BOSE Speaker
Amp. .................................................................... ... 31
Terminals and Reference Value for A/C and AV
Switch .................................................................. ... 33
Terminals and Reference Value for Woofer ......... ... 34
Terminals and Reference Value for Satellite Radio
Tuner ................................................................... ... 34
A/C and AV Switch Self-Diagnosis Function ....... ... 35
STARTING THE SELF-DIAGNOSIS MODE .... ... 35
DIAGNOSIS FUNCTION .................................. ... 35
EXITING THE SELF-DIAGNOSIS MODE ........ ... 35
Trouble Diagnosis ............................................... ... 36
Power Supply Circuit Inspection ......................... ... 37
Audio Steering Wheel Switch Inspection ............. ... 38
A/C and AV Switch Inspection ............................. ... 40
BOSE Speaker Amp. Inspection ......................... ... 40
Vehicle Speed Signal Inspection ......................... ... 41
Locking CD Auto-Changer Mechanism ............... ... 42
DAMPER LOCK PROCEDURE ....................... ... 42
Removal and Installation of Audio Unit ............... ... 43
REMOVAL ........................................................ ... 43
INSTALLATION ................................................ ... 43 Disassembly and Assembly for Audio Unit ..........
... 43
DISASSEMBLY ................................................ ... 43
ASSEMBLY ...................................................... ... 43
Removal and Installation for A/C and AV Switch . ... 44
REMOVAL ........................................................ ... 44
INSTALLATION ................................................ ... 44
Removal and Installation for Front Door Speaker ... 44
REMOVAL ........................................................ ... 44
INSTALLATION ................................................ ... 44
Removal and Installation for Rear Door Speaker ... 44 REMOVAL ........................................................ ... 44
INSTALLATION ................................................ ... 44
Removal and Installation for Instrument Speaker ... 45 REMOVAL ........................................................ ... 45
INSTALLATION ................................................ ... 45
Removal and Installation for Tweeter .................. ... 45
REMOVAL ........................................................ ... 45
INSTALLATION ................................................ ... 45
Removal and Installation for Woofer (BOSE Sys-
tem) ..................................................................... ... 45
REMOVAL ........................................................ ... 45
INSTALLATION ................................................ ... 45
Removal and Installation for BOSE Speaker Amp. ... 46
REMOVAL ........................................................ ... 46
INSTALLATION ................................................ ... 46
Removal and Installation of Satellite Radio Tuner ... 47
REMOVAL ........................................................ ... 47
INSTALLATION ................................................ ... 47
Removal and Installation of Satellite Radio Antenna ... 47
REMOVAL ........................................................ ... 47
INSTALLATION ................................................ ... 47
ANTENNA .............................................................. ... 48
System Description .............................................. ... 48
Wiring Diagram — M/ANT — .............................. ... 49
Terminals and Reference Value for Audio Unit .... ... 50
Antenna Amp. Inspection .................................... ... 50
Location of Antenna ............................................. ... 51
RADIO ANTENNA AND GPS ANTENNA ......... ... 51
SATELLITE RADIO ANTENNA ........................ ... 51
Window Antenna Repair ...................................... ... 52

AV-3
C
D E
F
G H
I
J
L
M A
B
AV
Revision: 2006 July 2007 FX35/FX45
Do Not Change ...................................................
. 150
Voice Guidance Is Not Heard .............................. . 151
Example of Symptoms Possible No Malfunction . . 152
BASIC OPERATIONS ...................................... . 152
VEHICLE MARKS ............................................ . 152
DVD-ROM ........................................................ . 153
ROUTE CALCULATION AND VISUAL GUID-
ANCE ............................................................... . 153
VOICE GUIDANCE .......................................... . 154
Removal and Installation of NAVI Control Unit .... . 155
REMOVAL ........................................................ . 155
INSTALLATION ................................................ . 155
Removal and Installation of GPS Antenna .......... . 155
REMOVAL ........................................................ . 155
INSTALLATION ................................................ . 155
Removal and Installation of A/C and AV Switch .. . 156
Removal and Installation of Display Unit ............. . 156
Removal and Installation of Display Control Unit . 156
INFINITI MOBILE ENTERTAINMENT SYSTEM ... . 157
System Description ............................................. . 157
Component Parts Location .................................. . 158
Wiring Diagram – MES – ..................................... . 159
Terminals and Reference Value for DVD Player . . 161
Terminals and Reference Value for DVD Display . 162
DVD Player Does Not Work ................................ . 164
Screen Is Not Shown (While Sounds Come Out of
an Audio Speaker, Did Not Do of a Head Phone) . 166
Screen Is not Shown (Sounds Come Out of Both
an Audio Speaker and a Head Phone) ............... . 167
Head Phone Does Not Sound ............................. . 168
Remote Controller Does Not Work ...................... . 169
No CD·DVD Sound From All Speakers ............... . 170
Removal and Installation for DVD Player ............ . 172 REMOVAL ........................................................
.172
INSTALLATION ................................................ .172
Removal and Installation for DVD Display Unit ... .172
REMOVAL ........................................................ .172
INSTALLATION ................................................ .173
TELEPHONE .......................................................... .174
System Description .............................................. .174
HANDS-FREE PHONE SYSTEM ..................... .174
Component Parts Location .................................. .175
Schematic ............................................................ .176
Wiring Diagram — H/PHON — ............................ .177
Terminals and Reference Value for TEL Adapter
Unit ...................................................................... .182
Self-Diagnosis Function ....................................... .183
OPERATION PROCEDURE ............................. .184
Basic Inspection of Hands-Free Phone ............... .186
Audio Steering Wheel Switch Does Not Operate . 186
Voice Activated Control Function Does Not Operate .188
TEL VOICE GUIDANCE IS HEARD WHEN
PRESSING AUDIO STEERING WHEEL
SWITCH ........................................................... .188
TEL VOICE GUIDANCE IS NOT HEARD WHEN
PRESSING AUDIO STEERING WHEEL
SWITCH ........................................................... .189
Removal and Installation of TEL Adapter Unit ..... .191
REMOVAL ........................................................ .191
INSTALLATION ................................................ .191
Removal and Installation for TEL Antenna .......... .191
REMOVAL ........................................................ .191
INSTALLATION ................................................ .191
Removal and Installation of Microphone ............. .191
REMOVAL ........................................................ .191
INSTALLATION ................................................ .191

AV-6
AUDIO
Revision: 2006 July 2007 FX35/FX45
AUDIOPFP:28111
System DescriptionNKS003AI
AUDIO SYSTEM
Refer to Owner's Manual for audio system operating instructions.
Power is supplied at all times

through 15A fuse (No. 32, located in the fuse and fusible link block)

to audio unit terminal 6

to A/C and AV switch terminal 1

to display control unit terminal 1

to woofer terminal 1

to satellite radio tuner terminal 12 (With satellite radio) and

to option connector–2 for satellite radio tuner terminal 12 (Without satellite radio),

through 20A fuse [No.17, located in the fuse block (J/B)]

to BOSE speaker amp. terminal 1.
With the ignition switch in the ACC or ON position, power is supplied

through 10A fuse [No. 6, located in the fuse block (J/B)]

to audio unit terminal 10

to A/C and AV switch terminal 2

to display control unit terminal 10

to satellite radio tuner terminal 16 (With satellite radio) and

to option connector–2 for satellite radio tuner terminal 11 (Without satellite radio).
Ground is supplied through the case of the audio unit.
Ground is also supplied

to BOSE speaker amp. terminal 17

to woofer terminal 2

to satellite radio tuner terminal 15 (With satellite radio) and

to option connector–2 for satellite radio receiver terminal 10 (Without satellite radio)

through body ground B203 and B210,

to A/C and AV switch terminal 5

to display control unit terminals 3,13 and

to display terminal 1

through body ground M35, M45 and M85.
Audio unit, A/C and audio controller are connected by FPC (Flexible Print Circuit).
A/C and audio controller integrates A/C switches and audio switches.
When A/C and audio controller is pressed to audio switch, it sends audio signal to audio unit. Then audio sig-
nals are supplied

through audio unit terminals 1, 2, 3, 4, 13, 14, 15, and 16

to BOSE speaker amp. terminals 23, 24, 25, 26, 27, 28, 29, and 30.
Audio signals are amplified by the BOSE speaker amp.
The amplified audio signals are supplied

through BOSE speaker amp. terminals 2, 3, 4, 9,10,11,12, 13, 14, 15, 16, 18, 19 and 20

to terminals 1 and 2 of front door speaker LH and RH

to terminals 1 and 2 of rear door speaker LH and RH

to terminals 1 and 2 of tweeter LH and RH

to terminals 1 and 2 of instrument speaker LH, RH, and CENTER, and

to terminals 7 and 8 of woofer.
When one of audio steering wheel switch is pressed to ON (With telephone system), mode ON (Without
telephone system), seek up, or volume up, resistance in steering switch circuit changes depending on which
button is pressed.

AUDIO AV-7
C
D E
F
G H
I
J
L
M A
B
AV
Revision: 2006 July 2007 FX35/FX45
When one of audio steering wheel switch is pressed to mode ON (With telephone system), power ON (Without
telephone system), seek down, or volume down, resistance in audio steering wheel switch circuit changes
depending on which button is pressed.
SPEED SENSITIVE VOLUME SYSTEM
Volume level of this system gone up and down automatically in proportion to the vehicle speed. And the con-
trol level can be selected by the customer.
Component Parts LocationNKS003AH
SKIB8644E

AUDIO AV-33
C
D E
F
G H
I
J
L
M A
B
AV
Revision: 2006 July 2007 FX35/FX45
Terminals and Reference Value for A/C and AV SwitchNKS003LA

*1: With telephone system

*2: Without telephone system Terminal
(Wire color) Item Signal
input/
output Condition
Reference value
+– Ignition
switch Operation
1 (W/L) Ground Battery power supply Input OFF — Battery voltage 2 (LG) Ground ACC power supply Input ACC — Battery voltage
5 (B) Ground Ground — ON — Approx. 0 V
6 (PU) Ground Communication
signal (+) Input/
Output ON —
7 — Shield — — — —
8 (LG) Ground Communication
signal (–) Input/
Output ON —
12 (R/W) Ground Steering SW A Input ON Press and hold PTT
*1
switch Approx. 0 V
Press and hold MODE
*2
switch Approx. 0 V
Press and hold SEEK UP
switch Approx. 1.7 V
Press and hold VOL UP
switch Approx. 3.3 V
Except for above Approx. 5 V
13 (G/W) Ground Steering SW B Input ON Press and hold MODE
*1
switch Approx. 0 V
Press and hold POWER
*2
switch Approx. 0 V
Press and hold SEEK
DOWN switch Approx. 1.7 V
Press and hold VOL DOWN
switch Approx. 3.3 V
Except for above Approx. 5 V
14 (B/Y) Ground Steering SW ground — ON — Approx. 0 V
SKIB7378E
SKIB7379E

AUDIO AV-35
C
D E
F
G H
I
J
L
M A
B
AV
Revision: 2006 July 2007 FX35/FX45
A/C and AV Switch Self-Diagnosis FunctionNKS003AT
It can check ON/OFF operation of each switch in the A/C and AV switch and diagnose the input signals to the
audio steering wheel switch.
STARTING THE SELF-DIAGNOSIS MODE
1. Turn ignition switch from OFF to ACC.
2. Within 10 seconds press and hold the switches “1” and “6” simultaneously for 3 seconds.
DIAGNOSIS FUNCTION
The following are checked:

All the indicators (LED) in the A/C and AV switch.

Continuity of the switches by sounding the buzzer when the A/C and AV switch and audio steering wheel
switch is pressed.

Continuity of harness between A/C and AV switch and audio steering switch.
NOTE:
Rear window defogger switch operation is not checked. (No beep sound even under normal status)
EXITING THE SELF-DIAGNOSIS MODE

Turn ignition switch OFF.
10 (L/W) Ground Communication signal
Rx (AUDIO-SAT) Input ON When setting to satellite
radio mode
12 (Y) Ground Battery power supply Input OFF — Battery voltage
15 (B) Ground Ground — ON — Approx. 0 V
16 (P) Ground ACC power supply Input ACC — Battery voltage 17 — Satellite radio antenna — — — — Terminal
(Wire color) Item Signal
input/
output Condition
Reference value
+– Ignition
switch Operation
SKIB7336E
SKIB8660E

AV-36
AUDIO
Revision: 2006 July 2007 FX35/FX45
Trouble DiagnosisNKS003LC

The majority of the audio malfunctions are the result of outside causes (bad CD, electromagnetic interfer-
ence, etc.). Check the symptoms below to diagnose the malfunction.

The vehicle itself can be a source of noise if noise prevention parts or electrical equipment is malfunction-
ing. Check if noise is caused and/or changed by engine speed, ignition switch turned to each position, and
operation of each piece of electrical equipment, and then determine the cause.

Make sure that other operation except audio system can be performed with A/C and AV switch. If these
operations are inoperative with A/C and AV switch, refer to AV- 8 4 , "
Unable to Operate System with A/C
and AV Switch" (Without navigation system), or AV- 1 3 9 , "Unable to Operate System with A/C and AV
Switch" (With navigation system).

Refer to "SERVICE BULLETIN ITB04-055" for the diagnosis of satellite radio.
NOTE:
Noise resulting from variations in field strength, such as fading noise and multi-path noise, or external noise
from trains and other sources. It is not a malfunction.

Fading noise: This noise occurs because of variations in the field strength in a narrow range due to moun-
tains or buildings blocking the signal.

Multi-path noise: This noise results from a time difference between the broadcast waves directly from the
station arriving at the antenna and the waves reflected by mountains or buildings.
Symptom Possible malfunction location
Audio system does not work properly.

Audio unit power supply circuit

Communication signal circuit between audio unit and display control unit

A/C and AV switch

Audio unit
No sound can be heard from all speakers.

BOSE speaker amp. power supply and ground circuit

BOSE speaker amp. ON signal circuit

Audio unit

BOSE speaker amp.
No sound can be heard from one or several speakers.

Audio signal circuit between audio unit and BOSE speaker amp.

Audio signal circuit between BOSE speaker amp. and speaker

Speaker

Tw e e te r

Audio unit

BOSE speaker amp.
No sound can be heard from woofer.

Audio signal circuit between BOSE speaker amp. and woofer

Woofer

BOSE speaker amp.
No sound can be heard from radio or noise is caught.

Antenna amp. ON signal circuit

Antenna feeder

Roof antenna

Antenna amp.

Audio unit
Audio steering switch does not operate properly.

Remote control signal circuit between audio steering switch and A/C and
AV switch

Audio steering switch

Spiral cable

TEL adapter unit (With telephone system)

A/C and AV switch

AV-38
AUDIO
Revision: 2006 July 2007 FX35/FX45
3. CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BOSE speaker amp. and woofer connectors.
3. Check continuity between BOSE speaker amp. harness connec- tor B212 terminal 17 and ground.
4. Check continuity between woofer harness connector B223 ter- minal 2 and ground.
OK or NG
OK >> INSPECTION END (System is OK.)
NG >> Repair harness or connector.
Audio Steering Wheel Switch InspectionNKS003AX
1. CHECK A/C AND AV SWITCH SELF-DIAGNOSIS FUNCTION
1. Start A/C and AV switch self-diagnosis function. Refer to AV- 3 5 , "
A/C and AV Switch Self-Diagnosis Func-
tion" .
2. Operate audio steering wheel switch.
Does audio steering wheel switch operate normally?
YES >> INSPECTION END
NO >>

GO TO 2. (Without telephone system)

GO TO 3. (With telephone system)
2. CHECK HARNESS
1. Turn ignition switch OFF.
2. Disconnect A/C and AV switch and spiral cable connectors.
3. Check continuity between A/C and AV switch harness connector M64 terminals 12, 13, 14 and spiral cable harness connector
M15 terminals 24, 32, 31.
4. Check continuity between A/C and AV switch and ground.
OK or NG
OK >> GO TO 5.
NG >> Repair harness or connector. 17 – Ground : Continuity should exist.
SKIA4312E
2 – Ground : Continuity should exist.
SKIB8692E
12 – 24 : Continuity should exist.
13 – 32 : Continuity should exist.
14 – 31 : Continuity should exist.
12, 13, 14 – ground : Continuity should not exist.
SKIA5955E

AUDIO AV-39
C
D E
F
G H
I
J
L
M A
B
AV
Revision: 2006 July 2007 FX35/FX45
3. CHECK HARNESS
1. Turn ignition switch OFF.
2. Disconnect A/C and AV switch and TEL adapter unit connectors.
3. Check continuity between A/C and AV switch harness connector (A) M64 terminals 12, 13, 14 and teladapter unit harness con-
nector (B) M102 terminals 17, 18, 19.
4. Check continuity between A/C and AV switch and ground.
OK or NG
OK >> GO TO 4.
NG >> Repair harness or connector.
4. CHECK HARNESS
1. Disconnect spiral cable connector.
2. Check continuity between TEL adapter unit harness connector (A) M102 terminals 12, 13, 14 and spiral cable harness connec-
tor (B) M15 terminals 24, 32, 31.
3. Check continuity between TEL adapter unit and ground.
OK or NG
OK >> GO TO 5.
NG >> Repair harness or connector.
5. CHECK SPIRAL CABLE
1. Disconnect spiral cable connector (Audio steering wheel switch harness side).
2. Check continuity between spiral cable connector M15 terminals 24, 31, 32 and spiral cable connector M203 terminals 20, 17, 16.
OK or NG
OK >> GO TO 6.
NG >> Replace spiral cable. 12 – 17 : Continuity should exist.
13 – 18 : Continuity should exist.
14 – 19 : Continuity should exist.
12, 13, 14 – ground : Continuity should not exist.
PKIC9369E
12 – 24 : Continuity should exist.
13 – 32 : Continuity should exist.
14 – 31 : Continuity should exist.
12, 13, 14 – ground : Continuity should not exist.
SKIB8681E
24 – 20 : Continuity should exist.
31 – 17 : Continuity should exist.
32 – 16 : Continuity should exist.
SKIA5874E

AV-40
AUDIO
Revision: 2006 July 2007 FX35/FX45
6. CHECK AUDIO STEERING WHEEL SWITCH RESISTANCE
Check resistance audio steering wheel switch terminals.

*1: Without telephone system

*2: With telephone system
OK or NG
OK >> INSPECTION END
NG >> Replace audio steering wheel switch.
A/C and AV Switch InspectionNKS003AY
1. A/C AND AV SWITCH SELF-DIAGNOSIS FUNCTION
1. Start A/C and AV switch self-diagnosis function. Refer to AV- 3 5 , "
A/C and AV Switch Self-Diagnosis Func-
tion" .
2. Operate A/C and AV switch.
Does the A/C and AV switch is operated normally?
YES >> INSPECTION END (System is OK)
NO >> Replace A/C and AV switch.
BOSE Speaker Amp. InspectionNKS003AZ
1. CHECK HARNESS
1. Turn ignition switch OFF.
2. Disconnect audio unit and BOSE speaker amp. connectors.
3. Check continuity between audio unit harness connector M59 ter- minal 12 and BOSE speaker amp. harness connector B213 ter-
minal 31.
4. Check continuity between audio unit harness connector M59 ter- minal 12 and ground.
OK or NG
OK >> GO TO 2.
NG >> Repair harness or connector.
Terminal Signal name Condition Resistance
( Ω )
16 17 Power
*1Depress power switch. Approx. 0
Mode
*2Depress mode switch. Approx. 0
Seek down Depress (station) down switch. Approx. 165
Volume (down) Depress volume down switch. Approx. 652
20 Mode
*1Depress mode switch. Approx. 0
PTT
*2Depress PTT switch. Approx. 0
Seek up Depress (station) up switch. Approx. 165
Volume (up) Depress volume up switch. Approx. 652
SKIA5010E
12 – 31 : Continuity should exist.
12 – Ground : Continuity should not exist.
SKIA6816E
