INFINITI MOBILE ENTERTAINMENT SYSTEMPFP:28184
System DescriptionNKS003E2
Refer to Owner's Manual for mobile entertainment system operating instructions.
Power is supplied at all times
through 15A fuse (No. 32, located in the fuse and fusible link block)
to DVD player terminal 16
through DVD player terminals 31 and 32
to DVD display terminals 15 and 16.
With the ignition switch in the ACC or ON position, power is supplied
through 10A fuse [No. 6, located in the fuse block (J/B)]
to DVD player terminal 15
through DVD player terminal 21
to DVD display terminal 5.
Ground is supplied
to DVD player terminal 22
through body ground B15 and B45
to DVD player terminals 19, 27
through DVD display terminals 6, 10 and 12.
When DVD player power switch is ON, power is supplied
through DVD player terminal 9
to audio unit terminal 38 and
through audio unit terminal 40
to DVD player terminal 11.
When DVD player power switch is ON, DVD sound signals are supplied
through DVD player terminals 17, 18, and 20
to DVD display terminals 1, 2 and 4.
DVD sound can be heard by the head phone.
When rear AV switch is ON, audio signals are supplied
through DVD player terminals 1, 2, 3, and 4
to audio unit terminals 37, 39, 43, and 42.
DVD sound can be heard from the speaker.
When DVD player power switch is ON, video signals are supplied
through DVD player terminals 23 and 24
to DVD display terminals 7 and 8.
When remote controller is operated, operation signals are supplied
through DVD display terminal 14
to DVD player terminal 30 and
through DVD player terminal 29
to DVD display terminal 13.
Page 775 of 4366
INFINITI MOBILE ENTERTAINMENT SYSTEM AV-169
C
D E
F
G H
I
J
L
M A
B
AV
Revision: 2006 July 2007 FX35/FX45
3. CHECK HARNESS
1. Turn ignition switch OFF.
2. Disconnect DVD player and DVD display connectors.
3. Check continuity between DVD player harness connector B19 terminals 17, 18, 19, 20 and DVD display harness connector
B61 terminals 1, 2, 3, 4.
4. Check continuity between DVD player harness connector B19 terminals 17, 18, 19, 20 and ground.
OK or NG
OK >> GO TO 4.
NG >> Repair harness or connector.
4. CHECK MES SOUND SIGNAL
1. Connect DVD player and DVD display connectors.
2. Turn the ignition switch ACC and Press “POWER” switch of DVD player.
3. Check the signal between DVD player harness connector B19 terminals 17, 18, 20 and 19 with CONSULT-II or oscilloscope.
OK or NG
OK >> Replace DVD display.
NG >> Replace DVD player.
Remote Controller Does Not WorkNKS003EB
1. CHECK DVD PLAYER OPERATION SWITCH
1. Turn ignition switch ACC.
2. Press “POWER” switch of DVD player and operate DVD player switch.
Dose the DVD player switches work?
YES >> Replace remote controller.
NO >> GO TO 2. 17 – 1 : Continuity should exist.
18 – 2 : Continuity should exist.
19 – 3 : Continuity should exist.
20 – 4 : Continuity should exist.
17, 18, 19, 20 – Ground : Continuity should not exist.
SKIA7033E
Te r m i n a l Condition Reference value
(+) (–)
17 19 Play CD or DVD video. Refer to
AV-161, "
Terminals and
Reference Value for DVD Player" .
18
20
SKIA7047E
Page 776 of 4366
AV-170
INFINITI MOBILE ENTERTAINMENT SYSTEM
Revision: 2006 July 2007 FX35/FX45
2. CHECK REMOTE CONTROLLER AND SENSOR
Check the inspection items below to diagnose the malfunction.
Check that remote controller is facing to the sensor.
Check that sensor does not have any seals or dirt that is inter-
rupting signal.
Check that the remote controller battery has run down.
OK or NG
OK >> GO TO 3.
NG >>
When operating, face remote controller to the sensor.
Remove seal or dirt that is interrupting signal.
If the battery has run down, replace it with new one.
3. CHECK HARNESS
1. Turn ignition switch OFF.
2. Disconnect DVD player and DVD display connectors.
3. Check continuity between DVD player harness connector B19 terminal 30 and DVD display harness connector B61 terminal
14.
4. Check continuity between DVD player harness connector B19 terminal 30 (BR) and ground.
OK or NG
OK >> GO TO 4.
NG >> Repair harness or connector.
4. CHECK DATA (LCD – DVD) SIGNAL
1. Connect DVD display connector.
2. Turn ignition switch ACC.
3. Check the signal between DVD player harness connector B19 terminal 30 and ground.
OK or NG
OK >> Replace DVD player.
NG >> Replace DVD display.
No CD·DVD Sound From All SpeakersNKS003EC
1. VERIFY THE PHENOMENON
1. Turn ignition switch ACC.
2. Turn on the radio, receive radio program, check that the sound is heard from all the speakers.
OK or NG
OK >> GO TO 2.
NG >> Replace audio unit.
SKIA5855E
30 – 14 : Continuity should exist.
30 – Ground : Continuity should not exist.
SKIB0335E
30 – Ground:
SKIA7043E
SKIA5832E
Page 788 of 4366
AV-182
TELEPHONE
Revision: 2006 July 2007 FX35/FX45
Terminals and Reference Value for TEL Adapter UnitNKS003IO
Te r m i n a l
(Wire color) Item Signal
input/
output Condition
Reference value
+– Ignition
switch Operation
1 (W/L) Ground Battery power supply Input OFF — Battery voltage 2 (LG) Ground ACC power supply Input ACC — Battery voltage
3 (W) Ground Ignition signal Input ON — Battery voltage4 (B) Ground Ground — ON — Approx. 0 V 6 — Shield — — — —
7 (R) 8 (B) MIC. signal Input ON Uttering in front of the
microphone while using the
hands-free phone system.
9 (P) 10 (L) TEL voice signal Output ON Receiving the party's voice
while using the hands-free
phone system.
11 (L/W) Ground TEL ON signal Output ON While using handsfree
phone system. Approx. 0 V
While not using handsfree
phone system. Approx. 5 V
12 (LG) Ground Remote control A Input ON Press switch
Approx. 0 V
Press SEEK UP switch Approx. 1.7 V
Press VOL UP switch Approx. 3.3 V
Except for above Approx. 5 V
13 (GY) Ground Remote control B Input ON Press switch
Approx. 0 V
Press SEEK DOWN switch Approx. 1.7 V
Press VOL DOWN switch Approx. 3.3 V
Except for above Approx. 5 V
14 (SB) Ground Remote control
ground — ON — Approx. 0 V
15 (PU) Ground Indicator signal Output ON Microphone indicator ON,
and lighting switch OFF Approx. 1.3 V
Microphone indicator ON,
and lighting switch ON Approx. 0.8 V
Microphone unit indicator
OFF Approx. 12 V
17 (R/W) Ground Remote control A Output ON Press switch
Approx. 0 V
Press SEEK UP switch Approx. 1.7 V
Press VOL UP switch Approx. 3.3 V
Except for above Approx. 5 V
PKIB5037J
SKIB3609E
Page 789 of 4366
TELEPHONE AV-183
C
D E
F
G H
I
J
L
M A
B
AV
Revision: 2006 July 2007 FX35/FX45
Self-Diagnosis FunctionNKS003IR
The followings are diagnosis functions performed by TEL adapter unit.
Performs the unit self−diagnosis and antenna diagnosis, and informs results with the indicator and voice
guidance.
Informs vehicle speed pulse count from the time of key switch ON with voice guidance, and enables to
check vehicle speed signal.
Outputs voice giving to microphone with speaker, and enables to check microphone function.
18 (G/W) Ground Remote control B Output ON Press switch
Approx. 0 V
Press SEEK DOWN switch Approx. 1.7 V
Press VOL DOWN switch Approx. 3.3 V
Except for above Approx. 5 V
19 (B/Y) Ground Remote control
ground — ON — Approx. 0 V
22 (B) Ground Ground — ON — Approx. 0 V
23 (B) Ground Ground — ON — Approx. 0 V
28 (G) Ground Vehicle
speed signal
(8-pulse) Input ON
When vehicle speed is
approx. 40 km/h (25 MPH)
29 (W) Ground MIC. VCC Output ON — Approx. 5 V 41 — TEL signal — — — — Terminal
(Wire color) Item Signal
input/
output Condition
Reference value
+– Ignition
switch Operation
SKIA6649J
Page 805 of 4366
BCM (BODY CONTROL MODULE) BCS-7
C
D E
F
G H
I
J
L
M A
B
BCS
Revision: 2006 July 2007 FX35/FX45
SYSTEMS CONTROLLED BY BCM DIRECTLY
NOTE:
Power supply only. No system control.
SYSTEMS CONTROLLED BY BCM AND IPDM E/R
SYSTEMS CONTROLLED BY BCM AND COMBINATION METER
SYSTEMS CONTROLLED BY BCM AND INTELLIGENT KEY UNIT
SYSTEMS CONTROLLED BY BCM, COMBINATION METER AND IPDM E/R
System Reference
Power door lock system BL-21, "
POWER DOOR LOCK SYSTEM"
Remote keyless entry systemBL-54, "REMOTE KEYLESS ENTRY SYSTEM"
Power window system NOTEGW-15, "POWER WINDOW SYSTEM"
Sunroof NOTERF-10, "SUNROOF"
Room lamp timerLT-152, "INTERIOR ROOM LAMP"
Rear wiper and washer systemWW-39, "REAR WIPER AND WASHER SYSTEM"
System Reference
Panic alarm
BL-54, "REMOTE KEYLESS ENTRY SYSTEM"
BL-86, "INTELLIGENT KEY SYSTEM"
Theft warning system BL-180, "VEHICLE SECURITY (THEFT WARNING) SYSTEM"
IVIS (NATS)BL-205, "IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-NATS)"
HeadlampLT- 6 , "HEADLAMP - XENON TYPE -"
Daytime light systemLT-38, "DAYTIME LIGHT SYSTEM"
Auto light systemLT-55, "AUTO LIGHT SYSTEM"
Front fog lampLT-78, "FRONT FOG LAMP"
Parking, license plate, side marker and tail lamps
Exterior lamp battery saver control LT-131, "PARKING, LICENSE PLATE AND TAIL LAMPS"
Front wiper and washer system
WW-4, "FRONT WIPER AND WASHER SYSTEM"
Rear window defoggerGW-67, "REAR WINDOW DEFOGGER"
System Reference
Warning chime DI-56, "
WARNING CHIME"
Turn signal and hazard warning lampsLT-90, "TURN SIGNAL AND HAZARD WARNING LAMPS"
Tire pressure monitoring systemWT-11, "TIRE PRESSURE MONITORING SYSTEM"
System Reference
Intelligent Key system BL-86, "
INTELLIGENT KEY SYSTEM"
System Reference
Oil pressure warning lamp DI-38, "
WARNING LAMPS"
Page 806 of 4366
BCS-8
BCM (BODY CONTROL MODULE)
Revision: 2006 July 2007 FX35/FX45
MAJOR COMPONENTS AND CONTROL SYSTEM
System Input Output
Remote control entry system Key fob
All-door locking actuator
Fuel lid Lock actuator
Turn signal lamp (LH, RH)
Combination meter
Intelligent key system Intelligent key unit
All-door locking actuator
Fuel lid Lock actuator
Turn signal lamp (LH, RH)
Combination meter
Power door lock system
Power window main switch
(door lock and unlock switch)
Power window sub switch (passenger side)
(door lock and unlock switch) All-door locking actuator
Power supply (IGN) to power window, sunroof Ignition power supply Power window and sunroof system
Power supply (BAT) to power window, sunroof
and power seat Battery power supplyPower window, sunroof system and
power seat
Panic alarm
Key switch
Key fob IPDM E/R
Theft warning system
All-door switch
Hood switch
Key fob
Power window main switch (door lock and
unlock switch)
Power window sub switch (passenger side)
(door lock and unlock switch)
IPDM E/R
Security indicator lamp
Auto light system
Optical sensor
Combination switch
Ignition switch IPDM E/R
Exterior lamp battery saver control
Ignition switch
Combination switch IPDM E/R
Headlamp Combination switch IPDM E/R
Daytime light system
Combination meter
ECM
Combination switch
Ignition switch IPDM E/R
Parking, license plate, side marker and tail
lamps Combination switch IPDM E/R
Front fog lamp Combination switch IPDM E/R
Turn signal lamp
Combination switch
Ignition switch
Turn signal lamp
Combination meter
Hazard lamp Hazard switch
Turn signal lamp
Combination meter
Room lamp timer
Key switch
Key fob
Power window main switch (door lock and
unlock switch)
Front door switch driver side
All-door switch Interior room lamp
Page 807 of 4366
BCM (BODY CONTROL MODULE) BCS-9
C
D E
F
G H
I
J
L
M A
B
BCS
Revision: 2006 July 2007 FX35/FX45
CAN Communication UnitNKS00340
Refer to LAN-49, "CAN System Specification Chart" .
Key warning chimeKey switch
Front door switch driver side Combination meter
(warning buzzer)
Light warning chime
Combination switch
Key switch
Front door switch driver side Combination meter
(warning buzzer)
Seat belt warning chime
Combination meter [Seat belt buckle
(driver side) switch]
Ignition switch Combination meter
(warning buzzer)
Front wiper and washer system
Combination switch
Combination meter
Ignition switch IPDM E/R
Rear wiper and washer system
Combination switch
Ignition switch Rear wiper motor
Rear window defogger
Rear window defogger switch
Ignition switch IPDM E/R
A/C switch signal Unified meter and A/C amp. ECM
Blower fan switch signal Unified meter and A/C amp. ECM
Low tire pressure warning system Remote keyless entry receiver Combination meter System Input Output
