BCM (BODY CONTROL MODULE) BCS-7
C
D E
F
G H
I
J
L
M A
B
BCS
Revision: 2006 July 2007 FX35/FX45
SYSTEMS CONTROLLED BY BCM DIRECTLY
NOTE:
Power supply only. No system control.
SYSTEMS CONTROLLED BY BCM AND IPDM E/R
SYSTEMS CONTROLLED BY BCM AND COMBINATION METER
SYSTEMS CONTROLLED BY BCM AND INTELLIGENT KEY UNIT
SYSTEMS CONTROLLED BY BCM, COMBINATION METER AND IPDM E/R
System Reference
Power door lock system BL-21, "
POWER DOOR LOCK SYSTEM"
Remote keyless entry systemBL-54, "REMOTE KEYLESS ENTRY SYSTEM"
Power window system NOTEGW-15, "POWER WINDOW SYSTEM"
Sunroof NOTERF-10, "SUNROOF"
Room lamp timerLT-152, "INTERIOR ROOM LAMP"
Rear wiper and washer systemWW-39, "REAR WIPER AND WASHER SYSTEM"
System Reference
Panic alarm
BL-54, "REMOTE KEYLESS ENTRY SYSTEM"
BL-86, "INTELLIGENT KEY SYSTEM"
Theft warning system BL-180, "VEHICLE SECURITY (THEFT WARNING) SYSTEM"
IVIS (NATS)BL-205, "IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-NATS)"
HeadlampLT- 6 , "HEADLAMP - XENON TYPE -"
Daytime light systemLT-38, "DAYTIME LIGHT SYSTEM"
Auto light systemLT-55, "AUTO LIGHT SYSTEM"
Front fog lampLT-78, "FRONT FOG LAMP"
Parking, license plate, side marker and tail lamps
Exterior lamp battery saver control LT-131, "PARKING, LICENSE PLATE AND TAIL LAMPS"
Front wiper and washer system
WW-4, "FRONT WIPER AND WASHER SYSTEM"
Rear window defoggerGW-67, "REAR WINDOW DEFOGGER"
System Reference
Warning chime DI-56, "
WARNING CHIME"
Turn signal and hazard warning lampsLT-90, "TURN SIGNAL AND HAZARD WARNING LAMPS"
Tire pressure monitoring systemWT-11, "TIRE PRESSURE MONITORING SYSTEM"
System Reference
Intelligent Key system BL-86, "
INTELLIGENT KEY SYSTEM"
System Reference
Oil pressure warning lamp DI-38, "
WARNING LAMPS"
Page 806 of 4366
BCS-8
BCM (BODY CONTROL MODULE)
Revision: 2006 July 2007 FX35/FX45
MAJOR COMPONENTS AND CONTROL SYSTEM
System Input Output
Remote control entry system Key fob
All-door locking actuator
Fuel lid Lock actuator
Turn signal lamp (LH, RH)
Combination meter
Intelligent key system Intelligent key unit
All-door locking actuator
Fuel lid Lock actuator
Turn signal lamp (LH, RH)
Combination meter
Power door lock system
Power window main switch
(door lock and unlock switch)
Power window sub switch (passenger side)
(door lock and unlock switch) All-door locking actuator
Power supply (IGN) to power window, sunroof Ignition power supply Power window and sunroof system
Power supply (BAT) to power window, sunroof
and power seat Battery power supplyPower window, sunroof system and
power seat
Panic alarm
Key switch
Key fob IPDM E/R
Theft warning system
All-door switch
Hood switch
Key fob
Power window main switch (door lock and
unlock switch)
Power window sub switch (passenger side)
(door lock and unlock switch)
IPDM E/R
Security indicator lamp
Auto light system
Optical sensor
Combination switch
Ignition switch IPDM E/R
Exterior lamp battery saver control
Ignition switch
Combination switch IPDM E/R
Headlamp Combination switch IPDM E/R
Daytime light system
Combination meter
ECM
Combination switch
Ignition switch IPDM E/R
Parking, license plate, side marker and tail
lamps Combination switch IPDM E/R
Front fog lamp Combination switch IPDM E/R
Turn signal lamp
Combination switch
Ignition switch
Turn signal lamp
Combination meter
Hazard lamp Hazard switch
Turn signal lamp
Combination meter
Room lamp timer
Key switch
Key fob
Power window main switch (door lock and
unlock switch)
Front door switch driver side
All-door switch Interior room lamp
Page 811 of 4366
BCM (BODY CONTROL MODULE) BCS-13
C
D E
F
G H
I
J
L
M A
B
BCS
Revision: 2006 July 2007 FX35/FX45
NOTE:
1: This item is displayed, but should not be used.
2: Vehicle with remote keyless entry system display this item.
3: Vehicle with Intelligent Key system display this item.
4: This item is displayed, but does not function.
WORK SUPPORT
Operation Procedure
1. Touch “BCM” on “SELECT TEST ITEM” screen.
2. Touch “WORK SUPPORT” on “SELECT DIAG MODE” screen.
3. Touch item on “SELECT WORK ITEM” screen.
4. Touch “START”.
5. Touch “CHANGE SET”.
6. The setting will be changed and “RESETTING COMPLETED” will be displayed.
7. Touch “END”.
Display Item List
CAN Communication Inspection Using CONSULT-II (Self-Diagnosis)NKS00343
1. CHECK SELF-DIAGNOSTIC RESULT
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carry out CAN communication.
1. Connect to CONSULT-II, and select “BCM” on “SELECT SYSTEM” screen.
2. Select “BCM control unit ” on “SELECT WORK ITEM” screen, and select “SELF-DIAG RESULTS”.
3. Check display content in self-diagnostic results.
Contents displayed
No malfunction>> INSPECTION END
Malfunction in CAN communication system>> After printing the monitor items, go to “CAN System”. Refer to
LAN-49, "
CAN System Specification Chart" .
Low tire pressure warning
system AIR PRESSURE
MONITOR ××× ×
Panic system PANIC ALARM ×
System and item CONSULT-II display
Diagnostic test mode (Inspection by part)
WORK SUP-
PORT SELF
−
DIAG
RESULTS DATA
MONI- TOR CAN
DIAG SUP-
PORT
MNTR ACTIVE
TEST ECU
PA RT
NUM- BER CONFIG-
URATION
Item Description
RESET SETTING VALUE Return a value set with WORK SUPPORT of each system to a default value in factory shipment.
CONSULT-II display code Diagnosis item
U1000 INITIAL DIAG
TRANSMIT DIAG ECM
IPDM E/R
METER/M&A I-KEY
Page 814 of 4366
BL-2Revision: 2006 July 2007 FX35/FX45
Check Front Door Key Cylinder Switch (Lock) ....
... 51
Check Front Door Key Cylinder Switch (Unlock) . ... 52
Check Select Unlock Relay Circuit ...................... ... 53
REMOTE KEYLESS ENTRY SYSTEM .................. ... 54
Component Parts and Harness Connector Location ... 54
System Description .............................................. ... 55
INPUTS ............................................................ ... 55
OPERATED PROCEDURE .............................. ... 56
CAN Communication System Description ........... ... 57
CAN Communication Unit .................................... ... 57
Schematic ............................................................ ... 58
Wiring Diagram — KEYLES — ............................ ... 59
Terminals and Reference Value for BCM ............. ... 62
Terminals and Reference Value for IPDM E/R ..... ... 63
CONSULT-II Function (BCM) ............................... ... 64
CONSULT-II INSPECTION PROCEDURE ....... ... 64
CONSULT-II APPLICATION ITEMS ................. ... 64
Work Flow ............................................................ ... 66
Trouble Diagnosis Chart by Symptom ................. ... 67
Check Key Fob Battery and Function .................. ... 69
Check ACC Switch .............................................. ... 70
Check Door Switch .............................................. ... 71
CHECK DOOR SWITCH (EXCEPT BACK DOOR
SWITCH) .......................................................... ... 71
CHECK BACK DOOR SWITCH ....................... ... 73
Check Key Switch ................................................ ... 75
Check Remote Keyless Entry Receiver ............... ... 76
Check IPDM E/R Operation ................................. ... 79
Check Hazard Warning Lamp Function ............... ... 80
Check Horn Function ........................................... ... 80
Check Headlamp Function .................................. ... 80
Check Map Lamp and Ignition Keyhole Illumination
Function ............................................................... ... 80
ID Code Entry Procedure .................................... ... 81
KEY FOB ID SET UP WITH CONSULT-II ........ ... 81
KEY FOB ID SET UP WITHOUT CONSULT-II . ... 83
Removal and Installation of Remote keyless Entry
receiver ................................................................ ... 84
REMOVAL ........................................................ ... 84
INSTALLATION ................................................. ... 84
Key Fob Battery Replacement ............................. ... 85
INTELLIGENT KEY SYSTEM ................................ ... 86
Component Parts and Harness Connector Location ... 86
System Description .............................................. ... 88
DOOR LOCK FUNCTION ................................ ... 88
REMOTE CONTROL ENTRY FUNCTIONS ..... ... 89
ENGINE STARTUP FUNCTION ....................... ... 90
WARNING AND ALARM FUNCTION ............... ... 91
CHANGE SETTINGS FUNCTION .................... ... 94
INTELLIGENT KEY REGISTRATION ............... ... 94
STEERING LOCK UNIT REGISTRATION ....... ... 94
CAN Communication System Description ........... ... 95
CAN Communication Unit .................................... ... 95
Schematic ............................................................ ... 96
Wiring Diagram — I/KEY — ................................ ... 98
Terminals and Reference Value for INTELLIGENT
KEY UNIT ............................................................ ..111
Terminals and Reference Value for Steering Lock
unit ....................................................................... .113 Terminals and Reference Value for BCM .............
.113
Terminals and Reference Value for IPDM E/R ..... .114
Diagnosis Procedure ............................................ .115
WORK FLOW ................................................... .115
CONSULT-II Functions (INTELLIGENT KEY) ...... .116
CONSULT-II Start Procedure ............................... .116
CONSULT-II Application Items ............................. .116
WORK SUPPORT ............................................ .116
SELF-DIAGNOSTIC RESULTS ........................ .116
DATA MONITOR ............................................... .117
ACTIVE TEST ................................................... .117
List of Operation Related Parts ............................ .118
Trouble Diagnosis Symptom Chart ...................... .119
ALL FUNCTIONS OF THE INTELLIGENT KEY
ARE NOT OPERATING .................................... .119
REMOTE CONTROL ENTRY FUNCTION MAL-
FUNCTION ....................................................... .119
DOOR LOCK FUNCTION MALFUNCTION ...... .120
ENGINE START FUNCTION MALFUNCTION . .121
WARNING CHIME FUNCTION MALFUNCTION .121
Check CAN Communication System Inspection .. .124
Check Intelligent Key Unit Power Supply and
Ground Circuit ...................................................... .124
Check Key Switch (Intelligent Key Unit Input) ...... .125
Check Key Switch (BCM Input) ............................ .126
Check Ignition Knob Switch ................................. .127
Check Door Switch .............................................. .129
CHECK DOOR SWITCH (EXCEPT BACK DOOR
SWITCH) ........................................................... .129
CHECK BACK DOOR SWITCH ........................ .130
Check Unlock Sensor .......................................... .131
Check Door Request Switch ................................ .133
Check Intelligent Key Warning Buzzer ................. .134
Check Outside Key Antenna ................................ .135
Check Inside Key Antenna ................................... .138
Check Steering Lock Unit ..................................... .139
Check Stop Lamp Switch ..................................... .141
Check Park Position Switch ................................. .142
Check Select Unlock Relay .................................. .144
Check Hazard Function ....................................... .145
Check Horn Function ........................................... .145
Check Headlamp Function ................................... .145
Check IPDM E/R Operation ................................. .145
Removal and Installation of Intelligent Key Unit ... .146
REMOVAL ......................................................... .146
INSTALLATION ................................................. .146
Intelligent Key Battery Replacement .................... .147
INTELLIGENT KEY BATTERY INSPECTION .. .147
DOOR ..................................................................... .148
Fitting Adjustment ................................................ .148
FRONT DOOR .................................................. .148
REAR DOOR .................................................... .148
STRIKER ADJUSTMENT ................................. .149
Removal and Installation of Front Door ............... .149
REMOVAL ......................................................... .149
INSTALLATION ................................................. .150
Removal and Installation of Rear Door ................ .150
REMOVAL ......................................................... .150
Page 815 of 4366
BL-3
C
D E
F
G H
J
K L
M A
B
BL
Revision: 2006 July 2007 FX35/FX45
INSTALLATION ................................................
. 151
Removal and Installation of Door Weatherstrip ... . 151
REMOVAL ........................................................ . 151
INSTALLATION ................................................ . 151
FRONT DOOR LOCK ............................................ . 152
Removal and Installation ..................................... . 152
REMOVAL ........................................................ . 152
INSTALLATION ................................................ . 154
REAR DOOR LOCK .............................................. . 155
Removal and Installation ..................................... . 155
REMOVAL ........................................................ . 155
INSTALLATION ................................................ . 157
BACK DOOR ......................................................... . 158
Fitting Adjustment ............................................... . 158
VERTICAL/LATERAL CLEARANCE ADJUST-
MENT ............................................................... . 158
Back Door Assembly ........................................... . 158
REMOVAL ........................................................ . 158
INSTALLATION ................................................ . 159
INSPECTION ................................................... . 159
Removal and Installation of Back Door Striker .... . 159
REMOVAL ........................................................ . 159
INSTALLATION ................................................ . 159
Removal and Installation of Back Door Stay ....... . 160
REMOVAL ........................................................ . 160
INSTALLATION ................................................ . 160
Removal and Installation of Dave Tail Male &
Female ................................................................ . 160
REMOVAL ........................................................ . 160
INSTALLATION ................................................ . 161
Removal and Installation of Back Door Weatherstrip . 161
REMOVAL ........................................................ . 161
INSTALLATION ................................................ . 161
BACK DOOR LOCK ASSEMBLY ......................... . 162
Removal and Installation of Back Door Lock & Clo-
sure Assembly ..................................................... . 162
REMOVAL ........................................................ . 162
INSTALLATION ................................................ . 162
INSPECTION ................................................... . 162
Removal and Installation of Back Door Opener
Switch .................................................................. . 162
REMOVAL ........................................................ . 162
INSTALLATION ................................................ . 163
Disassembly and Assembly ................................ . 163
BACK DOOR LOCK & CLOSURE ASSEMBLY . 163
BACK DOOR AUTO CLOSURE SYSTEM ............ . 164
Component Parts and Harness Connector Location . 164
System Description ............................................. . 164
CLOSE OPERATION ....................................... . 164
NON-OPERATION CONDITION ...................... . 164
OPEN OPERATION ......................................... . 165
Wiring Diagram — B/CLOS — ............................ . 166
Terminals and Reference Value for Back Door Clo-
sure Control Unit ................................................. . 168
Work Flow ........................................................... . 169
Preliminary Check ............................................... . 169
Trouble Diagnosis Chart by Symptom ................. . 169
Check Back Door Closure Control Unit Power Sup-
ply and Ground Circuit ........................................ . 170 Check Half-Latch Switch .....................................
.170
Check Close Switch ............................................. .172
Check Open Switch ............................................. .173
Check Back Door Opener Switch (With Intelligent
Key) ..................................................................... .174
Check Back Door Opener Switch (Without Intelli-
gent Key) ............................................................. .176
Check Unlock Sensor (Without Intelligent Key) ... .178
Check Closure Motor ........................................... .179
Removal and Installation of Back Door Closer Con-
trol Unit ................................................................ .179
VEHICLE SECURITY (THEFT WARNING) SYSTEM .180
Component Parts and Harness Connector Location .180
System Description .............................................. .182
DESCRIPTION ................................................. .182
POWER SUPPLY ............................................. .183
INITIAL CONDITION TO ACTIVATE THE SYS-
TEM .................................................................. .183
VEHICLE SECURITY SYSTEM ALARM OPER-
ATION ............................................................... .184
VEHICLE SECURITY SYSTEM DEACTIVATION .184
PANIC ALARM OPERATION ........................... .184
CAN Communication System Description ........... .184
CAN Communication Unit .................................... .184
Schematic ............................................................ .185
Wiring Diagram — VEHSEC — ........................... .186
Terminals and Reference Value for BCM ............ .191
Terminals and Reference Value for IPDM E/R .... .192
CONSULT-II Function (BCM) .............................. .192
CONSULT-II START PROCEDURE ................. .192
CONSULT-II APPLICATION ITEM ................... .192
Trouble Diagnosis ................................................ .194
WORK FLOW ................................................... .194
Preliminary Check ............................................... .195
Trouble Diagnosis Symptom Chart ...................... .196
Diagnostic Procedure 1 ....................................... .197
1 – 1 DOOR SWITCH CHECK ......................... .197
1 – 2 HOOD SWITCH CHECK ......................... .199
1 – 3 BACK DOOR SWITCH CHECK .............. .201
Diagnostic Procedure 2 ....................................... .203
SECURITY INDICATOR LAMP CHECK .......... .203
Diagnostic Procedure 3 ....................................... .204
FRONT DOOR KEY CYLINDER SWITCH
CHECK ............................................................. .204
Diagnostic Procedure 4 ....................................... .204
VEHICLE SECURITY HORN ALARM CHECK . 204
Diagnostic Procedure 5 ....................................... .204
VEHICLE SECURITY HEADLAMP ALARM
CHECK ............................................................. .204
Diagnostic Procedure 6 ....................................... .204
DOOR LOCK AND UNLOCK SWITCH CHECK .204
IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-
NATS) ..................................................................... .205
Component Parts and Harness Connector Location .205
System Description .............................................. .206
DESCRIPTION ................................................. .206
SECURITY INDICATOR ................................... .206
System Composition ............................................ .207
ECM Re-Communicating Function ...................... .207
Page 867 of 4366
REMOTE KEYLESS ENTRY SYSTEM BL-55
C
D E
F
G H
J
K L
M A
B
BL
Revision: 2006 July 2007 FX35/FX45
System DescriptionNIS001MI
INPUTS
Power is supplied at all times
to BCM terminal 55
through 50A fusible link (letter M , located in the fuse and fusible link box).
to BCM terminal 42
through 15A fuse [No. 22, located in the fuse block (J/B)].
to Horn relay terminal 2
through 15A fuse (No. 34, located in the fuse and fusible link box).
When the key switch is ON (key is inserted in ignition key cylinder), power is supplied
to BCM terminal 37
through key switch terminal 1 and 2
through 15A fuse [No. 22, located in the fuse block (J/B)].
When the ignition switch is ACC or ON, power is supplied
to BCM terminal 11
through 10A fuse [No. 6, located in the fuse block (J/B)].
When the ignition switch is ON or START, power is supplied
to BCM terminal 38
through 15A fuse [No. 1, located in the fuse block (J/B)].
When the front door switch (driver side) is ON (door is OPEN), ground is supplied
to BCM terminal 62
through front door switch (driver side) terminal 1
through front door switch (driver side) case ground.
When the front door switch (passenger side) is ON (door is OPEN), ground is supplied
to BCM terminal 12
through front door switch (passenger side) terminal 1
through front door switch (passenger side) case ground.
When the rear door switch LH is ON (door is OPEN), ground is supplied
to BCM terminal 63
through rear door switch LH terminal 1
through rear door switch LH case ground.
When the rear door switch RH is ON (door is OPEN), ground is supplied
to BCM meter terminal 13
through rear door switch RH terminal 1
through rear door switch RH case ground.
When the back door switch is ON (door is open), ground is supplied
to BCM terminal 58
through back door closure motor (door switch) terminals 7 and 8
through body grounds B15 and B45
Key fob signal is inputted to remote keyless entry receiver (the antenna of the system is built in remote keyless
entry receiver).
to BCM terminal 20
from remote keyless entry system controls operation of the
The remote keyless entry system controls operation of the
power door lock
hazard and horn reminder
auto door lock
panic alarm
keyless power window down (open)
Page 869 of 4366
REMOTE KEYLESS ENTRY SYSTEM BL-57
C
D E
F
G H
J
K L
M A
B
BL
Revision: 2006 July 2007 FX35/FX45
Panic Alarm Operation
When key switch is OFF (when ignition key is not inserted in key cylinder), BCM turns on and off horn and
headlamp intermittently with input of PANIC ALARM signal from key fob.
The alarm automatically turns off after 25 seconds or when BCM receives any signal from key fob.
Panic alarm operation mode can be changed using “PANIC ALARM SET” mode in “WORK SUPPORT”.
Refer to BL-65, "
Work Support" .
For detailed description, refer to BL-180, "
VEHICLE SECURITY (THEFT WARNING) SYSTEM" .
Keyless Power Window Down (Open) Operation
When key fob unlock switch is turned ON with ignition switch OFF, and key fob unlock switch is detected to be
on continuously for 3 seconds, the driver's door and passenger's door power windows are simultaneously
opened.
Power window is operated to open and the operation continues as long as the key fob unlock switch is
pressed.
Keyless power window down operation mode can be changed using “PW DOWN SET” mode in “WORK SUP-
PORT”. Refer to BL-65, "
Work Support"
Room Lamp and Ignition Key Ring Illumination Operation
When the following conditions come:
condition of interior lamp switch is DOOR position;
door switch OFF (when all the doors are closed);
Remote keyless entry system turns on interior lamp (for 30 seconds) with input of UNLOCK signal from key
fob. For detailed description, refer to LT- 1 5 2 , "
INTERIOR ROOM LAMP" .
CAN Communication System DescriptionNIS001MJ
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tronic control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only.
CAN Communication UnitNIS001MK
Refer to LAN-49, "CAN System Specification Chart" .
Page 876 of 4366
BL-64
REMOTE KEYLESS ENTRY SYSTEM
Revision: 2006 July 2007 FX35/FX45
CONSULT-II Function (BCM)NIS001MP
CONSULT-II can display each diagnostic item using the diagnostic test modes shown following.
*: Refer to LAN-49, "CAN System Specification Chart" .
CONSULT-II INSPECTION PROCEDURE
Refer to GI-38, "CONSULT-II Start Procedure" .
CONSULT-II APPLICATION ITEMS
Data Monitor
Active Test
BCM diagnosis position Inspection items and diagnosis mode Description
BCM C/U* Self-diagnosis results Carries out the self-diagnosis.
DATA MONITOR Displays the input data to BCM on real-time basis.
CAN DIAG SUPPORT MNTR Displays CAN communication system diagnosis, disabled
transmission status, and communication status of each unit
communicated with BCM.
MULTI REMOTE
ENT DATA MONITOR
Displays the input remote keyless entry system data to BCM
on real–time basis.
ACTIVE TEST Gives a drive to a load to check the operation.
WORK SUPPORT Changes the setting for each function.
Monitored Item Description
IGN ON SW Indicates [ON/OFF] condition of ignition switch in ON position.
KEY ON SW Indicates [ON/OFF] condition of key switch.
ACC ON SW Indicates [ON/OFF] condition of ignition switch in ACC position.
KEYLESS LOCK Indicates [ON/OFF] condition of lock signal from key fob.
KEYLWSS UNLOCK Indicates [ON/OFF] condition of unlock signal from key fob.
KEYLESS PANIC Indicates [ON/OFF] condition of panic signal from key fob.
KEYLESS TRUNK This is displayed even when it is not equipped.
DOOR SW-DR Indicates [ON/OFF] condition of front door switch driver side.
DOOR SW-AS Indicates [ON/OFF] condition of door switch passenger side.
DOOR SW-RR Indicates [ON/OFF] condition of front door switch RH.
DOOR SW-RL Indicates [ON/OFF] condition of door switch LH.
BACK DOOR SW Indicates [ON/OFF] condition of back door switch.
TRUNK OPN MNTR This is displayed even when it is not equipped.
CDL LOCK SW Indicates [ON/OFF] condition of lock signal from door lock and unlock switch.
CDL UNLOCK SW Indicates [ON/OFF] condition of unlock signal from door lock and unlock switch.
RKE LCK-UNLOCK Indicates [ON/OFF] condition of simultaneous signal of lock and unlock from key fob.
RKE KEEP UNLK Indicates [ON/OFF] condition of unlock continuousness signal from key fob.
KEY CYL LK-SW Indicates [ON/OFF] condition of lock signal from door key cylinder switch.
KEY CYL UN-SW Indicates [ON/OFF] condition of unlock signal from door key cylinder switch.
Test Item Description
FLASHER This test is able to check right hazard reminder operation. The right hazard lamp turns on when “ON” on CONSULT-II screen is touched.
POWER WINDOW DOWN This test is able to check power window open operation.
The front power windows activate for 10 seconds after “ON” on CONSULT-II screen is touched.
HORN This test is able to check panic alarm and horn reminder operations. The horn activate for 0.5 seconds after “ON” on CONSULT-II screen is touched.
Page 877 of 4366
REMOTE KEYLESS ENTRY SYSTEM BL-65
C
D E
F
G H
J
K L
M A
B
BL
Revision: 2006 July 2007 FX35/FX45
Work Support
*: Perform this mode always in the state of C mode. Refer to BL-56, "Hazard and Horn Reminder" .
HORN CHIRP SET*
*: Perform this mode always in the state of C mode. Refer to BL-56, "Hazard and Horn Reminder" .
This mode can be changed also on the display.
HAZARD LAMP BACK SET*
*: Perform this mode always in the state of C mode. Refer to BL-56, "Hazard and Horn Reminder" .
This mode can be changed also on the display. DOOR LOCK This test is able to check door lock actuator operation.
The all door lock actuator are locked when “ALL LOCK” on CONSULT-II screen is touched.
The all door lock actuator are unlocked when “ALL UNLOCK” on CONSULT-II screen is touched.
The door lock actuator (driver side) is unlocked when “DR UNLOCK” on CONSULT-II screen is
touched.
The all door lock actuator (except driver side) are unlocked when “OTHER UNLOCK” on CON-
SULT-II screen is touched.
TRUNK/BACK DOOR This is displayed even when it is not equipped. Test Item Description
Test Item Description
HORN CHIRP SET* Horn reminder mode can be changed in this mode. The horn reminder mode will be
changed when “CHANGE SETT” on CONSULT-II screen is touched.
HAZARD LAMP SET* Hazard reminder mode can be changed in this mode. The hazard reminder mode will be
changed when “CHANGE SETT” on CONSULT-II screen is touched.
MULTI ANSWER BACK SET Hazard and horn reminder mode can be changed in this mode. The hazard and horn
reminder mode will be changed when “CHANGE SETT” on CONSULT-II screen is touched.
AUTO LOCK SET Auto locking function mode can be changed in this mode. The function mode will be
changed when “CHANGE SETT” on CONSULT-II screen is touched.
PANIC ALRM SET Panic alarm operation mode can be changed in this mode. The operation mode will be
changed when “CHANGE SETT” on CONSULT-II screen is touched.
PW DOWN SET Keyless power window down (open) operation mode can be changed in this mode. The
operation mode will be changed when“CHANGE SETT” on CONSULT-II screen is touched.
Horn chirp function ON OFF
MODE1 MODE2 MODE3 MODE4
Hazard lamp operation mode Nothing Unlock only Lock only Lock and Unlock
Page 878 of 4366
BL-66
REMOTE KEYLESS ENTRY SYSTEM
Revision: 2006 July 2007 FX35/FX45
MULTI ANSWER BACK SET
AUTO LOCK SET
PANIC ALARM SET
PW DOWN SET
Work FlowNIS001MQ
1. Check the symptom and customer's requests.
2. Understand outline of system. Refer to BL-55, "
System Description" .
3. Confirm that power door lock system operates normally. Refer to BL-21, "
POWER DOOR LOCK SYSTEM" .
4. Repair or replace any malfunctioning parts. Refer to BL-67, "
Trouble Diagnosis Chart by Symptom" .
5. INSPECTION END
MODE 1
(C mode) MODE 2
(S mode)
Key fob operation Lock Unlock Lock Unlock
Hazard warning lamp flash Twice Once Twice —
Horn sound Once — — —
MODE 1 MODE 2 MODE 3
Auto locking function 1 minutes Nothing 5 minutes
MODE 1 MODE 2 MODE 3
Key fob operation 0.5 seconds Nothing 1.5 seconds
MODE 1 MODE 2 MODE 3
Key fob operation 3 seconds Nothing 5 seconds
