TROUBLE DIAGNOSISAT-55
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
2. Park the vehicle on a level surface.
3. Move selector lever to “P” position.
4. Start the engine.
5. Move selector lever to “D” position.
6. Press the accelerator pedal about half-way down to accelerate the vehicle. With CONSULT-III
Read the gear positions. Refer to AT-84, "
CONSULT-III Function (TRANSMISSION)".
Starts from D
1?
YES >> GO TO 2.
NO >> Enter a check mark at AT-180, "
Vehicle Cannot Be Started from D1" on the “Diagnostic Worksheet
Chart”, then continue the road test.
2.CHECK SHIFT-UP D1 → D2
Press down the accelerator pedal about half-way and inspect if the vehicle shifts up (D1 → D2) at the appropri-
ate speed. Refer to AT-58, "
Vehicle Speed at Which Gear Shifting Occurs".
With CONSULT-III
Read the gear position, throttle degree of opening, and vehicle speed. Refer to AT-84, "
CONSULT-III Function
(TRANSMISSION)".
Does the A/T shift-up D
1 → D2 at the correct speed?
YES >> GO TO 3.
NO >> Enter a check mark at AT-182, "
A/T Does Not Shift: D1→ D2" on the “Diagnostic Worksheet
Chart”, then continue the road test.
3.CHECK SHIFT-UP D2 → D3
Press down the accelerator pedal about half-way and inspect if the vehicle shifts up (D2 → D3) at the appropri-
ate speed. Refer to AT-58, "
Vehicle Speed at Which Gear Shifting Occurs".
With CONSULT-III
Read the gear position, throttle degree of opening, and vehicle speed. Refer to AT-84, "
CONSULT-III Function
(TRANSMISSION)".
Does the A/T shift-up D
2 → D3 at the correct speed?
YES >> GO TO 4.
NO >> Enter a check mark at AT-184, "
A/T Does Not Shift: D2→ D3" on the “Diagnostic Worksheet
Chart”, then continue the road test.
4.CHECK SHIFT-UP D3 → D4
Press down the accelerator pedal about half-way and inspect if the vehicle shifts up (D3 → D4) at the appropri-
ate speed. Refer to AT-58, "
Vehicle Speed at Which Gear Shifting Occurs".
With CONSULT-III
Read the gear position, throttle degree of opening, and vehicle speed. Refer to AT-84, "
CONSULT-III Function
(TRANSMISSION)".
Does the A/T shift-up D
3 → D4 at the correct speed?
YES >> GO TO 5.
NO >> Enter a check mark at AT-186, "
A/T Does Not Shift: D3→ D4" on the “Diagnostic Worksheet
Chart”, then continue the road test.
5.CHECK SHIFT-UP D4 → D5
Press down the accelerator pedal about half-way and inspect if the vehicle shifts up (D4 → D5) at the appropri-
ate speed. Refer to AT-58, "
Vehicle Speed at Which Gear Shifting Occurs".
With CONSULT-III
Read the gear position, throttle degree of opening, and vehicle speed. Refer to AT-84, "
CONSULT-III Function
(TRANSMISSION)".
Does the A/T shift-up D
4 → D5 at the correct speed?
YES >> GO TO 6.
NO >> Enter a check mark at AT-188, "
A/T Does Not Shift: D4→ D5" on the “Diagnostic Worksheet
Chart”, then continue the road test.
6.CHECK LOCK-UP
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 129 of 3924

AT-56
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
When releasing accelerator pedal from D5, check lock-up from D5 to L/U. Refer to AT-58, "Vehicle Speed at
Which Lock-up Occurs/Releases".
With CONSULT-III
Select “TCC SOLENOID” with the “DATA MONI TOR” mode for “TRANSMISSION”. Refer to AT-84, "
CON-
SULT-III Function (TRANSMISSION)".
Does it lock-up?
YES >> GO TO 7.
NO >> Enter a check mark at AT-190, "
A/T Does Not Lock-up" on the “Diagnostic Worksheet Chart”, then
continue the road test.
7.CHECK LOCK-UP HOLD
Check hold lock-up. With CONSULT-III
Select “TCC SOLENOID” with the “DATA MONI TOR” mode for “TRANSMISSION”. Refer to AT-84, "
CON-
SULT-III Function (TRANSMISSION)".
Does it maintain lock-up status?
YES >> GO TO 8.
NO >> Enter a check mark at AT-192, "
A/T Does Not Hold Lock-up Condition" on the “Diagnostic Work-
sheet Chart”, then continue the road test.
8.CHECK LOCK-UP RELEASE
Check lock-up cancellation by depressing brake pedal lightly to decelerate. With CONSULT-III
Select “TCC SOLENOID” with the “DATA MONI TOR” mode for “TRANSMISSION”. Refer to AT-84, "
CON-
SULT-III Function (TRANSMISSION)".
Does lock-up cancel?
YES >> GO TO 9.
NO >> Enter a check mark at AT-194, "
Lock-up Is Not Released" on the “Diagnostic Worksheet Chart”,
then continue the road test.
9.CHECK SHIFT-DOWN D5 → D4
Decelerate by pressing lightly on the brake pedal.
With CONSULT-III
Read the gear position and engine speed. Refer to AT-84, "
CONSULT-III Function (TRANSMISSION)".
When the A/T shift-down D
5 → D4, does the engine speed drop smoothly back to idle?
YES >> 1. Stop the vehicle. 2. Go to AT-53, "
Road Test".
NO >> Enter a check mark at AT-194, "
Engine Speed Does Not Return to Idle" on the “Diagnostic Work-
sheet Chart”, then continue the road test. Go to AT-53, "
Road Test".
CRUISE TEST - PART 2
1.CHECK STARTING FROM D1
1. Move selector lever into “D” position.
2. Accelerate at half throttle.
With CONSULT-III
Read the gear position. Refer to AT-84, "
CONSULT-III Function (TRANSMISSION)".
Does it start from D
1?
YES >> GO TO 2.
NO >> Enter a check mark at AT-180, "
Vehicle Cannot Be Started from D1" on the “Diagnostic Worksheet
Chart”, then continue the road test.
2.CHECK SHIFT-UP D1 → D2
Press the accelerator pedal down all the way and check whether or not the A/T shifts up (D1 → D2) at the cor-
rect speed. Refer to AT-58, "
Vehicle Speed at Which Gear Shifting Occurs".
With CONSULT-III
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 140 of 3924

TROUBLE DIAGNOSISAT-67
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
23
Slips/Will
Not En-
gage Vehicle cannot be
started from D
1.
Refer to AT- 1 8 0 , "
Ve-
hicle Cannot Be Start-
ed from D1". ON vehicle
1. A/T fluid level and state
AT- 4 9
2. Accelerator pedal position sensorAT- 1 3 0
3. Line pressure test AT- 4 9
4. CAN communication lineAT- 9 4
5. Control valve with TCMAT- 2 1 5
OFF vehicle6. Torque converter
AT- 2 6 7
7. Oil pump assemblyAT- 2 8 5
8. 3rd one-way clutchAT- 2 8 7
9. 1st one-way clutch AT- 2 9 5
10. Gear systemAT- 2 4 9
11. Reverse brakeAT- 2 6 7
12. Forward one-way clutch (Parts behind drum support is im-
possible to perform inspection by disassembly. Refer to AT-
16, "Cross-Sectional View (2WD Models)", AT- 1 7 , "Cross-
Sectional View (VQ35DE Models for AWD)" or AT- 1 8 , "Cross-
Sectional View (VK45DE Models for AWD)") AT- 2 6 7
13. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to
AT- 1 6 , "
Cross-
Sectional View (2WD Models)", AT- 1 7 , "Cross-Sectional View
(VQ35DE Models for AWD)" or AT- 1 8 , "Cross-Sectional View
(VK45DE Models for AWD)") AT- 2 6 7
24
Does not lock-up.
Refer to
AT- 1 9 0 , "A/T
Does Not Lock-up".ON vehicle 1. A/T fluid level and state
AT- 4 9
2. Line pressure testAT- 4 9
3. Engine speed signalAT- 11 2
4. Turbine revolution sensorAT- 1 0 6
5. Torque converter clutch solenoid valveAT- 1 2 4
6. CAN communication line AT- 9 4
7. Control valve with TCMAT- 2 1 5
OFF vehicle8. Torque converter
AT- 2 6 79. Oil pump assemblyAT- 2 8 5
25Does not hold lock-up
condition.
Refer to
AT- 1 9 2 , "A/T
Does Not Hold Lock-
up Condition". ON vehicle 1. A/T fluid level and state
AT- 4 9
2. Line pressure testAT- 4 9
3. Engine speed signalAT- 11 2
4. Turbine revolution sensorAT- 1 0 6
5. Torque converter clutch solenoid valveAT- 1 2 4
6. CAN communication line AT- 9 4
7. Control valve with TCMAT- 2 1 5
OFF vehicle8. Torque converter
AT- 2 6 79. Oil pump assemblyAT- 2 8 5
No. Items Symptom Condition Diagnostic Item Reference
page
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 146 of 3924

TROUBLE DIAGNOSISAT-73
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
36
Slips/Will
Not En-
gage With selector lever in
“R” position
, accelera-
tion is extremely poor. ON vehicle1. A/T fluid level and state
AT- 4 9
2. Line pressure testAT- 4 9
3. Accelerator pedal position sensorAT- 1 3 0
4. High and low reverse clutch solenoid valveAT- 1 4 9
5. CAN communication line AT- 9 4
6. PNP switchAT- 1 0 2
7. A/T positionAT- 2 0 7
8. Control valve with TCMAT- 2 1 5
OFF vehicle9. Gear system
AT- 2 4 910. Output shaft AT- 2 6 7
11. Reverse brakeAT- 2 6 7
37While starting off by
accelerating in 1st, en-
gine races or slippage
occurs. ON vehicle
1. A/T fluid level and state
AT- 4 9
2. Line pressure testAT- 4 9
3. Accelerator pedal position sensorAT- 1 3 0
4. CAN communication line AT- 9 4
5. Control valve with TCMAT- 2 1 5
OFF vehicle6. Torque converter
AT- 2 6 7
7. Oil pump assemblyAT- 2 8 5
8. 3rd one-way clutchAT- 2 8 7
9. 1st one-way clutchAT- 2 9 5
10. Gear systemAT- 2 4 9
11. Reverse brakeAT- 2 6 7
12. Forward one-way clutch (Parts behind drum support is im-
possible to perform inspection by disassembly. Refer to AT-
16, "Cross-Sectional View (2WD Models)", AT- 1 7 , "Cross-
Sectional View (VQ35DE Models for AWD)" or AT- 1 8 , "Cross-
Sectional View (VK45DE Models for AWD)") AT- 2 6 7
13. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to
AT- 1 6 , "
Cross-
Sectional View (2WD Models)", AT- 1 7 , "Cross-Sectional View
(VQ35DE Models for AWD)" or AT- 1 8 , "Cross-Sectional View
(VK45DE Models for AWD)") AT- 2 6 7
No. Items Symptom Condition Diagnostic Item
Reference
page
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 156 of 3924

TROUBLE DIAGNOSISAT-83
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
TCM Input/Output Signal Reference ValueINFOID:0000000001327162
A/T ASSEMBLY HARNESS CONNECTOR TERMINAL LAYOUT
TCM INSPECTION TABLE
68
Others Engine does not start
in “N” or “P” position.
Refer to
AT- 1 7 0 , "En-
gine Cannot Be Start-
ed in "P" or "N"
Position". ON vehicle
1. Ignition switch and starter
PG-3
,
SC-
8
2. A/T position AT- 2 0 7
3. PNP switchAT- 1 0 2
69Engine starts in posi-
tions other than “N” or
“P”. ON vehicle1. Ignition switch and starter
PG-3
,
SC-
8
2. A/T position AT- 2 0 7
3. PNP switchAT- 1 0 2
70 Engine stall.ON vehicle1. A/T fluid level and state
AT- 4 9
2. Engine speed signalAT- 11 2
3. Turbine revolution sensorAT- 1 0 6
4. Torque converter clutch solenoid valveAT- 1 2 4
5. CAN communication line AT- 9 4
6. Control valve with TCMAT- 2 1 5
OFF vehicle 7. Torque converter AT- 2 6 7
71Engine stalls when se-
lector lever shifted “N”
→
“D”, “R”. ON vehicle1. A/T fluid level and state
AT- 4 9
2. Engine speed signalAT- 11 2
3. Turbine revolution sensorAT- 1 0 6
4. Torque converter clutch solenoid valveAT- 1 2 4
5. CAN communication line AT- 9 4
6. Control valve with TCMAT- 2 1 5
OFF vehicle 7. Torque converter AT- 2 6 7
72Engine speed does
not return to idle.
Refer to
AT- 1 9 4 , "En-
gine Speed Does Not
Return to Idle". ON vehicle 1. A/T fluid level and state
AT- 4 9
2. Direct clutch solenoid valveAT- 1 4 7
3. Front brake solenoid valve AT- 1 4 5
4. Accelerator pedal position sensorAT- 1 3 0
5. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 1 3 7
6. CAN communication line AT- 9 4
7. Control valve with TCMAT- 2 1 5
OFF vehicle8. Front brake (brake band)
AT- 2 6 79. Direct clutchAT- 3 0 3
No. Items Symptom Condition Diagnostic Item Reference
page
SCIA1658E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 157 of 3924

AT-84
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
Data are reference value and are measured between each terminal and ground.
CONSULT-III Function (TRANSMISSION)INFOID:0000000001327163
CONSULT-III can display each diagnostic item us ing the diagnostic test models shown following.
FUNCTION
CONSULT-III REFERENCE VALUE
NOTICE:
1. The CONSULT-III electrically displays shift timi ng and lock-up timing (that is, operation timing of each
solenoid).
Check for time difference between actual shift timi ng and the CONSULT-III display. If the difference is
noticeable, mechanical parts (except solenoids, sens ors, etc.) may be malfunctioning. Check mechanical
parts using applicable diagnostic procedures.
2. Shift schedule (which implies gear position) display ed on CONSULT-III and that indicated in Service Man-
ual may differ slightly. This occurs because of the following reasons:
- Actual shift schedule has more or less tolerance or allowance,
- Shift schedule indicated in Service Manual refers to the point where shifts start, and
- Gear position displayed on CONSULT-III indicates the point where shifts are completed.
Te r m i n a l Wire
color Item Condition Data (Approx.)
1LG Power supply
(Memory back-up) Always Battery voltage
2LG Power supply
(Memory back-up)
Always Battery voltage
3 L CAN-H – –
4PU K-line (CONSULT-
III signal) The terminal is connected to the data link connector for CONSULT-III. –
5 B Ground – –
6YPower supply – Battery voltage
–0 V
7OR Back-up lamp re-
lay Selector lever in “R” position. 0 V
Selector lever in other positions. Battery voltage
8 P CAN-L – –
9 GY Starter relay Selector lever in “N” and “P
” positions. Battery voltage
Selector lever in other positions. 0 V
10 B Ground – –
Diagnostic test mode Function
Work support This mode enables a technician to adjust some devices faster and more accurately by following the in-
dications on CONSULT-III.
Self-diagnostic results Self-diagnostic results can be read and erased quickly.
Data monitor Input/Output data in the ECU can be read.
CAN diagnostic support mon-
itor The results of transmit/receive diagnosis of CAN communication can be read.
Function test Performed by CONSULT-III instead of a technician to determine whether each system is “OK” or “NG”.
DTC work support Select the operating condition to confirm Diagnosis Trouble Codes.
ECU part number TCM part number can be read.
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 158 of 3924

TROUBLE DIAGNOSISAT-85
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
3. Display of solenoid valves on CONSULT-III changes at t he start of shifting, while gear position is displayed
upon completion of shifting (which is computed by TCM).
Item name Condition Display value (Approx.)
ATF TEMP SE 1 0°C (32 °F) − 20 °C (68 °F) − 80 °C (176 °F) 3.3
− 2.7 − 0.9 V
ATF TEMP SE 2 3.3 − 2.5 − 0.7 V
ATF TEMP 1 Ignition switch ON Measured ATF temperature is dis-
played.
TCC SOLENOID Lock-up is active 0.4 − 0.6 A
SLCT LVR POSI Selector lever in “N
” and “P” positions. N/P
Selector lever in “R” position. R
Selector lever in “D” position. D
VHCL/S SE-A/T During driving Approximately matches the speedom-
eter reading.
VEHICLE SPEED During driving Approximately matches the speedom-
eter reading.
ENGINE SPEED Engine running Closely matches the tachometer read-
ing.
LINE PRES SOL During driving 0.2 − 0.6 A
TURBINE REV During driving (lock-up ON) Approximately matches the engine
speed.
VHCL/S SE-MTR During driving Approximately matches the speedom-
eter reading.
ATF PRES SW 2 Low coast brake engaged. Refer to
AT- 1 8
.ON
Low coast brake disengaged. Refer to AT- 1 8
. OFF
I/C SOLENOID Input clutch disengaged. Refer to
AT- 1 8
.0.6 − 0.8 A
Input clutch engaged. Refer to AT- 1 8
.0 − 0.05 A
FR/B SOLENOID Front brake engaged. Refer to
AT- 1 8
.0.6 − 0.8 A
Front brake disengaged. Refer to AT- 1 8
. 0 − 0.05 A
D/C SOLENOID Direct clutch disengaged. Refer to
AT- 1 8
.0.6 − 0.8 A
Direct clutch engaged. Refer to AT- 1 8
.0 − 0.05 A
HLR/C SOL High and low reverse clutch disengaged. Refer to
AT- 1 8
.0.6 − 0.8 A
High and low reverse clutch engaged. Refer to AT- 1 8
.0 − 0.05 A
ON OFF SOL Low coast brake engaged. Refer to
AT- 1 8
.ON
Low coast brake disengaged. Refer to AT- 1 8
.OFF
MANU MODE SW Manual shift gate position (neutral) ON
Other than the above OFF
NON M-MODE SW Manual shift gate position OFF
Other than the above ON
UP SW LEVER Selector lever: + side ON
Other than the above OFF
DOWN SW LEVER Selector lever: - side ON
Other than the above OFF
STARTER RELAY Selector lever in “N
” and “P” positions. ON
Selector lever in other positions. OFF
ACCELE POSI Released accelerator pedal. 0.0/8
Fully depressed accelerator pedal. 8.0/8
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 159 of 3924

AT-86
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
SELF-DIAGNOSTIC RESULT MODE
After performing “SELF-DIAGNOSTIC RESULT MODE”, place check marks for results on the AT-42, "How to
Perform Trouble Diagnosis for Quick and Accurate Repair". Reference pages are provided following the items.
Display Items List
X: Applicable, —: Not applicable
CLSD THL POSReleased accelerator pedal. ON
Fully depressed accelerator pedal. OFF
W/O THL POS Fully depressed accelerator pedal. ON
Released accelerator pedal. OFF
BRAKE SW Depressed brake pedal. ON.
Released brake pedal. OFF
GEAR During driving. 1,2,3,4,5, Item name Condition Display value (Approx.)
Items (CONSULT-
III screen terms) Malfunction is detected when... TCM self-di-
agnosis OBD-II
(DTC)
Reference page
“TRANS-
MISSION”
with CON- SULT-III MIL indica-
tor lamp(*1),
“ENGINE”
with CON-
SULT-III or GST
CAN COMM CIR-
CUIT When TCM is not transmitting or receiving CAN communication sig-
nal for 2 seconds or more.
U1000 U1000
AT- 9 4
STARTER RELAY/
CIRCIf this signal is ON other than in “P” or “N” position, this is judged to
be a malfunction.
(And if it is OFF in “P” or “N” position, this too is judged to be a mal-
function.)
P0615 —
AT- 9 7
TCM TCM is malfunctioning. P0700 P0700 AT- 1 0 1
PNP SW/CIRC PNP switch 1-4 signals input with impossible pattern.
“P” position is detected from “N” position without any other posi-
tion being detected in between. P0705 P0705
AT- 1 0 2
TURBINE REV S/
CIRC TCM does not receive the proper voltage signal from the sensor.
TCM detects an irregularity only at position of 4th gear for turbine
revolution sensor 2. P0717 P0717
AT- 1 0 6
VEH SPD SEN/CIR
AT Signal from vehicle speed sensor A/T (Revolution sensor) not in-
put due to cut line or the like.
Unexpected signal input during running.
After ignition switch is turned ON, unexpected signal input from vehicle speed sensor MTR before the vehicle starts moving. P0720 P0720
AT- 1 0 8
ENGINE SPEED
SIGTCM does not receive the CAN communication signal from the
ECM.
P0725 P0725
AT- 11 2
A/T 1ST GR
FNCTNA/T cannot shift to 1st gear. P0731 P0731
AT- 11 4
A/T 2ND GR
FNCTNA/T cannot shift to 2nd gear. P0732 P0732
AT- 11 6
A/T 3RD GR
FNCTNA/T cannot shift to 3rd gear. P0733 P0733
AT- 11 8
A/T 4TH GR
FNCTNA/T cannot shift to 4th gear. P0734 P0734
AT- 1 2 0
A/T 5TH GR
FNCTNA/T cannot shift to 5th gear. P0735 P0735
AT- 1 2 2
TCC SOLENOID/
CIRCNormal voltage not applied to solenoid due to cut line, short, or the
like.
P0740 P0740
AT- 1 2 4
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 163 of 3924

AT-90
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
R POSI IND (ON/OFF) — —
N POSI IND (ON/OFF) — —
D POSI IND (ON/OFF) — —
4TH POSI IND (ON/OFF) — —
3RD POSI IND (ON/OFF) — —
2ND POSI IND (ON/OFF) — —
1ST POSI IND (ON/OFF) — —
MANU MODE IND (ON/OFF) — —
POWER M LAMP (ON/OFF) — —
F-SAFE IND/L (ON/OFF) — —
ATF WARN LAMP (ON/OFF) — — Not mounted but displayed
BACK-UP LAMP (ON/OFF) — —
STARTER RELAY (ON/OFF) — —
PNP SW3 MON (ON/OFF) — —
C/V CLB ID1 — —
C/V CLB ID2 — —
C/V CLB ID3 — —
UNIT CLB ID1 — —
UNIT CLB ID2 — —
UNIT CLB ID3 — —
TRGT GR RATIO — —
TRGT PRES TCC (kPa) — —
TRGT PRES L/P (kPa) — —
TRGT PRES I/C (kPa) — —
TRGT PRE FR/B (kPa) — —
TRGT PRES D/C (kPa) — —
TRG PRE HLR/C (kPa) — —
SHIFT PATTERN — —
DRV CST JUDGE — —
START RLY MON — —
NEXT GR POSI — —
SHIFT MODE — —
MANU GR POSI — —
VEHICLE SPEED (km/h) — X Vehicle sp eed recognized by the TCM.
Monitored item (Unit)
Select Monitor Item
Remarks
ECU IN-
PUT SIG- NALS MAIN SIG-
NALS SELEC-
TION
FROM
MENU
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 164 of 3924

TROUBLE DIAGNOSISAT-91
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
DTC WORK SUPPORT MODE
Display Items List
Diagnosis Procedure without CONSULT-IIIINFOID:0000000001327164
OBD-II SELF-DIAGNOSTIC PROCEDURE (WITH GST)
Refer to EC-125, "Generic Scan Tool (GST) Function" (for VQ35DE) or EC-704, "Generic Scan Tool (GST)
Function" (for VK45DE).
OBD-II SELF-DIAGNOSTIC PROCEDURE (NO TOOLS)
Refer to EC-71, "Malfunction Indicator Lamp (MIL)" (for VQ35DE) or EC-649, "Malfunction Indicator Lamp
(MIL)" (for VK45DE).
TCM SELF-DIAGNOSTIC PROCEDURE (NO TOOLS)
Description
When the ignition switch is turned ON, the indicator la mp lights up for 2 seconds. As a method for locating the
suspect circuit, when the self-diagnostics start signal is input, the memory for the malfunction location is output
and the A/T CHECK indicator lamp flashes to display the corresponding DTC.
Diagnostic Procedure
Voltage (V) — — Displays the value measured by the voltage
probe.
Frequency (Hz) — —
The value measured by the pulse probe is dis-
played.
DUTY-HI (high) (%) — —
DUTY-LOW (low) (%) — —
PLS WIDTH-HI (ms) — —
PLS WIDTH-LOW (ms) — — Monitored item (Unit)
Select Monitor Item
Remarks
ECU IN-
PUT SIG- NALS MAIN SIG-
NALS SELEC-
TION
FROM
MENU
DTC work support item Description Check item
1ST GR FUNCTN P0731 Following items for “1st gear function” can be confirmed.
Self-diagnosis status (whether the diagnosis is being performed
or not)
Self-diagnostic results (OK or NG)
Input clutch solenoid valve
Front brake solenoid valve
Direct clutch solenoid valve
High and low reverse clutch solenoid valve
Each clutch
Hydraulic control circuit
2ND GR FUNCTN P0732
Following items for “2nd gear function” can be confirmed.
Self-diagnosis status (whether the diagnosis is being performed
or not)
Self-diagnostic results (OK or NG)
3RD GR FUNCTN P0733 Following items for “3rd gear function” can be confirmed.
Self-diagnosis status (whether the diagnosis is being performed
or not)
Self-diagnostic results (OK or NG)
4TH GR FUNCTN P0734 Following items for “4th gear function” can be confirmed.
Self-diagnosis status (whether the diagnosis is being performed
or not)
Self-diagnostic results (OK or NG)
5TH GR FUNCTN P0735 Following items for “5th gear function” can be confirmed.
Self-diagnosis status (whether the diagnosis is being performed
or not)
Self-diagnostic results (OK or NG)
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
