radio controls INFINITI FX35 2008 Service Manual

EC-28
< SERVICE INFORMATION >[VQ35DE]
PRECAUTIONS

B1 indicates the bank 1, B2 indicates the bank 2 as shown in
the figure.
 Do not operate fuel pump when there is no fuel in lines.
 Tighten fuel hose clamps to the specified torque.
 Do not depress accelerator pedal when starting.
 Immediately after starting, do not rev up engine unnecessar-
ily.
 Do not rev up engine just prior to shutdown.
 When installing C.B. ham radio or a mobile phone, be sure to
observe the following as it m ay adversely affect electronic
control systems depending on installation location.
- Keep the antenna as far as possi ble from the electronic con-
trol units.
- Keep the antenna feeder line more than 20 cm (8 in) away
from the harness of electronic controls.
Do not let them run parallel for a long distance.
- Adjust the antenna and feeder line so that the standing-wave
radio can be kept smaller.
- Be sure to ground the radio to vehicle body.
SEC893C
PBIB1569E
SEF709Y
SEF708Y
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

EC-606
< SERVICE INFORMATION >[VK45DE]
PRECAUTIONS

B1 indicates the bank 1, B2 indicates the bank 2 as shown in
the figure.
 Do not operate fuel pump when there is no fuel in lines.
 Tighten fuel hose clamps to the specified torque.
 Do not depress accelerator pedal when starting.
 Immediately after starting, do not rev up engine unnecessar-
ily.
 Do not rev up engine just prior to shutdown.
 When installing C.B. ham radio or a mobile phone, be sure to
observe the following as it m ay adversely affect electronic
control systems depending on installation location.
- Keep the antenna as far as possi ble from the electronic con-
trol units.
- Keep the antenna feeder line more than 20 cm (8 in) away
from the harness of electronic controls.
Do not let them run parallel for a long distance.
- Adjust the antenna and feeder line so that the standing-wave
radio can be kept smaller.
- Be sure to ground the radio to vehicle body.
PBIB1144E
PBIB1508E
SEF709Y
SEF708Y
