engine INFINITI G35 2006 User Guide

The odometer records the total distance
the vehicle has been driven.
The twin trip odometer records the dis-
tance of individual trips.
Changing the display:
Pushing the trip odometer reset switch
q 3
changes the display as follows.
AT models:
TRIP A ! TRIP B ! TRIP A
MT models:
TRIP A ! TRIP B ! Up-shift indicator set-
ting mode ! TRIP A
See ªDriving the vehicleº in the ª5. Start-
ing and drivingº section for the use of the
up-shift indicator.
Resetting the trip odometer:
Pushing the trip odometer reset switch for
more than 1 second resets the trip odom-
eter to zero.
TACHOMETER The tachometer indicates engine speed in
revolutions per minute (rpm). Do not rev
the engine into the red zone
q A
.
CAUTION When engine speed approaches the red
zone, shift to a higher gear. Operating the
engine in the red zone may cause serious en-
gine damage. ENGINE COOLANT TEMPERATURE
GAUGE The gauge indicates the engine coolant
temperature.
The engine coolant temperature is within
the normal range
q A
when the gauge
needle points within the zone shown in
the illustration.
The engine coolant temperature will vary
with the outside air temperature and driv-
ing conditions. SIC2560 SIC2561
2-4 Instruments and controls
w 06.1.4/V35-D/V5.0
X

CAUTIONIf the gauge indicates engine coolant tem-
perature near the hot (H) of the normal
range, reduce vehicle speed to decrease
temperature. If gauge is over the normal
range, stop the vehicle as soon as safely
possible. If the engine is overheated, contin-
ued operation of the vehicle may seriously
damage the engine. See ªIf your vehicle
overheatsº in the ª6. In case of emergencyº
section for immediate action required.
FUEL GAUGE The gauge indicates the approximate fuel
level in the tank.
The gauge may move slightly during brak-
ing, turning, acceleration, or going up or
down hill.
The gauge needle is designed to move to
the E (Empty) position when the ignition
key is turned to the OFF position.
Refill the fuel tank before the gauge regis-
ters the E (Empty) position. The low fuel warning light comes on when
the fuel tank is getting low. Refuel as soon
as it is convenient, preferably before the
gauge reaches the E (Empty) position.
There will be a small reserve of fuel in the
tank when the fuel gauge needle reaches
the E (Empty) position.
The indicates that the fuel-filler door
is located on the passenger's side of the
vehicle.
CAUTION O If the vehicle runs out of fuel, the
malfunction indicator lamp (MIL)
may come on. Refuel as soon as pos-
sible. After a few driving trips, the
lamp should turn off. If the lamp
remains on after a few driving trips, have
the vehicle inspected by an INFINITI
dealer.
O For additional information, see ªMal-
function indicator lamp (MIL)º later in
this section. SIC2562
Instruments and controls
2-5
w 06.1.4/V35-D/V5.0
X

All-wheel drive (AWD) warning light (AWD
models) Low tire pressure warning light Cruise set switch indicator light
or
Anti-lock brake warning light Low washer fluid warning light Front passenger air bag status light
Automatic transmission check warning
light P position selecting warning light (for
Intelligent Key system) High beam indicator light (Blue)
or Brake warning light Rear Active Steer (RAS) warning light (if
so equipped) Malfunction indicator lamp (MIL)
Charge warning light Seat belt warning light Slip indicator light
Door open warning light Supplemental air bag warning light Snow mode indicator light (if so
equipped)
Engine oil pressure warning light Automatic transmission position indicator
light Turn signal/hazard indicator lights
Intelligent Key warning light (for Intelli-
gent Key system) Cruise main switch indicator light Vehicle Dynamic Control (VDC) off indica-
tor light
Low fuel warning light
CHECKING BULBS Apply the parking brake and turn the igni-
tion key to ON without starting the en-
gine. The following lights will come on:
, or , , ,
The following lights come on briefly and
then go off:
, or , , , , , , ,
If any light fails to come on, it may indi-
cate a burned-out bulb or an open circuit
in the electrical system. Have the system
repaired promptly.
WARNING LIGHTS
All-wheel drive (AWD)
warning light (AWD models) The light comes on when the ignition
switch is turned to ON. It turns off soon
after the engine is started.WARNING/INDICATOR LIGHTS AND
AUDIBLE REMINDERS
Instruments and controls
2-9
w 06.1.4/V35-D/V5.0
X

If the AWD system malfunctions, or the di-
ameter of the front and the rear wheels
are different, the warning light will either
remain illuminated or blink. See ªAll-
wheel drive (AWD) warning lightº in the
ª5. Starting and drivingº section.
CAUTIONO If the warning light comes on while
driving there may be a malfunction in the
AWD system. Reduce the vehicle speed
and have your vehicle checked by an
INFINITI dealer as soon as possible.
O Do not drive on dry, hard surface roads in
the SNOW mode.
O If the AWD warning light blinks on when
you are driving:
· blinks rapidly (about twice a second):
Pull off the road in a safe area, and
idle the engine. The driving mode will
change to 2WD to prevent the AWD
system from malfunctioning.
If the warning light turns off, you can
drive again. · blinks slowly (about once every 2 sec-
onds):
Pull off the road in a safe area, and
idle the engine. Check that all tire
sizes are the same, tire pressure is
correct and tires are not worn.
If the warning light is still on after the above
operations, have your vehicle checked by an
INFINITI dealer as soon as possible.
or Anti-lock brake
warning lightWhen the ignition switch is turned to the
ON position, the anti-lock brake warning
light will illuminate and then turn off. This
indicates the anti-lock brake system (ABS)
is operational.
If the light comes on while the engine is
running, it may indicate the anti-lock
brake system is not functioning properly.
Have the system checked by an INFINITI
dealer.
If a malfunction occurs in the system, the
anti-lock function of the brake will cease
operation but the ordinary brakes will
continue to operate. See ªAnti-lock brake system (ABS)º in the ª5. Starting and
drivingº section for further details.
If the light comes on while you are driving,
contact an INFINITI dealer for repair.
Automatic transmission
check warning light When the ignition switch is turned to the
ON position, the automatic transmission
check warning light comes on and then
turns off. This indicates that the auto-
matic transmission system is operational.
If the light comes on while the engine is
running or while driving, it may indicate
that the automatic transmission system is
not functioning properly. Have an INFINITI
dealer check and repair the transmission.
or Brake warning
light The brake warning light indicates the
parking brake system operation, low
brake fluid level of the brake system and
Anti-lock Brake System (ABS) malfunction.
Parking brake indicator:
When the ignition switch is in the ON po-
sition, the light comes on when the park-
ing brake is applied.
2-10 Instruments and controls
w 06.1.4/V35-D/V5.0
X

Low brake fluid warning light:
The light warns of a low brake fluid level.
If the light comes on while the engine is
running with the parking brake not ap-
plied, stop the vehicle and perform the
following:
1. Check the brake fluid level. Add brake
fluid as necessary. See ªBrake fluidº
in the ª8. Maintenance and do-it-
yourselfº section.
2. If the brake fluid level is correct, have
the warning system checked by an
INFINITI dealer.
Anti-lock Brake System (ABS) warning
indicator:
When the parking brake is released and
the brake fluid level is sufficient, if both
the brake warning light and the anti-lock
brake system warning light illuminate, it
may indicate the anti-lock brake system is
not functioning properly. Have the brake
system checked by an INFINITI dealer. See
ªAnti-lock brake warning lightº earlier in
this section. WARNING O Your brake system may not be working
properly if the warning light is on.
Driving could be dangerous. If you judge
it to be safe, drive carefully to the
nearest service station for repairs. Oth-
erwise, have your vehicle towed because
driving it could be dangerous.
O Pressing the brake pedal with the engine
stopped and/or a low brake fluid level
may increase your stopping distance
and braking will require greater pedal ef-
fort as well as pedal travel.
O If the brake fluid level is below the MINI-
MUM or MIN mark on the brake fluid res-
ervoir, do not drive until the brake
system has been checked by an INFINITI
dealer.
Charge warning light If the light comes on while the engine is
running, it may indicate that the charging
system is not functioning properly. Turn
the engine off and check the alternator belt. If the belt is loose, broken, missing
or if the light remains on, see an INFINITI
dealer immediately.
CAUTION Do not continue driving if the generator belt
is loose, broken or missing.
Door open warning light This light comes on when any of the
doors are not closed securely while the
ignition switch is in the ON position.
Engine oil pressure warning
light This light warns of low engine oil pres-
sure. If the light flickers or comes on dur-
ing normal driving, pull off the road in a
safe area, stop the engine immediately
and call an INFINITI dealer or other autho-
rized repair shop.
The engine oil pressure warning light is
not designed to indicate a low oil level.
Use the dipstick to check the oil level. See
ªEngine oilº in the ª8. Maintenance and
do-it-yourselfº section.
Instruments and controls
2-11
w 06.1.4/V35-D/V5.0
X

CAUTIONRunning the engine with the engine oil pres-
sure warning light on could cause serious
damage to the engine almost immediately.
Turn off the engine as soon as it is safe to do
so.
Intelligent Key warning light
(for Intelligent Key system)This light comes on in green when it is
possible to turn the ignition switch.
When the light comes on in red, it is not
possible to turn the switch.
O The warning light blinks in red when
the Intelligent Key is outside the ve-
hicle with the ignition switch in the
ACC or ON position. Confirm the loca-
tion of the key as soon as possible
when the warning light blinks in red.
Be sure to carry the Intelligent Key
with you while driving the vehicle.
O The warning light goes off about 10
seconds after the Intelligent Key is
brought inside the vehicle. Low fuel warning light This light comes on when the fuel in the
tank is getting low. Refuel as soon as it is
convenient, preferably before the fuel
gauge reaches the E (Empty) position.
There will be a small reserve of fuel re-
maining in the fuel tank when the fuel
gauge needle reaches the E (Empty) posi-
tion.
Low tire pressure warning
light Your vehicle is equipped with a tire pres-
sure monitoring system (TPMS) that moni-
tors the tire pressure of all tires except
the spare.
The low tire pressure warning light warns
of low tire pressure or indicates that the
TPMS is not functioning properly.
After the ignition switch is turned ON, this
light illuminates for about 1 second and
turns off.
Low tire pressure warning:
If the vehicle is being driven with low tire
pressure, the warning light will illuminate.
When the low tire pressure warning light
illuminates, you should stop and adjust the tire pressure to the recommended
COLD tire pressure shown on the Tire and
Loading Information label to turn the light
OFF.
For additional information, see ªTire pres-
sure monitoring system (TPMS)º in the ª5.
Starting and drivingº section and in the
ª6. In case of emergencyº section.
TPMS malfunction:
If the TPMS is not functioning properly,
the low tire pressure warning light will
flash for approximately 1 minute when the
ignition switch is turned ON. The light will
remain on after the 1 minute. Have the
system checked by an INFINITI dealer.
For additional information, see ªTire pres-
sure monitoring system (TPMS)º in the ª5.
Starting and drivingº section.
WARNING O If the light does not illuminate with the
ignition switch turned ON, have the ve-
hicle checked by an INFINITI dealer as
soon as possible.
2-12 Instruments and controls
w 06.1.4/V35-D/V5.0
X

O If the light illuminates while driving,
avoid sudden steering maneuvers or
abrupt braking, reduce vehicle speed,
pull off the road to a safe location and
stop the vehicle as soon as possible. Se-
rious vehicle damage could occur and
may lead to an accident and could result
in serious personal injury. Check the tire
pressure for all four tires. Adjust the tire
pressure to the recommended COLD tire
pressure shown on the Tire and Loading
Information label to turn the low tire
pressure warning light OFF. If the light
still comes on while driving after ad-
justing the tire pressure, a tire may be
flat. If you have a flat tire, replace it with
a spare tire as soon as possible.
O
When a spare tire is mounted or a wheel is
replaced, tire pressure will not be indicated,
the TPMS will not function and the low tire
pressure warning light will flash. Contact
your INFINITI dealer as soon as possible for
tire replacement and/or system resetting.
O Replacing tires with those not originally
specified by INFINITI could affect the
proper operation of the TPMS. CAUTION O The TPMS is not a substitute for the
regular tire pressure check. Be sure to
check the tire pressure regularly.
O If the vehicle is being driven at speeds of
less than 16 MPH (25 km/h), the TPMS
may not operate correctly.
O Be sure to install the specified size of
tires to the four wheels correctly.
Low washer fluid warning
light This light comes on when the washer tank
fluid is at a low level. Add washer fluid as
necessary. See ªWindow washer fluidº in
the ª8. Maintenance and do-it-yourselfº
section.
P position selecting warning
light (for Intelligent Key
system) The light blinks in red when the selector
lever is not in the P (Park) position and
you are outside the vehicle with the Intel-
ligent Key. When the warning light blinks, move the
selector lever to P position and return the
ignition switch to the LOCK position.
Rear Active Steer (RAS)
warning light (if so
equipped) If the light comes on while the engine is
running, it may indicate that there is a
malfunction with the Rear Active Steer
(RAS) portion of the steering system. Have
the system checked by an INFINITI dealer.
For further information about the RAS sys-
tem, see ªRear Active Steer (RAS) systemº
in the ª5. Starting and drivingº section.
If a malfunction occurs in the system, the
RAS function will cease but driving can be
continued.
If the light comes on while you are driving,
contact an INFINITI dealer for repair.
Seat belt warning light and
chime The light and chime remind you to fasten
the driver's seat belt. The light illuminates
whenever the ignition switch is pushed to
the ON position, and will remain illumi-
nated until the driver's seat belt is fas-
Instruments and controls
2-13
w 06.1.4/V35-D/V5.0
X

Cruise set switch indicator
lightThe light comes on while the vehicle
speed is controlled by the cruise control
system. If the light blinks while the en-
gine is running, it may indicate the cruise
control system is not functioning prop-
erly. Have the system checked by an
INFINITI dealer.
Front passenger air bag
status lightThe front passenger air bag status light,
located on the center display, will be lit
and the passenger front air bag will be off
depending on how the front passenger
seat is being used.
For front passenger air bag status light
operation, see ªINFINITI advanced air bag
systemº in the ª1. Safety Ð Seats, seat
belts and supplemental restraint systemº
section of this manual.
High beam indicator light
(Blue)This light comes on when the headlight
high beam is on and goes out when the
low beam is selected. Malfunction indicator lamp
(MIL) If the malfunction indicator lamp (MIL)
comes on steady or blinks while the en-
gine is running, it may indicate a poten-
tial emission control malfunction.
The malfunction indicator lamp may also
come on steady if the fuel-filler cap is
loose or missing, or if the vehicle runs out
of fuel. Check to make sure the fuel-filler
cap is installed and closed tightly, and
that the vehicle has at least three gallons
(14 liters) of fuel in the fuel tank.
After a few driving trips, the lamp
should turn off if no other potential emis-
sion control system malfunction exists.
If this indicator lamp comes on steady for
20 seconds and then blinks for 10 sec-
onds when the engine is not running, it
indicates that the vehicle is not ready for
an emission control system inspection/
maintenance test. See ªReadiness for
inspection/maintenance (I/M) testº in the
ª9. Technical and consumer informationº
section of this manual.
Operation
The malfunction indicator lamp will come on in one of two ways:
O Malfunction indicator lamp on steady
Ð An emission control system mal-
function has been detected. Check the
fuel-filler cap. If the fuel-filler cap is
loose or missing, tighten or install the
cap and continue to drive the vehicle.
The lamp should turn off after a
few driving trips. If the lamp
does not turn off after a few driving
trips, have the vehicle inspected by an
INFINITI dealer. You do not need to
have your vehicle towed to the re-
tailer.
O Malfunction indicator lamp blinking Ð
An engine misfire has been detected
which may damage the emission con-
trol system. To reduce or avoid emis-
sion control system damage:
a) Do not drive at speeds above 45
MPH (72 km/h).
b) Avoid hard acceleration or decel-
eration.
c) Avoid steep uphill grades.
d) If possible, reduce the amount of
cargo being hauled or towed.
The malfunction indicator lamp may
stop blinking and come on steady.
Instruments and controls
2-15
w 06.1.4/V35-D/V5.0
X

3. Close and lock all doors, hood and
trunk lid.
Lock all doors by pushing the LOCK
button on the keyfob, the Intelli-
gent Key or by pushing any front door
handle request switch or turning the
door key. When using the remote key-
less entry, the hazard indicators will
operate as shown in ªRemote keyless
entry systemº or ªIntelligent Key
systemº in the ª3. Pre-driving checks
and adjustmentsº section.
4. Confirm that the security indicator
light
q A
comes on. The security indica-
tor light glows for about 30 seconds
and then blinks. The system is now
armed. If, during this 30-second time
period, the door is unlocked by the
key, the remote keyless entry or the
front door request switch, or the igni-
tion switch is turned to the ACC or ON
position, the system will not be
armed.
Even when the driver and/or passengers
are in the vehicle, the system will be
armed with all doors, hood and trunk lid
locked and ignition switch off. Turn the ig-
nition switch to the ACC position to turn off
the system. Vehicle security system activation The security system will give the following
alarm:
O The headlights blink and the horn
sounds intermittently.
O The alarm automatically turns off after
approximately 50 seconds. However,
the alarm reactivates if the vehicle is
tampered with again. The alarm can
be shut off by unlocking a door with
the key, by pushing any front door
handle request switch or by pushing
the UNLOCK button on the keyfob
or Intelligent Key.
The alarm is activated by:
O Opening the door without using the
key or keyfob or Intelligent Key.
O Opening the trunk lid without using
the keyfob or Intelligent Key.
O Opening the hood.
How to stop an activated alarm The alarm will stop only by unlocking a
door with the key, by pushing any door
handle request switch or by pushing the
UNLOCK button on keyfob or Intelli-
gent Key. The alarm will not stop if the ig- nition switch is turned to the ACC or ON
position.
If the system does not operate as de-
scribed above, have it checked by an
INFINITI dealer.
INFINITI VEHICLE IMMOBILIZER
SYSTEM The INFINITI Vehicle Immobilizer System
will not allow the engine to start without
the use of the registered key.
If the engine fails to start using the regis-
tered key (for example, when interference
is caused by another registered key, an
automated toll road device or automated
payment device on the key ring), restart
the engine using the following proce-
dures:
1. Leave the ignition switch in the ON po-
sition for approximately 5 seconds.
2. Turn the ignition switch to the OFF or
LOCK position and wait approximately
10 seconds.
3. Repeat steps 1 and 2.
4. Restart the engine while holding the
device (which may have caused the in-
2-18 Instruments and controls
w 06.1.4/V35-D/V5.0
X

terference) separate from the regis-
tered key.
If this procedure allows the engine to
start, INFINITI recommends placing the
registered key on a separate key ring
to avoid interference from other de-
vices.
Statement related to section 15 of FCC
rules for INFINITI Vehicle Immobilizer
System (CONT ASSY-BCM, ANT ASSY-
IMMOBILIZER)
This device complies with part 15 of the
FCC Rules and RSS-210 of Industry Canada.
Operation is subject to the following two
conditions;
(1) This device may not cause harmful in-
terference, and (2) this device must accept
any interference received, including inter-
ference that may cause undesired opera-
tion of the device.
CHANGES OR MODIFICATIONS NOT EX-
PRESSLY APPROVED BY THE PARTY RE-
SPONSIBLE FOR COMPLIANCE COULD VOID
THE USER'S AUTHORITY TO OPERATE THE
EQUIPMENT. Security indicator light If INFINITI Vehicle Immobilizer System is
malfunctioning, indicator light
q A
will re-
main on while the ignition switch is in the
ON position.
If the light still remains on and/or the en-
gine will not start, see an INFINITI dealer
for INFINITI Vehicle Immobilizer System
service as soon as possible. Bring all reg-
istered keys that you have when visiting
an INFINITI dealer for service. The windshield wiper and washer oper-
ates when the ignition switch is in the ON
position.
Push the lever down to operate the wiper
at the following speed:
q 1
Intermittent Ð intermittent operation
can be adjusted by turning the knob
toward
q A
(Slower) or
q B
(Faster). Also,
the intermittent operation speed varies
in accordance with the vehicle speed.
(For example, when the vehicle speed
is high, the intermittent operation
speed will be faster.) SIC2564 SIC2821
WINDSHIELD WIPER AND WASHER SWITCH
Instruments and controls
2-19
w 06.1.4/V35-D/V5.0
X
