Folder selection :
To change to another folder in the USB memory,
turn the folder selector or choose a folder
displayed on the screen using the INFINITI
controller.
REPEAT (RPT), RANDOM (RDM) :
When the RPT button is pushed while the USB
memory is played, the play pattern can be
change as follows.
To change the play mode, push the RPT button
repeatedly and the mode will change as follows.
Normal → 1 Folder Repeat → 1 Track Repeat →
All Random → 1 Folder Random → Normal
Text (models without navigation system) :
When the “Text” key is selected on the screen
using the INFINITI controller and then the ENTER
button is pushed while a USB memory is being
played, the music information listed below will
be displayed on the screen.
● Folder title
● File title
● Song title
● Album Title
● Artist Menu (models with navigation system) :
There are some options available during play-
back. Select one of the following options that
are displayed on the screen if necessary. Refer
to the following information for each item.
● Movie Playback
Switch to the movie playback mode. This
item is displayed only when a USB memory
contains movie files.
● Folder List/Track List
Displays the folder or track list. The “Movie
Playback” key is also displayed in this list
screen, and enables switching to the movie
playback mode. ● Play Mode
Select the preferred play mode.
SAA2502
4-64 Monitor, climate, audio, phone and voice recognition systems
 —
—
04/21/10—debbie


Movie file operation (models with
navigation system) Park the vehicle in a safe location for the front
seat occupants to operate the USB memory
while watching the images.
PLAY :
When the DISC·AUX button is pushed with the
system off and the USB memory inserted, the
system will turn on.
If another audio source is playing and a USB
memory is inserted, push the DISC·AUX button
repeatedly until the center display changes to
the USB memory mode. Operation keys :
To operate the USB memory, select the desired
key displayed on the operation screen using the
INFINITI controller.
Pause
Select the “
” key to pause the movie file.
To resume playing the movie file, select the
“ ” key.
Play
Select the “
” key to start playing a movie
file, for example, after pausing a movie file.
STOP
Select the “
” key to stop playing a movie
file.
Skip (Next chapter)
Select the “
” key to skip the chapter(s) of
the disc forward. The chapters will advance the
number of times the ENTER button is pushed. Skip (Previous chapter)
Select the “
” key to skip the chapter(s) of
the disc backward. The chapters will go back
the number of times the “ ” key is se-
lected.
List :
Select the “List” key on the movie file operation
screen to display the file list.SAA2503
Monitor, climate, audio, phone and voice recognition systems
4-65
 —
—
04/21/10—debbie


Settings :
Select the “Settings” key to adjust the following
settings.
● Audio File Playback
Switch to the audio playback mode. This
item is displayed only when the USB
memory contains the audio files.
● Play Mode
Select the “Normal” or “1 Track Repeat” play
mode. ● 10 Key Search
Select the “10 Key Search” key to open the
number entry screen.
Input the number to be searched and select
the “OK” key.
The specified folder/file will be played.
● Display
To adjust the image quality of the screen,
select the preferred adjustment items.
● DRC
DRC (Dynamic Range Compression) auto-
matically adjusts the soundtrack volume
level to maintain a more even sound to the
speakers.
● Audio
Select the preferred language for audio.
● Subtitle
Select the preferred language for subtitle.
● Display Mode
Select the “Normal”, “Wide”, “Cinema” or
“Full” mode. BLUETOOTH  STREAMING AUDIO
(models with navigation system) Your INFINITI is equipped with Bluetooth  Stream-
ing Audio. If you have a compatible Bluetooth
device with streaming audio (A2DP profile), you
can set up the wireless connection between your
Bluetooth  device and the in-vehicle audio sys-
tem. This connection allows you to listen to the
audio from the Bluetooth  device using your
vehicle speakers. It also may allow basic control
of the device for playing and skipping audio files
using the AVRCP Bluetooth  profile. All
Bluetooth  Devices do not have the same level of
controls for AVRCP. Please consult the manual for
your Bluetooth  Device for more details.
Once your Bluetooth  device is connected to
the in-vehicle audio system, it will automati-
cally reconnect whenever the device is present
in the vehicle and you select Bluetooth  Audio
from your audio system. You do not need to
manually reconnect for each usage.
Regulatory information FCC Regulatory information :
– CAUTION: To maintain compliance with FCC’s
RF exposure guidelines, use only the sup-
plied antenna. Unauthorized antenna, modi-
fication, or attachments could damage the
transmitter and may violate FCC regulations.Example SAA2504
4-66 Monitor, climate, audio, phone and voice recognition systems
 —
—
04/21/10—debbie


3. A confirmation screen will be displayed.
Select “No”.
Note: Selecting “Yes” will only connect the
hands free phone portion of a Bluetooth
device. 4. Choose a PIN code to use with the com-
patible Bluetooth  audio device using the
number input screen. The PIN code will
need to be entered into the Bluetooth
audio device after step 5. Select the “OK”
key. 5. The standby message screen will appear.
Operate the compatible Bluetooth  audio
device. For the connecting procedure of
the audio device, see the Bluetooth  au-
dio instructions.
When the connecting is completed, the
screen will return to the Bluetooth  setup
display.SAA2507 SAA3005 SAA2509
4-68 Monitor, climate, audio, phone and voice recognition systems
 —
—
04/21/10—debbie


Audio main operation Push the ignition switch to the ACC or ON
position. Then, push the DISC·AUX button re-
peatedly to switch to the Bluetooth  audio
mode. If the system has been turned off while
the Bluetooth  audio device was playing, push-
ing the ON·OFF/VOL control knob will start the
Bluetooth  audio device.
The ability to pause, change tracks, fast for-
ward, rewind, randomize and repeat music may
be different between devices. Some or all of
these functions may not be supported on each
device. DISC·AUX button :
When the DISC·AUX button is pushed with the
system off and the Bluetooth  audio device
connected, the system will turn on. If another
audio source is playing and the Bluetooth
audio device is connected, push the DISC·AUX
button repeatedly until the display changes to
the Bluetooth  audio mode.
Next/Previous Track and
Fast Forward/Rewind :
When the or button is pushed for
more than 1.5 seconds while a Bluetooth  audio
file is being played, the Bluetooth  audio de-
vice will play while forwarding or rewinding.
When the button is released, the Bluetooth
audio device will return to normal play speed.
When the or button is pushed for
less than 1.5 seconds while a Bluetooth  audio
file is being played, the next track or the
beginning of the current track on the
Bluetooth  audio device will be played. The
INFINITI controller can also be used to select
tracks when the Bluetooth  audio play mode
screen is shown on the display. (“Bluetooth
audio” will be indicated on the header of the
screen.) REPEAT (RPT), RANDOM (RDM) :
To change the play mode, push the
button repeatedly and the mode changes as
follows.
Normal → Shuffle All Tracks → Shuffle Group →
Repeat 1 Track → Repeat All Tracks → Repeat
Group → Normal
Operation keys :
To operate a Bluetooth  audio device, select a
key displayed on the operation screen using the
INFINITI controller.
Play
Select the “
” key to start playing when
pausing. Select this key again to pause the
audio play.
Pause
Select the “
” key to pause the Bluetooth
audio device. Select this key again to resume
playing.
Play Mode :
The play mode setting display will appear when
the “Menu” key is selected.SAA2510
Monitor, climate, audio, phone and voice recognition systems
4-69
 —
—
04/21/10—debbie


Choose the preferred play mode from the fol-
lowing items.
● Shuffle
Choose “Shuffle OFF”, “Shuffle All Tracks”
and “Shuffle Group”.
● Repeat
Choose from “Repeat OFF”, “Repeat 1 Track”,
“Repeat All Tracks” and “Repeat Group”.
Bluetooth  settingsTo set up the Bluetooth  device system to the
preferred settings, push the SETTING button
and select the “Bluetooth” key.
Bluetooth :
If this setting is turned off, the connection
between the Bluetooth  devices and the in-
vehicle Bluetooth  module will be canceled.
Connect Bluetooth :
Connects to the Bluetooth  device. See “Con-
necting procedure” earlier in this section. Up to
5 devices can be registered. Connected Devices :
Registered devices are shown on the list. Select
a Bluetooth  device from the list, the following
options will be available.
● Select
Select “Select” to connect the selected de-
vice to the vehicle. If there is a different
device currently connected, the selected de-
vice will replace the current device.
● Edit
Rename the selected Bluetooth  device us-
ing the keypad displayed on the screen. (See
“HOW TO USE TOUCH SCREEN (models with
navigation system)” earlier in this section.)
● Delete
Delete the selected Bluetooth  device.
Edit Bluetooth Info :
Change the name broadcasted by this system
over Bluetooth  . Change the PIN code that is
entered when connecting a hands free device to
this system. SAA2511
4-70 Monitor, climate, audio, phone and voice recognition systems
 —
—
04/21/10—debbie


Replace Connected Phone :
Replace the Bluetooth  connection with a con-
nected Bluetooth  cellular phone. For details
about Hands-Free Phone System, see
“BLUETOOTH  HANDS-FREE PHONE SYSTEM
(models with navigation system)” later in this
section.
IPOD  PLAYER OPERATION (if so
equipped)
Connecting iPod  Open the console lid and connect the iPod
cable to the USB connector. If compatible, the
battery of the iPod  is charged while the con-
nection to the vehicle.
Depending on the version of the iPod  , the
display on the iPod  shows an INFINITI or
Accessory Attached screen when the connection
is completed. When the iPod  is connected to
the vehicle, the iPod  music library can only be
operated by the vehicle audio controls.
* iPod  is a trademark of Apple Inc., registered
in the U.S. and other countries.
Compatibility The following models are available:
Models with navigation system :
● Fifth generation iPod  (version 1.2.3 or later)
● iPod Classic  (version 1.1.1 or later)
● First generation iPod touch  (version 2.0.0
or later)
● Second generation iPod touch  (version
1.2.3 or later)Automatic transmission models SAA2974
Manual transmission models SAA2426
Monitor, climate, audio, phone and voice recognition systems
4-71
 —
—
04/21/10—debbie


● First generation iPod nano  (version 1.3.1 or
later)
● Second generation iPod nano  (version 1.1.3
or later)
● Third generation iPod nano  (version 1.1 or
later)
● Fourth generation iPod nano  (version 1.0.2
or later)
Models without navigation system :
● Fifth generation iPod  (firmware version 1.3)
● First generation iPod Classic  (firmware ver-
sion 1.1.2 PC)
● Second generation iPod Classic  (firmware
version 2.0 PC)
● First generation iPod touch  (firmware ver-
sion 2.1)
● Second generation iPod touch  (firmware
version 2.1.1)
● First generation iPod nano  (firmware ver-
sion 1.3.1)
● Second generation iPod nano  (firmware
version 1.1.3)
● Third generation iPod nano  (firmware ver-
sion 1.1 PC)
Make sure that the iPod  version is updated. Audio main operation Push the ignition switch to the ACC or ON
position. Then, push the DISC·AUX or DISC
button repeatedly to switch to the iPod  mode.
If the system has been turned off while the
iPod  was playing, pushing the ON·OFF button
will start the iPod  .
or PLAY :
When the DISC·AUX or AUX button is pushed
with the system off and the iPod  connected,
the system will turn on. If another audio source
is playing and the iPod  is connected, push the
DISC·AUX or AUX button repeatedly until the
center display changes to the iPod  mode.
Interface :
The interface for iPod  operation shown on the
vehicle center display is similar to the iPod
interface. Use the INFINITI controller and the
ENTER or BACK button to play the iPod  with
your favorite settings.
The following items can be chosen from the
menu list screen. For further information about
each item, see the iPod  Owner’s Manual.
● Now Playing
● Playlists
● Artists ● Albums
● Songs
● Podcasts
● Genres
● Composers
● Audiobooks
● Shuffle Songs
The following touch-panel buttons shown on
the screen are also available:
● : returns to the previous screen.
●
: plays/pauses the music selected.
Next/Previous Track and
Fast Forward/Rewind :
When the or button is pushed for
more than 1.5 seconds while the iPod  is play-
ing, the iPod  will play while fast forwarding or
rewinding. When the button is released, the
iPod  will return to the normal play speed.
When the or button is pushed for
less than 1.5 seconds while the iPod  is play-
ing, the next track or the beginning of the
current track on the iPod  will be played.
The INFINITI controller can also be used to
select tracks when the iPod  is playing.
4-72 Monitor, climate, audio, phone and voice recognition systems
 —
—
04/21/10—debbie


If the title information of the track being re-
corded is stored either in the hard-disk drive or
in the CD, the title is automatically displayed on
the screen. For title acquisition from the hard-
disk drive, music recognition technology and
related data are provided by Gracenote  .
If a track is not recorded successfully due to
skipping sounds, the mark is displayed
behind the track number.
The “Music Box” hard disk drive cannot perform
recording under the following conditions.
● There is not enough space in the hard-disk
● The number of albums reaches the maximum
of 500.
● The number of tracks reaches the maximum
of 3,000.
Automatic recording :
If the “Automatic Recording” function is turned
to ON, recording starts when a CD is inserted.
(See “Music Box settings” later in this section.) Stopping recording :
To stop the recording, select the “Stop REC” key
button by touching the screen or using the
INFINITI controller.
If the CD is ejected, the audio system is turned
off or the ignition switch is pushed to the OFF
position, the recording also stops.
Models with navigation system SAA2515
Models without navigation system SAA2614
Monitor, climate, audio, phone and voice recognition systems
4-75
 —
—
04/21/10—debbie


Playing recorded songs Select the “Music Box” audio system by using
one of the following methods.
● Push the audio source switch on the steering
wheel repeatedly until the center display
changes to the Music Box mode. (See
“STEERING-WHEEL-MOUNTED CONTROLS
FOR AUDIO” later in this section.)
● Push the DISC·AUX or DISC button repeat-
edly until the center display changes to the
Music Box mode.
● Give voice commands. (See “INFINITI VOICE
RECOGNITION SYSTEM (models with naviga-
tion system)” later in this section.)
Stopping playback :
The system stops playing when:
a. another mode (radio, CD, DVD, USB
memory or iPod) is selected.
b. the audio system is turned off.
c. the ignition switch is pushed to the LOCK
position. Next/Previous Track and
Fast Forward/Rewind :
When the (fast forward) or (re-
wind) button is pushed for more than 1.5 sec-
onds while a track is being played, the track will
play while fast forwarding or rewinding. When
the button is released, the track will return to
the normal play speed.
When the or button is pushed for
less than 1.5 seconds while a track is being
played, the next track or the beginning of the
current track will be played.
The INFINITI controller can also be used to
select tracks when a track is being played.
Play mode selection :
The TUNE/FOLDER knob will skip from album to
album unless it is playing “All Songs” from the
Music Library menu. When playing “All Songs”,
the knob will change the track instead of the
album. The upper right corner of the main
screen will indicate if the TUNE knob is chang-
ing by track or album. REPEAT (RPT), RANDOM (RDM) :
When the RPT·RDM button is pushed while a
track is being played, the play pattern can be
changed as follows:
(Normal) → 1 Album Repeat → 1 Track Repeat →
1 Album Random → All Random → (Normal)
Tag Track (models with navigation system) :
Select “Tag Track” key on the screen when a
track is being played. A menu will show the 5
available playlists. Select one of the playlists to
add the current song to that playlist. If a playlist
is not selectable (text is grayed out), it means
the song already exists in that playlist.
4-76 Monitor, climate, audio, phone and voice recognition systems
 —
—
04/21/10—debbie
