bluetooth INFINITI G37 2010 Owners Manual

CALIFORNIA PROPOSITION 65
WARNING WARNINGEngine Exhaust, some of its constituents, and
certain vehicle components contain or emit
chemicals known to the State of California to
cause cancer and birth defects or other repro-
ductive harm. In addition, certain fluids con-
tained in vehicles and certain products of com-
ponent wear contain or emit chemicals known
to the State of California to cause cancer and
birth defects or other reproductive harm.
CALIFORNIA PERCHLORATE ADVISORY Some vehicle parts, such as lithium batteries, may
contain perchlorate material. The following advi-
sory is provided: “Perchlorate Material - special
handling may apply, See www.dtsc.ca.gov/
hazardouswaste/perchlorate.” BLUETOOTH  is a trade-
mark owned by Bluetooth
SIG, Inc., U.S.A. and li-
censed to Visteon
Corporation and Clarion
Co., Ltd.
Gracenote  is a registered
trademark of Gracenote,
Inc. The Gracenote logo
and logo type, and the
“Powered by Gracenote”
logo are trademarks of
Gracenote.
XM Radio  requires
subscription. Not available
in Alaska, Hawaii or Guam.
For more information, visit
www.xmradio.com. © 2010 NISSAN MOTOR CO., LTD.
All rights reserved. No part of this Owner’s
Manual may be reproduced or stored in a
retrieval system, or transmitted in any form, or
by any means, electronic, mechanical, photo-
copying, recording or otherwise, without the
prior written permission of Nissan Motor Co.,
Ltd.
 —
—
05/10/10—tbrooks


1. Side ventilator (P. 4-27)
2. Meters and gauges (P. 2-4)
3. Center ventilator (P. 4-27)
4. Audio system (P. 4-39)
5. Clock (P. 2-40) 6. Center multi-function control panel
— Navigation system* (if so equipped)
— Vehicle information and setting buttons
(P. 4-7)
— Bluetooth  Hands-Free Phone System
(P. 4-85)
— Audio system (P. 4-39) 7. Center display (P. 4-2)/Navigation
system* (if so equipped)
8. Hazard warning flasher switch (P. 2-37)
9. Front passenger supplemental air bag
(P. 1-40)
10. Fuse box cover (P. 8-20)
11. Parking brake
(for Automatic Transmission models)
— Parking (P. 5-18)
12. Push-button ignition switch (P. 5-7)
13. Automatic climate control system
(P. 4-28)
14. Cigarette lighter and ashtray
(if so equipped) (P. 2-42) or storage box
(if so equipped) (P. 2-47)
— Power outlet (if so equipped) (P. 2-41)
15. Parking brake (for Manual Transmission
models)
— Parking (P. 5-18)
16. Heated seat switch (if so equipped)
(P. 2-38)
17. SNOW mode switch (if so equipped)
(P. 2-40)
18. Rear window and outside mirror
(if so equipped) defogger switch (P. 2-32)
19. Glove box lid release handle (P. 2-45) SSI0671INSTRUMENT PANEL
0-10 Illustrated table of contents
 —
—
10/12/09—tbrooks


1. Side ventilator (P. 4-27)
2. Meters and gauges (P. 2-4)
3. Center ventilator (P. 4-27)
4. Audio system (P. 4-39)
5. Clock (P. 2-40) 6. Center multi-function control panel
— Navigation system* (if so equipped)
— Vehicle information and setting buttons
(P. 4-7)
— Bluetooth  Hands-Free Phone System
(P. 4-85)
— Audio system (P. 4-39) 7. Center display (P. 4-2)/Navigation
system* (if so equipped)
8. Hazard warning flasher switch (P. 2-37)
9. Front passenger supplemental air bag
(P. 1-40)
10. Fuse box cover (P. 8-20)
11. Parking brake
(for Automatic Transmission models)
— Parking (P. 5-18)
12. Push-button ignition switch (P. 5-7)
13. Automatic climate control system
(P. 4-28)
14. Cigarette lighter and ashtray
(if so equipped) (P. 2-42) or storage box
(if so equipped) (P. 2-47)
— Power outlet (if so equipped) (P. 2-41)
15. Parking brake (for Manual Transmission
models)
— Parking (P. 5-18)
16. Heated seat switch (if so equipped)
(P. 2-38)
17. SNOW mode switch (if so equipped)
(P. 2-40)
18. Rear window and outside mirror (if so
equipped) defogger switch (P. 2-32)
19. Glove box lid release handle (P. 2-45) SSI0671INSTRUMENT PANEL
Instruments and controls
2-3
 —
—
10/12/09—tbrooks


4 Monitor, climate, audio, phone and voice
recognition systems Safety note ....................................... 4-2
Center multi-function control panel ................. 4-2
How to use INFINITI controller ................... 4-4
How to use touch screen
(models with navigation system) ................. 4-4
Menu options (models with navigation
system) ....................................... 4-6
How to select menus on the screen .............. 4-7
Vehicle information and settings .................... 4-7
How to use STATUS button ...................... 4-7
How to use brightness control and display
ON/OFF button ................................. 4-7
How to use INFO button ........................ 4-8
How to use SETTING button .................... 4-12
Rearview monitor (if so equipped) ................. 4-22
How to read displayed lines .................... 4-22
How to park with predicted course lines ......... 4-23
Difference between predicted and actual
distances ..................................... 4-24
How to adjust screen .......................... 4-26
Operating tips ................................ 4-26
Ventilators ....................................... 4-27
Automatic climate control ......................... 4-28
Automatic climate control (Type A) .............. 4-30 Automatic climate control (Type B) .............. 4-32
Automatic climate control (Type C) .............. 4-34
Operating tips ................................ 4-37
In-cabin microfilter ............................ 4-38
Servicing climate control ....................... 4-38
Audio system .................................... 4-39
Audio operation precautions ................... 4-39
FM-AM-SAT radio with Compact Disc (CD)
player ........................................ 4-54
DVD (DIGITAL VERSATILE DISC) player
operation (models with navigation system) ...... 4-59
Usb input operation (if so equipped) ............ 4-62
Bluetooth  streaming audio
(models with navigation system) ................ 4-66
iPod  player operation (if so equipped) ......... 4-71
Music box hard-disk drive (if so equipped) ...... 4-73
Auxiliary input jacks (if so equipped) ............ 4-81
Cd/dvd/usb memory care and cleaning ......... 4-82
Steering-wheel-mounted controls for audio ...... 4-83
Antenna ...................................... 4-84
Car phone or CB radio ............................ 4-85
Bluetooth  Hands-Free Phone System
(models with navigation system) ................... 4-85
Regulatory information ......................... 4-87
 —
—
04/21/10—debbie


Voice commands .............................. 4-87
Control buttons ............................... 4-87
Connecting procedure ......................... 4-88
Phone selection ............................... 4-88
Vehicle phonebook ............................ 4-88
Making a call ................................. 4-91
Receiving a call ............................... 4-92
During a call .................................. 4-93
Phone setting ................................. 4-93
Troubleshooting guide ......................... 4-95
Bluetooth  Hands-Free Phone System
(models without navigation system) ................ 4-96
Regulatory information ......................... 4-97
Control buttons ............................... 4-97
Voice recognition system ...................... 4-98 Pairing procedure ............................ 4-102
Phonebook registration ....................... 4-103
Making a call ................................ 4-103
Receiving a call .............................. 4-104
During a call ................................. 4-104
Phone settings ............................... 4-105
Voice adaptation mode ....................... 4-108
INFINITI Voice Recognition system
(models with navigation system) .................. 4-109
INFINITI Voice Recognition standard mode ...... 4-109
Using the system .............................. 4-112
INFINITI Voice Recognition alternate
command mode .............................. 4-122
Using the system ............................. 4-128
Troubleshooting guide ........................ 4-133
 —
—
04/21/10—debbie


WARNING● Do not disassemble or modify this system. If
you do, it may result in accidents, fire, or
electric shock.
● Do not use this system if you notice any
abnormality, such as a frozen screen or lack
of sound. Continued use of the system may
result in accident, fire or electric shock.
● In case you notice any foreign object in the
system hardware, spill liquid on it, or notice
smoke or smell coming from it, stop using
the system immediately and contact your
nearest INFINITI retailer. Ignoring such con-
ditions may lead to accidents, fire, or electric
shock.
● Park the vehicle in a safe location and apply
the parking brake to view the images on the
front center display screen using devices
connected to the auxiliary input jacks.
Do not attempt to operate the system in extreme
temperature conditions [below  4°F (  20°C)
and above 158°F (70°C)]. Operating this system
under these conditions may result in system
malfunctions. 1. “ STATUS ” status display button (P. 4-7)
2, 6, 7, 10, 11. For navigation system control
buttons (Refer to the sepa-
rate Navigation System Own-
er’s Manual.)
3. INFINITI controller (P. 4-4)
4. “ PHONE ” Bluetooth  Hands-Free Phone
System button (P. 4-85)
5. “ OFF ” brightness control and dis-
play ON/OFF button (P. 4-7) 8. “ AM·FM·SAT ” band selector button
(P. 4-39)
9. “ DISC·AUX ” selector button (P. 4-39)
12. “ INFO ” vehicle and navigation informa-
tion button (P. 4-8)
13. “ SETTING ” button (P. 4-12)Models with navigation system SAA1523
SAFETY NOTE CENTER MULTI-FUNCTION CONTROL PANEL
4-2 Monitor, climate, audio, phone and voice recognition systems
 —
—
04/21/10—debbie


Audio settings The display as illustrated will appear when
pushing the SETTING button and selecting the
“Audio” key.
Bass/Treble/Balance/Fade :
To adjust the speaker tone quality and sound
balance, select the “Bass”, “Treble”, “Balance”
or “Fade” key and adjust it with the INFINITI
controller.
These items can also be adjusted by pushing
and turning the AUDIO knob.
Speed Sensitive Vol. :
The audio system’s volume is increased with
the vehicle speed. Select the “Speed Sensitive
Vol.” and adjust the effect level with the INFINITI
controller. The Speed Sensitive Volume function
is turned off when the level is set to OFF.
Increasing the value will cause the volume to
increase faster with vehicle speed.
Precision Phased Audio (if so equipped) :
When this item is turned to ON, super high pitch
sound and super low pitch sound are empha-
sized and midrange sound is played naturally. Driver’s Audio Stage (if so equipped) :
When this feature is turned to ON, better sound
will be provided to the driver’s position. The
driver can enjoy a more crisp and clear sound
that is specialized for the driver’s position. The
effect of this feature depends on the type of
music that is played. For some music, it may be
difficult to realize the effect of this feature.
DivX  Registration Code (models with naviga-
tion system) :
The registration code for a device that is used to
download DivX  files will be displayed on the
screen. If a disc is loaded or a USB memory is
connected to the audio system, this function
will not be activated.
Display Album Cover Art (models with naviga-
tion system) :
When this item is turned to ON, the album cover
image is displayed when playing iPod  or MP3
music files through a CD, DVD or USB memory.
When the image is not properly embedded in
the file or device, the image will not be dis-
played. Phone settings (models with
navigation system) For details of the “Phone” settings, see
“BLUETOOTH  HANDS-FREE PHONE SYSTEM
(models with navigation system)” later in this
section.
Bluetooth  settings (for models with
navigation system) For details of the “Bluetooth  ” settings, see
“BLUETOOTH  HANDS-FREE PHONE SYSTEM
(models with navigation system)” later in this
section.
Monitor, climate, audio, phone and voice recognition systems
4-13
 —
—
04/21/10—debbie


Volume and Beeps settings (models
with navigation system) The display as illustrated will appear when
pushing the SETTING button, selecting the “Vol-
ume & Beeps” key.
Audio Volume :
To increase or decrease the audio volume,
select the “Audio Volume” and adjust it with the
INFINITI controller. You can also adjust the
audio volume by turning the VOLUME control
knob. Guidance Volume :
To adjust the guidance voice volume louder or
softer, select the “Guidance Volume” and ad-
just it with the INFINITI controller.
You can also adjust the guidance voice volume
by turning the VOLUME control knob while voice
guidance is being announced.
Ringtone/Incoming Call/Outgoing Call :
For the details of these items, see “BLUETOOTH
HANDS-FREE PHONE SYSTEM (models with navi-
gation system)” later in this section.
Switch Beeps :
When this item is turned to ON, you will hear a
beep sound when you use a button.
Guidance Voice :
When this item is turned to ON, you will hear
voice guidance in the navigation operation or in
other operations.
NOTE:
When the voice guidance is being announced
during audio playback, turning the volume knob
does not adjust the music level; it adjusts the
guidance volume level. If voice guidance is not
being heard, please check the Guidance Volume
level. Button Beeps settings (models
without navigation system) The “Button Beeps” screen will appear when
pushing the SETTING button, selecting the “But-
ton Beeps” key with the INFINITI controller and
pushing the ENTER button.
Button Beeps :
When this item is turned to ON, you will hear a
beep sound when you use a button.SAA2554 SAA2605
4-14 Monitor, climate, audio, phone and voice recognition systems
 —
—
04/21/10—debbie


Bluetooth  Audio player (models with
navigation system) ● Some Bluetooth  audio devices may not be
recognized by the in-vehicle audio system.
● It is necessary to set up the wireless connec-
tion between a compatible Bluetooth  audio
device and the in-vehicle Bluetooth  module
before using the Bluetooth  audio player.
● Operating procedure of the Bluetooth  audio
player will vary depending on the device.
Make sure it is understood how to operate
an audio device before using it with this
system.
● The Bluetooth  audio player may be stopped
under the following conditions:
– Receiving a hands-free call.
– Checking the connection to the hands-
free phone.
● Do not place a Bluetooth  audio device in an
area surrounded by metal or far away from
the in-vehicle Bluetooth  module to prevent
tone quality degradation and wireless con-
nection disruption.
● While an audio device is connected through
a Bluetooth  wireless connection, the bat-
tery power of the device may discharge
quicker than usual. ● This system supports the Bluetooth  Audio
Distribution Profile (A2DP, AVRCP).
● Bluetooth  is a trademark owned by
Bluetooth SIG, Inc. and licensed to Clarion
Co., Ltd.
Music Box hard drive Recording :
● Note that data that is lost and not stored to
the hard disk drive due to system damage,
improper operation or malfunction is not
under warranty.
● Vehicle owners are not permitted to record
music without permission of the owner of
the copyright except for personal use.
● Check if the music is appropriately recorded
to the hard disk drive after recording when
the compact disc cannot be rerecorded.
● Some music cannot be recorded depending
on the disc condition due to high-speed
recording.
● Jumping sounds may be recorded when a
compact disc is recorded while driving on
rough roads and excessive vibration occurs.
● A mark indicating jumping sounds is dis-
played if jumping sounds are recorded. ● No sounds may be recorded if jumping
sounds occurs or the disc is in poor condi-
tion.
● Tracks that include Serial Copy Management
System (SCMS) are not recorded.
● If a compact disc is scratched or dirty, it may
not be recorded, jumping sounds may occur
or it may take a long time to record.
Automatic title download :
● The title information that is automatically
downloaded may differ from the actual title.
● When newly released compact discs are
recorded, their title information may not be
downloaded.
● The title information in the hard disk can be
updated. (See “Playing recorded songs”
later in this section.
Monitor, climate, audio, phone and voice recognition systems
4-51
 —
—
04/21/10—debbie


This vehicle has some sound effect functions as
follows:
● Speed Sensitive Vol.
● Precision Phased Audio (if so equipped)
● Driver’s Audio Stage (if so equipped)
For more details, see “VEHICLE INFORMATION
AND SETTINGS” earlier in this section.
Switching the display (Type A) :
● Models with navigation system
Pushing the DISC·AUX button will switch the
displays as follows:
iPod  /USB → CD/DVD → Music Box →
Bluetooth  Audio → iPod  /USB
● Models without navigation system
Pushing the DISC button will switch the display
as follows:
CD → Music Box → CD
Pushing the AUX button will switch the display
as follows:
USB/iPod → XM1 → XM2 → XM3 → USB/iPod
FM-AM-SAT radio operation When the radio band select button is pushed
while the ignition switch is in the ACC or ON
position, the radio will come on at the channel
last played. The last channel played will also come on when
the ON·OFF button is pushed to ON.
The satellite radio is not available in Alaska,
Hawaii and Guam.
If another audio source is playing when the
radio or satellite band select button is turned to
ON, the audio source will automatically be
turned off and the last radio channel played will
come on.
When the stereo broadcast signal is weak, the
radio will automatically change from stereo to
monaural reception.
or radio (FM/AM/SAT) band
select (Type A) :
Pushing the RADIO AM·FM or FM·AM radio band
select button will change the band as follows:
● Models with navigation system
AM → FM1 → FM2 → XM1 → XM2 → XM3 → AM
● Models without navigation system
AM → FM1 → FM2 → AM
radio (SAT) band select (Type A) :
Push the satellite band select button to select
the satellite radio mode XM1, XM2 or XM3. radio (FM/AM/SAT) band select
(Type B) :
Pushing the radio band select button will
change the band as follows:
AM → FM → XM → AM
When the radio band select button is pushed
while the ignition switch is in the ACC or ON
position, the radio will come on at the station
last played.
TUNE (Tuning) :
● For AM and FM radio
Turn the radio TUNE knob for manual tuning.
● For XM Satellite Radio
Turn the radio TUNE knob to seek channels
from all of the categories when any category
is not selected.
SEEK tuning/CATEGORY
(CAT) :
● For AM and FM radio
Push the SEEK·CAT or TRACK button
or to tune from low to high or high to
low frequencies and to stop at the next
broadcasting station.
Monitor, climate, audio, phone and voice recognition systems
4-55
 —
—
04/21/10—debbie
