display INFINITI G37 2012 Owners Manual

Black plate (265,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]SAA2923
Models with navigation system
SAA2924
Models without navigation system 1. Audio source switch
2. Menu control switch (models with
navigation system) or audio tuning
switch (models without navigation
system)
3. Volume control switch
4. Back switch
STEERING-WHEEL-MOUNTED CON-
TROLS FOR AUDIO GUID-619B0EB1-40C6-4771-A31A-F210615026F9
Menu control switch (models with
navigation system) or audio tuning
switch (models without navigation
system) GUID-658196B2-17D0-4C26-B7B5-F266229BD7BC
While the display is showing a MAP
(navigation systems only), STATUS or Audio
screen, tilt the switch upward or downward
to select a station, track, CD or folder. For
most audio sources, tilting the switch up/
down for more than 1.5 seconds provides a
different function than tilting up/down for
less than 1.5 seconds.
AM and FM radio: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. Tilting up/down for less than 1.5
seconds will increase or decrease the
preset station.
. Tilting up/down for more than 1.5
seconds will seek up or down to the next station.
. Pushing the menu control switch (mod-
els with navigation system) will show
the list of preset stations.
XM Satellite Radio: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. Tilting up/down for less than 1.5
seconds will increase or decrease the
preset channel.
. Tilting up/down for more than 1.5
seconds will go to the next or previous
category.
. Pushing the menu control switch (mod-
els with navigation system) will show
the XM Menu.
iPod ®
(if so equipped): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. Tilting up/down for less than 1.5
seconds will increase or decrease the
track number.
. Pushing the menu control switch will
show the iPod Menu.
CD: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. Tilting up/down for less than 1.5
seconds will increase or decrease the
track number.
. Tilting up/down for more than 1.5
seconds will increase/decrease the
folder number (if playing compressed
Monitor, climate, audio, phone and voice recognition systems
4-87

Black plate (266,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-88 Monitor, climate, audio, phone and voice recognition systemsaudio files).
. Pushing the menu control switch (mod-
els with navigation system) will show
the CD Menu.
DVD (models with navigation system): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. Tilting up/down for less than 1.5
seconds will increase or decrease the
track number.
. Tilting up/down for more than 1.5
seconds will increase or decrease the
title number.
. Pushing the menu control switch will
select an item from the DVD display.
. When the transparent operation menu
appears, the switch will control the
menu.
USB (if so equipped): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. Tilting up/down for less than 1.5
seconds will increase or decrease the
track number.
. Tilting up/down for more than 1.5
seconds will increase/decrease the
folder number
. Pushing the menu control switch will
show the USB Menu. Music Box ®
(if so equipped): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. Tilting up/down for less than 1.5
seconds will increase or decrease the
track number.
. Tilting up/down for more than 1.5
seconds will increase/decrease the
album (folder) number (if playing com-
pressed audio files).
. Pushing the menu control switch will
show the Music Box ®
Menu.
Bluetooth ®
Audio (models with navigation
system): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. Tilting up/down for less than 1.5
seconds will increase or decrease the
track number.
AUX (if so equipped): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. Pushing the menu control switch (mod-
els with navigation system) will show
the AUX Menu.
BACK switch (models with
navigation system) GUID-06356188-0EBC-4773-83BB-C5A3DF870F32
Push this switch to go back to the previous
screen or cancel the selection if it is not
completed. Volume control switches GUID-F5A8FDCD-1001-46F7-ADD1-4F45904F01A4
Push the upper (+) or lower ( − ) side switch
to increase or decrease the volume.
Audio source switch GUID-1F9B9EBE-148A-4808-8151-23DFA61D14B8
Push the audio source switch to change
the mode as follows.
Type A:
. Models with navigation system
AM ? FM ? SAT ? CD/DVD ? Music
Box ®
? USB/iPod ®
? Bluetooth ®
Audio
. Models without navigation system
AM ? FM ? CD ? Music Box ®
?
USB/iPod ®
? SAT
Type B:
Preset A ? Preset B ? Preset C ? CD
Media not connected/inserted will be
skipped.

Black plate (269,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]. Do not place the cellular phone in an
area surrounded by metal or far away
from the in-vehicle phone module to
prevent tone quality degradation and
wireless connection disruption.
. While a cellular phone is connected
through the Bluetooth ®
wireless con-
nection, the battery power of the
cellular phone may discharge quicker
than usual.
. If the Bluetooth ®
Hands-Free Phone
System seems to be malfunctioning,
please visit www.InfinitiUSA.com/blue-
tooth for troubleshooting help.
. Some cellular phones or other devices
may cause interference or a buzzing
noise to come from the audio system
speakers. Storing the device in a
different location may reduce or elim-
inate the noise.
. Refer to the cellular phone Owner ’ s
Manual regarding the telephone pairing
procedure specific to your phone,
battery charging, cellular phone anten-
na, etc.
. The antenna display on the monitor will
not coincide with the antenna display
of some cellular phones. . Keep the interior of the vehicle as quiet
as possible to hear the caller ’ s voice
clearly as well as to minimize its
echoes.
. If reception between callers is unclear,
adjusting the incoming or outgoing call
volume may improve the clarity.
REGULATORY INFORMATION GUID-45C8809D-13C7-484B-BAAA-A89D504ED503
FCC Regulatory information GUID-636F13F0-6D27-42F0-A915-498885D2D5D5
. CAUTION: To maintain compliance with
FCC ’ s RF exposure guidelines, use only
the supplied antenna. Unauthorized
antenna, modification, or attachments
could damage the transmitter and may
violate FCC regulations.
. Operation is subject to the following
two conditions:
1. this device may not cause interference
and
2. this device must accept any interfer-
ence, including interference that may
cause undesired operation of the de-
vice
IC Regulatory information GUID-81DEAF38-3ED8-4146-81F8-1F111A551209
. Operation is subject to the following
two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including
interference that may cause undesired
operation of the device.
. This Class B digital apparatus meets all
requirements of the Canadian Interfer-
ence-Causing Equipment Regulations.
Bluetooth trademark: Bluetooth ®
is a trademark
owned by Bluetooth SIG, Inc.,
and licensed to Clarion Co., Ltd.
VOICE COMMANDS GUID-DC1FBBFE-C9FC-4BE4-98EE-C78349271F4A
You can use voice commands to operate
various Bluetooth ®
Hands-Free Phone Sys-
tem features using the INFINITI Voice
Recognition system.
For more details, see “ INFINITI Voice
Recognition system (models with naviga-
tion system) ” (P.4-114).
Monitor, climate, audio, phone and voice recognition systems
4-91

Black plate (271,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]Phone menu display.
PHONE SELECTION GUID-55FEE7E0-1713-47B1-B3A9-605D3DAAC920
Up to 5 cellular phones can be registered
to the system. To switch to connect another
cellular phone, push PHONE button and
select the “ Connected Phones ” key. The
registered cellular phones are shown on
the list. If you select a cellular phone that
is different from the one currently con-
nected, the newly selected phone will be
connected to the system.
VEHICLE PHONEBOOK GUID-9C55C4DB-C8AB-40D9-9A84-A06D2C3EF82D
This vehicle has two phonebooks available
for hands-free use. Depending on the
phone, the system may automatically
download the entire cell phone ’ s phone-
book into the “ Handset Phonebook ” . For
the details about downloading a phone-
book, see “ Phone setting ” (P.4-98). If a
phonebook does not automatically down-
load, the vehicle phonebook may be set for
up to 1,000 entries. This phonebook allows
the recording of a name to speak while
using voice recognition. SAA2521
1. Push the PHONE button and select the
“ Vehicle Phonebook ” key.
2. Select the “ Add New ” key at the top of
the screen. SAA2522
3. Choose the method for entering the
phonebook entry. For this example,
select “ Enter Number by Keypad ” .
4. Enter the digits and select the “ OK ”
key. (See “ How to use touch screen
(models with navigation system) ” (P.4-
5).)
Monitor, climate, audio, phone and voice recognition systems
4-93

Black plate (272,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-94 Monitor, climate, audio, phone and voice recognition systems SAA2523
5. Select the “ Voicetag ” key to record a
name to speak when using the INFINITI
Voice Recognition system.
6. Select the “ Store ” key and prepare to
speak the name after the tone.
7. When the voicetag is successfully
saved, select the “ OK ” key to save the
phonebook entry.
8. After the phonebook entry is saved, it
will show a screen that is ready to call
the number. Press the BACK button to
return to the Vehicle Phonebook.
There are different methods to input a
phone number. Select one of the following options instead of “ Enter Number by Key-
pad ” in step 3.
. Copy from Call History
The system will show a list of incoming,
outgoing or missed calls that were
downloaded from the connected cellu-
lar phone (depending on the phone ’ s
compatibility). Select one of these
entries to save in the vehicle phone-
book.
. Copy from the Handset
The system will show the connected
cellular phone ’ s phonebook that was
downloaded (depending on the
phone ’ s compatibility). Select one of
these entries to save in the vehicle
phonebook. SAA2620
Editing the Vehicle Phonebook GUID-595130B1-D7D0-45B8-8BB0-FEE71007B86A
1. Push the PHONE button and select the
“ Vehicle Phonebook ” key.
2. Select the desired entry from the
displayed list.
3. Select the “ Edit ” key.
4. Select the desired item to change.

Black plate (273,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]SAA2523
The following editing items are available:
. Entry #
Changes the displayed number of the
selected entry.
. Name
Edit the name of the entry using the
keypad displayed on the screen.
. Number
Edit the phone number using the key-
pad displayed on the screen.
. Type
Select an icon from the icon list.
. Voicetag
Confirm and store the voicetag. Voice- tags allow easy dialing using the
INFINITI Voice Recognition system.
(See “ INFINITI Voice Recognition system
(models with navigation system) ” (P.4-
114).)
To delete an entry, select the “ Delete ” key
at step 3.
SAA2524
MAKING A CALL GUID-0C40BF3A-B58B-4CB6-9E2E-8530EF09E8AF
To make a call, follow this procedure.
1. Push the PHONE button on the instru-
ment panel or the
button on the
steering wheel. The “ PHONE ” screen
will appear on the display.
2. Select the “ Handset Phonebook ” key
on the “ PHONE ” menu.
3. Select the desired entry from the list.
4. Confirm the correct entry by selecting
for the correct number from the list.
Monitor, climate, audio, phone and voice recognition systems
4-95

Black plate (274,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-96 Monitor, climate, audio, phone and voice recognition systems SAA2621
5. Select the “ Call ” key to start dialing the
number.
There are different methods to make a call.
Select one of the following options instead
of “ Handset Phonebook ” in step 2 above.
. Vehicle Phonebook
Select an entry stored in the Vehicle ’ s
Phonebook.
. Call History
Select an outgoing, incoming or missed
call downloaded from your cell phone
(depending on your phone ’ s compat-
ibility). . Dial Number
Input the phone number manually
using the keypad displayed on the
screen. (See “ How to use touch screen
(models with navigation system) ” (P.4-
5).)
SAA2525
RECEIVING A CALL GUID-FE730D1E-3F70-48A5-8B81-14DE254EC5A9
When you hear a phone ring, the display
will change to the incoming call mode. To
receive a call, perform one of the following
procedures listed below.
1. Select the “ Answer ” key.
2. Push the PHONE button on the instru-
ment panel.
3. Push the
button on the steering
wheel.
There are some options available when
receiving a call. Select one of the following
displayed on the screen.

Black plate (275,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]. Answer
Accept an incoming call to talk.
. Hold Call
Put an incoming call on hold.
. Reject Call
Reject an incoming call.
To finish the call, perform one of the
following procedures listed below.
1. Select the “ Hang up ” key.
2. Push the PHONE button on the instru-
ment panel.
3. Push the
button on the steering
wheel. SAA3587
DURING A CALL GUID-E7292060-1082-4B42-B84D-1CC0C3989595
There are some options available during a
call. Select one of the following displayed
on the screen if necessary.
. Hang up
Finish the call.
. Use Handset
Transfer the call to the cellular phone.
. Mute
Mute your voice to the person.
. Keypad
Using the touch tone, send digits to the
connected party for using services such
as voicemail. . Cancel Mute
This will appear after “ Mute ” is se-
lected. Mute will be canceled.
. Switch Call*
Select “ Switch Call ” to answer another
incoming call. By selecting “ Hang up ” ,
you can end a call and can speak to a
caller who is on hold again.
* This function may not be usable,
depending on the model of phone.
To adjust the person ’ s voice to be louder or
quieter, push the volume control switch (+
or − ) on the steering wheel or turn the
volume control knob on the instrument
panel while talking on the phone. This
adjustment is also available in the SETTING
mode.
Monitor, climate, audio, phone and voice recognition systems
4-97

Black plate (279,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]. Immediately after the ignition switch is
pushed to the “ ON ” position, it may be
impossible to receive a call for a short
period of time.
. Do not place the cellular phone in an
area surrounded by metal or far away
from the in-vehicle phone module to
prevent tone quality degradation and
wireless connection disruption.
. While a cellular phone is connected
through the Bluetooth ®
wireless con-
nection, the battery power of the
cellular phone may discharge quicker
than usual.
. If the Bluetooth ®
Hands-Free Phone
System seems to be malfunctioning,
please contact an INFINITI retailer.
. Some cellular phones or other devices
may cause interference or a buzzing
noise to come from the audio system
speakers. Storing the device in a
different location may reduce or elim-
inate the noise.
. Refer to the cellular phone Owner ’ s
Manual regarding the telephone pairing
procedure specific to your phone,
battery charging, cellular phone anten-
na, etc. . The antenna display on the monitor will
not coincide with the antenna display
of some cellular phones.
. Keep the interior of the vehicle as quiet
as possible to hear the caller ’ s voice
clearly as well as to minimize its
echoes.
. If reception between callers is unclear,
adjusting the incoming or outgoing call
volume may improve the clarity.
. This wireless hands free car kit is based
on Bluetooth ®
technology,
— Frequency: 2402 MHz - 2480 MHz
— Output Power: 4.14 dBm E.I.R.P
— Modulation: FHSS GFSK 8DPSK, p /
4DQPSK
— Number of Channel: 79
— This wireless equipment can ’ t be
used for any services related to
safety because there is the possibi-
lity of radio interference. REGULATORY INFORMATION GUID-C749FDCB-737E-4519-B4F3-DFCB7CB3B425
FCC Regulatory information GUID-65EE5CA7-E4CB-455D-AF2F-D3892B1FD807
. CAUTION: To maintain compliance with
FCC ’ s RF exposure guidelines, use only
the supplied antenna. Unauthorized
antenna, modification, or attachments
could damage the transmitter and may
violate FCC regulations.
. Operation is subject to the following
two conditions:
1) this device may not cause interfer-
ence and
2) this device must accept any inter-
ference, including interference that
may cause undesired operation of
the device
IC Regulatory information GUID-D2159791-E888-41E9-AB71-827684C5E939
. Operation is subject to the following
two conditions: (1) this device may not
cause interference, and (2) this device
must accept any interference, including
interference that may cause undesired
operation of the device.
. This Class B digital apparatus meets all
requirements of the Canadian Interfer-
ence-Causing Equipment Regulations.
Monitor, climate, audio, phone and voice recognition systems
4-101

Black plate (283,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]cent Calls, Connect Phone or Help ” .
3. Give your instructions to the system by
saying: “ Dial John ” for example ( “ John ”
must have been previously set as a
voice tag for John ’ s phone number) or
“ Dial One ” if John is classified as one in
the phonebook.
If the system cannot understand your
command, repeat it according to the
recommendations mentioned in “ How
to speak commands ” (P.4-104).
4. If the given name (voice tag) is correct,
the phone system will dial the number
registered for “ John ” .
INFO
To end the voice command phase at any
stage of the procedure, push the
switch once in order to activate the cancel
command.
Manual command selection: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Commands can be selected manually.
While the commands are displayed on the
screen, select a command by operating the
Tune switch, and then push the
button. Once a command is manually
selected, the voice command function is
cancelled. To return to voice command
mode, push the
button to cancel the current operation, and then perform the
first procedure of voice command.
Monitor, climate, audio, phone and voice recognition systems
4-105
