Black plate (251,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]SAA2510
Audio main operation GUID-14B0AB43-2E50-4AF4-9B57-A348F7513796
Push the ignition switch to the ACC or ON
position. Then, push the DISC·AUX button
repeatedly to switch to the Bluetooth ®
audio mode. If the system has been turned
off while the Bluetooth ®
audio device was
playing, pushing the ON·OFF/VOL control
knob will start the Bluetooth ®
audio
device.
The ability to pause, change tracks, fast
forward, rewind, randomize and repeat
music may be different between devices.
Some or all of these functions may not be
supported on each device. DISC·AUX button: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When the DISC·AUX button is pushed with
the system off and the Bluetooth ®
audio
device connected, the system will turn on.
If another audio source is playing and the
Bluetooth ®
audio device is connected,
push the DISC·AUX button repeatedly until
the display changes to the Bluetooth ®
audio mode.
Next/Previous Track and Fast
Forward/Rewind: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When the or button is pushed for
more than 1.5 seconds while a Bluetooth ®
audio file is being played, the Bluetooth ®
audio device will play while forwarding or
rewinding. When the button is released,
the Bluetooth ®
audio device will return to
normal play speed.
When the
or button is pushed for
less than 1.5 seconds while a Bluetooth ®
audio file is being played, the next track or
the beginning of the current track on the
Bluetooth ®
audio device will be played.
The INFINITI controller can also be used to
select tracks when the Bluetooth ®
audio
play mode screen is shown on the display.
( “ Bluetooth audio ” will be indicated on the header of the screen.)
REPEAT (RPT), RANDOM (RDM): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
To change the play mode, push the
button repeatedly and the mode changes
as follows.
Normal ? Shuffle All Tracks ? Shuffle
Group ? Repeat 1 Track ? Repeat All
Tracks ? Repeat Group ? Normal
Operation keys: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
To operate a Bluetooth ®
audio device,
select a key displayed on the operation
screen using the INFINITI controller.
Play
Select the “
” key to start playing when
pausing. Select this key again to pause the
audio play.
Pause
Select the “
” key to pause the Blue-
tooth ®
audio device. Select this key again
to resume playing.
Play Mode: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
The play mode setting display will appear
when the “ Menu ” key is selected.
Choose the preferred play mode from the
Monitor, climate, audio, phone and voice recognition systems
4-73

Black plate (252,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-74 Monitor, climate, audio, phone and voice recognition systemsfollowing items.
. Shuffle
Choose “ Shuffle OFF ” , “ Shuffle All
Tracks ” and “ Shuffle Group ” .
. Repeat
Choose from “ Repeat OFF ” , “ Repeat 1
Track ” , “ Repeat All Tracks ” and “ Repeat
Group ” . SAA2511
Bluetooth ®
settings GUID-E740A90F-DA65-4B4B-9DB5-140E8E82A0BF
To set up the Bluetooth ®
device system to
the preferred settings, push the SETTING
button and select the “ Bluetooth ” key.
Bluetooth: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
If this setting is turned off, the connection
between the Bluetooth ®
devices and the
in-vehicle Bluetooth ®
module will be can-
celed.
Connect Bluetooth: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Connects to the Bluetooth ®
device. See
“ Connecting procedure ” (P.4-71). Up to 5
devices can be registered. Connected Devices: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Registered devices are shown on the list.
Select a Bluetooth ®
device from the list,
the following options will be available.
. Select
Select “ Select ” to connect the selected
device to the vehicle. If there is a
different device currently connected,
the selected device will replace the
current device.
. Edit
Rename the selected Bluetooth ®
device
using the keypad displayed on the
screen. (See “ How to use touch screen
(models with navigation system) ” (P.4-
5).)
. Delete
Delete the selected Bluetooth ®
device.
Edit Bluetooth Info: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Change the name broadcasted by this
system over Bluetooth ®
. Change the PIN
code that is entered when connecting a
hands free device to this system.
Replace Connected Phone: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Replace the Bluetooth ®
connection with a
connected Bluetooth ®
cellular phone. For
details about Hands-Free Phone System,

Black plate (253,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]see “ Bluetooth ®
Hands-Free Phone System
(models with navigation system) ” (P.4-90).
SAA2974
Automatic transmission models
SAA2426
Manual transmission models iPod ®
PLAYER OPERATION (if so
equipped) GUID-90F666E1-0F3B-4A21-AC5D-3DCDEFBD204E
Connecting iPod ® GUID-F75E089D-4DAB-4B27-BB33-FF3E7F0793C7
Open the console lid and connect the
iPod ®
cable to the USB connector. If
compatible, the battery of the iPod ®
is
charged while the connection to the
vehicle.
Depending on the version of the iPod ®
, the
display on the iPod ®
shows an INFINITI or
Accessory Attached screen when the con-
nection is completed. When the iPod ®
is
connected to the vehicle, the iPod ®
music
library can only be operated by the vehicle
audio controls.
* iPod ®
is a trademark of Apple Inc.,
registered in the U.S. and other countries.
Compatibility GUID-62CF64CA-AF90-4D76-AA98-3269E0716164
The following models are available:
Models with navigation system: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. Fifth generation iPod ®
(version 1.2.3 or
later)
. iPod Classic ®
(version 1.1.1 or later)
. First generation iPod touch ®
(version
2.0.0 or later)
Monitor, climate, audio, phone and voice recognition systems
4-75

Black plate (254,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-76 Monitor, climate, audio, phone and voice recognition systems. Second generation iPod touch ®
(version
1.2.3 or later)
. First generation iPod nano ®
(version
1.3.1 or later)
. Second generation iPod nano ®
(version
1.1.3 or later)
. Third generation iPod nano ®
(version
1.1 or later)
. Fourth generation iPod nano ®
(version
1.0.2 or later)
Models without navigation system: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. Fifth generation iPod ®
(firmware ver-
sion 1.3)
. First generation iPod Classic ®
(firmware
version 1.1.2 PC)
. Second generation iPod Classic ®
(firm-
ware version 2.0 PC)
. First generation iPod touch ®
(firmware
version 2.1)
. Second generation iPod touch ®
(firm-
ware version 2.1.1)
. First generation iPod nano ®
(firmware
version 1.3.1)
. Second generation iPod nano ®
(firm-
ware version 1.1.3)
. Third generation iPod nano ®
(firmware
version 1.1 PC) . Third generation iPhone ®
(firmware
version 2.1)
Make sure that the iPod ®
version is
updated.
Audio main operation GUID-12FEF761-1E1C-44EA-A5B7-774957A975FE
Push the ignition switch to the ACC or ON
position. Then, push the DISC·AUX or DISC
button repeatedly to switch to the iPod ®
mode.
If the system has been turned off while the
iPod ®
was playing, pushing the ON·OFF
button will start the iPod ®
.
or PLAY: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When the DISC·AUX or AUX button is
pushed with the system off and the iPod ®
connected, the system will turn on. If
another audio source is playing and the
iPod ®
is connected, push the DISC·AUX or
AUX button repeatedly until the center
display changes to the iPod ®
mode.
Interface: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
The interface for iPod ®
operation shown on
the vehicle center display is similar to the
iPod ®
interface. Use the INFINITI controller
and the ENTER or BACK button to play the
iPod ®
with your favorite settings. The following items can be chosen from the
menu list screen. For further information
about each item, see the iPod ®
Owner ’ s
Manual.
. Now Playing
. Playlists
. Artists
. Albums
. Songs
. Podcasts
. Genres
. Composers
. Audiobooks
. Shuffle Songs
The following touch-panel buttons shown
on the screen are also available:
.
: returns to the previous screen.
. : plays/pauses the music selected.
Next/Previous Track and Fast
Forward/Rewind: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When the or button is pushed for
more than 1.5 seconds while the iPod ®
is
playing, the iPod ®
will play while fast
forwarding or rewinding. When the button
is released, the iPod ®
will return to the
normal play speed.

Black plate (257,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]If the title information of the track being
recorded is stored either in the hard drive/
flash memory or in the CD, the title is
automatically displayed on the screen. For
title acquisition from the hard drive/flash
memory, music recognition technology and
related data are provided by Gracenote ®
.
If a track is not recorded successfully due
to skipping sounds, the
mark is
displayed behind the track number.
The Music Box ®
hard drive/flash memory
cannot perform recording under the follow-
ing conditions.
. There is not enough space on the hard
drive
. The number of albums reaches the
maximum of 500.
. The number of tracks reaches the
maximum of 3,000.
Automatic recording: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
If the “ Automatic Recording ” function is
turned to ON, recording starts when a CD is
inserted. (See “ Music Box ®
settings ” (P.4-
83).)
Stopping recording: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
To stop the recording, select the “ Stop
REC ” key button by touching the screen or using the INFINITI controller.
If the CD is ejected, the audio system is
turned off or the ignition switch is pushed
to the OFF position, the recording also
stops.
SAA2515
Models with navigation system
SAA2614
Models without navigation system
Monitor, climate, audio, phone and voice recognition systems
4-79

Black plate (258,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-80 Monitor, climate, audio, phone and voice recognition systemsPlaying recorded songs GUID-C323C968-3101-48FD-90F1-4F929759126E
Select the Music Box ®
audio system by
using one of the following methods.
. Push the audio source switch on the
steering wheel repeatedly until the
center display changes to the Music
Box ®
mode. (See “ Steering-wheel-
mounted controls for audio ” (P.4-87).)
. Push the DISC·AUX or DISC button
repeatedly until the center display
changes to the Music Box ®
mode.
. Give voice commands (models with
navigation system). (See “ INFINITI Voice
Recognition system (models with navi-
gation system) ” (P.4-114).)
Stopping playback: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
The system stops playing when:
a. another mode (radio, CD, DVD, USB
memory or iPod) is selected.
b. the audio system is turned off.
c. the ignition switch is pushed to the
LOCK position.
Next/Previous Track and Fast
Forward/Rewind: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When the or button is pushed for
more than 1.5 seconds while a track is being played, the track will play while fast
forwarding or rewinding. When the button
is released, the track will return to the
normal play speed.
When the
or button is pushed for
less than 1.5 seconds while a track is
being played, the next track or the begin-
ning of the current track will be played.
When the REW button is pushed for less
than 1.5 seconds within 3 seconds after
the current track started playing, the
previous track will be played.
When the REW button is pushed for less
than 1.5 seconds after 3 seconds from
when the current track started playing, the
beginning of the current track will be
played.
The INFINITI controller can also be used to
select tracks when a track is being played.
Play mode selection: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
The TUNE/FOLDER knob will skip from
album to album unless it is playing “ All
Songs ” from the Music Library menu. When
playing “ All Songs ” , the knob will change
the track instead of the album. The upper
right corner of the main screen will indicate
if the TUNE knob is changing by track or
album. REPEAT (RPT), RANDOM (RDM): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When the RPT·RDM button is pushed while
a track is being played, the play pattern
can be changed as follows:
(Normal) ? 1 Album Repeat ? 1 Track
Repeat ? 1 Album Random ? All Random
? (Normal)
Tag Track (models with navigation sys-
tem): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Select “ Tag Track ” key on the screen when
a track is being played. A menu will show
the 5 available playlists. Select one of the
playlists to add the current song to that
playlist. If a playlist is not selectable (text
is grayed out), it means the song already
exists in that playlist.

Black plate (259,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]SAA2516
Models with navigation system
SAA2725
Models without navigation system There are some options available by
selecting the “ Menu ” key on the screen
during playback. Select one of the follow-
ing options that are displayed on the
screen if necessary.
Now Playing (models with navigation
system): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Displays a track list to choose a preferred
track for playback.
Music Library: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
There are some options available during
playback. Select one of the following
options that are displayed on the screen
if necessary.
. Artists
Play tracks by an artist whose music is
currently being played. The artists are
sorted in alphabetical order.
. Albums
Play tracks in each album. The albums
are sorted in alphabetical order.
. All Songs
Play tracks from all recorded tracks. The
tracks are sorted in alphabetical order.
. Genres
Play tracks by a selected genre. My Playlists (models with navigation
system): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Displays the Playlist and edits the Playlist
if necessary.
Select the “ Edit ” key.
The following items are available
. Add Current Songs
Add a current track to the Playlist.
. Add Songs by Album
Displays a list of albums in alphabetical
order. Selecting an album displays all
of the tracks in the album. Select tracks
from the list to add to the Playlist.
. Add Songs by Artist
Displays a list of artists in alphabetical
order. Selecting an artist displays all of
the tracks by the artist. Select tracks
from the list to add to the Playlist.
. Edit Songs Order
Reorder the tracks in the Playlist by
selecting a track and specifying the
order.
. Edit Name
Edit the name of the Playlist using the
keypad displayed on the screen. (See
“ How to use INFINITI controller ” (P.4-5).)
Monitor, climate, audio, phone and voice recognition systems
4-81

Black plate (260,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-82 Monitor, climate, audio, phone and voice recognition systems. Delete Songs
Delete tracks in the Playlist by selecting
from the displayed song list.
Play Mode (models with navigation sys-
tem): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Choose the preferred play mode from the
following items.
. Normal
. 1 Album Repeat
. 1 Track Repeat
. 1 Playlist Random
. 1 Artist Random
. 1 Album Random
. 1 All Track Random
. 1 All Random
Edit Music Information: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Displays the following information about
the Music Box ®
hard drive/flash memory
to edit if necessary.
. Edit Information of Current Song (mod-
els with navigation system)
Edit the “ Track ” , “ Artist ” and “ Genre ”
information of the current track using
the keypad displayed on the screen.
(See “ How to use touch screen (models
with navigation system) ” (P.4-5).)
Edit the “ Mode ” information by select- ing from the list.
. Edit Information by Album (models with
navigation system)
Edit the displayed name and of a
selected album and the track informa-
tion in the album.
. Update Gracenote from USB Device
(models with navigation system)/
Transfer Titles from USB (models with-
out navigation system)
Update the in-vehicle Gracenote Data-
base using a USB memory. Search the
title from a information acquired on the
Internet.
Visit www.InfinitiUSA.com/music-up-
date/ for details.
. Transfer Missing Titles to USB
Transfer the information of an album
recorded without titles to a USB mem-
ory.
Visit www.InfinitiUSA.com/music-up-
date/ for details.
. Update Gracenote from HDD (models
with navigation system)/Update Miss-
ing Titles (models without navigation
system)
The title information is acquired from
the database stored on the hard drive/ flash memory.

Black plate (261,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]SAA2517
Models with navigation system
SAA2438
Models without navigation system Music Box ®
settings GUID-EBF55FB9-4A2B-4B66-8082-A26C6DBA92D6
To set the Music box ®
hard drive/flash
memory to your preferred settings, select
the “ Menu ” key during playback, and the
“ Music Box Settings ” key with the INFINITI
controller, and then push the ENTER
button.
Music Box Used/Free Space: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Information about “ Saved Album ” , “ Saved
Track ” and “ Remaining Time ” is displayed.
Automatic Recording: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When this item is turned to ON, the Music
Box ®
hard drive/flash memory automati-
cally starts recording when a CD is
inserted.
Delete Songs from Music Box: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Deletes the current song, selected songs or
albums by choosing from the list, or all
songs/albums in the Music Box ®
.
Recording Quality: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Set the recording quality of 105 kbps or
132 kbps. The default is set to 105 kbps.
CDDB Version (models with navigation
system)/Gracenote Database Version
(models without navigation system): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
The version of the built-in Gracenote Database is displayed.
Gracenote GUID-69AF800C-C11F-4941-B875-EB4F76825E2E
NOTE:
. The information contained in the Grace-
note Database is not fully guaranteed.
. The service of the Gracenote Database
on the Internet may be stopped with-
out prior notice for maintenance.
End-User License Agreement
USE OF THIS PRODUCT IMPLIES ACCEP-
TANCE OF THE TERMS BELOW.
Gracenote ®
MusicID ®
Terms of Use
This application or device contains soft-
ware from Gracenote, Inc. of Emeryville,
California ( “ Gracenote ” ). The software from
Gracenote (the “ Gracenote Software ” ) en-
ables this application to perform disc and/
or file identification and obtain music-
related information, including name, artist,
track, and title information ( “ Gracenote
Data ” ) from online servers or embedded
databases (collectively, “ Gracenote Ser-
vers ” ) and to perform other functions. You
may use Gracenote Data only by means of
the intended End-User functions of this
application or device. You agree that you
Monitor, climate, audio, phone and voice recognition systems
4-83

Black plate (264,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-86 Monitor, climate, audio, phone and voice recognition systems SAA1567
AUX Menu GUID-028F9869-7767-406B-A1DE-AB16A4EB4D4D
When the “ Setting ” key on the display is
selected while in the AUX mode, the menu
screen will be displayed.
Display Mode: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Choose the display mode from the follow-
ing items.
. Normal
. Wide
. Cinema SAA0451
CD/DVD/USB MEMORY CARE AND
CLEANING GUID-4EAEE317-77F3-4525-B6F0-95F17934528E
CD/DVD GUID-11617F31-8FAE-479F-A0DA-9DB80EE21C11
. Handle a CD/DVD by its edges. Never
touch the surface of the disc. Do not
bend the disc.
. Always place the discs in the storage
case when they are not being used.
. To clean a disc, wipe the surface from
the center to the outer edge using a
clean, soft cloth. Do not wipe the disc
using a circular motion.
Do not use a conventional record
cleaner or alcohol intended for indus- trial use.
. A new disc may be rough on the inner
and outer edges. Remove the rough
edges by rubbing the inner and outer
edges with the side of a pen or pencil
as illustrated.
USB memory GUID-CA5F5F5F-0A31-4007-B700-6C062828A2EB
. Never touch the terminal portion of the
USB memory.
. Do not place heavy objects on the USB
memory.
. Do not store the USB memory in highly
humid locations.
. Do not expose the USB memory to
direct sunlight.
. Do not spill any liquids on the USB
memory.
Refer to the USB memory Owner ’ s Manual
for the details.
