[ Edit: 2012/ 1/ 17 Model: V36-D ]5-38 Starting and driving SSD0284A
NOTE:
The approach warning chime may sound
and the system display may blink when
the ICC sensor detects some reflectors
* A
which are fitted on vehicles in other lanes
or on the side of the road. This may cause
the ICC system to decelerate or accelerate
the vehicle. The ICC sensor may detect
these reflectors when the vehicle is driven
on winding roads, hilly roads or when
entering or exiting a curve. The ICC sensor
may also detect reflectors on narrow roads
or in road construction zones. In these
cases you will have to manually control
the proper distance ahead of your vehicle. Also, the sensor sensitivity can be affected
by vehicle operation (steering maneuver or
driving position in the lane) or traffic or
vehicle condition (for example, if a vehicle
is being driven with some damage).
Automatic cancellation GUID-0AB14118-7E5E-448E-A4AF-D59A5196621E
A chime sounds under the following con-
ditions and the control is automatically
canceled.
. When the vehicle speed falls below
approximately 20 MPH (32 km/h)
. When the selector lever is not in the D
(Drive), DS (Drive Sport) or manual shift
mode
. When the windshield wipers are oper-
ated at low speed (LO) or high speed
(HI)
. When the SNOW mode switch is turned
on
. When the VDC is turned off
. When the VDC operates SSD0614
Warning light and display GUID-566B021F-2B96-48F1-8CEC-7D4CA960D1DE
Condition A: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
The chime sounds and the Intelligent
Cruise Control system is canceled auto-
matically in the conditions described be-
low. Part of the system display will come
on or blink, making it impossible to set.
. When the VDC is turned off
. When the ABS or VDC (including the
traction control system) operates
. When a tire slips
. When the SNOW mode switch is turned
on

Black plate (361,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]INFINITI retailer.
. Do not attach a sticker (including
transparent material) or install an
accessory near the sensor. This could
cause failure or malfunction.
CONVENTIONAL (fixed speed)
CRUISE CONTROL MODE GUID-3DA7CE5D-69B5-4A2E-98E2-95413EE4F1CC
This mode allows driving at a speed
between 25 to 89 MPH (40 to 144 km/h)
without keeping your foot on the accel-
erator pedal.
WARNING. In the conventional (fixed speed) cruise
control mode, a warning chime does not
sound to warn you if you are too close to
the vehicle ahead, as neither the pre-
sence of the vehicle ahead nor the
vehicle-to-vehicle distance is detected.
. Pay special attention to the distance
between your vehicle and the vehicle
ahead of you or a collision could occur.
. Always confirm the setting in the In-
telligent Cruise Control system display.
. Do not use the conventional (fixed
speed) cruise control mode when driving under the following conditions:
— when it is not possible to keep the
vehicle at a set speed
— in heavy traffic or in traffic that
varies in speed
— on winding or hilly roads
—
on slippery roads (rain, snow, ice,
etc.)
— in very windy areas
. Doing so could cause a loss of vehicle
control and result in an accident. SSD0617
Conventional (fixed speed) cruise
control switch GUID-56C647E0-81F9-468F-A1CA-BDF85042367A
1. ACCELERATE/RESUME switch:
Resumes set speed or increases speed
incrementally.
2. COAST/SET switch:
Sets the desired cruise speed, reduces
speed incrementally.
3. CANCEL switch:
Deactivates the system without erasing
the set speed.
4. MAIN switch:
Master switch to activate the system.
Starting and driving
5-41

Black plate (362,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]5-42 Starting and driving SSD0618
Conventional (fixed speed) cruise
control mode display and indica-
tors GUID-E2A2ADAB-017E-4E8A-AC56-F75C293753E2
The display is located between the speed-
ometer and tachometer.
1. MAIN switch indicator:
Indicates that the MAIN switch is ON.
2. Cruise set switch indicator:
Displays while the vehicle speed is
controlled by the conventional (fixed
speed) cruise control mode of the ICC
system. 3. Cruise system warning light:
Comes on if there is a malfunction in
the cruise control system.
SSD0619
Operating conventional (fixed
speed) cruise control mode GUID-E7361754-7EA1-4F3D-BBE9-EF37A8D74CDE
To turn on the conventional (fixed speed)
cruise control mode, push and hold the
MAIN switch
* A
for longer than about 1.5
seconds.
When pushing the MAIN switch on, the
Intelligent Cruise Control system display
and the CRUISE indicator are displayed on
the dot matrix crystal display. After you
hold the MAIN switch on for longer than
about 1.5 seconds, the Intelligent Cruise
Control system display goes out. The
CRUISE indicator stays lit. You can now

Black plate (363,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]set your desired cruising speed. Pushing
the MAIN switch again will turn the system
completely off.
When the ignition switch is pushed to the
OFF position, the system is also automati-
cally turned off. To use the Intelligent
Cruise Control again, quickly push and
release the MAIN switch (vehicle-to-vehicle
distance control mode) or push and hold it
(conventional cruise control mode) again to
turn it on.
CAUTIONTo avoid accidentally engaging cruise con-
trol, make sure to turn the MAIN switch off
when not using the Intelligent Cruise Con-
trol system. SSD0620
To set cruising speed, accelerate your
vehicle to the desired speed, push the
COAST/SET switch and release it. (The SET
indicator will come on in the display.) Take
your foot off the accelerator pedal. Your
vehicle will maintain the set speed.
. To pass another vehicle, depress the
accelerator pedal. When you release
the pedal, the vehicle will return to the
previously set speed.
. The vehicle may not maintain the set
speed when going up or down steep
hills. If this happens, manually main-
tain vehicle speed.
To cancel the preset speed, use any of the following methods:
1. Push the CANCEL button. The SET
indicator will go out.
2. Tap the brake pedal. The SET indicator
will go out.
3. Turn the MAIN switch off. Both the
CRUISE indicator and SET indicator will
go out.
To reset at a faster cruising speed, use one
of the following three methods:
1. Depress the accelerator pedal. When
the vehicle attains the desired speed,
push and release the COAST/SET
switch.
2. Push and hold the ACCELERATE/RE-
SUME set switch. When the vehicle
attains the speed you desire, release
the switch.
3. Push, then quickly release the ACCEL-
ERATE/RESUME switch. Each time you
do this, the set speed will increase by
about 1 MPH (1.6 km/h).
To reset at a slower cruising speed, use
one of the following three methods:
1. Lightly tap the brake pedal. When the
vehicle attains the desired speed, push
the COAST/SET switch and release it.
Starting and driving
5-43

Black plate (369,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]stacles or false alarms.
CAUTIONKeep the interior of the vehicle as quiet as
possible to hear the tone clearly.
The sonar system sounds a tone to warn
the driver of obstacles near the bumper.
When the “ Sonar Display ” key is ON, the
sonar indicator will also appear in the
center display. (See “ Sonar indicator ” (P.5-
49).) The system detects rear obstacles
when the selector lever is in the “ R ”
(Reverse) position.
The system may not detect objects at
speeds above 6 MPH (10 km/h) and may
not detect certain angular or moving
objects.
The sonar system detects obstacles up to
3.9 feet (1.2 m) from the bumper with a
decreased coverage area at the outer
corners of the bumper. Refer to the
illustration for approximate zone coverage
areas. As you move closer to the obstacle,
the rate of the tone increases. When the
obstacle is less than 11.8 in (30 cm) away, the tone will sound continuously.
Keep the corner/center sonar (located on
the bumper fascia) free from snow, ice and
large accumulations of dirt (do not clean
the sonar with sharp objects). If the sonar
is covered, it will affect the accuracy of the
sonar system.
The sensitivity level of the corner/center
sonar can be adjusted (higher or lower) in
the SONAR setting display. (See “ How to
use SETTING button ” (P.4-14) for the
“ Sonar ” settings.) SSD0928
* 1
Rear view monitor display
* A
Corner sonar indicator
* B
Center sonar indicator
SONAR INDICATOR GUID-BCE909B1-A1DD-4D6D-AC06-E3739C301FD2
With the “ Sonar Display ” key ON in the
“ Sonar ” settings, when the corner/center
sonar detects obstacles near the bumper, a
tone will sound and the sonar indicator will
appear in the center display. When the rear
view monitor is displayed, the sonar
indicator will appear in the upper corner
of the display
* 1
.
The sonar indicators
* A
and
* B
indicate
the position of the object and the distance
Starting and driving
5-49

Black plate (370,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]5-50 Starting and drivingto the object with its color and rate of
blinking.
When an object is detected, the indicator
(green) appears and blinks (the tone
sounds intermittently). When the vehicle
moves closer to the object, the color of the
indicator turns yellow and the rate of
blinking increases (the rate of the tone
increases). When the corner of the vehicle
is very close to the object, less than 11.8 in
(30 cm) away, the indicator stops blinking
and turns red (the tone sounds continu-
ously).
When the rear view monitor is displayed,
the colors of the sonar indicator and the
distance guide lines in the rear view
indicate different distances to the object.
The sonar indicator can be turned off in the
SONAR setting display. (See “ How to use
SETTING button ” (P.4-14) for the “ Sonar ”
settings.) When the sonar indicator is off,
only a tone sounds when the sonar detects
obstacles. SSD0929
SONAR SYSTEM OFF SWITCH GUID-446340A3-E5C0-4566-9701-88DF98FE3774
The sonar system OFF switch on the
instrument panel allows the driver to turn
the sonar system on and off. To turn the
sonar system on and off, the ignition
switch must be in the “ ON ” position. The
indicator light
* 1
on the switch will
illuminate when the system is turned off.
If the indicator light flashes when the
sonar system is not turned off, it may
indicate a malfunction in the sonar system. GUID-7A26DC9E-F480-487F-A4C2-174FF498CC5C
WARNING If the engine is not running or is turned off
while driving, the power assist for the
steering will not work. Steering will be
harder to operate.
The power assisted steering uses a hy-
draulic pump, driven by the engine, to
assist steering.
If the engine stops or the drive belt breaks,
you will still have control of the vehicle.
However, much greater steering effort is
needed, especially in sharp turns and at
low speeds.POWER STEERING

Black plate (373,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]all times.
. As there is a performance limit to the
Preview Function, never rely solely on
this system. This system does not
correct careless inattentive or absent-
minded driving, or overcome poor visi-
bility in rain, fog, or other bad weather.
Reduce vehicle speed by depressing the
brake pedal, in order to maintain a safe
distance between vehicles.
. The system may not detect the vehicle in
front of you in certain road or weather
conditions. The Preview Function may
not operate properly under the following
conditions. The vehicle is still driveable
under normal conditions and the Brake
Assist will operate.
— When rain, snow or dirt adhere to
the system sensor
— When strong light (for example, at
sunrise or sunset) is directly shining
on the front of the vehicle
— Winding or hilly roads may cause
the sensor to temporarily not detect
a vehicle in the same lane or may
detect objects or vehicles in other
lanes. — Vehicle position in the lane may
cause the sensor to temporarily not
detect a vehicle in the same lane or
may detect objects or vehicles in
other lanes.
SSD0471
Warning light and display GUID-A2927947-1E33-4EB3-9D1D-6799F67E6AB2
When the Preview Function is not operating
properly, a chime sounds and the system
warning light (orange) will come on.
Action to take: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
If the warning light comes on, park the
vehicle in a safe place. Turn the engine off,
restart the engine and resume driving.
If the indicator stays on, it may indicate
that the Preview Function is malfunction-
ing (the brake is operative). Although the
Vehicle is still driveable under normal
conditions, have the vehicle checked at
an INFINITI retailer.
Starting and driving
5-53

Black plate (382,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]6-2 In case of emergency GUID-B26201B1-5E14-45EB-9707-DC8F1E4219FD
In the event of a roadside emergency,
Roadside Assistance Service is available to
you. Please refer to your Warranty Informa-
tion Booklet (U.S.) or Warranty & Roadside
Assistance Information Booklet (Canada)
for details. GUID-FB799410-A0CC-4EDA-A522-6DA1F88B3F1E
To shut off the engine in an emergency
situation while driving, perform the follow-
ing procedure:
. Rapidly push the push-button ignition
switch 3 consecutive times in less than
1.5 seconds, or
. Push and hold the push-button ignition
switch for more than 2 seconds. GUID-17D7421B-973E-4FF8-B56B-831261C859DB
TIRE PRESSURE MONITORING SYS-
TEM (TPMS) GUID-EFDE8E6D-AFA0-4243-A90D-0D01CCEE6814
This vehicle is equipped with the Tire
Pressure Monitoring System (TPMS). It
monitors tire pressure of all tires except
the spare. When the low tire pressure
warning light is lit and the CHECK TIRE
PRESSURE warning appears on the dot
matrix liquid crystal display, one or more
of your tires is significantly under-inflated.
If the vehicle is being driven with low tire
pressure, the TPMS will activate and warn
you of it by the low tire pressure warning
light. This system will activate only when
the vehicle is driven at speeds above 16
MPH (25 km/h). For more details, see
“ Warning/indicator lights and audible re-
minders ” (P.2-12) and “ Tire Pressure Mon-
itoring System (TPMS) ” (P.5-4).
WARNING . If the low tire pressure warning light
illuminates while driving, avoid sudden
steering maneuvers or abrupt braking,
reduce vehicle speed, pull off the road to
a safe location and stop the vehicle as
soon as possible. Driving with under-
inflated tires may permanently damageROADSIDE ASSISTANCE PROGRAM EMERGENCY ENGINE SHUT OFF FLAT TIRE

Black plate (439,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]GUID-9503AF79-9CA5-400E-9F06-81B6757D713C
If you have a flat tire, see “ Flat tire ” (P.6-
2).
TIRE PRESSURE GUID-059CBC2D-BB1C-4DE2-B26E-A89198E003F1
Tire Pressure Monitoring System
(TPMS) GUID-54149EBD-6C2B-4EEC-AE1A-FDADBBA021B3
This vehicle is equipped with the Tire
Pressure Monitoring System (TPMS). It
monitors tire pressure of all tires except
the spare. When the low tire pressure
warning light is lit and the CHECK TIRE
PRESSURE warning appears on the dot
matrix liquid crystal display, one or more
of your tires is significantly under-inflated.
The TPMS will activate only when the
vehicle is driven at speeds above 16 MPH
(25 km/h). Also, this system may not
detect a sudden drop in tire pressure (for
example a flat tire while driving).
For more details, see “ Low tire pressure
warning light ” (P.2-15), “ Tire Pressure
Monitoring System (TPMS) ” (P.5-4) and
“ Tire Pressure Monitoring System (TPMS) ”
(P.6-2).
Tire inflation pressure GUID-FDC2587E-609D-4595-9387-574BE1BDEAC6
Check the pressure of the tires
(including the spare) often and al- ways prior to long distance trips. The
recommended tire pressure specifi-
cations are shown on the Tire and
Loading Information label under the
“ Cold Tire Pressure ” heading. The
Tire and Loading Information label is
affixed to the driver side center pillar.
Tire pressures should be checked
regularly because: .
Most tires naturally lose air over
time. .
Tires can lose air suddenly when
driven over potholes or other
objects or if the vehicle strikes a
curb while parking.
The tire pressures should be checked
when the tires are cold. The tires are
considered COLD after the vehicle
has been parked for 3 or more hours,
or driven less than 1 mile (1.6 km) at
moderate speeds.
Incorrect tire pressure, including
under inflation, may adversely affect
tire life and vehicle handling. WARNING .
Improperly inflated tires can fail
suddenly and cause an accident. .
The Gross Vehicle Weight rating
(GVWR) is located on the F.M.V.S.
S./C.M.V.S.S. label. The vehicle
weight capacity is indicated on
the Tire and Loading Information
label. Do not load your vehicle
beyond this capacity. Overloading
your vehicle may result in reduced
tire life, unsafe operating condi-
tions due to premature tire failure,
or unfavorable handling character-
istics and could also lead to a
serious accident. Loading beyond
the specified capacity may also
result in failure of other vehicle
components. .
Before taking a long trip, or
whenever you heavily load your
vehicle, use a tire pressure gauge
to ensure that the tire pressures
Maintenance and do-it-yourself
8-33WHEELS AND TIRES

Black plate (479,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]10 Index Number4 Wheel Active Steer (4WAS) system .................... 5-57
4 Wheel Active Steer (4WAS) warning light .......... 2-14
AABS (Anti-lock Braking System) ............................ 5-54
Advanced air bag system ..................................... 1-46
Air bag system
Advanced air bag system ................................ 1-46
Front passenger air bag and status light ......... 1-49
Front-seat mounted side-impact supplemental
air bag system ................................................ 1-52
Roof-mounted curtain side-impact
supplemental air bag system .......................... 1-52
Air bag warning labels ......................................... 1-55
Air bag warning light .................................. 1-55, 2-17
Air cleaner housing filter ...................................... 8-21
Air conditioner
Air conditioner service .................................... 4-41
Air conditioner specification label ................... 9-14
Air conditioning system refrigerant and
lubricant recommendations ..................... 4-41, 9-7
Automatic climate control ............................... 4-31
In-cabin microfilter .......................................... 4-40
Alarm, How to stop alarm (see vehicle
security system) ................................................... 2-29
Alcohol, drugs and driving ..................................... 5-8
All-wheel drive (AWD) ........................................... 5-45 All-wheel drive (AWD) driving
safety precautions ................................................. 5-8
All-wheel drive (AWD) warning light ..................... 2-12
Antenna ............................................................... 4-89
Anti-lock Braking System (ABS) ............................ 5-54
Anti-lock braking system (ABS) warning light ....... 2-13
Appearance care
Exterior appearance care ................................... 7-2
Interior appearance care ................................... 7-4
Armrest ................................................................ 1-13
Ashtrays (See cigarette lighter and ashtrays) ....... 2-44
Audible reminders ............................................... 2-19
Audio operation precautions ................................ 4-41
Audio system ....................................................... 4-41
Steering wheel audio controls ......................... 4-87
Autolight system .................................................. 2-35
Automatic
Automatic adjusting function
(front windows) ............................................... 2-54
Automatic climate control ..................... 4-32, 4-34
Automatic transmission fluid (ATF) .................. 8-14
Climate control ............................................... 4-31
Door locks ........................................................ 3-6
Drive positioner .............................................. 3-31
Driving with automatic transmission ............... 5-14
Moonroof ........................................................ 2-55
Seat positioner ............................................... 3-31
Average fuel consumption and speed ................... 2-26
Avoiding collision and rollover ............................... 5-6 B Battery ................................................................. 8-17
Battery saver system ...................................... 2-37
Intelligent Key ................................................. 8-26
Variable voltage control system ...................... 8-19
Before starting the engine ................................... 5-12
Belts (See drive belts) .......................................... 8-19
Bluetooth ®
hands-free phone system
(models with navigation system) .......................... 4-90
Bluetooth ®
hands-free phone system
(models without navigation system) ................... 4-100
Bluetooth ®
streaming audio ................................ 4-70
Brake
Anti-lock Braking System (ABS) ....................... 5-54
Brake and clutch fluid ..................................... 8-15
Brake fluid ...................................................... 8-15
Brake system .................................................. 5-51
Parking brake operation .................................. 5-20
Warning light .................................................. 2-13
Break-in schedule ................................................ 5-45
Brightness control
Display ON/OFF button ..................................... 4-9
Instrument panel ............................................ 2-38
Bulb check/instrument panel ............................... 2-12
Bulb replacement ................................................. 8-28
