[ Edit: 2012/ 1/ 17 Model: V36-D ]4-22 Monitor, climate, audio, phone and voice recognition systems SAA2491
Image Viewer (models with naviga-
tion system) GUID-3A8CCE29-BAF6-4276-8E18-96A1950EFDF7
The image files in the USB memory will be
displayed. To display the Image Viewer,
push the SETTING button, select the
“ Other ” key and then select the “ Image
Viewer ” key. The image of the selected file
is displayed on the right side of the screen.
When a number of folders are included in
the USB memory, select a folder from the
list to display the file list.
Images will not be shown on the display
while the vehicle is in any drive position to
reduce driver distraction. To view images, stop the vehicle in a safe location and
apply the parking brake.
SAA2492
Full Screen Display: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
The full screen display will appear when
selecting the “ Full Screen Display ” key.
To operate the Image Viewer or to change
the settings, select the desired key using
the INFINITI controller.
.
(Start)
Select the “ ” key to start playing
the slideshow.
.
(Stop)
Select the “
” key to stop the
slideshow.
.
(Next)
Select the “ ” key to display the next

Black plate (201,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]file.
. (Previous)
Select the “
” key to display the
previous file.
Setting the Image Viewer: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
The Image Viewer setting display will
appear when selecting the “ Settings ” key
on the full screen display. The following
settings are available for the full screen
display.
. Slideshow Speed
Select the “ Slideshow Speed ” key.
From the following display, select the
changing time from 5, 10, 30, 60
seconds or “ No Auto Change ” .
. Slideshow Order
Select the “ Slideshow Order ” key. From
the following display, select “ Random ”
or “ Order List ” . For “ Order List ” , the
image order is the order of the files as
stored on the USB memory.
Operating tips: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. Only files that meet the following
conditions will be displayed.
— Image type: JPEG
— File Extensions: *.jpg, *jpeg — Maximum Resolution: 2048 6 1536
pixels
— Maximum Size: 2-MB
— Colors: 32768 (15-bit)
— Maximum File Name lengths: 253-
Bytes
— Maximum Folders: 500
— Maximum Images per Folder: 1024
. If an electronic device (such as a digital
camera) is directly connected to the
vehicle using a USB cable, no image
will be displayed on the screen.
. If the file name is too long, some file
names may not be entirely displayed.
. When the total number of characters in
the file name exceeds 100 or if 1 file
name in a directory exceeds 100
characters, all files will show a shor-
tened 8-character version. The image
will still be displayed when selected. GUID-63214A06-C148-4301-9B23-AF1E0EA151B6
When the selector/shift lever is shifted into
the “ R ” (Reverse) position, the monitor
display shows view to the rear of the
vehicle.
The system is designed as an aid to the
driver in detecting large stationary objects
to help avoid damaging the vehicle. The
system will not detect small objects below
the bumper and may not detect objects
close to the bumper or on the ground.
WARNING . The rearview monitor is a convenience
but it is not a substitute for proper
vehicle operation because it has areas
where objects cannot be viewed. Always
look out the windows and check mirrors
to be sure that it is safe to move before
operating the vehicle. Always operate
the vehicle slowly.
. Objects viewed in the RearView Monitor
differ from actual distance because a
wide-angle lens is used. Objects in the
RearView Monitor will appear visually
opposite like ones viewed in the inside
and outside mirrors.
. Make sure that the trunk is securely
closed when backing up.
Monitor, climate, audio, phone and voice recognition systems
4-23REARVIEW MONITOR (if so equipped)

Black plate (202,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-24 Monitor, climate, audio, phone and voice recognition systems. Underneath the bumper and the corner
areas of the bumper cannot be viewed on
the rearview monitor because of its
monitoring range limitation.
. Do not put anything on the rearview
camera. The rearview camera is installed
above the license plate.
. When washing the vehicle with high-
pressure water, be sure not to spray it
around the camera. Otherwise, water
may enter the camera unit causing water
condensation on the lens, a malfunction,
fire or an electric shock.
. Do not strike the camera. It is a precision
instrument. Otherwise, it may malfunc-
tion or cause damage resulting in a fire
or an electric shock.
CAUTIONThere is a plastic cover over the camera. Do
not scratch the cover when cleaning dirt or
snow from the cover. SAA1896
HOW TO READ DISPLAYED LINES GUID-2618A9E5-1A1F-4AE7-9A2B-28557D8D9F81
Guiding lines which indicate the vehicle
width and distances to objects with re-
ference to the bumper line
* A
are dis-
played on the monitor.
Distance guide lines:
Indicate distances from the bumper.
. Red line
* 1
: approx. 1.5 ft (0.5 m)
. Yellow line
* 2
: approx. 3 ft (1 m)
. Green line
* 3
: approx. 7 ft (2 m)
. Green line
* 4
: approx. 10 ft (3 m)
Vehicle width guide lines
* 5
:
Indicate the vehicle width when backing up.
Predicted course lines
* 6
:
Indicate the predicted course when back-
ing up. The predicted course lines will be
displayed on the monitor when the selec-
tor/shift lever is in the “ R ” (Reverse)
position and the steering wheel is turned.
The predicted course lines will move
depending on how much the steering
wheel is turned and will not be displayed
while the steering wheel is in the neutral
position.
HOW TO PARK WITH PREDICTED
COURSE LINES GUID-E6DBE254-D73E-4977-91E5-7921E8117C6E
WARNING . Always turn and check that it is safe to
park your car before backing up. Always
back up slowly.
. Use the displayed lines as a reference.
The lines are highly affected by the
number of occupants, fuel level, vehicle
position, road condition and road grade.
. If the tires are replaced with different
sized tires, the predicted course line
may not be displayed correctly.

Black plate (203,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]. On a snow-covered or slippery road,
there may be a difference between the
predicted course line and the actual
course line.
. If the battery is disconnected or be-
comes discharged, the predicted course
lines may not be displayed correctly. If
this occurs, drive the vehicle on a
straight road for more than 5 minutes.
. The displayed lines will appear slightly
off to the right because the rearview
camera is not installed in the rear center
of the vehicle.
. The distance guide line and the vehicle
width guide line should be used as a
reference only when the vehicle is on a
level paved surface. The distance viewed
on the monitor is for reference only and
may be different than the actual distance
between the vehicle and displayed ob-
jects.
. When backing up the vehicle up a hill,
objects viewed in the monitor are further
than they appear. When backing up the
vehicle down a hill, objects viewed in the
monitor are closer than they appear. Use
the inside mirror or glance over your
shoulder to properly judge distances to other objects.
The vehicle width and predicted course
lines are wider than the actual width and
course.
SAA1897
1. Visually check that the parking space is
safe before parking your vehicle.
2. The rearview of the vehicle is displayed
on the screen
* A
as illustrated when
the selector/shift lever is moved to the
“ R ” (Reverse) position.
Monitor, climate, audio, phone and voice recognition systems
4-25

Black plate (204,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-26 Monitor, climate, audio, phone and voice recognition systems SAA1898
3. Slowly back up the vehicle adjusting
the steering wheel so that the predicted
course lines
* B
enter the parking
space
* C
.
4. Maneuver the steering wheel to make
the vehicle width guide lines
* D
parallel to the parking space
* C
while referring to the predicted course lines.
5. When the vehicle is parked in the space
completely, move the selector/shift
lever to the P (Park) position (Automatic
Transmission models) or in an appro-
priate gear (Manual Transmission mod-
els) and apply the parking brake.
DIFFERENCE BETWEEN PREDICTED
AND ACTUAL DISTANCES GUID-9C8077A7-378D-4FBF-A8ED-EAB27EE0942F
The distance guide line and the vehicle
width guide line should be used as a
reference only when the vehicle is on a
level, paved surface. The distance viewed
on the monitor is for reference only and
may be different from the actual distance
between the vehicle and displayed objects.
SAA1899
Backing up on a steep uphill GUID-FBF6C947-02DC-491C-94A4-77253C889F35
When backing up the vehicle up a hill, the
distance guide lines and the vehicle width
guide lines are shown closer than the
actual distance. For example, the display
shows 3 ft (1 m) to the place
* A
, but the
actual 3 ft (1 m) distance on the hill is the

Black plate (205,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]place
* B
. Note that any object on the hill is
further than it appears on the monitor.
SAA1900
Backing up on a steep downhill GUID-371DFD18-DBE9-419F-9782-291E25E969AA
When backing up the vehicle down a hill,
the distance guide lines and the vehicle
width guide lines are shown further than
the actual distance. For example, the
display shows 3 ft (1 m) to the place
* A
,
but the actual 3 ft (1 m) distance on the hill is the place
* B
. Note that any object on
the hill is closer than it appears on the
monitor.
Monitor, climate, audio, phone and voice recognition systems
4-27

Black plate (206,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-28 Monitor, climate, audio, phone and voice recognition systems SAA1923
Backing up near a projecting object GUID-21E0DDA2-D6DF-4BEC-9EC6-DAA45C5A151A
The predicted course lines
* A
do not touch
the object in the display. However, the
vehicle may hit the object if it projects over
the actual backing up course. SAA1924
Backing up behind a projecting
object GUID-2B9F6D88-E4A9-43BC-A5D2-C5EF6F380AE0
The position
* C
is shown further than the
position
* B
in the display. However, the
position
* C
is actually at the same
distance as the position
* A
. The vehicle may hit the object when backing up to the
position
* A
if the object projects over the
actual backing up course.

Black plate (207,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]SAA2404
Models with navigation system
SAA2606
Models without navigation system PREDICTIVE COURSE LINE SETTINGS GUID-E2F40034-05E0-401F-9E99-A34483BA8B36
To turn ON or OFF the predictive course line
display, push the SETTING button, select
the “ Camera ” key and push the ENTER
button.
. Predictive Course Lines
When this item is turned to ON, the
predicted course lines will be displayed
on the monitor when the selector/shift
lever is in the “ R ” (Reverse) position.
HOW TO ADJUST SCREEN GUID-8EC63937-DDFF-48F5-9E13-CE42D28EBED6
To adjust the Display ON/OFF, Brightness,
Tint, Color, Contrast and Black Level of the
rearview monitor, push the SETTING button
with the rearview monitor on, select the
“ Display ” key on the screen and select the
item key and adjust the level using the
INFINITI controller.
Do not adjust the Brightness, Tint, Color,
Contrast and Black Level of the rearview
monitor while the vehicle is moving. Make
sure the parking brake is firmly applied
and the engine is not running. OPERATING TIPS GUID-C7806C41-88DD-4A7A-BEE4-AA3328E302E3
. When the selector/shift lever is shifted
to the “ R ” (Reverse) position, the
monitor screen automatically changes
to the rearview monitor mode. How-
ever, the radio can be heard.
. It may take some time until the rearview
monitor is displayed after the selector/
shift lever has been shifted to “ R ” from
another position or to another position
from “ R ” . Objects may be distorted
momentarily until the rearview monitor
screen is displayed completely.
. When the temperature is extremely high
or low, the screen may not clearly
display objects. This is not a malfunc-
tion.
. When strong light directly enters the
camera, objects may not be displayed
clearly. This is not a malfunction.
. Vertical lines may be seen in objects on
the screen. This is due to strong
reflected light from the bumper. This
is not a malfunction.
. The screen may flicker under fluores-
cent light. This is not a malfunction.
. The colors of objects on the rearview
monitor may differ somewhat from
those of the actual object.
Monitor, climate, audio, phone and voice recognition systems
4-29

Black plate (208,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-30 Monitor, climate, audio, phone and voice recognition systems. Objects on the monitor may not be clear
in a dark place or at night. This is not a
malfunction.
. If dirt, rain or snow attaches to the
camera, the rearview monitor may not
clearly display objects. Clean the cam-
era.
. Do not use alcohol, benzine or thinner
to clean the camera. This will cause
discoloration. To clean the camera,
wipe with a cloth dampened with
diluted mild cleaning agent and then
wipe with a dry cloth.
. Do not damage the camera as the
monitor screen may be adversely af-
fected.
. Do not use wax on the camera window.
Wipe off any wax with a clean cloth
dampened with mild detergent diluted
with water. GUID-FF3BF386-CA16-4E70-96E6-5D697D98198B
SAA1499
Center ventilators
SAA1500
Side ventilators SAA0564B
Rear (if so equipped)
Open or close, and adjust the air flow
direction of ventilators. : This symbol indicates that the vents are
closed.
: This symbol indicates that the vents are open.VENTILATORS

Black plate (209,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]GUID-75B26382-3BA8-4480-A2A3-F834A9B75BC4
WARNING. The air conditioner cooling function
operates only when the engine is run-
ning.
. Do not leave children or adults who
would normally require the support of
others alone in your vehicle. Pets should
not be left alone either. On hot, sunny
days, temperatures in a closed vehicle
could quickly become high enough to
cause severe or possibly fatal injuries to
people or animals.
. Do not use the recirculation mode for
long periods as it may cause the interior
air to become stale and the windows to
fog up.
Start the engine and operate the automatic
climate control system.
When the “ STATUS ” button is pushed, the
automatic climate control status screen
will appear. (See “ How to use STATUS
button ” (P.4-9).) SAA2723
Models with navigation system
SAA1520
Models without navigation system You can individually set the driver and front
passenger side temperature using each
temperature control button (if so
equipped).
Monitor, climate, audio, phone and voice recognition systems
4-31AUTOMATIC CLIMATE CONTROL
