display INFINITI G37 2012 Service Manual

Black plate (196,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-18 Monitor, climate, audio, phone and voice recognition systems SAA2487
Clock settings (models with navi-
gation system) GUID-B9CF9FB9-D5FE-4867-98B3-5D7755C52672
The display as illustrated will appear when
pushing the SETTING button and selecting
the “ Clock ” key.
On-screen Clock: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When this item is turned to ON, a clock is
always displayed in the upper right corner
of the screen.
This clock will indicate the time almost
exactly because it is always adjusted by
the GPS system. Clock Format (24h): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When this item is turned to ON, the 24-
hour clock is displayed. When this item is
not turned to ON, the 12-hour clock is
displayed.
Offset (hour)/(min): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Adjust the time by increasing or decreasing
per hour or per minute.
Daylight Saving Time: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Turn this item to ON for daylight saving
time application.
Time Zone: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Choose the time zone from the following
. Pacific
. Mountain
. Central
. Eastern
. Atlantic
. Newfoundland
. Hawaii
. Alaska SAA3019
Others settings (models with navi-
gation system) GUID-5502AFAA-980F-4CBD-AAF3-40F5218DA4F3
The Others settings display will appear
when pushing the SETTING button and
selecting the “ Others ” key.
The following items are available:
. Comfort
. Language & Units
. Voice Recognition
. Camera
. Sonar
. Image Viewer

Black plate (197,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]SAA2488
Models with navigation system
SAA3150
Models without navigation system Comfort settings GUID-E6BF814A-EA39-4468-827A-98326ACDC872
Models with navigation system:
The display as illustrated will appear when
pushing the SETTING button, selecting the
“ Others ” key and then selecting the
“ Comfort ” key. This key does not appear
on the display until the ignition switch is
pushed to the ON position.
Models without navigation system:
The display as illustrated will appear when
pushing the SETTING button and selecting
the “ Comfort ” key. This key does not
appear on the display until the ignition
switch is pushed to the ON position.
Auto Interior Illumination: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When this item is turned to ON, the interior
lights will illuminate if any door is un-
locked.
Light Sensitivity: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Adjust the sensitivity of the automatic
headlights higher (right) or lower (left).
Lift Steering Wheel on Exit (if so
equipped): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When this item is turned to ON, the
steering wheel moves upward for easy exit
if the ignition switch is in the LOCK
position and the driver ’ s door is opened. After getting into the vehicle and pushing
the ignition switch to the ACC position, the
steering wheel moves to the previous
position.
Slide Driver Seat Back on Exit (if so
equipped): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When this item is turned to ON, the driver ’ s
seat moves backward for easy exit if the
ignition switch is in the OFF position and
the driver ’ s door is opened. After getting
into the vehicle and pushing the ignition
switch to the ACC position, the driver ’ s seat
moves to the previous position.
Light Off Delay: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Choose the duration of the automatic
headlight off timer from 0, 30, 45, 60, 90,
120, 150 and 180 second periods.
Speed Sensing Wiper Interval (if so
equipped): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When this item is turned to ON, the wiper
interval is adjusted automatically accord-
ing to the vehicle speed.
Selective Door Unlock: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When this item is turned to ON, only the
driver ’ s door is unlocked first after the door
unlock operation. When the door handle
request switch on the driver ’ s or front
Monitor, climate, audio, phone and voice recognition systems
4-19

Black plate (198,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-20 Monitor, climate, audio, phone and voice recognition systemspassenger ’ s side door is pushed to be
unlocked, only the corresponding door is
unlocked first. All the doors can be
unlocked if the door unlock operation is
performed again within 60 seconds.
When this item is turned to OFF, all the
doors will be unlocked after the door
unlock operation is performed once.
Intelligent Key Lock/Unlock: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When this item is turned to ON, door lock/
unlock function by pushing the door
handle request switch will be activated.
Return All Settings to Default: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Select this item and then select “ YES ” to
return all settings to the default. SAA2490
Models with navigation system
SAA1092
Models without navigation system Language & Units settings GUID-2D1FB194-339E-4AB6-A28E-3E1121BEF0F9
The Language & Units settings display will
appear when pushing the SETTING button,
selecting the “ Language & Units ” key with
the INFINITI controller and pushing the
ENTER button.
For models with the navigation system,
select the “ Others ” key to show the
“ Language & Units ” key.
Select Language: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Select the “ Select Language ” key. Choose
“ English ” , “ Français ” or “ Español ” for your
favorite display appearance.
If you select the “ Français ” key, the French
language will be displayed, so please use
the French Owner ’ s Manual. To obtain a
French Owner ’ s Manual, see “ Owner ’ s
Manual/Service Manual order information ”
(P.9-28).
Select Units: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Select the “ Select Units ” key. Choose “ US ”
(Mile, 8 F, MPG) or “ Metric ” (km, 8 C, L/100
km) for your favorite display appearance.
Voice Recognition settings (models
with navigation system) GUID-CA02A577-3092-4FA9-B79C-9BA33C2AE64F
For details about the “ Voice Recognition ”
settings, see “ INFINITI Voice Recognition

Black plate (199,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]system (models with navigation system) ”
(P.4-114).
Camera settings (if so equipped) GUID-80B11575-71A9-4388-9AFE-30F59A573C6D
The “ CAMERA ” screen will appear when
selecting the “ Camera ” key with the
INFINITI controller and pushing the ENTER
button.
For the details about the camera system
operation, see “ RearView monitor ” (P.4-
23). JVH0141M
Models with navigation system
JVH0142M
Models without navigation system Sonar settings (if so equipped) GUID-99894C51-99A7-40BC-AF20-0BFD30B2C365
The “ Sonar ” screen will appear when
selecting the “ Sonar ” key with the INFINITI
controller and pushing the ENTER button.
For the details of the sonar system opera-
tion, see “ Sonar system ” (P.5-48).
Sonar Display: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When this item is turned ON, the corner/
center sonar indicator will appear when the
sonar detect rear obstacles near the
bumper.
Corner Sonar Sensitivity: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Adjust the sensitivity level of the corner
sonar higher (right) or lower (left).
Center Sonar Sensitivity: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Adjust the sensitivity level of the center
sonar higher (right) or lower (left).
Monitor, climate, audio, phone and voice recognition systems
4-21

Black plate (200,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-22 Monitor, climate, audio, phone and voice recognition systems SAA2491
Image Viewer (models with naviga-
tion system) GUID-3A8CCE29-BAF6-4276-8E18-96A1950EFDF7
The image files in the USB memory will be
displayed. To display the Image Viewer,
push the SETTING button, select the
“ Other ” key and then select the “ Image
Viewer ” key. The image of the selected file
is displayed on the right side of the screen.
When a number of folders are included in
the USB memory, select a folder from the
list to display the file list.
Images will not be shown on the display
while the vehicle is in any drive position to
reduce driver distraction. To view images, stop the vehicle in a safe location and
apply the parking brake.
SAA2492
Full Screen Display: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
The full screen display will appear when
selecting the “ Full Screen Display ” key.
To operate the Image Viewer or to change
the settings, select the desired key using
the INFINITI controller.
.
(Start)
Select the “ ” key to start playing
the slideshow.
.
(Stop)
Select the “
” key to stop the
slideshow.
.
(Next)
Select the “ ” key to display the next

Black plate (201,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]file.
. (Previous)
Select the “
” key to display the
previous file.
Setting the Image Viewer: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
The Image Viewer setting display will
appear when selecting the “ Settings ” key
on the full screen display. The following
settings are available for the full screen
display.
. Slideshow Speed
Select the “ Slideshow Speed ” key.
From the following display, select the
changing time from 5, 10, 30, 60
seconds or “ No Auto Change ” .
. Slideshow Order
Select the “ Slideshow Order ” key. From
the following display, select “ Random ”
or “ Order List ” . For “ Order List ” , the
image order is the order of the files as
stored on the USB memory.
Operating tips: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. Only files that meet the following
conditions will be displayed.
— Image type: JPEG
— File Extensions: *.jpg, *jpeg — Maximum Resolution: 2048 6 1536
pixels
— Maximum Size: 2-MB
— Colors: 32768 (15-bit)
— Maximum File Name lengths: 253-
Bytes
— Maximum Folders: 500
— Maximum Images per Folder: 1024
. If an electronic device (such as a digital
camera) is directly connected to the
vehicle using a USB cable, no image
will be displayed on the screen.
. If the file name is too long, some file
names may not be entirely displayed.
. When the total number of characters in
the file name exceeds 100 or if 1 file
name in a directory exceeds 100
characters, all files will show a shor-
tened 8-character version. The image
will still be displayed when selected. GUID-63214A06-C148-4301-9B23-AF1E0EA151B6
When the selector/shift lever is shifted into
the “ R ” (Reverse) position, the monitor
display shows view to the rear of the
vehicle.
The system is designed as an aid to the
driver in detecting large stationary objects
to help avoid damaging the vehicle. The
system will not detect small objects below
the bumper and may not detect objects
close to the bumper or on the ground.
WARNING . The rearview monitor is a convenience
but it is not a substitute for proper
vehicle operation because it has areas
where objects cannot be viewed. Always
look out the windows and check mirrors
to be sure that it is safe to move before
operating the vehicle. Always operate
the vehicle slowly.
. Objects viewed in the RearView Monitor
differ from actual distance because a
wide-angle lens is used. Objects in the
RearView Monitor will appear visually
opposite like ones viewed in the inside
and outside mirrors.
. Make sure that the trunk is securely
closed when backing up.
Monitor, climate, audio, phone and voice recognition systems
4-23REARVIEW MONITOR (if so equipped)

Black plate (202,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-24 Monitor, climate, audio, phone and voice recognition systems. Underneath the bumper and the corner
areas of the bumper cannot be viewed on
the rearview monitor because of its
monitoring range limitation.
. Do not put anything on the rearview
camera. The rearview camera is installed
above the license plate.
. When washing the vehicle with high-
pressure water, be sure not to spray it
around the camera. Otherwise, water
may enter the camera unit causing water
condensation on the lens, a malfunction,
fire or an electric shock.
. Do not strike the camera. It is a precision
instrument. Otherwise, it may malfunc-
tion or cause damage resulting in a fire
or an electric shock.
CAUTIONThere is a plastic cover over the camera. Do
not scratch the cover when cleaning dirt or
snow from the cover. SAA1896
HOW TO READ DISPLAYED LINES GUID-2618A9E5-1A1F-4AE7-9A2B-28557D8D9F81
Guiding lines which indicate the vehicle
width and distances to objects with re-
ference to the bumper line
* A
are dis-
played on the monitor.
Distance guide lines:
Indicate distances from the bumper.
. Red line
* 1
: approx. 1.5 ft (0.5 m)
. Yellow line
* 2
: approx. 3 ft (1 m)
. Green line
* 3
: approx. 7 ft (2 m)
. Green line
* 4
: approx. 10 ft (3 m)
Vehicle width guide lines
* 5
:
Indicate the vehicle width when backing up.
Predicted course lines
* 6
:
Indicate the predicted course when back-
ing up. The predicted course lines will be
displayed on the monitor when the selec-
tor/shift lever is in the “ R ” (Reverse)
position and the steering wheel is turned.
The predicted course lines will move
depending on how much the steering
wheel is turned and will not be displayed
while the steering wheel is in the neutral
position.
HOW TO PARK WITH PREDICTED
COURSE LINES GUID-E6DBE254-D73E-4977-91E5-7921E8117C6E
WARNING . Always turn and check that it is safe to
park your car before backing up. Always
back up slowly.
. Use the displayed lines as a reference.
The lines are highly affected by the
number of occupants, fuel level, vehicle
position, road condition and road grade.
. If the tires are replaced with different
sized tires, the predicted course line
may not be displayed correctly.

Black plate (203,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]. On a snow-covered or slippery road,
there may be a difference between the
predicted course line and the actual
course line.
. If the battery is disconnected or be-
comes discharged, the predicted course
lines may not be displayed correctly. If
this occurs, drive the vehicle on a
straight road for more than 5 minutes.
. The displayed lines will appear slightly
off to the right because the rearview
camera is not installed in the rear center
of the vehicle.
. The distance guide line and the vehicle
width guide line should be used as a
reference only when the vehicle is on a
level paved surface. The distance viewed
on the monitor is for reference only and
may be different than the actual distance
between the vehicle and displayed ob-
jects.
. When backing up the vehicle up a hill,
objects viewed in the monitor are further
than they appear. When backing up the
vehicle down a hill, objects viewed in the
monitor are closer than they appear. Use
the inside mirror or glance over your
shoulder to properly judge distances to other objects.
The vehicle width and predicted course
lines are wider than the actual width and
course.
SAA1897
1. Visually check that the parking space is
safe before parking your vehicle.
2. The rearview of the vehicle is displayed
on the screen
* A
as illustrated when
the selector/shift lever is moved to the
“ R ” (Reverse) position.
Monitor, climate, audio, phone and voice recognition systems
4-25

Black plate (204,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-26 Monitor, climate, audio, phone and voice recognition systems SAA1898
3. Slowly back up the vehicle adjusting
the steering wheel so that the predicted
course lines
* B
enter the parking
space
* C
.
4. Maneuver the steering wheel to make
the vehicle width guide lines
* D
parallel to the parking space
* C
while referring to the predicted course lines.
5. When the vehicle is parked in the space
completely, move the selector/shift
lever to the P (Park) position (Automatic
Transmission models) or in an appro-
priate gear (Manual Transmission mod-
els) and apply the parking brake.
DIFFERENCE BETWEEN PREDICTED
AND ACTUAL DISTANCES GUID-9C8077A7-378D-4FBF-A8ED-EAB27EE0942F
The distance guide line and the vehicle
width guide line should be used as a
reference only when the vehicle is on a
level, paved surface. The distance viewed
on the monitor is for reference only and
may be different from the actual distance
between the vehicle and displayed objects.
SAA1899
Backing up on a steep uphill GUID-FBF6C947-02DC-491C-94A4-77253C889F35
When backing up the vehicle up a hill, the
distance guide lines and the vehicle width
guide lines are shown closer than the
actual distance. For example, the display
shows 3 ft (1 m) to the place
* A
, but the
actual 3 ft (1 m) distance on the hill is the

Black plate (205,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]place
* B
. Note that any object on the hill is
further than it appears on the monitor.
SAA1900
Backing up on a steep downhill GUID-371DFD18-DBE9-419F-9782-291E25E969AA
When backing up the vehicle down a hill,
the distance guide lines and the vehicle
width guide lines are shown further than
the actual distance. For example, the
display shows 3 ft (1 m) to the place
* A
,
but the actual 3 ft (1 m) distance on the hill is the place
* B
. Note that any object on
the hill is closer than it appears on the
monitor.
Monitor, climate, audio, phone and voice recognition systems
4-27
