key INFINITI G37 2012 Service Manual

Black plate (162,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]3-20 Pre-driving checks and adjustments SPA2308
TRUNK RELEASE POWER CANCEL
SWITCH GUID-BABECA89-BBB5-4942-9D94-72F9F1663F69
When the switch located inside the glove
box is in the OFF position
* A
, the power to
the trunk lid will be canceled and the trunk
lid cannot be opened by the trunk lid
release switch, the trunk open request
switch or the TRUNK button on the
Intelligent Key.
When you have to leave the vehicle with a
valet and want to keep your belongings
safe in the glove box and the trunk, push
this switch to OFF and lock the glove box
with the mechanical key. Then leave the vehicle and the Intelligent Key with the
valet and keep the mechanical key with
you.
See “ Keys ” (P.3-2).
To connect the power to the trunk lid, push
the switch to the ON
* B
position.
SPA2553
Sedan
SPA2402
Coupe

Black plate (163,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]INTERIOR TRUNK LID RELEASE GUID-4587ADD7-0824-4CA3-90BC-0B9E1446FA5C
WARNINGClosely supervise children when they are
around cars to prevent them from playing
and becoming locked in the trunk where
they could be seriously injured. Keep the car
locked, with the trunk lid securely latched,
when not in use, and prevent children ’ s
access to Intelligent Keys.
The interior trunk lid release mechanism
allows opening of the trunk lid in the event
that people become locked inside the trunk
or in the event of the loss of electrical
power such as a discharged battery.
Releasing inside the trunk GUID-4F494B4A-9594-4D01-BDD8-8ECF0B6F8122
To open the trunk lid from the inside, pull
the release handle
* 1
until the lock
releases and push up on the trunk lid.
The release lever is made of a material that
glows in the dark after a brief exposure to
ambient light.
The handle is located on the back of the
trunk lid as illustrated. Releasing from the rear seat GUID-0C5756BB-309D-4BDC-A10C-7CD141078C7C
Sedan: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
You can access the release handle through
the trunk pass-through (rear seat armrest).
(See “ Armrest ” (P.1-13).)
To open the trunk lid from the rear seat,
pull the release handle towards front of
vehicle until the lock releases.
Coupe: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
You can access the release handle by
folding the rear seat.
Pull the strap, located at the center bottom
of the seatback, and then fold down the
seatback. (See “ Rear seats ” (P.1-7).)
To open the trunk lid from the rear seat,
pull the release handle towards front of
vehicle until the lock releases. GUID-C9906368-3B16-4944-9B2F-9A9D4F648106
SPA2834
INFINITI Performance Line models
The INFINITI Performance Line models have
unique exhaust pipes. These parts are
close to the ground and may be damaged
if they contact objects such as parking
blocks, etc.
CAUTION Reduce vehicle speed to decrease the
possibility of damaging these parts when:
. driving on bumpy or rutted roads
. entering or exiting parking garages and
driveways
Pre-driving checks and adjustments
3-21UNIQUE FRONT AND REAR PARTS (INFINITI
Performance Line, Aerodynamic Package
models)

Black plate (165,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]GUID-02CF0A75-C84C-42E5-8EC5-1F52978DFE6D
SPA2554
Sedan
SPA1562A
Coupe OPENING THE FUEL-FILLER DOOR GUID-992E40DE-AC25-44A9-842E-2A963AAA7D5B
To open the fuel-filler door, unlock the fuel-
filler door by using one of the following
operations, then push the right side of the
door (Sedan) or push the left side of the
door (Coupe).
. Push the door handle request switch
with the Intelligent Key carried with
you.
. Push the UNLOCK button on the Intelli-
gent Key.
. Insert the mechanical key into the door
lock cylinder and turn it to the rear of
the vehicle.
. Push the power door lock switch to the
UNLOCK position.
To lock, close the fuel-filler door securely
and lock all doors by operating the door
handle request switch, the LOCK button on
the Intelligent Key, the mechanical key or
the power door lock switch. FUEL-FILLER CAP GUID-FACDECE2-8451-40C3-841E-0B67C4802921
WARNING . Gasoline is extremely flammable and
highly explosive under certain condi-
tions. You could be burned or seriously
injured if it is misused or mishandled.
Always stop engine and do not smoke or
allow open flames or sparks near the
vehicle when refueling.
. Do not attempt to top off the fuel tank
after the fuel pump nozzle shuts off
automatically. Continued refueling may
cause fuel overflow, resulting in fuel
spray and possibly a fire.
. Use only an original equipment type
fuel-filler cap as a replacement. It has a
built-in safety valve needed for proper
operation of the fuel system and emis-
sion control system. An incorrect cap can
result in a serious malfunction and
possible injury. It could also cause the
malfunction indicator light (MIL) to
come on.
. Never pour fuel into the throttle body to
attempt to start your vehicle.
Pre-driving checks and adjustments
3-23FUEL-FILLER DOOR

Black plate (173,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]VANITY MIRROR GUID-418E781F-468D-4640-B3BF-4DA5D9BE4DFA
To use the front vanity mirror, pull down
the sun visor and pull up the cover. GUID-3EDC2AC8-B979-442D-AEB4-1AF89546AADA
The automatic drive positioner system has
three features:
. Entry/exit function (Automatic Trans-
mission Sedan models)
. Seat synchronization function
. Memory storage
ENTRY/EXIT FUNCTION (Automatic
Transmission Sedan models) GUID-30995ABA-8234-45F4-9B5C-ECA6C07F73E6
This system is designed so that the driver ’ s
seat and steering column will automati-
cally move when the automatic transmis-
sion selector lever is in the P (Park)
position. This allows the driver to get into
and out of the driver ’ s seat more easily.
The driver ’ s seat will slide backward and
the steering wheel will move up when the
driver ’ s door is opened with the ignition
switch in the LOCK position.
The driver ’ s seat and steering wheel will
return to the previous positions when one
of the following is operated:
. When the ignition switch is pushed to
the ACC position after the driver ’ s door
is closed.
. When the ignition switch is pushed to
the ON position.
. When the Intelligent Key is inserted into the port after the driver ’ s door is
closed.
The driver ’ s seat will not return to the
previous positions if the seat or steering
adjusting switch is operated when the seat
is at the exit position.
Cancel or activate entry/exit func-
tion GUID-8D71F741-560B-4B4E-AA55-F9F223C96E4F
The selector lever must be in the P (Park)
position with the ignition switch in the OFF
position.
The entry/exit function can be activated or
canceled by pressing and holding the SET
switch for more than 10 seconds.
The indicator lights on the memory
switches (1 and 2) will blink once when
the function is canceled, and the indicator
lights will blink twice when the function is
activated. Note that the indicator lights
may illuminate after 5 seconds while
holding the SET switch. This indicates
readiness for linking the Intelligent Key to
a stored memory position. Keep the SET
switch pressed for more than 10 seconds
to turn on or off the entry/exit function.
The entry/exit function can also be acti-
vated or canceled if the “ Lift Steering
Wheel on Exit ” key or “ Slide Driver Seat
Pre-driving checks and adjustments
3-31AUTOMATIC DRIVE POSITIONER (if so
equipped)

Black plate (174,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]3-32 Pre-driving checks and adjustmentsBack on Exit ” key is turned to ON or OFF in
the “ Comfort ” settings. (See “ Vehicle
information and settings ” (P.4-9).)
Initialize entry/exit function GUID-0EEBBCEC-2899-4DC8-AE43-1CC42FE3C5C1
If the battery cable is disconnected, or if
the fuse opens, the entry/exit function will
not work though this function was set on
before. In such a case, after connecting the
battery or replacing with a new fuse, open
and close the driver ’ s door more than two
times after the ignition switch is turned
from the ON position to the LOCK position.
The entry/exit function will be activated. SPA2322
SEAT SYNCHRONIZATION FUNCTION GUID-44A9BCE7-C5A3-4DE5-84C7-DAFAF434BFA8
The seat synchronization function automa-
tically adjusts the positions of the steering
wheel and outside mirrors when the seat is
adjusted using the power seat switches.
However, the steering wheel and outside
mirrors will not move if the seat is adjusted
over the maximum thresholds. The system
considers that the steering wheel and
outside mirror adjustments are not neces-
sary because the seat may not be adjusted
for the driving position. Note that the
function is set to disabled as the factory
default setting. The seat synchronization function operates
under the following conditions:
. The ignition switch is in the ON posi-
tion.
. The selector lever is in the P (Park)
position (Automatic Transmission mod-
els) or the parking brake is applied
(Manual Transmission models).
. The seatback is raised (Coupe).
If the outside mirrors or the steering wheel
reaches its maximum adjustment, the
function is automatically disabled. Restart
the function by selecting a previously
stored seat memory position using the
memory switches (1 or 2). An Intelligent
Key that was previously linked to the
stored seat memory can also be used to
restart the function.
If a seat position was not previously stored
in the seat memory, restart the function by
adjusting the steering wheel and outside
mirrors manually for your best driving
position and then drive the vehicle above
4 MPH (7 km/h).

Black plate (175,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]Cancel or activate seat synchroni-
zation function GUID-9FA1381E-62FE-4338-8BE9-EF06F61AFC12
For Automatic Transmission models:
The selector lever must be in the P (Park)
position with the ignition switch in the ACC
position.
For Manual Transmission models:
The parking brake must be applied with
the ignition switch in the ACC position.
The seat synchronization function can be
activated or canceled by pushing and
holding the SET switch for more than 10
seconds while the ignition switch is in the
ACC position.
The indicator lights on the memory
switches (1 and 2) will blink once when
the function is canceled, and the indicator
lights will blink twice when the function is
activated. Note that the indicator lights
may illuminate after 5 seconds while
holding the SET switch. This indicates
readiness for linking the Intelligent Key to
a stored memory position. Keep the SET
switch pushed for more than 10 seconds to
turn on or off the seat synchronization
function. MEMORY STORAGE GUID-A3BE9A91-CE23-4574-92F2-3FB031E53D7E
Two positions for the driver ’ s seat, steering
column and outside mirrors can be stored
in the automatic drive positioner memory.
Follow these procedures to use the mem-
ory system.
1. Automatic transmission models:
Move the selector lever to the P (Park)
position.
Manual transmission models:
Apply the parking brake.
2. Raise the seatback (Coupe).
3. Push the ignition switch to the ON
position.
4. Adjust the driver ’ s seat, steering col-
umn and outside mirrors to the desired
positions by manually operating each
adjusting switch. For additional infor-
mation, see “ Seats ” (P.1-2) and “ Tilt/
telescopic steering ” (P.3-26) and “ Out-
side mirrors ” (P.3-29).
5. Push the SET switch and, within 5
seconds, push the memory switch (1
or 2) fully for at least 1 second.
The indicator light for the pushed
memory switch will stay on for approxi-
mately 5 seconds after pushing the switch.
If memory is stored in the same
memory switch, the previous memory
will be deleted.
Linking Intelligent Key to a stored
memory position GUID-260E8272-8777-4E19-9288-E40B723FABBA
The Intelligent Key can be linked to a
stored memory position with the following
procedure.
1. Follow the steps for storing a memory
position.
2. While the indicator light for the memory
switch being set is illuminated for 5
seconds, push the
button on the
Intelligent Key. If the indicator light
blinks, the Intelligent Key is linked to
that memory setting.
Push the ignition switch to the OFF posi-
tion, and then push the
button on the
Intelligent Key. The driver ’ s seat, steering
wheel and outside mirrors will move to the
memorized position.
Confirming memory storage GUID-E5D175B3-57DC-4C96-A449-0B72F25D2264
. Push the ignition switch to the ON
position and push the SET switch. If
the main memory has not been stored,
the indicator light will come on for
Pre-driving checks and adjustments
3-33

Black plate (176,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]3-34 Pre-driving checks and adjustmentsapproximately 0.5 second. When the
memory has stored in position, the
indicator light will stay on for approxi-
mately 5 seconds.
. If the battery cable is disconnected, or if
the fuse opens, the memory will be
canceled. In this case, reset the desired
position using the previous procedure.
. If optional Intelligent Keys are added to
your vehicle, the memory storage pro-
cedure to switch 1 or 2 and linking
Intelligent Key procedure to a stored
memory position should be performed
again for each Intelligent Key. For
additional Intelligent Key information,
see “ Keys ” (P.3-2).
Selecting the memorized position GUID-739A81F0-8862-49C2-BBA8-117F41F648F9
1. Automatic transmission models:
Move the selector lever to the P (Park)
position.
Manual transmission models:
Apply the parking brake.
2. Raise the seatback (Coupe).
3. Use one of the following methods to
move the driver ’ s seat, the outside
mirrors and the steering wheel. .
Push the ignition switch to the ON
position and push the memory
switch (1 or 2) fully for at least 1
second. .
Within 45 seconds of opening the
driver ’ s door, push the memory
switch (1 or 2) fully for at least 1
second.
The driver ’ s seat, steering column
and outside mirrors will move to the
memorized position with the indica-
tor light flashing, and then the light
will stay on for approximately 5
seconds.
For manual transmission models, the
memory positions can be selected even
when the engine is running. In this case,
move the shift lever to the N (Neutral)
position and apply the parking brake.
Then, perform step 2.
SYSTEM OPERATION GUID-0383C8BF-12F8-48D0-9B28-5A2A0DCC8D55
The automatic drive positioner system will
not work or will stop operating under the
following conditions:
. When the vehicle speed is above 4 MPH
(7 km/h).
. When the adjusting switch for the
driver ’ s seat and steering column is
turned on while the automatic drive positioner is operating.
. When the memory switch 1 or 2 is not
pushed for at least 1 second.
. When the seat, steering column and
outside mirrors have already been
moved to the memorized position.
. When no position is stored in the
memory switch.
. When the parking brake is released (MT
models).
. When the speed is above 4 MPH (7
km/h) while the parking brake is
applied (MT models).
To restart the drive positioner system,
move the parking brake to off and on.
. When the engine is started while
moving the automatic drive positioner.
. When the AT selector lever is moved
from the P (Park) position to any other
position. (However, it will not be
canceled if the switch is pushed while
the seat and steering column are
returning to the previous positions
(entry/exit function).)
. When the driver ’ s door remains open
for more than 45 seconds and the
ignition switch is not in the ON posi-
tion.

Black plate (184,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-6 Monitor, climate, audio, phone and voice recognition systems SAA2473
Selecting the item: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Touch an item to select it. To select the
“ Audio ” settings, touch the “ Audio ” area
* 1
on the screen.
Touch the “ BACK ”
* 2
key to return to the
previous screen. SAA2474
Adjusting an item: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Touch the +
* 1
or −
* 2
key to adjust the
settings.
Touch the
* 3
or
* 4
key to move to
the previous or next item.
Touch the
* 5
or
* 6
key to move to
the previous or next page. SAA2475
Inputting characters: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Touch the letter or number
* 1
.
There are some options available when
inputting characters.
. Uppercase:
Shows uppercase characters.
. Lowercase:
Shows lowercase characters.
. Symbols:
Shows symbols such as the question
mark (?).
. Space:
Inserts a space.

Black plate (186,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-8 Monitor, climate, audio, phone and voice recognition systems SAA2477
Models with navigation system
SAA1510
Models without navigation system HOW TO SELECT MENUS ON THE
SCREEN GUID-7F980AEB-984A-4A26-A3B2-C2F82F17CC7C
Vehicle functions are viewed on the display
screen in menus. To select each key item,
highlight the preferred item using the
INFINITI controller and push the ENTER
button.
Whenever a menu selection is made or
menu item is highlighted, different areas
on the screen provide you with important
information. See the following for details.
1. Header:
Shows the path used to get to the
current screen.
2. Menu Selections:
Shows the options to choose within
that menu screen.
3. UP/DOWN Movement indicator:
Shows that the INFINITI controller may
be used to move UP/DOWN on the
screen and select more options.
4. Menu Items Counter:
Shows the total number of items listed
across all pages for the current menu.
5. Footer/Information Line:
Provides more information (if available) about the menu selection currently
highlighted.

Black plate (189,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]Fuel Economy information GUID-189D7485-90CC-4656-8551-1D08F50ECB7D
The approximate distance to empty, aver-
age fuel economy and current fuel econo-
my will be displayed for reference.
To reset the average fuel economy (Avg
Fuel Econ), select the “ Reset Fuel Eco ” or
“ Reset ” key.
If the “ Fuel Eco History ” or “ View ” key is
selected, the average fuel consumption
history will be displayed in graph form
along with the average for the previous
Reset-to-Reset period.
The unit can be converted between “ US ”
and “ Metric ” . (See “ How to use SETTING
button ” (P.4-14).)
The fuel economy information may differ
from the information displayed on the
vehicle information display. This is due to
the timing difference in updating the
information and does not indicate a mal-
function. SAA2481
SAA2482
Models with navigation system SAA2830
SAA2722
Models without navigation system
Monitor, climate, audio, phone and voice recognition systems
4-11
