bluetooth INFINITI M35 2006 Factory Service Manual

AV-1
AUDIO-VISUAL SYSTEM
K ELECTRICAL
CONTENTS
C
D
E
F
G
H
I
J
L
M
SECTION AV
A
B
AV
Revision: 2006 January2006 M35/M45
AUDIO-VISUAL SYSTEM
WITHOUT MOBILE ENTERTAINMENT SYS-
TEM
PRECAUTION ............................................................ 6
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 6
Precautions for Trouble Diagnosis ........................... 6
AV COMMUNICATION SYSTEM .......................... 6
Precautions for Harness Repair ............................... 6
AV COMMUNICATION SYSTEM .......................... 6
PREPARATION ........................................................... 7
Commercial Service Tools ........................................ 7
SYSTEM DESCRIPTION ............................................ 8
System Functions ..................................................... 8
AUDIO ................................................................... 8
VEHICLE INFORMATION SYSTEM ..................... 8
NAVIGATION SYSTEM ......................................... 8
HANDS-FREE PHONE ....................................... 10
REAR VIEW MONITOR ...................................... 10
Component Description ........................................... 11
AUDIO UNIT ........................................................ 11
BOSE AMP .......................................................... 11
SATELLITE TUNER ............................................ 12
AV CONTROL UNIT (WITHOUT NAVI) .............. 12
NAVI CONTROL UNIT (WITH NAVI) .................. 12
FRONT DISPLAY UNIT ...................................... 13
DVD PLAYER ...................................................... 13
CAMERA CONTROL UNIT ................................. 13
CAN Communication System Description .............. 13
CAN Communication Unit ...................................... 13
Schematic — Base Audio System — ..................... 14
Wiring Diagram — AV — / Base Audio System ..... 15
Schematic — BOSE Audio 2ch System — ............ 26
W i r i n g D i a g r a m — A V — / B O S E A u d i o 2 c h S y s t e m ... 28
Schematic — BOSE Surround Audio 5.1ch System
— ............................................................................ 42Wiring Diagram — AV — / BOSE Surround Audio
5.1ch System .......................................................... 45
Component Parts Location ..................................... 64
Location of Antenna ................................................ 65
TERMINALS AND REFERENCE VALUE FOR CON-
TROL UNIT ............................................................... 66
Audio Unit for Base System .................................... 66
Audio Unit for BOSE System .................................. 68
BOSE Amp ............................................................. 70
Satellite Radio Tuner .............................................. 74
AV (NAVI) Control Unit ........................................... 75
Front Display Unit ................................................... 78
DVD Player ............................................................. 80
Camera Control Unit ............................................ ... 83
DIAGNOSIS SYSTEM ............................................... 86
Multifunction Switch Self-Diagnosis Function ......... 86
SELF-DIAGNOSIS MODE .................................. 86
FINISHING SELF-DIAGNOSIS MODE ............... 86
Multi AV System Diagnosis Functions .................... 86
On Board Diagnosis ............................................... 86
DESCRIPTION .................................................... 86
STARTING PROCEDURE ................................... 87
Self Diagnosis Mode ............................................... 88
DIAGNOSIS RESULT .......................................... 89
Confirmation/Adjustment Mode .............................. 91
DISPLAY DIAGNOSIS ......................................... 91
VEHICLE SIGNALS ............................................ 92
SPEAKER TEST ................................................. 92
CLIMATE CONTROL ........................................... 92
NAVIGATION ....................................................... 93
ERROR HISTORY ............................................... 93
VEHICLE CAN DIAGNOSIS ............................... 97
AV COMM DIAGNOSIS ....................................... 97
HANDSFREE PHONE ........................................ 98
CAMERA CONT. ................................................. 99
BLUETOOTH .....................................................100
DELETE UNIT CONNECTION LOG .................100

AV-3
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2006 January2006 M35/M45 Front Display Unit (Base System) ........................136
REMOVAL ........................................................
.136
INSTALLATION .................................................136
Front Display Unit (BOSE System) ......................137
REMOVAL ........................................................
.137
INSTALLATION .................................................137
Multifunction Switch .............................................137
REMOVAL ........................................................
.137
INSTALLATION .................................................137
Preset Switch .......................................................137
REMOVAL ........................................................
.137
INSTALLATION .................................................138
Steering Switch ....................................................138
REMOVAL ........................................................
.138
INSTALLATION .................................................138
DVD Player ..........................................................138
REMOVAL ........................................................
.138
INSTALLATION .................................................139
Auxiliary Input Jacks ............................................140
REMOVAL ........................................................
.140
INSTALLATION .................................................140
Microphone ..........................................................140
REMOVAL ........................................................
.140
INSTALLATION .................................................140
GPS Antenna .......................................................140
REMOVAL ........................................................
.140
INSTALLATION .................................................141
Camera Control Unit ............................................142
REMOVAL ........................................................
.142
INSTALLATION .................................................142
Rear View Camera ...............................................142
REMOVAL ........................................................
.142
INSTALLATION .................................................142
Steering Angle Sensor .........................................142
REMOVAL ........................................................
.142
INSTALLATION .................................................143
WITH MOBILE ENTERTAINMENT SYSTEM
PRECAUTION ........................................................144
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ..............................................................144
Precautions for Trouble Diagnosis .......................144
AV COMMUNICATION SYSTEM ......................144
Precautions for Harness Repair ...........................144
AV COMMUNICATION SYSTEM ......................144
PREPARATION .......................................................145
Commercial Service Tools ....................................145
SYSTEM DESCRIPTION ........................................146
System Functions .................................................146
AUDIO ...............................................................146
VEHICLE INFORMATION SYSTEM .................146
NAVIGATION SYSTEM .....................................146
MOBILE ENTERTAINMENT SYSTEM ..............148
HANDS-FREE PHONE .....................................148
REAR VIEW MONITOR ....................................148Component Description ........................................149
AUDIO UNIT ..................................................... .149
BOSE AMP ........................................................149
SATELLITE TUNER ..........................................150
AV CONTROL UNIT (WITHOUT NAVI) .............150
NAVI CONTROL UNIT (WITH NAVI) .................150
FRONT DISPLAY UNIT .....................................150
REAR DISPLAY UNIT .......................................151
VIDEO DISTRIBUTOR ......................................151
DVD PLAYER ....................................................151
CAMERA CONTROL UNIT ...............................151
CAN Communication System Description ............152
CAN Communication Unit .....................................152
Schematic — BOSE Audio 2ch System — ...........153
W i r i n g D i a g r a m — A V — / B O S E A u d i o 2 c h S y s t e m .156
Schematic — BOSE Surround Audio 5.1ch System
— ..........................................................................175
Wiring Diagram — AV — / BOSE Surround Audio
5.1ch System ........................................................178
Component Parts Location ...................................202
Location of Antenna ..............................................203
TERMINALS AND REFERENCE VALUE FOR CON-
TROL UNIT .............................................................204
Audio Unit .............................................................204
BOSE Amp ...........................................................206
Satellite Radio Tuner ............................................210
AV (NAVI) Control Unit .........................................211
Video Distributor ...................................................214
Front Display Unit ................................................
.219
Rear Display Unit ..................................................221
DVD Player ...........................................................223
Headphone Amp ...................................................226
Camera Control Unit ............................................ .227
DIAGNOSIS SYSTEM .............................................230
Multifunction Switch Self-Diagnosis Function .......230
SELF-DIAGNOSIS MODE ................................230
FINISHING SELF-DIAGNOSIS MODE .............230
Multi AV System Diagnosis Functions ..................230
On Board Diagnosis .............................................230
DESCRIPTION ..................................................230
STARTING PROCEDURE .................................231
Self Diagnosis .......................................................232
DIAGNOSIS RESULTS .....................................233
Confirmation/Adjustment Mode ............................235
DISPLAY DIAGNOSIS .......................................235
VEHICLE SIGNALS ..........................................236
SPEAKER TEST ...............................................236
CLIMATE CONTROL .........................................236
NAVIGATION .....................................................237
ERROR HISTORY .............................................237
VEHICLE CAN DIAGNOSIS .............................241
AV COMM DIAGNOSIS .....................................241
HANDSFREE PHONE ......................................242
REAR DISPLAY .................................................242
CAMERA CONT. ...............................................243
BLUETOOTH .....................................................244
DELETE UNIT CONNECTION LOG .................244

AV-10
[WITHOUT MOBILE ENTERTAINMENT SYSTEM]
SYSTEM DESCRIPTION
Revision: 2006 January2006 M35/M45
Map-matching does not function correctly when a road on which
the vehicle is driving is new and not recorded in the map DVD-
ROM, or when road pattern stored in the map data and the
actual road pattern are different due to repair.
When driving on a road not present in the map, the map-match-
ing function may find another road and position the vehicle mark
on it. Then, when the correct road is detected, the vehicle mark
may change to it.
Effective range for comparing the vehicle position and travel
direction calculated by the distance and direction with the road
data read from the map DVD-ROM is limited. Therefore, when
there is an excessive gap between current vehicle position and
the position on the map, correction by map-matching is not possible.
GPS (Global Positioning System)
GPS (Global Positioning System) was developed for and is con-
trolled by the US Department of Defense. The system utilizes GPS
satellites (NAVSTAR), sending out radio waves while flying on an
orbit around the earth at an altitude of approximately 21,000 km
(13,100miles).
The GPS receiver calculates the vehicle's position in three dimen-
sions (latitude/longitude/altitude) according to the time lag of the
radio waves received from four or more GPS satellites (three-dimen-
sional positioning). If radio waves were received only from three
GPS satellites, the GPS receiver calculates the vehicle's position in
two dimensions (latitude/longitude), utilizing the altitude data calcu-
lated previously with radio waves from four or more GPS satellites
(two-dimensional positioning).
Position correction by GPS is not available while the vehicle is stopped.
Accuracy of GPS will deteriorate under the following conditions:
In two-dimensional positioning, GPS accuracy will deteriorate when altitude of the vehicle position
changes.
The accuracy can be even lower depending on the arrangement of the GPS satellites utilized for the posi-
tioning.
Position detection is not possible when vehicle is in an area where radio waves from the GPS satellite do
not reach, such as in a tunnel, parking lot in a building, and under an elevated highway. Radio waves from
the GPS satellites may not be received when some object is located over the GPS antenna.
NOTE:
Even a high-precision three dimensional positioning, the detection result has an error about 10 m (30 ft).
Because the signals of GPS satellite is controlled by the Tracking and Control Center in the United States,
the accuracy may be degraded lower intentionally or the radio waves may stop.
HANDS-FREE PHONE
AV (NAVI) control unit has Bluetooth module. It can perform wireless hands-free telephone calls using a
cellular phone in vehicle compartment.
5 or more portable phones can be registered into the AV (NAVI) control unit.
REAR VIEW MONITOR
The small CCD camera is equipped into the rear end of the vehicle. The rear view monitor that displays
the area behind the vehicle while backing up is equipped.
Guiding lines indicating side and rear clearances are provided in the rear view monitor image, which
allows the driver to more easily judge distances between the vehicle and objects in the display. The possi-
ble route lines that indicate the possible route according to the steering angle are provided to help backing
up when parking.
Image quality of the rear view image and of the navigation screen can be adjusted separately.
SKIA0613E
SEL526V

DIAGNOSIS SYSTEM
AV-87
[WITHOUT MOBILE ENTERTAINMENT SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2006 January2006 M35/M45
On Board Diagnosis Item
*1: With navigation system
*2: With rear view monitor
STARTING PROCEDURE
1. Start the engine.
2. Turn the audio system OFF.
3. While pushing the “SETTING” button, turn the volume control
dial clockwise or counterclockwise for 40 clicks or more. (When
the self-diagnosis mode is started, a short beep will be heard.)
Shifting from current screen to previous screen is performed
by pushing “BACK” button.
Mode Description
Self Diagnosis
AV (NAVI) control unit diagnosis and connection diagnosis between
AV (NAVI) control unit and each unit
The DVD-ROM drive diagnosis of NAVI control unit and the connec-
tion diagnosis between NAVI control unit and GPS antenna can be
performed
(DVD-ROM drive will not be diagnosed when no map DVD-ROM is in
it.)
Confirmation/
AdjustmentDisplay DiagnosisThe tint can be confirmed by the color spectrum bar display. The shad-
ing of color can be confirmed by the gradation bar display.
Vehicle SignalsDiagnosis of signals can be performed for vehicle speed, parking brake,
lights, ignition switch, and reverse.
Speaker Test The connection of a speaker can be confirmed by test tone.
Climate Control Start auto air conditioner system self-diagnosis.
Navigation
*1
Steering Angle
AdjustmentWhen there is a difference between the actual turning angle and the
vehicle mark turning angle, it can be adjusted.
Speed CalibrationWhen there is a difference between the current location mark and the
actual location, it can be adjusted.
Error HistoryThe system malfunction and the frequency when occurred in the past
are displayed. When the malfunctioning item is selected, the time and
place that the selected malfunction last occurred are displayed.
Synchronizer FES clock -
Vehicle CAN Diagnosis The transmitting/receiving of CAN communication can be monitored.
AV COMM DiagnosisThe communication condition of each unit of Multi AV system can be
monitored.
Handsfree PhoneThe received volume adjustment of hands-free phone, microphone
speaker check, and erase memory can be performed.
Camera Cont.
*2The signal connected to camera control unit can be checked and the
guiding line position that overlaps rear view camera image can be
adjusted.
Bluetooth The passkey and the name of device can be checked and changed
Delete Unit Connection Log Erase the connection history of unit and error history
SKIB3655E

AV-96
[WITHOUT MOBILE ENTERTAINMENT SYSTEM]
DIAGNOSIS SYSTEM
Revision: 2006 January2006 M35/M45
AV COMM CIRCUIT
Amplifier Connection Error
BOSE amp power supply and
ground circuit malfunction is
detected
Malfunction is detected on communi-
cation signal between BOSE amp
and AV (NAVI) control unit
BOSE amp power supply and ground
circuit
BOSE amp
AV (NAVI) control unit
Front Display Connection Error
Front display unit power supply and
ground circuit malfunction is
detected
Malfunction is detected on communi-
cation circuit between front display
unit and AV (NAVI) control unit
Malfunction is detected on communi-
cation signal between front display
unit and AV (NAVI) control unit
Front display unit power supply and
ground
Communication circuit between front
display unit and AV (NAVI) control unit
Front display unit
AV (NAVI) control unit
GPS Antenna ErrorGPS antenna connection malfunction
is detected
GPS antenna feeder
GPS antenna
NAVI control unit
Camera Control Unit Connection ErrorCamera and connection recognition
signal circuit malfunction is detected
Camera-connection recognition signal
circuit
Camera control unit
AV (NAVI) control unit
FLASH-ROM Error Of Control UnitAV (NAVI) control unit malfunction is
detectedReplace AV (NAVI) control unit
Refer to AV-135, "
AV (NAVI) Control Unit"
Connection Of GyroNAVI control unit malfunction is
detectedReplace NAVI control unit
Refer to AV-135, "AV (NAVI) Control Unit"
GPS Communication Error
GPS malfunction is detectedIf the symptoms such as the GPS receipt
malfunction occur, intermittent malfunction
caused by strong radio interference may
be detected.
If the malfunction always occurs, replace
NAVI control unit. GPS ROM Error
GPS RAM Error
GPS RTC Error
DVD-ROM Communication Error
Malfunction is detected on DVD-
ROM drive pickup lens in NAVI con-
trol unit
There is dirt and damage on the map
disc
Map disc
NAVI control unit
Refer to AV-135, "
AV (NAVI) Control
Unit" DVD-ROM Read Error
DVD-ROM Disc Error
DVD-ROM Mechanism not Detected
DVD-ROM Mechanism Error
DVD-ROM Focus Error
DVD-ROM TOC Error
DVD-ROM Seek Error
DVD-ROM Error Correction Error
DVD-ROM Data Transfer Error
DVD-ROM Data Error
DVD-ROM Time-out
DVD-ROM Loading / Eject Error
CAN Controller Memory Error
AV (NAVI) control unit malfunction is
detectedReplace AV (NAVI) control unit
Refer to AV-135, "
AV (NAVI) Control Unit"Bluetooth Module Connection ErrorError item Description Possible cause/Action to take

AV-100
[WITHOUT MOBILE ENTERTAINMENT SYSTEM]
DIAGNOSIS SYSTEM
Revision: 2006 January2006 M35/M45
BLUETOOTH
Confirm/Change Passkey
The passkey of Bluetooth can be confirmed and changed.
The passkey can be changed by four digits within 0 to 9.
Confirm/Change Device Name
The device name of Bluetooth can be confirmed and changed.
The device name can be changed by sixteen digits within A to Z
(small characters can be used) and - (hyphen).
DELETE UNIT CONNECTION LOG
Erase the connection history of unit and error history that is recorded
in AV (NAVI) control unit (clear the connection history of the removed
unit).
SKIB3669E
SKIB3670E
SKIB3671E

DIAGNOSIS SYSTEM
AV-105
[WITHOUT MOBILE ENTERTAINMENT SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2006 January2006 M35/M45
DATA MONITOR
When “DATA MONITOR” is selected, “ALL SIGNALS” and “SELEC-
TION FROM MENU” are displayed.
GPS ANTENNA CONN [U1244]GPS antenna connection malfunction
is detected
GPS antenna feeder
GPS antenna
NAVI control unit
CAMERA CONT CONN [U1250]Camera and connection recognition
signal circuit malfunction is detected
Camera-connection recognition signal circuit
Camera control unit
AV (NAVI) control unit
Cont Unit FLASH-ROM [U1200]AV (NAVI) control unit malfunction is
detectedReplace AV (NAVI) control unit
Refer to AV-135, "
AV (NAVI) Control Unit" .
GYRO NO CONN [U1201]NAVI control unit malfunction is
detectedReplace NAVI control unit
Refer to AV-135, "
AV (NAVI) Control Unit" .
GPS COMM [U1204]
GPS malfunction is detectedIf the symptoms such as the GPS receipt mal-
function occur, intermittent malfunction caused
by strong radio interference may be detected.
If the malfunction always occurs, replace NAVI
control unit. GPS ROM [U1205]
GPS RAM [U1206]
GPS RTC [U1207]
DVD-ROM COMM [U1208]
Malfunction is detected on DVD-
ROM drive pickup lens in NAVI con-
trol unit
There is dirt and damage on the map
disc
Map disc
NAVI control unit
Refer to AV-135, "
AV (NAVI) Control Unit" . DVD-ROM READ [U1209]
DVD-ROM DISC [U120A]
DVD-ROM MECHA DETECT [U120C]
DVD-ROM DRIVE MECHA [U120D]
DVD-ROM FOCUS [U120E]
DVD-ROM TOC [U120F]
DVD-ROM SEEK [U1210]
DVD-ROM ERR CORRECTION
[U1211]
DVD-ROM DATA FORWARD [U1212]
DVD-ROM DATA [U1213]
DVD-ROM TIMEOUT [U1214]
DVD-ROM LOAD [U1215]
CAN CONT [U1216]
AV (NAVI) control unit malfunction is
detectedReplace AV (NAVI) control unit
Refer to AV-135, "
AV (NAVI) Control Unit" .
BLUETOOTH CONN [U1217]Error item Description Possible cause/Action to take
SKIB3675E

AV-148
[WITH MOBILE ENTERTAINMENT SYSTEM]
SYSTEM DESCRIPTION
Revision: 2006 January2006 M35/M45
GPS (Global Positioning System)
GPS (Global Positioning System) was developed for and is con-
trolled by the US Department of Defense. The system utilizes GPS
satellites (NAVSTAR), sending out radio waves while flying on an
orbit around the earth at an altitude of approximately 21,000 km
(13,100miles).
The GPS receiver calculates the vehicle's position in three dimen-
sions (latitude/longitude/altitude) according to the time lag of the
radio waves received from four or more GPS satellites (three-dimen-
sional positioning). If radio waves were received only from three
GPS satellites, the GPS receiver calculates the vehicle's position in
two dimensions (latitude/longitude), utilizing the altitude data calcu-
lated previously with radio waves from four or more GPS satellites
(two-dimensional positioning).
Position correction by GPS is not available while the vehicle is stopped.
