INFINITI Q50 2014 User Guide

0-4Illustrated table of contents
JVC0439X
1. Trunk—Intelligent Key system (P.3-6)
— Remote keyless entry system
(P.3-14)
— Trunk lid (P.3-19)
2. High-mounted stop light (P.8-26) 3. Satellite antenna (P.4-3)
4. Rear window defroster (P.2-36)/Anten-
na (P.4-3)
5. Sonar system (if so equipped)* —Back-up Collision Intervention (BCI)
system (if so equipped) (P.5-48) 6. Rear view camera*
7. Recovery hook (P.6-16)
8. Rear combination light (P.8-26)
9. Fuel-filler door
—Operation (P.3-21)
— Fuel information (P.9-4)
10. Child safety rear door locks (P.3-6)
*: Refer to the Infiniti InTouch Owner’s Manual.
EXTERIOR REAR

JVC0518X
1. Coat hooks (P.2-48)
2. Rear personal light (P.2-54)
3. Sun visors (P.3-25)
4. Map light (P.2-53)—SOS call switch (if so equipped)* 5. Moonroof switch (if so equipped)
(P.2-51)
6. Sunglasses holder (P.2-46)
7. Power window switch (P.2-49)
8. Automatic drive positioner switch (if so equipped) (P.3-29) 9. Inside mirror
—Operation (P.3-26)
— HomeLink
®universal transceiver (if
so equipped) (P.2-56)
— Compass (if so equipped) (P.2-9)
10. Trunk pass-through/Rear armrest (P.1-7)
11. Rear cup holders (P.2-45)
12. Rear ashtray (if so equipped) (P.2-44)
13. Console box (P.2-47) —Power outlet (P.2-44)
— Media hub*
14. Front cup holders (P.2-45)
15. Front passenger air bag status light (P.1-49)
*: Refer to the Infiniti InTouch Owner’s Manual.
Illustrated table of contents0-5
PASSENGER COMPARTMENT

0-6Illustrated table of contents
JVC0426X
1. Side ventilator (P.4-2)
2. Headlight, fog light and turn signalswitch (P.2-36)
3. Steering wheel —Horn (P.2-43) —
Driver supplemental air bag
(P.1-42)
— Heated steering wheel (if so
equipped)*
— Steering system (P.5-104) 4. Windshield wiper and washer switch
(P.2-33)
5. Hazard warning flasher switch (P.6-2)
6. Shift lever (P.5-15)
7. INFINITI controller*
8. Vehicle Dynamic Control (VDC) OFF switch (P.2-43, P.5-108)
9. Trunk lid release switch (P.3-19)
10. Instrument brightness control switch (P.2-42)
11. TRIP/RESET switch for twin trip od- ometer (P.2-7)
12. Electric tilting/telescopic steering wheel switch (if so equipped)
(P.3-24)
13. Manual tilting/telescopic steering wheel lever (if so equipped) (P.3-24)
14. Steering-wheel-mounted controls (left side)
—Audio control steering switch*
— Hands-Free Phone System switch*
— Voice recognition system switch*
15. Steering-wheel-mounted controls (right side)
—Trip computer switches (P.2-28)
— Cruise control switches (if so
equipped) (P.5-56)
COCKPIT

—Intelligent Cruise Control (ICC)
switches (if so equipped) (P.5-58)
— Dynamic driver assistance switch
(if so equipped) (P.5-30, P.5-37,
P.5-79)
16. INFINITI Drive Mode Selector (P.5-21)
*: Refer to the Infiniti InTouch Owner’s Manual.
Illustrated table of contents0-7

0-8Illustrated table of contents
JVC0427X
1. Paddle shifter (if so equipped) (P.5-17)
2. Meters and gauges (P.2-6)—Clock (P.2-30)
3. Push-button ignition switch (P.5-10)
4. Center ventilator (P.4-2)
5. Automatic climate control system* 6. Upper touch screen display (upper
display)* and Navigation system (if so
equipped)*
7. Lower touch screen display (lower display)*
8. Rear window and outside mirror defroster switch (P.2-36)
9. Front passenger supplemental air bag (P.1-42)
10. Hood release handle (P.3-18)
11. Fuse box cover (P.8-22)
12. Parking brake (P.5-20)
13. Seat heater switch (if so equipped)*
14. Audio system*
15. Trunk release power cancel switch (P.3-20)
16. Glove box (P.2-47)
*: Refer to the Infiniti InTouch Owner’s Manual.
INSTRUMENT PANEL

JVC0428X
1. Tachometer (P.2-8)
2. Warning/Indicator lights (P.2-12)
3. Speedometer (P.2-7)
4. Engine coolant temperature gauge(P.2-8)
5. Vehicle information display (P.2-20)/ Odometer/twin trip odometer (P.2-7)
6. Fuel gauge (P.2-9)
Illustrated table of contents0-9
METERS AND GAUGES

0-10Illustrated table of contents
JVM0250X
VQ37VHR ENGINE
1. Battery (P.8-15)
2. Engine oil filler cap (P.8-10)
3. Brake fluid reservoir (P.8-13)
4. Power steering fluid reservoir (if soequipped) (P.8-13)
5. Air cleaner (P.8-19)
6. Radiator filler cap (P.8-8)
7. Engine coolant reservoir (P.8-8)
8. Engine oil dipstick (P.8-10)
9. Engine drive belt location (P.8-17)
10. Fuse/fusible link holder (P.8-22)
11. Window washer fluid reservoir (P.8-14)
ENGINE COMPARTMENT

Warninglight Name
Page
Anti-lock Braking System (ABS)
warning light 2-12
Brake warning light
2-13
Charge warning light2-13
Forward emergency braking
system warning light* 2-13
Low fuel warning light
2-14
Low tire pressure warning light 2-14
Master warning light 2-16
Power steering warning light* 2-16
Seat belt warning light 2-16
Supplemental air bag warning
light 2-16
Vehicle Dynamic Control (VDC)
warning light2-17Indicator
light Name
Page
ECO drive indicator light
2-17
Exterior light indicator2-17
Front fog light indicator light
2-17
Front passenger air bag status
light2-17
High beam assist indicator
light*2-18
High beam indicator light
2-18
Malfunction Indicator Light
(MIL)2-18
Security indicator light 2-19
Turn signal/hazard indicator
lights
2-19
Vehicle Dynamic Control (VDC)
off indicator light2-19
*: if so equipped
Illustrated table of contents0-11
WARNING AND INDICATOR LIGHTS

0-12Illustrated table of contents
MEMO

1 Safety—Seats, seat belts and supplemental
restraint system
Seats................................................................... 1-2
Front seats ...................................................... 1-3
Rear seats ....................................................... 1-5
Armrest ........................................................... 1-7
Head restraints/headrests ................................... 1-8 Adjustable head
restraint/headrest components........................ 1-9
Non-adjustable head
restraint/headrest components........................ 1-9
Remove ........................................................... 1-9
Install............................................................ 1-10
Adjust ........................................................... 1-10
Seat belts .......................................................... 1-12
Precautions on seat belt usage ..................... 1-12
Pregnant women ........................................... 1-14
Injured persons ............................................. 1-14
Pre-crash seat belts with comfort function
(front seats) (if so equipped) ......................... 1-14
Three-point type seat belt ............................. 1-15
Seat belt extenders ....................................... 1-21
Seat belt maintenance................................... 1-21
Child safety ....................................................... 1-22 Infants........................................................... 1-23
Small children ............................................... 1-23
Larger children .............................................. 1-23 Child restraints ................................................. 1-24
Precautions on child restraints..................... 1-24
Lower Anchors and Tethers for CHildren
System (LATCH) ............................................ 1-26
Rear-facing child restraint installation
using LATCH................................................. 1-28
Rear-facing child restraint installation using
the seat belts .............................................. 1-30
Forward-facing child restraint installation
using LATCH................................................. 1-33
Forward-facing child restraint installation
using the seat belts ..................................... 1-35
Installing top tether strap ............................ 1-38
Booster seats .............................................. 1-39
Supplemental restraint system .......................... 1-42 Precautions on supplemental
restraint system........................................... 1-42
INFINITI Advanced Air Bag System
(front seats) ................................................. 1-47
Front seat-mounted side-impact supplemental
air bag and roof-mounted curtain side-impact
supplemental air bag systems ..................... 1-52
Seat belts with pretensioners (front seats).... 1-54
Supplemental air bag warning labels ........... 1-55
Supplemental air bag warning light ............. 1-55
Repair and replacement procedure............... 1-56
