brake light INFINITI QX30 2018 Owner's Manual

1. Turn signal, wiper, washer, and high beam
switch (P. 2-67, 2-61)
2.
Steering-wheel-mounted controls (left side)
(P. 2-15)
3. Ignition switch (P. 5-13)
— Push button ignition switch* (P. 5-14)4. Steering-wheel-mounted controls (right
side) (P. 4-2**)
5. Light switch
— Headlight (P. 2-65)
— Fog light (P. 2-71)
6. Parking brake (P. 3-27)7. Cruise Control switch
— Cruise Control (P. 5-46)
— Intelligent Cruise Control (P. 2-49*)
8. USB connection ports (P. 4-2**)
9. Shift lever (P. 5-19)
10. Front cup holders (P. 2-82)
11. INFINITI controller (P. 4-2**)
* if equipped
** refer to the INFINITI InTouch Owner’s
Manual
NIC2649
COCKPIT
0-6Illustrated table of contents

1. Ventilators (P. 4-28)
2. Center display* (P. 4-2**)
3. Meters and gauges (P. 2-4)
4. Light switch (P. 2-65)
5. Parking brake (P. 3-27)6. Steering wheel
— Power steering system (P. 5-89)
— Horn (P. 2-72)
— Driver’s supplemental front-impact air
bag (P. 1-37)
7. Audio system (P. 4-2**)8. Ignition switch (P. 5-13)
— Push button ignition switch* (P. 5-14)
9. Heater and air conditioner (P. 4-29)
10. Switch panel
— Seat heater switches* (P. 2-73)
— Hazard indicator flasher switch
(P. 6-2)
— Idle Stop/Start system on/off switch
(P. 5-30)
— Front passenger air bag status light
(P. 1-45)
11. Vehicle Information Display (P. 2-15)
12. Glove box (P. 2-80)
13. Front passenger supplemental air bag
(P. 1-37)
*: if equipped
** refer to the INFINITI InTouch Owner’s
Manual
NIC2898
INSTRUMENT PANEL
Illustrated table of contents0-7

Light Name Page Light Name Page Light Name Page
Anti-lock Braking System
(ABS) warning light2-9Seat belt (driver and front
passenger) warning light2-11High beam assist indicator
light *2-14
Brake warning light (red) 2-11Supplemental Restraint
System (SRS) air bag
warning light2-12High beam indicator light 2-14
Low tire pressure warning
light*2-9Low fuel warning light 2-13Rear fog light indicator
light2-14
Malfunction indicator light
(yellow)2-11Vehicle Dynamic Control
(VDC) warning light2-13Side light indicator light 2-14
Distance warning light* 2-11Turn signal/hazard indica-
tor lights2-13Front passenger air bag
status light**2-14
Electric parking brake
warning light (red)2-11Low beam indicator light 2-14
Electric parking brake
warning light (yellow)2-11Vehicle Dynamic Control
(VDC) OFF indicator light2-13
Coolant warning light 2-13Front fog light indicator
light*2-14 *: if equipped
**: located above heater and air condi-
tioner controls
WARNING AND INDICATOR LIGHTS
0-10Illustrated table of contents

1. Turn signal, wiper, washer, and high beam
switch (P. 2-67, 2-61)
2.
Steering-wheel-mounted controls (left side)
(P. 2-15)
3. Ignition switch (P. 5-13)
— Push button ignition switch* (P. 5-14)4. Steering-wheel-mounted controls (right
side) (P. 4-2**)
5. Light switch
— Headlight (P. 2-65)
— Fog light (P. 2-71)
6. Parking brake (P. 3-27)7. Cruise Control switch
— Cruise Control (P. 5-46)
— Intelligent Cruise Control (P. 2-49*)
8. USB connection ports (P. 4-2**)
9. Shift lever (P. 5-19)
10. Front cup holders (P. 2-82)
11. INFINITI controller (P. 4-2**)
* if equipped
** refer to the INFINITI InTouch Owner’s
Manual
NIC2649
COCKPIT
2-2Instruments and controls

1. Ventilators (P. 4-28)
2. Center display* (P. 4-2**)
3. Meters and gauges (P. 2-4)
4. Light switch (P. 2-65)
5. Parking brake (P. 3-27)6. Steering wheel
— Power steering system (P. 5-89)
— Horn (P. 2-72)
— Driver’s supplemental front-impact air
bag (P. 1-37)
7. Audio system (P. 4-2**)8. Ignition switch (P. 5-13)
— Push button ignition switch* (P. 5-14)
9. Heater and air conditioner (P. 4-29)
10. Switch panel
— Seat heater switches* (P. 2-73)
— Hazard indicator flasher switch
(P. 6-2)
— Idle Stop/Start system on/off switch
(P. 5-30)
— Front passenger air bag status light
(P. 1-45)
11. Vehicle Information Display (P. 2-15)
12. Glove box (P. 2-80)
13. Front passenger supplemental air bag
(P. 1-37)
*: if equipped
** refer to the INFINITI InTouch Owner’s
Manual
NIC2898
INSTRUMENT PANEL
Instruments and controls2-3

Anti-lock Braking System (ABS)
warning lightSeat belt (driver and front passenger)
warning lightHigh beam assist indicator light *
Brake warning light (red)Supplemental Restraint System (SRS)
air bag warning lightHigh beam indicator light
Low tire pressure warning light*Low fuel warning lightRear fog light indicator light
Malfunction indicator light (yellow)Vehicle Dynamic Control (VDC)
warning lightSide light indicator light
Distance warning light*Turn signal/hazard indicator lightsFront passenger air bag status light**
Electric parking brake warning light (red)Low beam indicator light
Electric parking brake warning light
(yellow)Vehicle Dynamic Control (VDC) OFF
indicator light
Coolant warning lightFront fog light indicator light* *: if equipped
**: located above heater and air conditioner controls
Some indicators and warnings are also dis-
played in the vehicle information display be-
tween the speedometer and tachometer see
"Vehicle information display".CHECKING LIGHTS
With all doors closed, apply the parking brake,
fasten the seat belts and place the ignition
switch in the ON position without starting the
engine. The following lights (if so equipped) will
come on, ,
,,,,
,,,,. These lights
should go out within a few seconds after start-
ing the engine. If any light fails to come on oroperates in a way other than described, it may
indicate a burned out bulb and/or a system
malfunction. Have the system checked. It is rec-
ommended you visit an INFINITI retailer for this
service.
WARNING LIGHTS, INDICATOR
LIGHTS AND AUDIBLE REMINDERS
2-8Instruments and controls

WARNING LIGHTS
Also see "Vehicle information display" later in
this section.
Anti-lock Braking System
(ABS) warning light
When the ignition switch is in the ON posi-
tion, the ABS warning light illuminates to in-
dicate that the ABS is operational. The light
then turns off within a few seconds after the
engine is started.
If the ABS light comes on while the engine is
running, it may indicate the anti-lock braking
system is not functioning properly. Have the
system checked. It is recommended that you
visit an INFINITI retailer for this service.
If the ABS warning light comes on while driv-
ing, it may indicate the ABS is not functioning
properly. Observe the additional display mes-
sages (if any) in the vehicle information dis-
play. Have the system checked by an
INFINITI retailer.
If an ABS malfunction occurs, the anti-lock
function is turned off. The brake system then
operates normally, but without anti-lock as-
sistance (see "Brake system").
BRAKE warning light (red)
WARNING
•Your brake system may not be working
properly if the warning light is on. Driv-
ing could be dangerous. If you judge it to
be safe, drive carefully to the nearest
service station for repairs. Otherwise,
have your vehicle towed because driving
it could be dangerous.
•Pressing the brake pedal when the igni-
tion switch is not in the ON position
and/or when the brake fluid level is low
may increase the stopping distance and
braking will require greater pedal effort
as well as pedal travel.
•If the brake fluid level is below the mini-
mum or MIN mark on the brake fluid
reservoir, do not drive until the brake
system has been checked. It is recom-
mended that you visit an INFINITI re-
tailer for this service.
When the ignition switch is placed in the ON
position, the light remains illuminated and
turns off when the engine is started. If the
light illuminates at any other time, it may
indicate that the brake system is not func-
tioning properly. If the BRAKE warning lightilluminates, stop the vehicle immediately and
contact an INFINITI retailer.
This light functions for both the parking brake
and the foot brake systems.
Low tire pressure warning
light (if equipped)
Your vehicle is equipped with a Tire Pressure
Monitoring System (TPMS) that monitors the
tire pressure of all its tires.
The low tire pressure warning light warns of
low tire pressure or indicates that the TPMS
is not functioning properly.
When the ignition switch is in the ON posi-
tion, the Low tire pressure warming light illu-
minates to indicate that the system is opera-
tional. The light then tuns off within a few
seconds after the engine is started.
Low tire pressure warning:
If the vehicle is being driven with low tire
pressure, the warning light will illuminate. A
tire pressure warning message also appears
in the vehicle information display.
When the low tire pressure warning light
illuminates, you should stop and adjust the
tire pressure of all 4 tires to the recom-
mended COLD tire pressure shown on the
Tire and Loading Information label located in
Instruments and controls2-9

Malfunction Indicator light
(MIL) (yellow)
When the ignition switch is turned to the ON
position, the yellow Malfunction Indicator
light illuminates. This means that the system
is operational.
If the yellow engine malfunction indicator
light lights up while the engine is running,
there may be a fault, for example:
•In the engine management
•In the fuel injection system
•In the exhaust system
•In the ignition system (for vehicles with
gasoline engines)
•In the fuel system (including a loose or
missing fuel filler cap).
•In other monitored items, for example the
automatic transmission.
The emission limit values may be exceeded
and the engine may be running in emergency
mode.
CAUTION
Continued vehicle operation without having
the engine control system checked and re-
paired as necessary could lead to poor drive-
ability, reduced fuel economy and possible
damage to the engine control system.
Incorrect setting of the engine control system
may lead to non-compliance of local and na-
tional emission laws and regulations.
Have the vehicle checked as soon as possible.
It is recommended you visit an INFINITI re-
tailer for this service.
Distance warning light
(if equipped)
This light illuminates if the distance to the
vehicle in front is too small for the speed
selected.
If a warning tone also sounds, you are ap-
proaching a vehicle or stationary obstacle in
your line of travel at too high a speed. For
additional information see " Forward emer-
gency braking (FEB) system (if equipped)".
Electric parking brake
warning light
The red indicator illuminates when the elec-
tric parking brake is engaged.
If the red indicator light for the electric park-
ing brake flashes or is lit and/or the yellow
warning light for the electric parking brake is
lit, observe the additional messages dis-
played in the vehicle information display.
For further parking brake operation informa-
tion see "Parking brake".
Seat belt (driver and front
passenger) warning light
The seat belt warning light reminds you to
fasten your seat belts. The light illuminates if
the engine is started, all doors are closed and
the driver’s and/or front passenger’s seat
belt is unfastened. It will remain illuminated
until the driver and/or front passenger fas-
tens their seat belt. A chime will sound once
the vehicle is in motion, see "Seat belt re-
minder chime" later in this section. See "Seat
belts" for precautions on seat belt usage.
The seat belt warning light may also illumi-
nate if there are objects on the front passen-
ger seat. Remove the objects and stow them
in a safe place.
Instruments and controls2-11

Have the system checked. It is recommended
you visit an INFINITI retailer for these services.
If an abnormality occurs in the system, the
VDC system function will be canceled, but
the vehicle is still driveable. For additional
information, see "Vehicle Dynamic Control
(VDC) system".
WARNING
VDC should remain on unless freeing a ve-
hicle from mud or snow.
While the VDC system is operating, you
might feel a slight vibration or hear the sys-
tem working when starting the vehicle or ac-
celerating, but this is normal.
Front fog light indicator light
(if equipped)
The light comes on when the front fog lights
are switched on (see " Fog light switch (If so
equipped)" later in this section).
High beam assist indicator
light (if equipped)
The indicator light illuminates when the
headlights come on while the headlight
switch is in the AUTO position with the high
beam selected. This indicates that the high
beam assist system is operational. (See 2-65.)
High beam indicator light
This blue light comes on when the headlight
high beams are on and goes out when the
low beams are selected.
The high beam indicator light also comes on
when the passing signal is activated.
Rear fog light indicator light
The light comes on when the rear fog light is
switched on (see " Fog light switch (If so
equipped)" later in this section).
Side light and headlight
indicator light
This light comes on when the side light or
headlight position is selected, see "Headlight
and turn signal switches" later in this section
for further details.
/Front passenger air
bag status light
The front passenger air bag status light
() located on the center console above
the shift lever will illuminate when the front
passenger air bag is turned OFF. When the
front passenger air bag is turned on, the front
passenger air bag status light ON (
) will
illuminate.For more details, see "Front passenger air
bag and status light".
AUDIBLE REMINDERS
Parking brake reminder chime
A chime will sound when driving away if the
parking brake has not been released. Stop the
vehicle and release the parking brake.
Light reminder chime
With the ignition switch placed in the OFF
position, a chime sounds when the driver's
door is opened if the side lights are on. Turn
the headlight control switch off before leav-
ing the vehicle.
Seat belt reminder chime
A chime will sound for approximately 120
seconds if the vehicle's speed exceeds
16 MPH (25 km/h) and the driver's seat belt
or front passenger's seat belt, if occupied is
not securely fastened. See "Seat belt warning
light".
2-14Instruments and controls

•Lane Departure Warning (LDW)
•Blind Spot Warning (BSW)
•Rear window wiper
Deactivating/activating VDC:
The vehicle should be driven with the Vehicle
Dynamic Control (VDC) system on for most
driving conditions.
If the vehicle is stuck in mud or snow, the
VDC system reduces the engine output to
reduce wheel spin. The engine speed will be
reduced even if the accelerator is depressed
to the floor. If maximum engine power is
needed to free a stuck vehicle, turn the VDC
system off.
For further information about VDC, see "Ve-
hicle Dynamic Control (VDC) system".
1. Start the engine.
2. Press the
orbutton on the
steering wheel to select the [DriveAssist]
menu.
3. Press the
orbutton to select
[ESP].
4. Press the button.
The current selection is displayed.5. To activate/deactivate: press the
button again.
VDC is deactivated if the
warning
light in the combination meter lights up
continuously when the engine is running.
If both the
warning light andwarning light are lit continuously, VDC is not
available due to a malfunction.
Activating/deactivating Forward Emergency
Braking:
1. Press theorbutton on the
steering wheel to select the [DriveAssist]
menu.
2. Press the
orbutton to select
[Emergency Brake].
3. Press the button.
The current selection is displayed.
4. To activate/deactivate: press the
button again.
When Forward Emergency Braking is de-
activated, the
symbol appears in the
vehicle information display in the assis-
tance graphic display.
For further information about Forward
Emergency Braking, see " Forward emer-
gency braking (FEB) system (if equipped)".Activating/deactivating Blind Spot
Warning (BSW):
1. Press the
orbutton on the
steering wheel to select the [DriveAssist]
menu.
2. Press the
orbutton to select
[Blind Spot Warning].
3. Press the button.
The current selection is displayed.
4. To activate/deactivate: press the
button again.
For further information about Blind Spot
Warning, see " Blind Spot Warning (BSW)
system (if equipped)".
Activating/deactivating Lane Departure
Warning (LDW):
1. Press the
orbutton on the
steering wheel to select the [DriveAssist]
menu on the Menu bar.
2. Press the
orbutton to select
[Lane Departure Warning].
3. Press thebutton on the steering
wheel. The current selection is displayed.
4. Press theto confirm.
Instruments and controls2-23
