Safety systems
Message Possible causes/consequences and solutions
[Currently Unavailable See
Operator's Manual]ABS (Anti-Lock Braking System), BAS (Brake Assist System), VDC (Vehicle Dynamic Control), and hill start assist are temporarily
unavailable.
Forward Emergency Braking (FEB) may also have failed.
In addition, the,andwarning lights may light up in the combination meter.
Possible causes:
•Self-diagnosis is not yet complete.•The on-board voltage may be insufficient.
WARNING
The brake system continues to function normally, but without the functions listed above. The wheels could therefore lock if you
brake hard, for example.
The steering and braking characteristics may be severely affected. The braking distance may increase in an emergency braking
situation.
If VDC is not operational, VDC is unable to stabilize the vehicle. There is an increased danger of skidding and risk of an accident.
Carefully drive on a suitable stretch of road, making slight steering movements, at a speed above 12 MPH (20 km/h). If the display
message disappears, the functions mentioned above are available again.
If the display message continues to be displayed, drive on carefully and have the system checked. It is recommended you visit an
INFINITI retailer for this service.
2-30Instruments and controls

Message Possible causes/consequences and solutions
[Inoperative See Operator's
Manual]ABS (Anti-Lock Braking System), BAS (Brake Assist System), VDC (Vehicle Dynamic Control), and hill start assist are not available
due to a malfunction.
Forward Emergency Braking (FEB) may also have failed.
In addition, the,,andwarning lights may light up in the combination meter.
WARNING
The brake system continues to function normally, but without the functions listed above. The wheels could therefore lock if you
brake hard, for example.
The steering and braking characteristics may be severely affected. The braking distance may increase in an emergency braking
situation.
If VDC is not operational, VDC is unable to stabilize the vehicle. There is an increased danger of skidding and risk of an accident.
Drive on carefully and have the system checked immediately. It is recommended you visit an INFINITI retailer for this service.
[Currently Unavailable See
Operator's Manual]BAS (Brake Assist System), VDC (Vehicle Dynamic Control), and hill start assist are temporarily unavailable.
Forward Emergency Braking (FEB) may also have failed.
In addition, theandwarning lights may light up in the combination meter.
The self-diagnosis function, for example, may not be complete.
WARNING
The brake system continues to function normally, but without the functions listed above.
The braking distance may increase in an emergency braking situation.
If VDC is not operational, VDC is unable to stabilize the vehicle. There is an increased danger of skidding and risk of an accident.
Carefully drive on a suitable stretch of road, making slight steering movements, at a speed above 12 MPH (20 km/h). If the display
message disappears, the functions mentioned above are available again.
If the display message continues to be displayed, drive on carefully and have the system checked. It is recommended you an INFINITI
retailer for this service.
Instruments and controls2-31

Message Possible causes/consequences and solutions
[Inoperative See Operator's
Manual]BAS (Brake Assist System), VDC (Vehicle Dynamic Control), and hill start assist are not available due to a malfunction.
Forward Emergency Braking (FEB) may also have failed.
In addition, theandwarning lights may light up in the combination meter.
WARNING
The brake system continues to function normally, but without the functions listed above.
The braking distance may increase in an emergency braking situation.
If VDC is not operational, VDC is unable to stabilize the vehicle. There is an increased danger of skidding and risk of an accident.
Drive on carefully and have the system checked. It is recommended you visit an INFINITI retailer for this service.
[Inoperative See Operator's
Manual]EBD (Electronic Brake Force Distribution) ABS (Anti-Lock Braking System), BAS (Brake Assist System), VDC (Vehicle Dynamic
Control), and hill start assist are not available due to a malfunction.
Forward Emergency Braking (FEB) may also have failed.
A warning tone sounds.
In addition, the,andwarning lights may light up in the combination meter.
WARNING
The brake system continues to function normally, but without the functions listed above. The front and rear wheels could
therefore lock if you brake hard, for example.
The steering and braking characteristics may be severely affected. The braking distance may increase in an emergency braking
situation.
If VDC is not operational, VDC is unable to stabilize the vehicle. There is an increased danger of skidding and risk of an accident.
Drive on carefully and have the system checked immediately. It is recommended you visit an INFINITI retailer for this service.
[Turn On The Ignition to
Release the Parking Brake]The redindicator light lights up.
You attempted to release the electric parking brake while the ignition was switched off.
Key: turn the key to the ON position in the ignition switch
2-32Instruments and controls

Message Possible causes/consequences and solutions
[Please Release Parking
Brake]The redindicator light flashes and a warning tone sounds. A condition for automatic release of the electric parking brake is
not fulfilled (see " Applying automatically (vehicles with automatic transmission)").
You are driving with the electric parking brake applied.
Release the electric parking brake manually.
The red
indicator light flashes and a warning tone sounds.
You are making an emergency stop using the electric parking brake (see "Emergency braking")
[Parking Brake See
Operator's Manual]The yellowwarning light lights up.
The electric parking brake is malfunctioning.
To apply:
1. Switch the ignition off.
2. Press the electric parking brake handle for at least ten seconds.
3. Press the P (Park) button.
4. Have the system checked. It is recommended you consult an INFINITI retailer.
The yellow
warning light and the redindicator light are lit.
The electric parking brake is malfunctioning.
To release:
1. Switch the ignition off and turn it back on.
2. Release the electric parking brake manually.or
3. Release the electric parking brake automatically (see " Applying automatically (vehicles with automatic transmission)").
If the electric parking brake still cannot be released: DO NOT drive on. It is recommended you consult an INFINITI retailer.
Instruments and controls2-33

Message Possible causes/consequences and solutions
The yellow
warning light is lit. The redindicator light flashes.
The electric parking brake is malfunctioning.
To release:
1. Switch the ignition off and turn it back on.
2. Release the electric parking brake manually.or
To apply:
1. Switch the ignition off and turn it back on.
2. Apply the electric parking brake manually.
If the red
. indicator light continues to flash:
1 DO NOT drive on
2. Secure the vehicle against rolling away
3. Press the P (Park) button.
4. Turn the front wheels towards the curb.
It is recommended you consult an INFINITI retailer.
The yellow
warning light is lit. The redindicator light flashes for about ten seconds after the electric parking brake
has been applied or released. It then goes out or remains lit.
The electric parking brake is malfunctioning.
To apply:
1. Switch the ignition off and turn it back on.
2. Apply the electric parking brake manually.If it is not possible to apply the electric parking brake:
3. Press the P (Park) button.
It is recommended you consult an INFINITI retailer.
If it is not possible to release the electric parking brake:
Release the electric parking brake automatically (see " Applying automatically (vehicles with automatic transmission)").
If the electric parking: brake still cannot be released, it is recommended you consult an INFINITI retailer.
2-34Instruments and controls

Message Possible causes/consequences and solutions
The yellow
warning light is lit. If you manually apply or release the electric parking brake, the redindicator light flashes.
The electric parking brake is malfunctioning. It is not possible to apply the electric parking brake manually.
or
Insert the seat belt in the belt buckle and accelerate slightly more when pulling away.
Press the P (Park) button, as the electric parking brake is not applied automatically.
It is recommended you consult an INFINITI retailer.
If you do not wish the electric parking brake to be applied, leave the ignition switched on, e. g. when washing the vehicle in an
automatic car wash or when having the vehicle towed.
[Parking Brake Inoperative]The yellowwarning light is lit. The redindicator light flashes for about ten seconds after the electric parking brake
has been applied or released. It then goes out or remains lit.
The electric parking brake is malfunctioning, e.g. because of overvoltage or undervoltage.
1. Rectify the cause of the overvoltage or undervoltage, e.g. by charging the battery or restarting the engine.
2. Apply or release the electric parking brake.
If the electric parking brake still cannot be applied or released:
1. Switch the ignition off and turn it back on.
2. Apply or release the electric parking brake manually.
If the electric parking brake still cannot be applied or released, it is recommended you consult an INFINITI retailer.
The yellow
warning light is lit. The redindicator light flashes.
It is not possible to apply the electric parking brake manually.
1. Press the P (Park) button.
Consult an INFINITI retailer.
[Brake Immediately]A tone may also sound at regular intervals. If you attempt to lock the vehicle, the tone becomes louder.
You cannot start the engine.
1. Paying attention to the traffic situation, immediately depress the brake pedal firmly and hold until the display message
disappears.
2. Secure the vehicle against rolling away. You can restart the engine.
Instruments and controls2-35

Message Possible causes/consequences and solutions
[Check Brake Fluid Level]There is insufficient brake fluid in the brake fluid reservoir.
In addition, the redwarning light lights up in the combination meter and a warning tone sounds.
1. Pull over and stop the vehicle safely as soon as possible, paying attention to road and traffic conditions. Do not continue driving
under any circumstances.
2. Secure the vehicle against rolling away.
3. Check the brake fluid level. If brake fluid is necessary, add fluid and have the system checked. It is recommended you visit an
INFINITI retailer for this service. See "Brake fluid".
4. If the brake fluid level is correct, have the warning system checked. It is recommended you visit an INFINITI retailer for this
service.
WARNING•Your brake system may not be working properly if the warning light is on. Driving could be dangerous. If you judge it to be safe,
drive carefully to the nearest service station for repairs. Otherwise, have your vehicle towed because driving it could be
dangerous.
•Pressing the brake pedal with the engine stopped and/or low brake fluid level may increase your stopping distance and braking
will require greater pedal effort as well as pedal travel.
•If the brake fluid level is below the minimum or MIN mark on the brake fluid reservoir, do not drive until the brake system has
been checked. It is recommended you visit an INFINITI retailer for this service.
[Check Brake Pad Wear]The brake pads/linings have reached their wear limit.
It is recommended you visit an INFINITI retailer.
2-36Instruments and controls

Message Possible causes/consequences and solutions
[Check Center Brake Lamp]The third brake light is faulty.
Have the system checked. It is recommended you visit an INFINITI retailer for this service.
[Check Left Brake Lamp] or
[Check Right Brake Lamp]The left-hand or right-hand brake light is faulty.
Have the system checked. It is recommended you visit an INFINITI retailer for this service.
[Check Left Main Beam] or
[Check Right Main Beam]The left or right-hand high beam headlight is faulty.•Check whether you are permitted to replace the bulb yourself (see "Lights").
or:
•Have the system checked. It is recommended you visit an INFINITI retailer for this service.
[License Plate Lamp]The left or right-hand license plate light is faulty.
Have the system checked. It is recommended you visit an INFINITI retailer for this service.
[Check Left Fog Lamp] or
[Check Right Fog Lamp]The left or right-hand fog light is faulty.
Have the system checked. It is recommended you visit an INFINITI retailer for this service.
[Rear Fog Lamp]The rear fog light is faulty.
Have the system checked. It is recommended you visit an INFINITI retailer for this service.
[Check Front Left Side-
marker Lamp] or [Check
Front Right Sidemarker
Lamp]The front left or front right parking light is faulty.
Have the system checked. It is recommended you visit an INFINITI retailer for this service.
2-42Instruments and controls

2. Maintain a firm grip on the steering wheel
with both hands and try to hold a straight
course.
3. When appropriate, slowly release the ac-
celerator pedal to gradually slow the ve-
hicle.
4. Gradually steer the vehicle to a safe loca-
tion off the road and away from traffic if
possible.
5. Lightly apply the brake pedal to gradually
stop the vehicle.
6. Turn on the hazard warning flashers and
contact a roadside emergency service to
change the tire. For additional informa-
tion, refer to "Flat tire".
DRINKING ALCOHOL/DRUGS
AND DRIVING
WARNING
Never drive under the influence of alcohol
or drugs. Alcohol in the bloodstream re-
duces coordination, delays reaction time
and impairs judgement. Driving after
drinking alcohol increases the likelihood of
being involved in an accident injuring your-
self and others. Additionally, if you are in-
jured in an accident, alcohol can increase
the severity of the injury.INFINITI is committed to safe driving. How-
ever, you must choose not to drive under the
influence of alcohol. Every year thousands of
people are injured or killed in alcohol-related
accidents. Although the local laws vary on
what is considered to be legally intoxicated,
the fact is that alcohol affects all people dif-
ferently and most people underestimate the
effects of alcohol.
Remember, drinking and driving don’t mix!
And that is true for drugs, too (over-the-
counter, prescription, and illegal drugs). Don’t
drive if your ability to operate your vehicle is
impaired by alcohol, drugs, or some other
physical condition.
DRIVING SAFETY PRECAUTIONS
Your INFINITI is designed for both normal
and off-road use. However, avoid driving in
deep water or mud as your INFINITI is mainly
designed for leisure use, unlike a conventional
off-road vehicle.
Remember that 2–wheel drive vehicles are
less capable than all-wheel drive (AWD)
models for rough road driving and extrication
when stuck in deep snow or mud, or the like.Please observe the following precautions:
WARNING
•Spinning the front wheels on slippery
surfaces may cause the AWD warning
message to display and the AWD system
to automatically switch from the AWD
to 2WD mode. This could reduce the
traction. Be especially careful when
towing a trailer. (AWD models)
•Drive carefully when off the road and
avoid dangerous areas. Every person
who drives or rides in this vehicle should
be seated with their seat belt fastened.
This will keep you and your passengers
in position when driving over rough ter-
rain.
•Do not drive across steep slopes. Instead
drive either straight up or straight down
the slopes. Off-road vehicles can tip
over sideways much more easily than
they can forward or backward.
•Many hills are too steep for any vehicle.
If you drive up them, you may stall. If you
drive down them, you may not be able to
control your speed. If you drive across
them, you may roll over.
5-10Starting and driving

•Do not shift gears while driving on
downhill grades as this could cause loss
of control of the vehicle.
•Stay alert when driving to the top of a
hill. At the top there could be a drop-off
or other hazard that could cause an ac-
cident.
•If your engine stalls or you cannot make
it to the top of a steep hill, never at-
tempt to turn around. Your vehicle could
tip or roll over. Always back straight
down in R (Reverse) gear and apply
brakes to control your speed.
•Heavy braking going down a hill could
cause your brakes to overheat and fade,
resulting in loss of control and an acci-
dent. Apply brakes lightly and use a low
gear to control your speed.
•Unsecured cargo can be thrown around
when driving over rough terrain. Prop-
erly secure all cargo so it will not be
thrown forward and cause injury to you
or your passengers.
•Secure heavy loads in the cargo area as
far forward and as low as possible. Do
not equip the vehicle with tires larger
than specified in this manual. This could
cause your vehicle to roll over.
•Do not grip the inside or spokes of the
steering wheel when driving off-road.
The steering wheel could move suddenly
and injure your hands. Instead drive with
your fingers and thumbs on the outside
of the rim.
•Before operating the vehicle, ensure
that the driver and all passengers have
their seat belts fastened.
•Always drive with the floor mats in place
as the floor may become hot.
•Lower your speed when encountering
strong crosswinds. With a higher center
of gravity, your INFINITI is more af-
fected by strong side winds. Slower
speeds ensure better vehicle control.
•Do not drive beyond the performance
capability of the tires, even with AWD
engaged.
•For AWD equipped vehicles, do not at-
tempt to raise two wheels off the
ground and shift the transmission to any
drive or reverse position with the engine
running. Doing so may result in drive-
train damage or unexpected vehicle
movement which could result in serious
vehicle damage or personal injury.
•Do not attempt to test an AWD
equipped vehicle on a 2-wheel dyna-
mometer (such as the dynamometers
used by some states for emissions test-
ing), or similar equipment even if the
other two wheels are raised off the
ground. Make sure you inform test facil-
ity personnel that your vehicle is
equipped with AWD before it is placed
on a dynamometer. Using the wrong
test equipment may result in drivetrain
damage or unexpected vehicle move-
ment which could result in serious ve-
hicle damage or personal injury.
•When a wheel is off the ground due to an
unlevel surface, do not spin the wheel
excessively.
•Accelerating quickly, sharp steering ma-
neuvers or sudden braking may cause
loss of control.
•If at all possible, avoid sharp turning ma-
neuvers, particularly at high speeds.
Your INFINITI vehicle has a higher cen-
ter of gravity than a passenger car. The
vehicle is not designed for cornering at
the same speeds as passenger cars. Fail-
ure to operate this vehicle correctly
could result in loss of control and/or a
rollover accident.
Starting and driving5-11
