•Lane Departure Warning (LDW)
•Blind Spot Warning (BSW)
•Rear window wiper
Deactivating/activating VDC:
The vehicle should be driven with the Vehicle
Dynamic Control (VDC) system on for most
driving conditions.
If the vehicle is stuck in mud or snow, the
VDC system reduces the engine output to
reduce wheel spin. The engine speed will be
reduced even if the accelerator is depressed
to the floor. If maximum engine power is
needed to free a stuck vehicle, turn the VDC
system off.
For further information about VDC, see "Ve-
hicle Dynamic Control (VDC) system".
1. Start the engine.
2. Press the
orbutton on the
steering wheel to select the [DriveAssist]
menu.
3. Press the
orbutton to select
[ESP].
4. Press the button.
The current selection is displayed.5. To activate/deactivate: press the
button again.
VDC is deactivated if the
warning
light in the combination meter lights up
continuously when the engine is running.
If both the
warning light andwarning light are lit continuously, VDC is not
available due to a malfunction.
Activating/deactivating Forward Emergency
Braking:
1. Press theorbutton on the
steering wheel to select the [DriveAssist]
menu.
2. Press the
orbutton to select
[Emergency Brake].
3. Press the button.
The current selection is displayed.
4. To activate/deactivate: press the
button again.
When Forward Emergency Braking is de-
activated, the
symbol appears in the
vehicle information display in the assis-
tance graphic display.
For further information about Forward
Emergency Braking, see " Forward emer-
gency braking (FEB) system (if equipped)".Activating/deactivating Blind Spot
Warning (BSW):
1. Press the
orbutton on the
steering wheel to select the [DriveAssist]
menu.
2. Press the
orbutton to select
[Blind Spot Warning].
3. Press the button.
The current selection is displayed.
4. To activate/deactivate: press the
button again.
For further information about Blind Spot
Warning, see " Blind Spot Warning (BSW)
system (if equipped)".
Activating/deactivating Lane Departure
Warning (LDW):
1. Press the
orbutton on the
steering wheel to select the [DriveAssist]
menu on the Menu bar.
2. Press the
orbutton to select
[Lane Departure Warning].
3. Press thebutton on the steering
wheel. The current selection is displayed.
4. Press theto confirm.
Instruments and controls2-23

5. Press theorbutton to set
[Off], [Standard] or [Adaptive].
6. Press thebutton to save the setting.
For further information about Lane Depar-
ture Warning, see " Lane departure warning
(LDW) system (if equipped) ".
Service menu ([Serv.])
Depending on the equipment fitted in the
vehicle, you have the following options in the
[Serv.] menu:
•Calling up display messages in the mes-
sage memory (see "Message memory"
later in this section).
•Restarting the tire pressure monitoring
system (TPMS) (see "Restarting TPMS".
•Checking the tire pressure electronically
(see "Checking the tire pressure electroni-
cally").
•Calling up the service due date (see "Main-
tenance service messages").
Settings menu
Depending on the equipment fitted in the
vehicle, in the [Settings] menu you have the
following options:
•Changing the instrument cluster settings.
•Changing the light setting.
•Changing the vehicle setting.
•Changing the convenience setting.
•Restoring the factory setting.
Instrument cluster:
Unit of measurement for distance: The Dis-
play unit Speed-/odometer function allows
you to choose whether certain displays ap-
pear in kilometers or miles in the vehicle infor-
mation display.
NIC2874NIC2731
2-24Instruments and controls

DISPLAY MESSAGES
Display messages appear in the vehicle infor-
mation display.
Display messages with graphic symbols are
simplified in the Owner's Manual and may
differ from the symbols in the vehicle infor-
mation display.
Certain display messages are accompanied
by an audible warning tone or a continuous
tone.
When the ignition is switched off, all display
messages are deleted apart from some high-
priority display messages. Once the causes of
the high-priority display messages have been
rectified, these display messages are deleted
as well.
When you stop and park the vehicle, please
observe the notes on parking (see "Parking").
Hiding display messages
Press the orbutton to hide the
display message. The display message is hid-
den.
The vehicle information display shows high-
priority display messages in red. Some high-
priority display messages cannot be hidden.
The vehicle information display shows these
messages continuously until the causes for
the messages have been remedied.
Message memory
The vehicle information display saves certain
messages in the message memory. You can
call up these display messages:
1. Press the
orbutton on the
steering wheel to select the [Service]
menu.
If there are display messages, the vehicle
information display shows [2 messages],
for example.
2. Press the
orbutton to select
the entry, e.g. [2 messages].
3. Press to confirm.
4. Press the
orbutton to scroll
through the display messages.
Instruments and controls2-29

Safety systems
Message Possible causes/consequences and solutions
[Currently Unavailable See
Operator's Manual]ABS (Anti-Lock Braking System), BAS (Brake Assist System), VDC (Vehicle Dynamic Control), and hill start assist are temporarily
unavailable.
Forward Emergency Braking (FEB) may also have failed.
In addition, the,andwarning lights may light up in the combination meter.
Possible causes:
•Self-diagnosis is not yet complete.•The on-board voltage may be insufficient.
WARNING
The brake system continues to function normally, but without the functions listed above. The wheels could therefore lock if you
brake hard, for example.
The steering and braking characteristics may be severely affected. The braking distance may increase in an emergency braking
situation.
If VDC is not operational, VDC is unable to stabilize the vehicle. There is an increased danger of skidding and risk of an accident.
Carefully drive on a suitable stretch of road, making slight steering movements, at a speed above 12 MPH (20 km/h). If the display
message disappears, the functions mentioned above are available again.
If the display message continues to be displayed, drive on carefully and have the system checked. It is recommended you visit an
INFINITI retailer for this service.
2-30Instruments and controls

Message Possible causes/consequences and solutions
[Inoperative See Operator's
Manual]ABS (Anti-Lock Braking System), BAS (Brake Assist System), VDC (Vehicle Dynamic Control), and hill start assist are not available
due to a malfunction.
Forward Emergency Braking (FEB) may also have failed.
In addition, the,,andwarning lights may light up in the combination meter.
WARNING
The brake system continues to function normally, but without the functions listed above. The wheels could therefore lock if you
brake hard, for example.
The steering and braking characteristics may be severely affected. The braking distance may increase in an emergency braking
situation.
If VDC is not operational, VDC is unable to stabilize the vehicle. There is an increased danger of skidding and risk of an accident.
Drive on carefully and have the system checked immediately. It is recommended you visit an INFINITI retailer for this service.
[Currently Unavailable See
Operator's Manual]BAS (Brake Assist System), VDC (Vehicle Dynamic Control), and hill start assist are temporarily unavailable.
Forward Emergency Braking (FEB) may also have failed.
In addition, theandwarning lights may light up in the combination meter.
The self-diagnosis function, for example, may not be complete.
WARNING
The brake system continues to function normally, but without the functions listed above.
The braking distance may increase in an emergency braking situation.
If VDC is not operational, VDC is unable to stabilize the vehicle. There is an increased danger of skidding and risk of an accident.
Carefully drive on a suitable stretch of road, making slight steering movements, at a speed above 12 MPH (20 km/h). If the display
message disappears, the functions mentioned above are available again.
If the display message continues to be displayed, drive on carefully and have the system checked. It is recommended you an INFINITI
retailer for this service.
Instruments and controls2-31

Message Possible causes/consequences and solutions
[Inoperative See Operator's
Manual]BAS (Brake Assist System), VDC (Vehicle Dynamic Control), and hill start assist are not available due to a malfunction.
Forward Emergency Braking (FEB) may also have failed.
In addition, theandwarning lights may light up in the combination meter.
WARNING
The brake system continues to function normally, but without the functions listed above.
The braking distance may increase in an emergency braking situation.
If VDC is not operational, VDC is unable to stabilize the vehicle. There is an increased danger of skidding and risk of an accident.
Drive on carefully and have the system checked. It is recommended you visit an INFINITI retailer for this service.
[Inoperative See Operator's
Manual]EBD (Electronic Brake Force Distribution) ABS (Anti-Lock Braking System), BAS (Brake Assist System), VDC (Vehicle Dynamic
Control), and hill start assist are not available due to a malfunction.
Forward Emergency Braking (FEB) may also have failed.
A warning tone sounds.
In addition, the,andwarning lights may light up in the combination meter.
WARNING
The brake system continues to function normally, but without the functions listed above. The front and rear wheels could
therefore lock if you brake hard, for example.
The steering and braking characteristics may be severely affected. The braking distance may increase in an emergency braking
situation.
If VDC is not operational, VDC is unable to stabilize the vehicle. There is an increased danger of skidding and risk of an accident.
Drive on carefully and have the system checked immediately. It is recommended you visit an INFINITI retailer for this service.
[Turn On The Ignition to
Release the Parking Brake]The redindicator light lights up.
You attempted to release the electric parking brake while the ignition was switched off.
Key: turn the key to the ON position in the ignition switch
2-32Instruments and controls

Message Possible causes/consequences and solutions
[Please Release Parking
Brake]The redindicator light flashes and a warning tone sounds. A condition for automatic release of the electric parking brake is
not fulfilled (see " Applying automatically (vehicles with automatic transmission)").
You are driving with the electric parking brake applied.
Release the electric parking brake manually.
The red
indicator light flashes and a warning tone sounds.
You are making an emergency stop using the electric parking brake (see "Emergency braking")
[Parking Brake See
Operator's Manual]The yellowwarning light lights up.
The electric parking brake is malfunctioning.
To apply:
1. Switch the ignition off.
2. Press the electric parking brake handle for at least ten seconds.
3. Press the P (Park) button.
4. Have the system checked. It is recommended you consult an INFINITI retailer.
The yellow
warning light and the redindicator light are lit.
The electric parking brake is malfunctioning.
To release:
1. Switch the ignition off and turn it back on.
2. Release the electric parking brake manually.or
3. Release the electric parking brake automatically (see " Applying automatically (vehicles with automatic transmission)").
If the electric parking brake still cannot be released: DO NOT drive on. It is recommended you consult an INFINITI retailer.
Instruments and controls2-33

Message Possible causes/consequences and solutions
The yellow
warning light is lit. The redindicator light flashes.
The electric parking brake is malfunctioning.
To release:
1. Switch the ignition off and turn it back on.
2. Release the electric parking brake manually.or
To apply:
1. Switch the ignition off and turn it back on.
2. Apply the electric parking brake manually.
If the red
. indicator light continues to flash:
1 DO NOT drive on
2. Secure the vehicle against rolling away
3. Press the P (Park) button.
4. Turn the front wheels towards the curb.
It is recommended you consult an INFINITI retailer.
The yellow
warning light is lit. The redindicator light flashes for about ten seconds after the electric parking brake
has been applied or released. It then goes out or remains lit.
The electric parking brake is malfunctioning.
To apply:
1. Switch the ignition off and turn it back on.
2. Apply the electric parking brake manually.If it is not possible to apply the electric parking brake:
3. Press the P (Park) button.
It is recommended you consult an INFINITI retailer.
If it is not possible to release the electric parking brake:
Release the electric parking brake automatically (see " Applying automatically (vehicles with automatic transmission)").
If the electric parking: brake still cannot be released, it is recommended you consult an INFINITI retailer.
2-34Instruments and controls

Message Possible causes/consequences and solutions
The yellow
warning light is lit. If you manually apply or release the electric parking brake, the redindicator light flashes.
The electric parking brake is malfunctioning. It is not possible to apply the electric parking brake manually.
or
Insert the seat belt in the belt buckle and accelerate slightly more when pulling away.
Press the P (Park) button, as the electric parking brake is not applied automatically.
It is recommended you consult an INFINITI retailer.
If you do not wish the electric parking brake to be applied, leave the ignition switched on, e. g. when washing the vehicle in an
automatic car wash or when having the vehicle towed.
[Parking Brake Inoperative]The yellowwarning light is lit. The redindicator light flashes for about ten seconds after the electric parking brake
has been applied or released. It then goes out or remains lit.
The electric parking brake is malfunctioning, e.g. because of overvoltage or undervoltage.
1. Rectify the cause of the overvoltage or undervoltage, e.g. by charging the battery or restarting the engine.
2. Apply or release the electric parking brake.
If the electric parking brake still cannot be applied or released:
1. Switch the ignition off and turn it back on.
2. Apply or release the electric parking brake manually.
If the electric parking brake still cannot be applied or released, it is recommended you consult an INFINITI retailer.
The yellow
warning light is lit. The redindicator light flashes.
It is not possible to apply the electric parking brake manually.
1. Press the P (Park) button.
Consult an INFINITI retailer.
[Brake Immediately]A tone may also sound at regular intervals. If you attempt to lock the vehicle, the tone becomes louder.
You cannot start the engine.
1. Paying attention to the traffic situation, immediately depress the brake pedal firmly and hold until the display message
disappears.
2. Secure the vehicle against rolling away. You can restart the engine.
Instruments and controls2-35

Message Possible causes/consequences and solutions
[Check Brake Fluid Level]There is insufficient brake fluid in the brake fluid reservoir.
In addition, the redwarning light lights up in the combination meter and a warning tone sounds.
1. Pull over and stop the vehicle safely as soon as possible, paying attention to road and traffic conditions. Do not continue driving
under any circumstances.
2. Secure the vehicle against rolling away.
3. Check the brake fluid level. If brake fluid is necessary, add fluid and have the system checked. It is recommended you visit an
INFINITI retailer for this service. See "Brake fluid".
4. If the brake fluid level is correct, have the warning system checked. It is recommended you visit an INFINITI retailer for this
service.
WARNING•Your brake system may not be working properly if the warning light is on. Driving could be dangerous. If you judge it to be safe,
drive carefully to the nearest service station for repairs. Otherwise, have your vehicle towed because driving it could be
dangerous.
•Pressing the brake pedal with the engine stopped and/or low brake fluid level may increase your stopping distance and braking
will require greater pedal effort as well as pedal travel.
•If the brake fluid level is below the minimum or MIN mark on the brake fluid reservoir, do not drive until the brake system has
been checked. It is recommended you visit an INFINITI retailer for this service.
[Check Brake Pad Wear]The brake pads/linings have reached their wear limit.
It is recommended you visit an INFINITI retailer.
2-36Instruments and controls
