Page 2239 of 3419
GW-84
REAR WINDOW DEFOGGER
Revision: October 20052005 QX56
CONSULT-II Function (BCM)EIS005YU
CONSULT-II can display each diagnostic item using the diagnostic test modes shown following.
CONSULT-II BASIC OPERATION PROCEDURE
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carry out CAN communication.
1. Turn ignition switch OFF.
2. Connect CONSULT-II and CONSULT-II CONVERTER to data
link connector.
3. Turn ignition switch ON.
4. Touch “START (NISSAN BASED VHCL)”.
5. Touch “BCM”.
If “BCM” is not indicated, go to GI-39, "
CONSULT-II Data Link
Connector (DLC) Circuit" .
BCM diagnostic
test itemDiagnostic mode Content
Inspection by partWORK SUPPORT Changes setting of each function.
DATA MONITOR Displays BCM input/output data in real time.
ACTIVE TEST Operation of electrical loads can be checked by sending drive signal to them.
SELF-DIAG RESULTS Displays BCM self-diagnosis results.
CAN DIAG SUPPORT MNTR The results of transmit/receive diagnosis of CAN communication can be read.
ECU PART NUMBER BCM part number can be read.
CONFIGURATION Performs BCM configuration read/write functions.
BBIA0369E
BCIA0029E
BCIA0030E
Page 2249 of 3419
GW-94
REAR WINDOW DEFOGGER
Revision: October 20052005 QX56
3. CHECK DOOR MIRROR DEFOGGER
Check continuity between door mirror RH terminals 10 and 11.
OK or NG
OK >> Repair or replace harness.
NG >> Replace door mirror RH. Refer to GW-97, "
Door Mirror
Assembly" .
Rear Window Defogger Signal CheckEIS005Z3
1. CHECK AV COMMUNICATION LINE
AV communication line check is executed. Refer to BCS-8, "
CAN Communication System Description" .
OK or NG
OK >> GO TO 2.
NG >> Replace display control unit. Refer to AV- 1 5 8 , "
Removal and Installation of Display Unit" .
2. CHECK CAN COMMUNICATION LINE
CAN communication line check is executed. Refer to LAN-5, "
CAN COMMUNICATION" .
OK or NG
OK >> Check the condition of the harness and the connector.
NG >> In addition, it is necessary to check CAN communication line. Refer to LAN-5, "
CAN COMMUNI-
CATION" .
Filament CheckEIS005Z4
1. When measuring voltage, wrap tin foil around the top of the neg-
ative probe.Then press the foil against the wire with your finger.
2. Attach probe circuit tester (in Volt range) to middle portion of
each filament.10 - 11 : Continuity should exist.
LIIA2305E
Is rear window defogger displayed on the display?
SEL122R
SEL263
Page 2260 of 3419
IDX-7
A
C
D
E
F
G
H
I
J
K
L B
IDX
ALPHABETICAL INDEX
Rear bumper ....................................................... EI-15
Rear case (Transfer) .......................... TF-146, TF-179
Rear combination lamp removal and installation ... LT-
122
Rear cover packing replacement diff. .............. RFD-24
Rear door ........................................... BL-128, GW-71
Rear seat ......................................................... SE-104
Rear seat belt ...................................................... SB-6
Rear suspension ............................................. RSU-25
Rear view monitor ............................................... DI-71
Rear washer .................................................... WW-35
Rear window defogger ..................................... GW-77
Rear wiper ....................................................... WW-35
Refrigerant connection precaution .................... ATC-7
Refrigerant discharging evacuating charging ATC-175
Refrigerant general precaution .......................... ATC-6
Refrigerant lines ........... ATC-175, ATC-183, ATC-184
Refrigerant pressure sensor ............ EC-643, ATC-185
Relay box .......................................................... PG-78
Remote keyless entry system ............................ BL-44
Removal and installation (A/T) ........... AT-244, AT-247
Removal and installation (Transfer) ................. TF-143
Revolution sensor (A/T) ................................... AT-108
Ring gear diff. inspection ................................. RFD-13
Road wheel size ................................................. GI-49
Rocker cover ..................................................... EM-33
Room lamp ....................................................... LT-129
Room lamp - See Interior lamp ........................ LT-129
ROOM/L - Wiring diagram ................................ LT-135
RP/SEN - Wiring diagram ............................... EC-644
S
SAE J1979 - Service $01 - 09 ........................... EC-48
Seat belt inspection ............................... SB-10, MA-32
Seat belt pre-tensioner .................................... SRS-58
Seat belt, front ..................................................... SB-3
Seat belt, rear ...................................................... SB-6
Seat, front .......................................................... SE-97
Seat, rear ........................................................ SE-104
Self-diagnosis (Transfer) .................................... TF-50
SEN/PW - Wiring diagram ............................... EC-455
SHIFT - Wiring diagram ................................... AT-223
Shift control (Transfer) ....................... TF-147, TF-174
Shift lock system .............................................. AT-222
Shock absorber (front) .................................... FSU-10
Shock absorber (rear) ..................................... RSU-34
Side air bag (satellite) sensor .......................... SRS-57
Side bearing preload diff. ................................ RFD-19
Side curtain air bag ......................................... SRS-54
Side trim .............................................................. EI-35
SMJ (super multiple junction) ............................ PG-74
SONAR - Wiring diagram .................................... DI-61
Spare tire size .................................................... GI-49
Spark plug ......................................................... EM-27
Spark plug replacement .................................... MA-18
Specification value .......................................... EC-146
Speedometer ......................................................... DI-5
Spiral cable ..................................................... SRS-48
SROOF - Wiring diagram .................................. RF-13
SRS - See Supplemental Restraint System ...... SRS-5
SRS - Wiring diagram ...................................... SRS-12
SRS Trouble diagnoses ..................................... SRS-8
Stabilizer bar (front) ......................................... FSU-12
Stabilizer bar (rear) ......................................... RSU-41
Stall test (A/T) .................................................... AT-50
Standardized relay ............................................. PG-72
START - Wiring diagram ................................... SC-11
Starting system .................................................. SC-10
Steering gear, linkage and transfer gear inspection .....
MA-29
Steering linkage ................................................. PS-15
Steering wheel and column ................................. PS-7
Step lamp ......................................................... LT-130
Stop lamp ......................................................... LT-103
Stop lamp switch ................. EC-569, EC-586, EC-657
STOP/L - Wiring diagram ................................. LT-104
Strut (front) ...................................................... FSU-10
Sub-oil pump (Transfer) ...................... TF-152, TF-165
Sun gear (Transfer) ............................ TF-147, TF-174
Sun roof, electric ................................................ RF-10
Sunload sensor .............................................. ATC-143
Sunroof .............................................................. RF-23
Supplemental Restraint System ........................ SRS-5
Supplemental restraint system - Wiring diagram . SRS-
12
Symbols and abbreviations ..................... GI-10, GI-22
Symptom matrix chart ...................................... EC-104
System readiness test (SRT) code .................... EC-54
T
Tachometer .......................................................... DI-5
Tail lamp ........................................................... LT-108
TAIL/L - Wiring diagram .................................... LT-110
TCM circuit diagram .......................................... AT-49
TCM inspection table ......................................... AT-82
TCS - Wiring diagram ..................................... BRC-16
TCS (traction control system) ........................... BRC-7
TCS component parts and connector location BRC-14
TCS wheel sensors ........................................ BRC-14
Theft warning system - See Vehicle security (Theft warn-
ing) system ......................................................... BL-75
Thermometer ...................................................... DI-26
Three way catalyst ............................................. EM-19
Three way catalyst function (Bank 1) .............. EC-298
Three way catalyst function (Bank 2) .............. EC-298
Three way catalyst precautions ............................ GI-5
Throttle control motor ...................................... EC-410
Throttle control motor relay .............................. EC-405
Throttle position sensor (TPS) ... EC-201, EC-264, EC-
450, EC-452, EC-604
Throttle valve closed position learning .............. EC-90
Tie-rod ............................................................... PS-15
Timing chain ...................................................... EM-35
Tire rotation ....................................................... MA-28
Tire size .............................................................. GI-49
Tooth contact diff. ............................................ RFD-20
Page 2261 of 3419
IDX-8
ALPHABETICAL INDEX
Torque converter installation AT-245, AT-246, AT-248,
AT-249
Torque convertor clutch solenoid valve ... AT-115, AT-
117
Tow truck towing ................................................. GI-42
Towing point ....................................................... GI-43
TPS1 - Wiring diagram .................................... EC-266
TPS2 - Wiring diagram .................................... EC-203
TPS3 - Wiring diagram .................................... EC-606
Traction control system - Wiring diagram ....... BRC-16
Transfer control device ............. TF-76, TF-80, TF-138
Transfer control unit inspection table ................. TF-36
Transfer dropping resistor .................................. TF-90
Transfer fluid temperature sensor TF-104, TF-152, TF-
165
Transfer motor .................................... TF-102, TF-140
Transfer motor relay ........................................ TF-102
Transfer oil replacement ................................... MA-24
Transfer serial number ........................................ GI-48
Transmission serial number ................................ GI-48
Tread-FR&RR (Dimensions) ............................... GI-49
Trim ..................................................................... EI-35
TRNSCV - Wiring diagram .................. BL-140, BL-156
Trouble diagnoses .............................................. GI-11
Turbine revolution sensor ................................ AT-131
TURN - Wiring diagram ...................................... LT-83
Turn signal lamp ................................................. LT-80
Two trip detection logic ...................................... EC-48
Two-pole lift ........................................................ GI-41
V
Vacuum hose (brake system) ............................ BR-19
Vacuum hose drawing (Engine control) ........... EC-114
Valve clearance ................................................ EM-51
Valve guide ....................................................... EM-65
Vanity mirror lamp ............................................. LT-129
VDC (vehicle dynamics control) ........................ BRC-7
VDC -Wiring diagram ...................................... BRC-16
Vehicle identification number .............................. GI-47
Vehicle recovery (freeing a stuck vehicle) .......... GI-43
Vehicle security (theft warning) system ............. BL-75
Vehicle speed sensor (VSS) ............................ EC-372
VEHSEC - Wiring diagram ................................. BL-79
VENT/V - Wiring diagram .................. EC-327, EC-541
Video Monitor ..................................................... AV-60
VIN registration .................................................. EC-90
Viscosity number (SAE) .................................... MA-12
W
W/ANT - Wiring diagram .................................... AV-49
Wait detection switch ......................................... TF-69
WARN - Wiring diagram ..................................... DI-31
Warning chime .................................................... DI-42
Warning lamps .................................................... DI-30
Washer, front ..................................................... WW-4
Washer, rear .................................................... WW-35
Water pump ...................................................... CO-17
Water temperature gauge ..................................... DI-5
Wheel alignment (front) ..................................... FSU-6
Wheel alignment (rear) ................................... RSU-27
Wheel bearing (front) ........................................ FAX-5
Wheel bearing (rear) ......................................... RAX-5
Wheel hub (rear) ............................................... RAX-5
Wheel size .......................................................... GI-49
Wheelbase (Dimensions) .................................... GI-49
Width (Dimensions) ............................................. GI-49
WINDOW - Wiring diagram .............................. GW-22
Window, door ...................................... GW-68, GW-71
Windshield ....................................................... GW-11
WIP/R - Wiring diagram ................................... WW-39
WIPER - Wiring diagram .................................. WW-11
Wiper, front ........................................................ WW-4
Wiper, rear ....................................................... WW-35
Wiring Diagram (Cell code) list ......................... PG-60
Wiring diagrams .................................................. GI-15
WT-T/WARN - Wiring diagram .......................... WT-11
Page 2266 of 3419
SQUEAK AND RATTLE TROUBLE DIAGNOSIS
IP-5
C
D
E
F
G
H
J
K
L
MA
B
IP
Revision: October 20052005 QX56
DUPLICATE THE NOISE AND TEST DRIVE
If possible, drive the vehicle with the customer until the noise is duplicated. Note any additional information on
the Diagnostic Worksheet regarding the conditions or location of the noise. This information can be used to
duplicate the same conditions when you confirm the repair.
If the noise can be duplicated easily during the test drive, to help identify the source of the noise, try to dupli-
cate the noise with the vehicle stopped by doing one or all of the following:
1. Close a door.
2. Tap or push/pull around the area where the noise appears to be coming from.
3. Rev the engine.
4. Use a floor jack to recreate vehicle “twist”.
5. At idle, apply engine load (electrical load, drive position on A/T model).
6. Raise the vehicle on a hoist and hit a tire with a rubber hammer.
Drive the vehicle and attempt to duplicate the conditions the customer states exist when the noise occurs.
If it is difficult to duplicate the noise, drive the vehicle slowly on an undulating or rough road to stress the
vehicle body.
CHECK RELATED SERVICE BULLETINS
After verifying the customer concern or symptom, check ASIST for Technical Service Bulletins (TSBs) related
to that concern or symptom.
If a TSB relates to the symptom, follow the procedure to repair the noise.
LOCATE THE NOISE AND IDENTIFY THE ROOT CAUSE
1. Narrow down the noise to a general area. To help pinpoint the source of the noise, use a listening tool
(Chassis Ear: J-39570, Engine Ear: J-39565 and mechanics stethoscope).
2. Narrow down the noise to a more specific area and identify the cause of the noise by:
Removing the components in the area that you suspect the noise is coming from.
Do not use too much force when removing clips and fasteners, otherwise clips and fasteners
can be broken or lost during the repair, resulting in the creation of new noise.
Tapping or pushing/pulling the component that you suspect is causing the noise.
Do not tap or push/pull the component with excessive force, otherwise the noise will be elimi-
nated only temporarily.
Feeling for a vibration with your hand by touching the component(s) that you suspect is (are) causing
the noise.
Placing a piece of paper between components that you suspect are causing the noise.
Looking for loose components and contact marks.
Refer to IP-6, "
Generic Squeak and Rattle Troubleshooting" .
REPAIR THE CAUSE
If the cause is a loose component, tighten the component securely.
If the cause is insufficient clearance between components:
–Separate components by repositioning or loosening and retightening the component, if possible.
–Insulate components with a suitable insulator such as urethane pads, foam blocks, felt cloth tape or ure-
thane tape. A NISSAN Squeak and Rattle Kit (J-43980) is available through your authorized NISSAN
Parts Department.
CAUTION:
Do not use excessive force as many components are constructed of plastic and may be damaged.
Always check with the Parts Department for the latest parts information.
The following materials are contained in the NISSAN Squeak and Rattle Kit (J-43980). Each item can be
ordered separately as needed.
URETHANE PADS [1.5 mm (0.059 in) thick]
Insulates connectors, harness, etc.
76268-9E005: 100 x 135 mm (3.94 x 5.31 in)/76884-71L01: 60 x 85 mm (2.36 x 3.35 in)/76884-71L02: 15 x 25
mm (0.59 x 0.98 in)
INSULATOR (Foam blocks)
Insulates components from contact. Can be used to fill space behind a panel.
Page 2268 of 3419
SQUEAK AND RATTLE TROUBLE DIAGNOSIS
IP-7
C
D
E
F
G
H
J
K
L
MA
B
IP
Revision: October 20052005 QX56
Tapping or moving the components or pressing on them while driving to duplicate the conditions can isolate
many of these incidents. You can usually insulate the areas with felt cloth tape or insulator foam blocks from
the NISSAN Squeak and Rattle Kit (J-43980) to repair the noise.
TRUNK
Trunk noises are often caused by a loose jack or loose items put into the trunk by the owner.
In addition look for:
1. Trunk lid bumpers out of adjustment
2. Trunk lid striker out of adjustment
3. The trunk lid torsion bars knocking together
4. A loose license plate or bracket
Most of these incidents can be repaired by adjusting, securing or insulating the item(s) or component(s) caus-
ing the noise.
SUNROOF/HEADLINING
Noises in the sunroof/headlining area can often be traced to one of the following:
1. Sunroof lid, rail, linkage or seals making a rattle or light knocking noise
2. Sun visor shaft shaking in the holder
3. Front or rear windshield touching headliner and squeaking
Again, pressing on the components to stop the noise while duplicating the conditions can isolate most of these
incidents. Repairs usually consist of insulating with felt cloth tape.
OVERHEAD CONSOLE (FRONT AND REAR)
Overhead console noises are often caused by the console panel clips not being engaged correctly. Most of
these incidents are repaired by pushing up on the console at the clip locations until the clips engage.
In addition look for:
1. Loose harness or harness connectors.
2. Front console map/reading lamp lens loose.
3. Loose screws at console attachment points.
SEATS
When isolating seat noise it's important to note the position the seat is in and the load placed on the seat when
the noise is present. These conditions should be duplicated when verifying and isolating the cause of the
noise.
Cause of seat noise include:
1. Headrest rods and holder
2. A squeak between the seat pad cushion and frame
3. The rearseat back lock and bracket
These noises can be isolated by moving or pressing on the suspected components while duplicating the con-
ditions under which the noise occurs. Most of these incidents can be repaired by repositioning the component
or applying urethane tape to the contact area.
UNDERHOOD
Some interior noise may be caused by components under the hood or on the engine wall. The noise is then
transmitted into the passenger compartment.
Causes of transmitted underhood noise include:
1. Any component mounted to the engine wall
2. Components that pass through the engine wall
3. Engine wall mounts and connectors
4. Loose radiator mounting pins
5. Hood bumpers out of adjustment
6. Hood striker out of adjustment
These noises can be difficult to isolate since they cannot be reached from the interior of the vehicle. The best
method is to secure, move or insulate one component at a time and test drive the vehicle. Also, engine RPM
or load can be changed to isolate the noise. Repairs can usually be made by moving, adjusting, securing, or
insulating the component causing the noise.
Page 2448 of 3419
LT-1
LIGHTING SYSTEM
K ELECTRICAL
CONTENTS
C
D
E
F
G
H
I
J
L
M
SECTION LT
A
B
LT
Revision: October 20052005 QX56 PRECAUTIONS .......................................................... 4
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 4
General precautions for service operations ............. 4
Wiring Diagrams and Trouble Diagnosis .................. 4
HEADLAMP (FOR USA) ............................................ 6
Component Parts and Harness Connector Location ..... 6
System Description .................................................. 6
OUTLINE ............................................................... 6
XENON HEADLAMP ............................................. 7
BATTERY SAVER CONTROL .............................. 8
AUTO LIGHT OPERATION ................................... 8
VEHICLE SECURITY SYSTEM (PANIC ALARM) ..... 8
CAN Communication System Description ................ 8
Schematic ................................................................ 9
Wiring Diagram — H/LAMP — ............................... 10
Terminals and Reference Values for BCM ............. 14
Terminals and Reference Values for IPDM E/R ..... 15
How to Proceed With Trouble Diagnosis ................ 15
Preliminary Check .................................................. 15
CHECK POWER SUPPLY AND GROUND CIR-
CUIT .................................................................... 15
CONSULT-II Function (BCM) ................................. 17
CONSULT-II OPERATION .................................. 17
WORK SUPPORT ............................................... 18
DATA MONITOR ................................................. 18
ACTIVE TEST ..................................................... 19
SELF-DIAGNOSTIC RESULTS .......................... 19
CONSULT-II Function (IPDM E/R) ......................... 20
CONSULT-II OPERATION .................................. 20
DATA MONITOR ................................................. 21
ACTIVE TEST ..................................................... 21
Headlamp HI Does Not Illuminate (Both Sides) ..... 22
Headlamp HI Does Not Illuminate (One Side) ....... 24
High Beam Indicator Lamp Does Not Illuminate .... 25
Headlamp LO Does Not Illuminate (Both Sides) .... 25
Headlamp LO Does Not Illuminate (One Side) ...... 27
Headlamps Do Not Turn OFF ................................ 28
Aiming Adjustment ................................................. 30LOW BEAM AND HIGH BEAM ........................... 30
Bulb Replacement .................................................. 31
HEADLAMP (OUTER SIDE), FOR LOW BEAM ... 31
HEADLAMP (INNER SIDE), FOR HIGH BEAM ... 31
FRONT PARKING LAMP (INNER OR OUTER) ... 31
FRONT SIDE MARKER LAMP ........................... 31
Removal and Installation ........................................ 32
REMOVAL ........................................................... 32
INSTALLATION ................................................... 32
Disassembly and Assembly .................................... 32
HEADLAMP (FOR CANADA) - DAYTIME LIGHT
SYSTEM - .................................................................. 33
Component Parts and Harness Connector Location ... 33
System Description ................................................. 34
OUTLINE ............................................................. 34
DAYTIME LIGHT OPERATION ........................... 34
COMBINATION SWITCH READING FUNCTION ... 34
AUTO LIGHT OPERATION ................................. 35
CAN Communication System Description .............. 35
Schematic ............................................................... 36
Wiring Diagram — DTRL — ................................... 37
Terminals and Reference Values for BCM .............. 41
How to Proceed With Trouble Diagnosis ................ 42
Preliminary Check .................................................. 42
CHECK BCM CONFIGURATION ........................ 42
INSPECTION FOR POWER SUPPLY AND
GROUND CIRCUIT ............................................. 42
INSPECTION PARKING BRAKE SWITCH CIR-
CUIT .................................................................... 43
CONSULT-II Functions ........................................... 44
Daytime Light Control Does Not Operate Properly
(Normal Headlamps Operate Properly) .................. 44
Aiming Adjustment .................................................. 46
Bulb Replacement .................................................. 46
Removal and Installation ........................................ 46
Disassembly and Assembly .................................... 46
AUTO LIGHT SYSTEM ............................................. 47
Component Parts and Harness Connector Location ... 47
System Description ................................................. 48
OUTLINE ............................................................. 48
Page 2455 of 3419
LT-8
HEADLAMP (FOR USA)
Revision: October 20052005 QX56
Power consumption is approximately 25 percent less than halogen headlamps, reducing battery load.
BATTERY SAVER CONTROL
When the combination switch (lighting switch) is in the 2ND position (ON), and the ignition switch is turned
from ON or ACC to OFF, the battery saver control feature is activated.
Under this condition, the headlamps remain illuminated for 5 minutes, unless the combination switch (lighting
switch) position is changed. If the combination switch (lighting switch) position is changed, then the headlamps
are turned off.
AUTO LIGHT OPERATION
Refer to LT- 4 8 , "System Description" for auto light operation.
VEHICLE SECURITY SYSTEM (PANIC ALARM)
The vehicle security system (panic alarm) will flash the high beams if the system is triggered. Refer to BL-48,
"Panic Alarm Operation" .
CAN Communication System DescriptionEKS00B7U
Refer to LAN-5, "CAN COMMUNICATION" .
Page 2464 of 3419
HEADLAMP (FOR USA)
LT-17
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: October 20052005 QX56
CONSULT-II Function (BCM)EKS00B81
CONSULT-II can display each diagnostic item using the diagnostic test modes shown following.
CONSULT-II OPERATION
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carries out CAN communication.
1. With the ignition switch OFF, connect CONSULT-II and CON-
SULT-II CONVERTER to the data link connector, then turn igni-
tion switch ON.
2. Touch "START (NISSAN BASED VHCL)".
3. Touch "BCM" on "SELECT SYSTEM" screen.
If "BCM" is not indicated, go to GI-39, "
CONSULT-II Data Link
Connector (DLC) Circuit" .
BCM diagnostic
test itemDiagnostic mode Description
Inspection by partWORK SUPPORTSupports inspections and adjustments. Commands are transmitted to the BCM
for setting the status suitable for required operation, input/output signals are
received from the BCM and received data is displayed.
DATA MONITOR Displays BCM input/output data in real time.
ACTIVE TEST Operation of electrical loads can be checked by sending drive signal to them.
SELF-DIAG RESULTS Displays BCM self-diagnosis results.
CAN DIAG SUPPORT MNTR The result of transmit/receive diagnosis of CAN communication can be read.
ECU PART NUMBER BCM part number can be read.
CONFIGURATION Performs BCM configuration read/write functions.
BBIA0369E
BCIA0029E
BCIA0030E
Page 2479 of 3419
LT-32
HEADLAMP (FOR USA)
Revision: October 20052005 QX56
Installation is in the reverse order of removal.
CAUTION:
After installing the bulb, be sure to install the bulb socket securely to ensure watertightness.
Do not touch the glass of bulb directly by hand. Keep grease and other oily substances away from
it. Do not touch bulb by hand while it is lit or right after being turned off. Burning may result.
Do not leave bulb out of headlamp assembly for a long time because dust, moisture, smoke, etc.
may affect the performance of the lamp. When replacing bulb, be sure to replace it with a new one.
Removal and InstallationEKS00B8B
REMOVAL
1. Remove the front bumper. Refer to EI-13, "Removal and Installation" .
2. Disconnect the connector.
3. Remove the 5 headlamp mounting bolts.
INSTALLATION
Installation is in the reverse order of removal.
Disassembly and AssemblyEKS00B8C
WKIA1860E
: 6.0 N·m (0.61 kg-m, 53 in-lb)
WKIA1861E
1. Parking lamp bulb (Outer) 2. Parking lamp bulb (Inner) 3. Headlamp bulb (High beam)
4. Headlamp assembly 5. Xenon bulb (Low beam) 6. Side marker lamp bulb
7. Ballast 8. Wiring harness assembly
