INFINITI QX4 2005 Factory Service Manual

GI-40
LIFTING POINT
Revision: October 20052005 QX56
LIFTING POINTPFP:00000
Pantograph JackEAS001FV
WAR NIN G:

Never get under the vehicle while it is supported only by the jack. Always use safety stands to
support the frame when you have to get under the vehicle.

Place wheel chocks at both front and back of the wheels on the ground.
Garage Jack and Safety StandEAS001FW
CAUTION:
Place a wooden or rubber block between safety stand and vehicle body when the supporting body is
flat.
LAIA0042E
WAIA0028E

LIFTING POINT
GI-41
C
D
E
F
G
H
I
J
K
L
MB
GI
Revision: October 20052005 QX56
2-Pole LiftEAS001FX
WA RN ING:

When lifting the vehicle, open the lift arms as wide as possible and ensure that the front and rear
of the vehicle are well balanced.

When setting the lift arm, do not allow the arm to contact the brake tubes, brake cable, or fuel
lines.
WAIA0029E

GI-42
TOW TRUCK TOWING
Revision: October 20052005 QX56
TOW TRUCK TOWINGPFP:00000
To w Tr u c k To w i n gEAS001FY
WAR NIN G:

Never get under the vehicle while it is supported only by the jack. Always use safety stands to
support the frame when you have to get under the vehicle.

Place wheel chocks at both front and back of the wheels on the ground.
CAUTION:

All applicable State or Provincial (in Canada) laws and local laws regarding the towing operation
must be obeyed.

It is necessary to use proper towing equipment to avoid possible damage during towing opera-
tion. Towing is in accordance with Towing Procedure Manual at dealer.

Always attach safety chains before towing.

When towing, make sure that the transmission, steering system and powertrain are in good order.
If any unit is damaged, dollies must be used.

Never tow an automatic transmission model from the rear
(i.e., backward) with four wheels on the ground as this may
cause serious and expensive damage to the transmission.
2WD MODELS
NISSAN does not recommend towing automatic transmission
equipped vehicles with the drive wheels on the ground.
CAUTION:

When towing with the front wheels on the ground: Turn the
ignition key to the OFF position and move the transmission
selector lever to N (neutral) position, turn the ignition key to
OFF position and secure the steering wheel in a straight
ahead position with a rope or similar device. Never place
the ignition key in the LOCK position. This will result in
damage to the steering lock mechanism.
WAIA0030E
WAIA0031E

TOW TRUCK TOWING
GI-43
C
D
E
F
G
H
I
J
K
L
MB
GI
Revision: October 20052005 QX56
4WD MODELS
NISSAN does not recommend towing automatic transmission
equipped vehicles with the drive wheels on the ground.
CAUTION:

When towing with the front wheels on the ground or rear
wheels on the ground (If you do not use towing dollies): Set
the free-running hubs to the free position and move the
transfer case shift lever into the “2H” position.

When towing with the front on the ground: Turn the ignition
key to the OFF position and secure the steering wheel in a
straight ahead position with a rope or similar device. Never
place the ignition key in the LOCK position. This will result
in damage to the steering lock mechanism.
Towing Point
CAUTION:
Never tow the vehicle using only the towing points. To avoid
damaging the vehicle body, use proper towing equipment when
towing.
Vehicle Recovery (Freeing a stuck vehicle)EAS001FZ

Tow chains or cables must be attached only to the main structural members of the vehicle or the
towing hooks (if so equipped). Otherwise, the vehicle body will be damaged.

Use the towing hook (if so equipped) only to free a vehicle stuck in sand, snow, mud, etc. Never
tow the vehicle for a long distance using only the towing hook.

The towing hook is under tremendous force when used to free a stuck vehicle. Never pull the hook
at an angle.

Always pull the cable straight out from the front or rear of the vehicle.

Pulling devices should be routed so they do not touch any part of the suspension, steering, brake,
or cooling systems.

Pulling devices such as ropes or canvas straps are not recommended for use in vehicle towing or
recovery.
WA RN ING:

Stand clear of a stuck vehicle.

Do not spin your tires at high speed. This could cause them to explode and result in serious injury.
Parts of your vehicle could also overheat and be damaged.
WAIA0032E
WAIA0055E

GI-44
TIGHTENING TORQUE OF STANDARD BOLTS
Revision: October 20052005 QX56
TIGHTENING TORQUE OF STANDARD BOLTSPFP:00000
Tightening Torque Table EAS001G0
*: Nominal diameter
1.Special parts are excluded.
2.This standard is applicable to bolts having the following marks embossed on the bolt head. Grade Bolt sizeBolt diam-
eter *
mmPitch
mmTightening torque (Without lubricant)
Hexagon head bolt Hexagon flange bolt
N·m kg-m ft-lb in-lb N·m kg-m ft-lb in-lb
4TM6 6.0 1.0 5.1 0.52 3.8 45.1 6.1 0.62 4.5 53.8
M8 8.01.25 13 1.3 9 — 15 1.5 11 —
1.0 13 1.3 9 — 16 1.6 12 —
M10 10.01.5 25 2.5 18 — 29 3.0 22 —
1.25 25 2.6 19 — 30 3.1 22 —
M12 12.01.75 42 4.3 31 — 51 5.2 38 —
1.25 46 4.7 34 — 56 5.7 41 —
M14 14.0 1.5 74 7.5 54 — 88 9.0 65 —
7TM6 6.0 1.0 8.4 0.86 6.2 74.6 10 1.0 7 87
M8 8.01.25 21 2.1 15 — 25 2.5 18 —
1.0 22 2.2 16 — 26 2.7 20 —
M10 10.01.5 41 4.2 30 — 48 4.9 35 —
1.25 43 4.4 32 — 51 5.2 38 —
M12 12.01.75 71 7.2 52 — 84 8.6 62 —
1.25 77 7.9 57 — 92 9.4 68 —
M14 14.0 1.5 127 13.0 94 — 147 15.0 108 —
9TM6 6.0 1.0 12 1.2 9 — 15 1.5 11 —
M8 8.01.25 29 3.0 22 — 35 3.6 26 —
1.0 31 3.2 23 — 37 3.8 27 —
M10 10.01.5 59 6.0 43 — 70 7.1 51 —
1.25 62 6.3 46 — 74 7.5 54 —
M12 12.01.75 98 10.0 72 — 118 12.0 87 —
1.25 108 11.0 80 — 137 14.0 101 —
M14 14.0 1.5 177 18.0 130 — 206 21.0 152 —
MGI044A

RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS
GI-45
C
D
E
F
G
H
I
J
K
L
MB
GI
Revision: October 20052005 QX56
RECOMMENDED CHEMICAL PRODUCTS AND SEALANTSPFP:00000
Recommended Chemical Products and SealantsEAS001G1
Refer to the following chart for help in selecting the appropriate chemical product or sealant.
Product Description PurposeNissan North America
Part No. (USA)Nissan Canada Part
No. (Canada)Aftermarket Cross-
reference Part Nos.
1Rear View Mirror
AdhesiveUsed to permanently
remount rear view mirrors
to windows.999MP-AM000P 99998-50505 Permatex 81844
2Anaerobic Liquid Gas-
ketFor metal-to-metal flange
sealing.
Can fill a 0.38 mm (0.015
inch) gap and provide
instant sealing for most
powertrain applications.999MP-AM001P 99998-50503Permatex 51813 and
51817
3High Performance
Thread SealantProvides instant sealing on
any threaded straight or
parallel threaded fitting.
(Thread sealant only, no
locking ability.)

Do not use on plastic.999MP-AM002P 999MP-AM002P Permatex 56521
4 Silicone RTVGasket Maker999MP-AM003P
(Ultra Grey)99998-50506
(Ultra Grey)Permatex Ultra Grey
82194;
Three Bond
1207,1215, 1216,
1217F and 1217G;
Nissan RTV Part No.
999MP-A7007
Gasket Maker for Maxima/
Quest 5-speed automatic
transmission
(RE5F22A)––Three Bond 1281B
or exact equivalent
in its quality
5High Temperature,
High Strength Thread
Locking Sealant (Red)Threadlocker 999MP-AM004P 999MP-AM004PPermatex 27200;
Three Bond 1360,
1360N, 1305 N&P,
1307N, 1335,
1335B, 1363B,
1377C, 1386B, D&E
and 1388
6Medium Strength
Thread Locking Seal-
ant (Blue)Threadlocker (service tool
removable)999MP-AM005P 999MP-AM005PPermatex 24200,
24206, 24240,
24283 and 09178;
Three Bond 1322,
1322N, 1324 D&N,
1333D, 1361C,
1364D, 1370C and
1374

GI-46
IDENTIFICATION INFORMATION
Revision: October 20052005 QX56
IDENTIFICATION INFORMATIONPFP:00010
Model VariationEAS001G2
Prefix and suffix designations:
Position Character Qualifier Definition
1 J Body type J: Wagon
2
PK Engine PK: VK56DE
3
4AAxleA: 2WD
W: 4WD
5LDrive L: LH
6VGradeV: LE
7 K Transmission K: RE5R05A (5A/T)
8
I40 Model I40: 2005 QX56 9
10
11 E Intake E: Multiport fuel injection system engine
12 U ZoneN: Canada
U: USA
13 A Equipment A: Standard
14
XXXXX Option Codes Option Codes 15
16
17
18
Drive Type Body Engine Transmission Destination Grade Model
2WD Wagon VK56DE RE5R05A (5A/T) U.S.A. LE JPKALVK-EUA
4WD Wagon VK56DE RE5R05A (5A/T)U.S.A.
LEJPKWLVK-EUA
Canada JPKWLVK-ENA

IDENTIFICATION INFORMATION
GI-47
C
D
E
F
G
H
I
J
K
L
MB
GI
Revision: October 20052005 QX56
Identification NumberEAS001G3
VEHICLE IDENTIFICATION NUMBER ARRANGEMENT
1. Emission control information label 2. Tire placard 3. F.M.V.S.S. certification label
4. Vehicle identification number plate 5. Vacuum hose diagram
WAIA0053E
Position Character Qualifier Definition
1
5N3 Manufacturer 5N3: USA produced multi-purpose vehicle 2
3
4 A Engine type A: VK56DE
5 A Vehicle line A: Infiniti QX56
6 0 Model change (0-9)
7 8 Body type 8: 4 door wagon
8AGross vehicle
weight ratingA: 2WD, 4-wheel ABS, Class E
B: 4WD, 4-wheel ABS, Class E
9 * Check digit(0 to 9 or X) The code for the check digit is determined by a mathematical
computation.
10 5 Model year 2005
11 NManufacturing
plantN: Canton Mississippi
12
XXXXXVehicle serial num-
berChassis number 13
14
15
16
17

GI-48
IDENTIFICATION INFORMATION
Revision: October 20052005 QX56
ENGINE SERIAL NUMBER
TRANSFER SERIAL NUMBER
AUTOMATIC TRANSMISSION NUMBER
LAIA0044E
LAIA0048E
PAIA0054E

IDENTIFICATION INFORMATION
GI-49
C
D
E
F
G
H
I
J
K
L
MB
GI
Revision: October 20052005 QX56
DimensionsEAS001G4
Unit: mm (in)
Wheels & TiresEAS001G5
Drive type4x2 4x4
Overall length 5255 (206.9) 5255 (206.9)
Overall width 2001 (78.8) 2001 (78.8)
Overall height (with roof rack) 1976.8 (77.8) 1997.7 (78.7)
Front tread width 1725 (67.9) 1725 (67.9)
Rear tread width 1725 (67.9) 1725 (67.9)
Wheelbase 3130 (123.2) 3130 (123.2)
Minimum Running Ground Clearance (at front sus-
pension)With standard
undercover254.8 (10.03) 273.7 (10.77)
With oil pan skid
plate250.5 (9.86) 269.5 (10.61)
Drive Type Grade Road wheel Tire Spare tire size
All LE7-Spoke 18x8J Chromium Aluminum
AlloyP265/70R18 P265/70R18
