Rear Oil SealECS00CKY
REMOVAL AND INSTALLATION
Removal
1. Remove rear propeller shaft. Refer to PR-5, "REMOVAL" .
2. Remove transfer from transmission (4WD models). Refer to TF-
143, "REMOVAL" .
3. Remove rear oil seal using a flat-bladed screwdriver or suitable
tool.
CAUTION:
Be careful not to scratch rear extension assembly (2WD
models) or adapter case assembly (4WD models).
Installation
CAUTION:
After completing installation, check for A/T fluid leakage and fluid level. Refer to MA-24, "
Changing A/
T Fluid" , MA-22, "Checking A/T Fluid" .
1. Install new rear oil seal into the extension case (2WD models) or
adapter case (4WD models) until it is flush with component face,
using Tool or suitable drift.
CAUTION:

Apply ATF to rear oil seal.

Do not reuse rear oil seal.
2. Install transfer to transmission (4WD models). Refer to TF-143,
"INSTALLATION" .
3. Install rear propeller shaft. Refer to PR-9, "
INSTALLATION"
SCIA5254E
SCIA5583E

TRANSMISSION ASSEMBLY
AT-245
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: October 20052005 QX56
8. Remove crankshaft position sensor (POS) from A/T assembly.
9. Remove fluid cooler tube.
10. Remove dust cover from converter housing part.
11. Secure drive plate using Tool then remove drive plate to torque
converter bolts.
CAUTION:
When turning crankshaft, turn it clockwise as viewed from
the front of the engine.
NOTE:
Tool must be removed and drive plate turned to access all drive
plate to torque converter bolts.
12. Support A/T assembly with a transmission jack.
CAUTION:
When setting the transmission jack, be careful not to allow it to collide against the drain plug.
13. Remove cross member with power tool.
14. Remove air breather hose. Refer to AT-242, "
Removal and Installation" .
15. Disconnect A/T assembly connector.
16. Remove A/T fluid indicator pipe from A/T assembly.
17. Plug up openings such as the A/T fluid indicator pipe hole, etc.
18. Remove the A/T assembly to engine bolts with power tool.
19. Remove A/T assembly from vehicle using Tool and a transmis-
sion jack.
CAUTION:

Secure torque converter to prevent it from dropping.

Secure A/T assembly to a transmission jack.
INSPECTION
Installation and Inspection of Torque Converter

After inserting a torque converter to a transmission, be sure to
check dimension A to ensure it is within the reference value
limit.
LCIA0334E
Tool number : — (J-47245)
LCIA0335E
SCIA0499E
Dimension A : 24.0 mm (0.94 in) or more
SAT0 1 7B

AT-246
TRANSMISSION ASSEMBLY
Revision: October 20052005 QX56
INSTALLATION
Installation of the remaining components is in the reverse order of the removal, while paying attention to the
following:

When installing transmission to the engine, attach the bolts as shown.
NOTE:
*: No.2 bolt also secures air breather vent.

Align the positions of bolts for drive plate with those of the torque
converter, and temporarily tighten the bolts. Then, tighten the
bolts with the specified torque, using Tool to secure drive plate.
CAUTION:

When turning crankshaft, turn it clockwise as viewed from
the front of the engine.

After converter is installed to drive plate, rotate crankshaft
several turns and check to be sure that transmission
rotates freely without binding.

Install crankshaft position sensor (POS).

After completing installation, check fluid leakage, fluid level, and the positions of A/T. Refer to MA-22,
"Checking A/T Fluid" , AT - 2 2 8 , "Checking of A/T Position" , AT-228, "Adjustment of A/T Position" . Transmission to
engine bolts: 113 N·m (12 kg-m, 83 ft-lb)
LCIA0371E
Tool number : — (J-47245)
LCIA0335E

AT-248
TRANSMISSION ASSEMBLY
Revision: October 20052005 QX56
8. Remove crankshaft position sensor (POS) from A/T assembly.
9. Disconnect A/T fluid cooler tube from A/T assembly.
10. Remove dust cover from converter housing part.
11. Secure drive plate using Tool then remove drive plate to torque
converter bolts.
CAUTION:
When turning crankshaft, turn it clockwise as viewed from
the front of the engine.
NOTE:
Tool must be removed and drive plate turned to access all drive
plate to torque converter bolts.
12. Support A/T assembly with a transmission jack.
CAUTION:
When setting the transmission jack, be careful not to allow it to collide against the drain plug.
13. Remove cross member with power tool.
14. Tilt the transmission slightly to keep the clearance between body and transmission, and then disconnect
air breather hose from A/T fluid indicator pipe. Refer to AT-244, "
REMOVAL" .
15. Disconnect A/T assembly connector and transfer unit connector.
16. Remove A/T fluid indicator pipe.
17. Plug up openings such as the fluid charging pipe hole, etc.
18. Remove A/T assembly to engine bolts with power tool.
19. Remove A/T assembly with transfer from vehicle, using Tool.
CAUTION:

Secure torque converter to prevent it from dropping.

Secure A/T assembly to a transmission jack.
NOTE:
The actual special service tool may differ from tool shown.
20. Remove transfer from A/T assembly. Refer to TF-143,
"REMOVAL" .
INSPECTION
Installation and Inspection of Torque Converter

After inserting a torque converter to a transmission, be sure to
check dimension A to ensure it is within the reference value
limit.
LCIA0334E
Tool number : — (J-47245)
Tool number : — (J-47002)
LCIA0335E
SCIA2203E
Dimension A : 24.0 mm (0.94 in) or more
SAT0 1 7B

TRANSMISSION ASSEMBLY
AT-249
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: October 20052005 QX56
INSTALLATION
Installation of the remaining components is in the reverse order of removal, while paying attention to the fol-
lowing:

When installing transmission to the engine, attach the bolts as shown.
NOTE:
*: No.2 bolt also secures air breather vent.

Align the positions of bolts for drive plate with those of the torque
converter, and temporarily tighten the bolts. Then, tighten the
bolts with the specified torque, using Tool to secure drive plate.
CAUTION:

When turning crankshaft, turn it clockwise as viewed from
the front of the engine.

After converter is installed to drive plate, rotate crankshaft
several turns and check to be sure that transmission
rotates freely without binding.

Install crankshaft position sensor (POS).

After completing installation, check fluid leakage, fluid level, and the positions of A/T. Refer to MA-22,
"Checking A/T Fluid" , AT-228, "Checking of A/T Position" , AT- 2 2 8 , "Adjustment of A/T Position" . Transmission to engine
bolts: 113 N·m (12 kg-m, 83 ft-lb)
LCIA0371E
Tool number : — (J-47245)
LCIA0335E

EM-72Revision: October 2005
ENGINE ASSEMBLY
2005 QX56
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:

When replacing an engine or transmission you must make sure the dowels are installed correctly
during re-assembly.

Improper alignment caused by missing dowels may cause vibration, oil leaks or breakage of driv-
etrain components.
INSPECTION AFTER INSTALLATION

Before starting the engine, check oil/fluid levels including engine coolant and engine oil. If the levels are
lower than required quantity, fill to the specified level. Refer to MA-11, "
RECOMMENDED FLUIDS AND
LUBRICANTS" .

Use procedure below to check for fuel leakage.

Turn ignition switch ON (with engine stopped). With fuel pressure applied to the fuel piping, check for fuel
leakage at the connection points.

Start engine. With engine speed increased, check again for fuel leakage at connection points.

Run engine to check for unusual noise and vibration.

Warm up engine thoroughly to make sure there is no leakage of fuel, exhaust gas, or any oils/fluids includ-
ing engine oil and engine coolant.

Bleed air from passages in lines and hoses, such as in cooling system.

After cooling down the engine, again check oil/fluid levels including engine oil and engine coolant. Refill to
specified level if necessary.

Summary of the inspection items:
*Transmission/transaxle/CVT fluid, power steering fluid, brake fluid, etc.Item Before starting engine Engine running After engine stopped
Engine coolant Level Leakage Level
Engine oil Level Leakage Level
Other oils and fluids* Level Leakage Level
Fuel Leakage Leakage Leakage
Exhaust gas — Leakage —
