7. On the “SELF DIAGNOSIS” screen, each unit name will be col-
ored according to the diagnosis result, as follows.

If several malfunctions are present in a unit, color of its switch
on the screen will be either red, yellow, or gray, determined by
the malfunction of the highest priority.
8. Select a switch on the “SELF DIAGNOSIS” screen and com-
ments for the diagnosis results will be shown.

When the switch is green, the following comment will be
shown. “Self-diagnosis was successful. Further diagnosis and
adjustments are recommended. Follow the “confirmation/
adjustment” menu or refer to the service manual.”

When the switch is yellow, the following comment will be
shown. “Connection to the following unit is abnormal. See the
service manual for further details”.

When the switch is red, the following comment will be shown.
“DCU is abnormal”.
SELF–DIAGNOSIS RESULT
Quick reference table
1. Select a malfunctioning diagnosis No. in the diagnosis result quick reference table.
2. Find estimated malfunctioning system in the diagnosis No. table and perform check by referring to AV-87,
"Wiring Diagram — COMM —" .
3. Turn the ignition switch OFF and perform self-diagnosis again.
*: DCU = Display control unit
CAUTION:

When AV switch has a malfunction, you cannot start. Refer to AV-145, "Unable to Operate All of AV
Switches (Unable to Start Self-Diagnosis)" .

When display unit has a malfunction, you cannot start. Refer to AV-143, "Screen is Not Shown" .
Self-Diagnosis Codes
Green : Not malfunctioning.
Yellow : Cannot be judged by self-diagnosis results.
Red : Unit is malfunctioning.
Gray : Diagnosis has not been done.
WKIA1189E
SKIA4 211 E
Screen switch
Diagnosis No.
Switch color DCU* DISPLAY Audio unit NavigationGPS
antenna
Red×1
Gray×x2
xx 3
×××4
Diagnosis
No.Possible causeReference
page
1 Display control unit malfunction Refer to AV- 1 5 8
.
2 Display communication line between display control unit and display unit Refer to AV- 1 2 8
.
3Audio unit power supply and ground circuit
Audio communication line between display control unit and audio unitRefer to AV- 1 2 5
.
4NAVI control unit power supply and ground circuit
AV communication line between display control unit and NAVI control unitRefer to AV- 1 2 5
.

AV-104
NAVIGATION SYSTEM
Revision: October 20052005 QX56
Self-Diagnosis Mode (NAVI)EKS00BJR
OPERATION PROCEDURE
1. Start the engine.
2. Turn the audio system off.
3. While pressing the “PAUSE/MUTE” button, turn the volume con-
trol dial clockwise or counterclockwise for 30 clicks or more.
(When the self-diagnosis mode is started, a short beep will be
heard.)

Shifting from current screen to previous screen is performed
by pressing “PREV” button.
4. The initial self-diagnosis screen will be shown, and items “Self-
Diagnosis (DCU)”, “Self-Diagnosis (NAVI)”, “Confirmation/
Adjustment” and “CAN DIAG SUPPORT MONITOR” will
become selective.
5. Perform self-diagnosis by selecting the “Self-diagnosis (NAVI)”.

Self-diagnosis subdivision screen will be shown and the oper-
ation enters the self-diagnosis mode.

A bar graph will be shown on the screen to indicate progress
of the diagnosis.
WKIA1504E
SKIA4207E
SKIA4212E

NAVIGATION SYSTEM
AV-107
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: October 20052005 QX56
Confirmation/Adjustment ModeEKS00BJS
OPERATION PROCEDURE
1. Start the engine.
2. Turn the audio system off.
3. While pressing the “PAUSE/MUTE” button, turn the volume con-
trol dial clockwise or counterclockwise for 30 clicks or more.
(When the self-diagnosis mode is started, a short beep will be
heard.)

Shifting from current screen to previous screen is performed
by pressing “PREV” button.
4. The initial self-diagnosis screen will be shown, and items “Self-
Diagnosis (DCU)”, “Self-Diagnosis (NAVI)”, “Confirmation/
Adjustment” and “CAN DIAG SUPPORT MONITOR” will
become selective.
5. When “Confirmation/Adjustment” is selected on the initial self-
diagnosis screen, the operation will enter the CONFIRMATION/
ADJUSTMENT mode. In this mode, check and adjustment of
each item will become possible.
6. The initial trouble diagnosis screen will be shown, and items
“Display Diagnosis”, “Vehicle Signals”, “Auto Climate Control”
and “Navigation” will become selective.
7. Select each switch on “CONFIRMATION/ADJUSTMENT”
screen to display the relevant diagnosis screen.
WKIA1504E
SKIA4207E
SKIA4220E

AV-114
NAVIGATION SYSTEM
Revision: October 20052005 QX56
CAN DIAG SUPPORT MONITOREKS00BJT
OPERATION PROCEDURE
1. Start the engine.
2. Turn the audio system off.
3. While pressing the “PAUSE/MUTE” button, turn the volume con-
trol dial clockwise or counterclockwise for 30 clicks or more.
(When the self-diagnosis mode is started, a short beep will be
heard.)

Shifting from current screen to previous screen is performed
by pressing “PREV” button.
4. The initial self-diagnosis screen will be shown, and items “Self-
Diagnosis (DCU)”, “Self-Diagnosis (NAVI)”, “Confirmation/
Adjustment” and “CAN DIAG SUPPORT MONITOR” will
become selective.
5. Select “CAN DIAG SUPPORT MONITOR”.
6. Display status of CAN communication.

If the ignition is turned on and UNKWN is shown on the screen, the value of the counter will be up.
(MAX50)
WKIA1504E
SKIA4207E
Item Content Error counter
CANCOMM OK/NG 0-50
CAN_CIRC_1 OK/UNKWN 0-50
CAN_CIRC_2 OK/UNKWN 0-50
CAN_CIRC_3 OK/UNKWN 0-50
CAN_CIRC_4 OK/UNKWN 0-50
CAN_CIRC_5 OK/UNKWN 0-50
CAN_CIRC_6 OK/UNKWN 0-50
CAN_CIRC_7 OK/UNKWN 0-50
CAN_CIRC_8 OK/UNKWN 0-50
CAN_CIRC_9 OK/UNKWN 0-50
SKIA4288E

AV-126
NAVIGATION SYSTEM
Revision: October 20052005 QX56
3. CHECK SELF-DIAGNOSIS OF DCU
1. Replace NAVI control unit.
2. Connect NAVI control unit connector and display control unit connector.
3. Turn ignition switch ON.
4. Start self-diagnosis of DCU and check the self-diagnosis result.
OK or NG
OK >> Inspection End.
NG >> Replace display control unit. Refer to AV- 1 5 8 , "
Removal and Installation of Display Control Unit" .
Audio Communication Line Check (Between Display Control Unit and Audio
Unit)
EKS00BK8
1. CHECK POWER SUPPLY AND GROUND CIRCUIT
1. Check power supply and ground circuit for audio unit. Refer to AV- 3 0 , "
Power Supply Circuit Inspection" .
OK or NG
OK >> GO TO 2.
NG >> Check the malfunctioning parts.
2. CHECK HARNESS
1. Turn ignition switch OFF.
2. Disconnect audio unit connector M45 and display control unit connector M95.
3. Check continuity between audio unit and display control unit.
4. Check continuity between display control unit and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair harness or connector.
Te r m i n a l s
Continuity Display control unit Audio unit
ConnectorTerminal
(Wire color)ConnectorTe r m i n a l
(Wire color)
M9540 (O/L)
M4565 (O/L)
Ye s
42 (W/L) 66 (W/L)
Te r m i n a l s
Continuity Display control unit
—
Connector Terminal (Wire color)
M9540 (O/L)
Ground No
42 (W/L)
WKIA1192E

NAVIGATION SYSTEM
AV-127
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: October 20052005 QX56
3. CHECK 1: AUDIO-TX COMMUNICATION SIGNAL
1. Connect display control unit connector.
2. Turn ignition switch ON.
3. Check voltage between display control unit harness connector
M95 terminal 42 (W/L) and ground.
OK or NG
OK >> GO TO 4.
NG >> Replace display control unit. Refer to AV-158, "
Removal
and Installation of Display Control Unit" .
4. CHECK 2: AUDIO-RX COMMUNICATION SIGNAL
1. Turn ignition switch OFF.
2. Disconnect display control unit connector M95.
3. Connect audio unit connector M45.
4. Turn ignition switch ON.
5. Check voltage between audio unit harness connector M45 ter-
minal 65 (O/L) and ground.
OK or NG
OK >> GO TO 5.
NG >> Replace audio unit. Refer to AV- 4 5 , "
Removal and
Installation for Audio Unit" .
5. CHECK 3: AUDIO-TX COMMUNICATION SIGNAL
1. Turn ignition switch OFF.
2. Connect display control unit connector M95.
3. Turn ignition switch ON.
4. Check signal between display control unit harness connector
M95 terminal 40 (O/L) and ground with CONSULT-II or oscillo-
scope.
OK or NG
OK >> GO TO 6.
NG >> Replace display control unit. Refer to AV-158, "
Removal
and Installation of Display Control Unit" . Approx. 3.5V or more.
WKIA1770E
Approx. 3.5V or more.
WKIA1771E
40 (O/L) - Ground : Refer to AV- 9 2 , "Terminals
and Reference Value for Dis-
play Control unit" .
SKIA4447E

AV-128
NAVIGATION SYSTEM
Revision: October 20052005 QX56
6. CHECK 4: AUDIO-RX COMMUNICATION SIGNAL
1. Turn ignition switch ON.
2. Check signal between display control unit harness connector
M95 terminal 42 (W/L) and ground with CONSULT-II or oscillo-
scope.
OK or NG
OK >> Inspection End.
NG >> Replace audio unit. Refer to AV- 4 5 , "
Removal and
Installation for Audio Unit" .
Display Communication Line Check (Between Display Control Unit and Display
Unit)
EKS00BK9
1. CHECK HARNESS
1. Turn ignition switch OFF.
2. Disconnect display unit connector M93 and display control unit connector M95.
3. Check continuity between display control unit and display unit.
4. Check continuity between display control unit and ground.
OK or NG
OK >> GO TO 2.
NG >> Repair harness or connector.
2. CHECK 1: COMMUNICATION SIGNAL (DCU–DSP)
1. Connect display unit connector.
2. Turn ignition switch ON.
3. Check voltage between display unit harness connector M93 ter-
minal 11 (B/W) and ground.
OK or NG
OK >> GO TO 3.
NG >> Replace display unit. Refer to AV- 1 5 8 , "
Removal and
Installation of Display Unit" . 42 (W/L) - Ground : Refer to AV-92, "
Te r m i na l s
and Reference Value for Dis-
play Control unit" .
SKIA4448E
Te r m i n a l s
Continuity Display control unit Display unit
ConnectorTerminal
(Wire color)ConnectorTe r m i n a l
(Wire color)
M9536 (B/W)
M9311 (B/W)
Ye s
38 (L) 22 (L)
Te r m i n a l s
Continuity Display control unit
—
Connector Terminal (Wire color)
M9536 (B/W)
Ground No
38 (L)
WKIA2019E
Approx. 3.5V or more.
WKIA1377E

AV-132
NAVIGATION SYSTEM
Revision: October 20052005 QX56
2. CHECK 2: DVD-ROM
1. Check DVD-ROM for dirt, scratches and warpage.
OK or NG
OK >> GO TO 3.
NG >> Replace DVD-ROM map.
3. CHECK 3: DVD-ROM
1. Insert same DVD-ROM to make sure same diagnosis result is found as last self-diagnosis.
OK or NG
OK >> Replace NAVI control unit. Refer to AV- 1 5 7 , "Removal and Installation of NAVI Control Unit" .
NG >> Replace DVD-ROM map.
If Connection Between NAVI Control Unit and GPS Antenna is MalfunctioningEKS00BKE
1. CHECK GPS ANTENNA
1. Check cable for GPS antenna for damage.
OK or NG
OK >> GO TO 2.
NG >> Replace GPS antenna. Refer to AV- 1 5 7 , "
Removal and Installation of GPS Antenna" .
2. CHECK BY REPLACEMENT OF GPS ANTENNA
1. Replace other functional GPS antenna to try self-diagnosis again.
Result of self-diagnosis; Found same result?
YES >> Replace NAVI control unit. Refer to AV- 1 5 7 , "Removal and Installation of NAVI Control Unit" .
NO >> Replace GPS antenna. Refer to AV- 1 5 7 , "
Removal and Installation of GPS Antenna" .
Operating Screen for Audio and A/C is Not Displayed When Showing NAVI
Screen
EKS00BKF
1. CHECK HARNESS
1. Turn ignition switch OFF.
2. Disconnect display control unit connector M95 and display unit connector M93.
3. Check continuity between display control unit harness connector M95 terminal 49, 51 (B), 53 (W), 55 (R)
and display unit harness connector M93 terminal 21, 9 (B), 20 (W), 8 (R).
4. Check continuity between display control unit harness connector
M95 terminal 49, 51 (B), 53 (W), 55 (R) and ground.
OK or NG
OK >> GO TO 2.
NG >> Repair harness.Continuity should exist.
Continuity should not exist.
WKIA1965E

AV-142
NAVIGATION SYSTEM
Revision: October 20052005 QX56
Guide Sound is Not HeardEKS00BKN
1. CHECK VOICE GUIDE SETTING

While driving in the dark pink route, voice guide does not operate. (note)

Is volume setting not switched ON?
NOTE:
Voice guide is only available at intersections that satisfy certain conditions (indicated by
on the map). There-
fore, guidance may not be given even when the route on the map changes direction.
Ye s o r N o
YES >> GO TO 2.
NO >> Switch the setting ON and turn the volume up.
2. CHECK HARNESS
1. Turn ignition switch OFF.
2. Disconnect NAVI control unit connector B151 and audio unit connector M45.
3. Check continuity between NAVI control unit and audio unit.
4. Check continuity between NAVI control unit and ground.
Ok or NG
OK >> GO TO 3.
NG >> Repair harness.
3. CHECK VOICE GUIDE
1. Connect NAVI control unit connector and audio unit connector.
2. Turn ignition switch ON.
3. Check signal between NAVI control unit harness connector
B151 terminal 7 (B) and 8 (W) with CONSULT-II or oscilloscope.
OK or NG
OK >> Replace audio unit. Refer to AV- 4 5 , "Removal and
Installation for Audio Unit" .
NG >> Replace NAVI control unit. Refer to AV- 1 5 7 , "
Removal
and Installation of NAVI Control Unit" .
Te r m i n a l s
Continuity NAVI control unit Audio unit
ConnectorTerminal
(Wire color)ConnectorTe r m i n a l
(Wire color)
B1517 (B)
M4571 (B)
Ye s
8 (W) 69 (W)
Te r m i n a l s
Continuity NAVI control unit
—
Connector Terminal (Wire color)
B1517 (B)
Ground No
8 (W)
WKIA1193E
7 (B) – 8 (W) : Refer to AV-90, "Terminals
and Reference Value for
NAVI Control unit" .
SKIA4362E

NAVIGATION SYSTEM
AV-145
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: October 20052005 QX56
3. CHECK CAN COMMUNICATION LINE
Check CAN communication line. Refer to AV- 1 3 1 , "
CAN Communication Line Check" .
OK or NG
OK >> Replace display control unit. Refer to AV-158, "Removal and Installation of Display Control Unit" .
NG >> After filling out CAN DIAG SUPPORT MONITOR check sheet, GO TO LAN-5, "
CAN COMMUNI-
CATION" .
Unable to Operate All of AV Switches (Unable to Start Self-Diagnosis)EKS00BKV
1. CHECK POWER SUPPLY AND GROUND CIRCUIT
Check power supply and ground circuit for AV switch. Refer to AV-120, "
Power Supply and Ground Circuit
Check for AV Switch" .
OK or NG
OK >> GO TO 2.
NG >> Check the malfunctioning parts.
2. AV SWITCH SELF-DIAGNOSIS
AV switch self-diagnosis. Refer to AV- 11 5 , "
AV Switch Self-Diagnosis Function" .
OK or NG
OK >> GO TO 3.
NG >> Check the malfunctioning parts.
3. CHECK POWER SUPPLY AND GROUND CIRCUIT
Check power supply and ground circuit for display control unit. Refer to AV- 11 7 , "
Power Supply and Ground
Circuit Check for Display Control Unit" .
OK or NG
OK >> GO TO 4.
NG >> Check the malfunctioning parts.
4. CHECK COMMUNICATION LINE
Check communication line. Refer to AV- 1 3 0 , "
AV Communication Line Check (Between Display Control Unit
and AV Switch)" .
OK or NG
OK >> Replace AV switch. Refer to AV-158, "Removal and Installation of AV Switch" .
NG >> Replace display control unit. Refer to AV-158, "
Removal and Installation of Display Control Unit" .
Audio Does Not WorkEKS00BKW
Refer to AV-28, "Trouble Diagnosis" .
Navigation System Does Not ActivateEKS00BKX
1. POWER SUPPLY AND GROUND CIRCUIT CHECK
Check power supply and ground circuit for NAVI control unit. Refer to AV- 11 6 , "
Power Supply and Ground Cir-
cuit Check for NAVI Control Unit" .
OK or NG
OK >> Replace NAVI control unit. Refer to AV-157, "Removal and Installation of NAVI Control Unit" .
NG >> Check the malfunctioning parts.
