Page 547 of 3419
ATC-152
BLOWER MOTOR
Revision: October 20052005 QX56
BLOWER MOTORPFP:27226
ComponentsEJS003YB
Front Blower Motor
Rear Blower Motor
Removal and InstallationEJS003YC
FRONT BLOWER MOTOR
Removal
1. Remove the glove box assembly. Refer to IP-14, "Instrument Lower Cover RH and Glove Box" .
2. Disconnect the front blower motor electrical connector.
3. Remove the three screws and remove the front blower motor.
Installation
Installation is in the reverse order of removal.
LJIA0136E
1. Front heater and cooling unit assembly 2. Front blower motor 3. Variable blower control
LJIA0055E
1. Rear blower motor 2. Rear blower motor case 3. Rear blower motor resistor
Page 549 of 3419
ATC-154
IN-CABIN MICROFILTER
Revision: October 20052005 QX56
IN-CABIN MICROFILTERPFP:27277
Removal and InstallationEJS003YD
FUNCTION
The air inside the passenger compartment is filtered by the in-cabin
microfilters when the heater or A/C controls are set on either the
recirculation or fresh mode. The two in-cabin microfilters are located
in the front heater and cooling unit assembly. The rear heater and
cooling unit assembly only draws in air from the passenger compart-
ment to recirculate into the passenger compartment, so the rear
heater and cooling unit assembly is not equipped with in-cabin
microfilters.
REPLACEMENT TIMING
Replacement of the two in-cabin microfilters is recommended on a regular interval depending on the driving
conditions. Refer to MA-7, "
PERIODIC MAINTENANCE" . It may also be necessary to replace the two in-cabin
microfilters as part of a component replacement if the in-cabin microfilters are damaged.
REPLACEMENT PROCEDURE
1. Remove the two lower glove box hinge pins to remove the glove
box from the instrument panel and let it hang from the cord.
2. Remove the screw and remove the in-cabin microfilter cover.
3. Remove the in-cabin microfilters from the front heater and cool-
ing unit assembly housing.
4. Insert the first new in-cabin microfilter into the front heater and
cooling unit assembly housing and slide it over to the right.
Insert the second new in-cabin microfilter into the front heater
and cooling unit assembly housing.
NOTE:
The in-cabin microfilters are marked with air flow arrows. The
end of the microfilter with the arrow should face the rear of the
vehicle. The arrows should point downward.
LJIA0012E
WLIA0027E
LJIA0134E
LJIA0148E
Page 550 of 3419
IN-CABIN MICROFILTER
ATC-155
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: October 20052005 QX56
5. Install the in-cabin microfilter cover.
6. Install the lower glove box in the instrument panel and secure it
with the two hinge pins.
LJIA0134E
WLIA0027E
Page 563 of 3419
ATC-168
VARIABLE BLOWER CONTROL
Revision: October 20052005 QX56
VARIABLE BLOWER CONTROLPFP:27200
Removal and InstallationEJS003YN
Variable Blower Control - Front Heater and Cooling Unit Assembly
REMOVAL
1. Remove the glove box assembly. Refer to IP-14, "Instrument Lower Cover RH and Glove Box" .
2. Disconnect the variable blower control electrical connector.
3. Remove the two screws and remove the variable blower control.
INSTALLATION
Installation is in the reverse order of removal.
LJIA0139E
1. Front heater and cooling unit assembly 2. Intake door motor 3. Air mix door motor (passenger)
4. Variable blower control 5. Air mix door motor (driver) 6. Mode door motor
7. Defroster door motor
Page 2257 of 3419
IDX-4
ALPHABETICAL INDEX
Drive chain (Transfer) ......................... TF-147, TF-174
Drive pinion diff. inspection ............................. RFD-13
Drive pinion height .......................................... RFD-18
Drive shaft (rear) ............................................... RAX-7
Driver air bag .................................................. SRS-46
DTC work support ............................................ EC-136
DTRL - Wiring diagram ....................................... LT-37
Duct and grilles .............................................. ATC-170
DVD Player ........................................................ AV-60
E
ECM input/output signal ..................... EC-117
, EC-141
ECM power supply ............................. EC-157, EC-393
ECM relay ........................................................ EC-157
ECM/PW - Wiring diagram ............................... EC-394
ECTS - Wiring diagram .................................... EC-197
Electric sunroof .................................................. RF-10
Electric throttle control actuator ......... EC-397, EC-399
Electrical load signal circuit .............................. EC-648
Electrical units location ...................................... PG-63
Electronic ignition (EI) system ........................... EC-26
Engine control circuit diagram ......................... EC-115
Engine control component parts location ......... EC-108
Engine control module (ECM) .......................... EC-383
Engine control system diagram ......................... EC-23
Engine coolant .................................................. CO-10
Engine coolant temperature sensor (ECTS) ... EC-195,
EC-208
Engine fail-safe system .................................... EC-103
Engine oil ............................................................. LU-7
Engine oil filter replacement ............................. MA-17
Engine oil precautions .......................................... GI-7
Engine oil replacement ..................................... MA-17
Engine removal ................................................. EM-69
Engine room cover ............................................ EM-11
Engine serial number .......................................... GI-48
ETC1 - Wiring diagram .................................... EC-400
ETC2 - Wiring diagram .................................... EC-407
ETC3 - Wiring diagram .................................... EC-411
EVAP canister .................................................... EC-35
EVAP canister purge volume control solenoid valve ....
EC-318
, EC-531
EVAP canister vent control valve ....... EC-325, EC-539
EVAP control system (small leak) diagnosis .. EC-309,
EC-349
, EC-357
EVAP control system pressure sensor .... EC-332, EC-
335, EC-341
EVAP control system purge flow monitoring diagnosis
EC-304
EVAP vapor lines inspection ............................. MA-20
Evaporative emission (EVAP) system ............... EC-32
Evaporator ..................................................... ATC-186
Exhaust manifold .............................................. EM-19
Exhaust system ................................................... EX-3
Exhaust system inspection .................................. EX-3
Expansion valve ............................................. ATC-188
F
F/FOG - Wiring diagram ..................................... LT-71
F/PUMP - Wiring diagram ............................... EC-638
Final drive pre-inspection .................. FFD-14, RFD-13
Final drive removal and installation ... FFD-11, RFD-10
Flow charts .......................................................... GI-27
Fluid temperature sensor (A/T) ........................ AT-126
Fluids ................................................................ MA-11
Fluorescent leak detector .............................. ATC-189
Fog lamp, front ................................................... LT-69
Foot lamp ......................................................... LT-130
Freeze frame data ............................... EC-54, EC-130
Front brake solenoid valve ................. AT-144, AT-146
Front bumper ...................................................... EI-13
Front case (Transfer) .......................... TF-147, TF-174
Front combination lamp removal and installation LT-32
Front door ............................. BL-128, BL-131, GW-68
Front Door Trim ................................................... EI-32
Front drive shaft (Transfer) ................. TF-147, TF-174
Front fog lamp .................................................... LT-69
Front passenger air bag .................................. SRS-51
Front seat ........................................................... SE-97
Front seat belt ...................................................... SB-3
Front seat belt pre-tensioner ............... SRS-3, SRS-58
Front washer ...................................................... WW-4
Front wiper ......................................................... WW-4
FTTS - Wiring diagram ...................... EC-255, EC-260
Fuel cut control (at no load high engine speed) EC-27
Fuel filter replacement ......................................... FL-5
Fuel gauge ............................................................ DI-5
Fuel injection system (Bank 1) .......... EC-236, EC-245
Fuel injection system (Bank 2) .......... EC-236, EC-245
Fuel injector and fuel tube ................................. EM-29
Fuel level sensor ................. EC-366, EC-368, EC-370
Fuel line inspection .............................................. FL-3
Fuel pressure check .......................................... EC-93
Fuel pressure release ....................................... EC-93
Fuel pump ....................................................... EC-637
Fuel pump and gauge .......................................... FL-5
Fuel system .......................................................... FL-3
Fuel tank .............................................................. FL-9
Fuel tank temperature sensor ........... EC-253, EC-259
Fuel tank vacuum relief valve ........................... EC-35
FUELB1 - Wiring diagram ................. EC-238, EC-247
FUELB2 - Wiring diagram ................. EC-239, EC-248
Fuse ...................................................... PG-66, PG-77
Fuse and fusible link box .................................. PG-77
Fuse block ......................................................... PG-76
Fusible link ............................................ PG-66, PG-77
G
Garage jack and safety stand ............................. GI-40
Gauges ................................................................. DI-5
Generator .......................................................... SC-17
Generic scan tool (GST) ................................. EC-139
Glass ...................................... GW-11, GW-68, GW-71
Glove box lamp ................................................ LT-153
Page 2272 of 3419
INSTRUMENT PANEL ASSEMBLY
IP-11
C
D
E
F
G
H
J
K
L
MA
B
IP
Revision: October 20052005 QX56
1. Remove instrument lower cover LH. Refer to IP-13, "Instrument Lower Cover LH" .
2. Remove glove box assembly.
3. Remove center console lower covers.
4. Remove shift knob and A/T finisher. Refer to IP-13, "
A/T Finisher" .
Disconnect harness from bottom of A/T finisher.
5. Remove control device. Refer to AT-227, "
Control Device Removal and Installation" .
6. Remove center console and disconnect harness.
7. Remove cluster lid C and disconnect harnesses.
8. Remove cluster lid D and disconnect harness.
9. Remove display assembly and the audio unit. Refer to AV-45, "
Removal and Installation for Audio Unit"
and AV- 1 5 8 , "Removal and Installation of Display Unit" .
10. Remove power point assemblies.
11. Remove front passenger air bag status light.
12. Remove hazard switch.
13. Remove clock.
14. Remove combination meter cover.
15. Remove cluster lid A and disconnect harness.
16. Remove combination meter and disconnect harness.
17. Remove lower knee protector LH.
18. Remove the upper and lower steering column covers.
Disconnect harness from ADP steering switch.
19. Remove defrost grille and disconnect optical sensor harness.
20. Remove side ventilator assembly LH.
21. Remove side ventilator assembly RH.
22. Remove instrument panel.
Remove passenger air bag nuts and remove air bag. Refer to SRS-51, "FRONT PASSENGER AIR
BAG MODULE" .
Disconnect GPS antenna.
Disconnect harnesses to instrument panel speakers LH and RH and remove speakers.
Disconnect all remaining harnesses.
Installation is in the reverse order of removal.
1. Steering member brackets 2. Bracket assembly LH 3. Steering member assembly
4. Combination meter cover 5. Defrost grille 6. Instrument panel speaker LH
7. Instrument panel 8. Bin mat 9. Side ventilator assembly LH
10. Instrument lower cover LH 11. Lower knee protector LH 12. Steering column cover upper
13. Steering column cover lower 14. Center console lower cover LH 15. Combination meter
16. Audio unit bracket LH 17. Driver instrument stay 18. Audio unit
19. Passenger instrument stay 20. Display assembly 21. Switch assembly
22. Cluster lid A 23. Cluster lid D ventilator LH 24. Front passenger air bag status light
25. Power point assemblies 26. Clock 27. Cluster lid C
28. Front air control 29. Audio control 30. Hazard switch
31. Cluster lid D ventilator RH 32. Cluster lid D 33. Glove box door
34. Glove box assembly 35. Glove box housing 36. Glove box striker
37. Rubber bumpers 38. Glove box damper 39. Audio unit bracket RH
40. Center console lower cover RH 41. Fuse block cover 42. Side ventilator assembly RH
43. Instrument panel bracket 44. Instrument panel speaker RH 45. Bracket assembly RH
46. Key cylinder escutcheon 47. Instrument lower cover RH
Page 2275 of 3419
IP-14
INSTRUMENT PANEL ASSEMBLY
Revision: October 20052005 QX56
Instrument Lower Cover RH and Glove Box
1. Remove the instrument lower cover RH.
2. Remove screws using power tool, release clips and remove
glove box and housing as an assembly.
3. Remove damper clip from glove box.
4. Remove glove box pins and glove box.
5. Remove screws from glove box striker using power tool and
remove striker.
6. Remove fuse block cover.
7. Remove screws and remove glove box damper from back of
glove box housing.
Installation is in the reverse order of removal.
1. Glove box damper 2. Lower instrument panel RH 3. Glove box pins
4. Glove box 5. Glove box striker 6. Fuse block cover
7. Glove box assembly A. Damper clip B. Clips
WIIA1087E
LLIA0072E
Page 2277 of 3419
IP-16
INSTRUMENT PANEL ASSEMBLY
Revision: October 20052005 QX56
1. Remove instrument lower cover RH. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Remove glove box assembly. Refer to IP-14, "
Instrument Lower Cover RH and Glove Box" .
3. Remove instrument lower cover LH. Refer to IP-10, "
INSTRUMENT PANEL ASSEMBLY" .
4. Remove shift knob and A/T console finisher. Refer to IP-13, "
A/T Finisher" .
Remove cup holder insert.
Remove shift indicator.
5. Remove cluster lid D. Refer to IP-12, "
Cluster Lid D" .
6. Disconnect shift cable and electrical harness from control device.
7. Remove control device. Refer to AT-227, "
Control Device Removal and Installation" .
8. Remove screws from center console.
Disconnect electrical harnesses.
9. Move front seats forward and remove center console assembly in a rearward direction.
10. Remove tray and mat from console bin.
11. Remove latch from console lid.
12. Remove hinge from console lid. Remove console lid.
Remove console lid mat.
13. Remove console bin.
Disconnect electrical harness from DVD player, if equipped.
Remove hinge from console bin.
14. Remove rear upper finisher.
15. Remove rear cup holder assembly.
16. Remove upper side finishers LH/RH.
17. Remove screws on each side, disconnect clips and remove console covers LH/RH.
18. Remove rear finisher assembly.
Disconnect electrical connectors.
19. Remove power point assembly.
20. Remove mask and storage compartment.
21. Remove console front bracket.
22. Remove heat duct and console rear duct.
23. Remove console rear bracket.
Assembly is in the reverse order of disassembly.
1. Console lid assembly 2. A/T finisher 3. Tray
4. Storage compartment 5. Storage compartment mask 6. Console reinforcement assembly
7. Console front bracket 8. Upper side finisher LH 9. Console cover LH
10. Rear console duct 11. Power point assembly 12. Rear cup holder assembly
13. Rear finisher assembly 14. Console rear bracket 15. Heat duct
16. Rear upper finisher 17. Console bin mat 18. Console bin
19. Console cover RH 20. Upper side finisher RH 21. A/T transmission control
22. Mask 23. Cup holder insert
Page 2600 of 3419
ILLUMINATION
LT-153
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: October 20052005 QX56
to combination meter terminal 8.
With the ignition switch in the ON or START position, power is supplied
to ignition relay, located in the IPDM E/R, and
to BCM terminal 38, and
through 10A fuse (No. 59, located in the fuse and relay box)
through 10A fuse [No. 14, located in the fuse block (J/B)]
to combination meter terminal 24.
Ground is supplied
to BCM terminal 67 and
to combination meter terminal 17
through grounds M57, M61 and M79, and
to IPDM E/R terminals 38 and 59
through grounds E9, E15 and E24.
ILLUMINATION OPERATION BY LIGHTING SWITCH
With the lighting switch in the 1ST or 2ND position (or if the auto light system is activated), the BCM receives
input signal requesting the illumination lamps to illuminate. This input signal is communicated to the IPDM E/R
across the CAN communication lines. The CPU of the IPDM E/R controls the tail lamp relay coil, which, when
energized, directs power
through 10A fuse (No. 36, located in the IPDM E/R)
through IPDM E/R terminal 49
to illumination control switch terminal 1
to power liftgate switch terminal 3
to front room/map lamp assembly (console box illumination) terminal 7
to hazard switch terminal 3
to rear sonar system OFF switch terminal 3
to glove box lamp terminal +
to display control unit terminal 14
to 4WD shift switch terminal 7 (with 4-wheel drive)
to front air control terminal 23
to rear power vent window switch terminal 5
to DVD player terminal 12 (with DVD entertainment system)
to NAVI control unit terminal 25
to pedal adjusting switch terminal 5
to electric brake (pre-wiring) terminal 4
to front and rear heated seat switch LH and RH terminal 5
to A/T device terminal 11
to VDC OFF switch terminal 3
to tow mode switch terminal 3
to headlamp aiming switch terminal 3 (with headlamp aiming control)
to clock terminal 3
to compass and thermometer terminal 4, and
through 10A fuse (No. 37, located in the IPDM E/R)
through IPDM E/R terminal 57
to AV switch terminal 3
to audio unit terminal 8
to rear air control terminal 1 and
to rear audio remote control unit terminal 6.
Illumination is controlled
through illumination control switch terminal 2
Page 2601 of 3419
LT-154
ILLUMINATION
Revision: October 20052005 QX56
to power liftgate switch terminal 4
to front room/map lamp assembly (console box illumination) terminal 8
to AV switch terminal 4
to hazard switch terminal 4
to audio unit terminal 7
to rear sonar system OFF switch terminal 4
to 4WD switch terminal 8 (with 4-wheel drive)
to front air control terminal 24
to rear power vent window switch terminal 6
to DVD player terminal 10 (with DVD entertainment system)
to pedal adjusting switch terminal 6
to A/T device terminal 12
to front heated seat switch LH and RH terminal 6
to VDC OFF switch terminal 4
to tow mode switch terminal 4
to headlamp aiming switch terminal 4 (with headlamp aiming control)
to clock terminal 4 and
to combination meter terminal 18.
Ground is supplied
to illumination control switch terminal 3
to glove box lamp terminal –
to display control unit terminal 3
to rear heated seat switches terminal 6
to electric brake (pre-wiring) terminal 1 and
to compass and thermometer terminal 7
through grounds M57, M61 and M79, and
to NAVI control unit terminal 30
to rear air control terminal 3 and
to rear audio remote control unit terminal 15
through grounds B117 and B132.
With power and ground supplied, illumination lamps illuminate.
EXTERIOR LAMP BATTERY SAVER CONTROL
When the combination switch (lighting switch) is in the 1ST or 2ND position (or if auto light system is acti-
vated), and the ignition switch is turned from ON or ACC to OFF, the battery saver control function is activated.
Under this condition, the illumination lamps remain illuminated for 5 minutes, then the illumination lamps are
turned off.
When the lighting switch is turned from OFF to 1ST or 2ND position (or if auto light system is activated) after
illumination lamps are turned off by the battery saver control, the illumination lamps illuminate again.
Exterior lamp battery saver control mode can be changed by the function setting of CONSULT-II.
CAN Communication System DescriptionEKS00BBK
Refer to LAN-5, "CAN COMMUNICATION" .
