0 Illustrated table of contents
Air bags, seat belts and child restraints........... 0-2
Exterior front ................................... 0-3
Exterior rear .................................... 0-4
Passenger compartment ........................ 0-5 Instrument panel
................................ 0-6
Engine compartment check locations ............ 0-8
Warning/indicator lights ........................ 0-9

1. Vent (P. 4-34)
2. Bluetooth® Hands-Free Phone System*Steering wheel switch for audio control* Center display multi-function control
buttons*3. High beam/turn signal switch (P. 2-46)
Paddle shifters (P. 5-22)
Trip reset switch (P. 2-5)
4. Driver supplemental air bag (P. 1-41) Horn (P. 2-47)
5. Meters and gauges (P. 2-4) Warning and indicator lights (P. 2-9)
Vehicle information display (P. 2-19)
6. Wiper and washer switch (P. 2-36) Rear wiper and washer switch (P. 2-38)
7. Automatic heater and air conditioning
controls (P. 4-35)
Driver side climate controlled seat
switches (if so equipped) (P. 2-48)
Driver side heated seat switches (if so
equipped) (P. 2-49)
8. Upper and lower displays* Navigation system* (if so equipped)
9. Automatic heater and air conditioning
controls (P. 4-35)
Passenger side climate controlled seat
switches (if so equipped) (P. 2-48)
Passenger side heated seat switches
(if so equipped) (P. 2-49)
Rear window defroster, outside mirror
defroster (if so equipped), and wiper
deicer (if so equipped) switch (P. 2-39)
10. Front passenger supplemental air bag
(P. 1-41)
LII2779
INSTRUMENT PANEL
0-6Illustrated table of contents

11. Front passenger supplemental knee airbag (P. 1-59)
12. Glove box (P. 2-62)
13. Audio system controls* Front passenger air bag status light
(P. 1-52)
14. INFINITI controller*
15. Power outlet (P. 2-59) USB port*
Cup holders (P. 2-63)
Wireless charger and indicator (P. 2-55)
16. Shift lever (P. 5-18)
17. Push-button ignition switch (P. 5-13) Electronic parking brake switch (P. 5-24)
Automatic brake hold switch (P. 5-26)
INFINITI Drive Mode Selector (P. 5-29)
18. Hazard warning flasher switch (P. 6-2)
19. ProPILOT Assist Switch (P. 5-76) Cruise control switches (P. 5-78)
Distance control switch (P. 5-76)
Control panel and vehicle information
display switches (P. 2-20)
20. Driver supplemental knee air bag
(P. 1-59)
21. Tilt and telescopic steering wheel control
(P. 3-31)
22. Hood release (P. 3-21) 23. Instrument brightness control (P. 2-46)
Front and rear sonar system switch (if so
equipped) (P. 2-51)
Steering assist switch (P. 2-51)
Instrument panel liftgate switch (P. 3-22)
Headlight switch (P. 2-40)
Fog light switch (if so equipped) (P. 2-47)
Head Up Display (HUD) OFF switch
(if so equipped) (P. 2-52)
*: Refer to the separate INFINITI InTouch®
Owner's Manual.
Refer to the page number indicated in paren-
theses for operating details.
Illustrated table of contents0-7

Warning/Indicator
light (red) Name Page
or
Brake warning
light
2-10
Charge warning
light 2-11
Electric shift
control system
warning light2-11
or
Electronic parking
brake indicator
light2-11
Warning/
Indicator
light (red) Name Page
Engine oil pressure
warning light
2-12
Master warning
light2-12
Pop-up engine
hood warning light2-12
Seat belt warning
light and chime 2-12
Security indicator
light2-13
Supplemental air
bag warning light2-13
Warning/
Indicator light
(yellow) Name Page
or
Anti-lock Braking
System (ABS)
warning light
2-13
or
Electronic parking
brake warning
light2-13
Forward Emer-
gency Braking
(FEB) with Pedes-
trian Detection
system warning
light2-14
WARNING/INDICATOR LIGHTS
Illustrated table of contents0-9

Warning/Indicator light
(yellow) Name Page
Front passenger
air bag status light
2-14
Low tire pressure
warning light2-14
Malfunction Indi-
cator Light (MIL) 2-15
Master warning
light2-16
Power steering
warning light2-16
Rear Automatic
Braking (RAB) sys-
tem warning light 2-17
Warning/
Indicator light
(yellow) Name Page
Slip indicator light 2-17
Vehicle Dynamic
Control (VDC)
OFF indicator light
2-17
Warning/
Indicator light
(other) Name Page
Automatic brake
hold indicator light
(white/green)
2-17
Eco drive indicator
light (green) (if so
equipped)2-17
Warning/
Indicator light
(other) Name Page
Front fog light
indicator light
(green) (if so
equipped) 2-18
High Beam Assist
indicator light
(green)
2-18
High beam indica-
tor light (blue)
2-18
Side light and
headlight indicator
light (green)2-18
Turn signal/hazard
indicator lights
(green)2-18
0-10Illustrated table of contents

1 Safety-Seats, seat belts and supplemental
restraint system
Seats............................................1-2
Front power seat adjustment ..................1-3
Rear bench seat adjustment ...................1-5
Armrest ......................................1-5
Flexible seating ...............................1-6
Head restraints/headrests .......................1-7
Adjustable head restraint/headrest
components ..................................1-8
Non-adjustable head restraint/headrest
components ..................................1-9
Remove ......................................1-9
Install ...................................... 1-10
Adjust ...................................... 1-10
Seat belts ....................................... 1-12
Precautions on seat belt usage ...............1-12
Seat belt warning light and chime .............1-15
Pregnant women ............................ 1-15
Injured persons .............................. 1-16
Three-point type seat belt with retractor ......1-16
Seat belt extenders .......................... 1-19
Seat belt maintenance .......................1-19
Child safety .................................... 1-20
Infants ..................................... 1-20Small Children
.............................. 1-20
Larger children ............................... 1-21
Child restraints .................................. 1-22
Precautions on child restraints ................1-22
LATCH (Lower Anchors and Tethers for
CHildren) system ............................ 1-24
Rear-facing child restraint installation
using LATCH ................................ 1-27
Rear-facing child restraint installation
using the seat belts ......................... 1-29
Forward-facing child restraint installation
using LATCH ................................ 1-31
Forward-facing child restraint installation
using the seat belts ......................... 1-34
Booster seats ............................... 1-38
Supplemental Restraint System (SRS) ............1-41
Precautions on SRS .......................... 1-41
Supplemental air bag warning labels ..........1-61
Supplemental air bag warning light ..........1-62
Pop-up engine hood ........................... 1-63
Pop-up engine hood activation
conditions ..................................
1-64

WARNING
• Always route the shoulder belt over your
shoulder and across your chest. Never
put the belt behind your back, under your
arm or across your neck. The belt should
be away from your face and neck, but not
falling off your shoulder.
• Position the lap belt as low and snug as
possible AROUND THE HIPS, NOT THE
WAIST. A lap belt worn too high could
increase the risk of internal injuries in an
accident. •
Be sure the seat belt tongue is securely
fastened to the proper buckle.
• Do not wear the seat belt inside out or
twisted. Doing so may reduce its
effectiveness.
• Do not allow more than one person to use
the same seat belt.
• Never carry more people in the vehicle
than there are seat belts.
• If the seat belt warning light glows con-
tinuously or chime continues while the
ignition is turned on with all doors closed
and all seat belts fastened, it may indi-
cate a malfunction in the system. Have
the system checked. It is recommended
that you visit an INFINITI retailer for this
service.
• No changes should be made to the seat
belt system. For example, do not modify
the seat belt, add material, or install de-
vices that may change the seat belt
routing or tension. Doing so may affect
the operation of the seat belt system.
Modifying or tampering with the seat
belt system may result in serious per-
sonal injury. •
Once the seat belt pretensioner(s) have
activated, they cannot be reused and
must be replaced together with the re-
tractor. It is recommended that you visit
an INFINITI retailer for this service.
• All seat belt assemblies, including retrac-
tors and attaching hardware, should be
inspected after any collision. It is recom-
mended that you visit an INFINITI re-
tailer for this service. INFINITI recom-
mends that all seat belt assemblies in use
during a collision be replaced unless the
collision was minor and the belts show no
damage and continue to operate prop-
erly. Seat belt assemblies not in use dur-
ing a collision should also be inspected
and replaced if either damage or im-
proper operation is noted.
• All child restraints and attaching hard-
ware should be inspected after any
collision. Always follow the restraint
manufacturer's inspection instructions
and replacement recommendations. The
child restraints should be replaced if they
are damaged.
SSS0014
1-14Safety-Seats, seat belts and supplemental restraint system

SEAT BELT WARNING LIGHT
AND CHIME
The driver and front passenger seat is
equipped with an enhanced seat belt reminder
function. If your vehicle is equipped with an
enhanced seat belt reminder function, a visual
and audible alert will operate if a driver or front
passenger seat belt is unbuckled at speeds of
approximately 9 mph (15 km/h) or more under
the following conditions:
• If the driver seat belt is not fastened.
• The front passenger’s seat belt is not fas-tened and the seat is occupied by a passen-
ger for 7 seconds after the ignition switch is
placed in the ON position. • The front passenger’s seat belt is not fas-
tened and objects or external force on the
passenger seat change the seat belt re-
minder classification to Occupied.
The seat belt warning light will flash under
the conditions shown above until the neces-
sary seat belt is securely fastened.
A warning chime will sound for approxi-
mately 90 seconds or until one of the follow-
ing conditions is met:
• The unbuckled front occupant’s seat belt is securely fastened.
• The seat belt reminder function in the front passenger seat no longer detects that the
front passenger seat is occupied.
• The ignition is turned off or the vehicle is parked.
The below situations could result in the seat
belt reminder light being illuminated and the
chime sounding, even with no occupant pres-
ent in the passenger seat:
• Heavy objects placed on the seat.
• Someone pushing or pulling on the front passenger seat.
• An object placed under the front passenger seat. • An object placed between the seat cushion
and center console or between the seat
cushion and the door.
• An object hanging on the seat or placed in the seatback pocket.
• A child restraint or other object pressing against the rear of the seatback.
NOTE:
The rear seats may be equipped with a seat
belt reminder in the vehicle information
display.
The rear seat belt icons will illuminate when
not fastened. When a rear passenger's seat
belt has been securely fastened, the color of
the corresponding seat belt icon will change.
For additional information, see “Vehicle in-
formation display” (P. 2-19).
PREGNANT WOMEN
INFINITI recommends that pregnant women
use seat belts. The seat belt should be worn
snug and always position the lap belt as low
as possible around the hips, not the waist.
Place the shoulder belt over your shoulder
and across your chest. Never run the lap/
shoulder belt over your abdominal area.
Contact your doctor for specific recommen-
dations.
LRS0786
Safety-Seats, seat belts and supplemental restraint system1-15

3. Position the lap belt portionlow and snug
on the hips
OBas shown.
4. Pull the shoulder belt portion toward the retractor to take up extra slack
OC. Be sure
the shoulder belt is routed over your
shoulder and across your chest.
The front passenger seat and the rear seating
positions three-point seat belts have two
modes of operation:
• Emergency Locking Retractor (ELR)
• Automatic Locking Retractor (ALR) The ELR mode allows the seat belt to extend
and retract to allow the driver and passen-
gers some freedom of movement in the seat.
The ELR locks the seat belt when the vehicle
slows down rapidly or during certain impacts.
The ALR mode (child restraint mode) locks
the seat belt for child restraint installation.
When the ALR mode is activated, the seat
belt cannot be extended again until the seat
belt tongue is detached from the buckle and
fully retracted. The seat belt returns to the
ELR mode after the seat belt fully retracts.
The ALR mode should be used only for child
restraint installation. During normal seat
belt use by an occupant, the ALR mode
should not be activated. If it is activated, it
may cause uncomfortable seat belt tension.
It can also change the operation of the front
passenger air bag. For additional informa-
tion, see “Front passenger air bag and status
light” (P. 1-52).
WARNING
When fastening the seat belts, be certain
that the seatbacks are completely secured
in the latched position. If they are not com-
pletely secured, passengers may be injured
in an accident or sudden stop.
Unfastening the seat belts
To unfasten the seat belt, press the button on
the buckle
O1. The seat belt automatically
retracts.
LRS2675WRS0139
Safety-Seats, seat belts and supplemental restraint system1-17

7. Check to make sure the child restraint isproperly secured prior to each use. If the
child restraint is loose, repeat steps 3
through 6.
FORWARD-FACING CHILD
RESTRAINT INSTALLATION
USING THE SEAT BELTS
WARNING
The three-point seat belt with Automatic
Locking Retractor (ALR) must be used
when installing a child restraint. Failure to
use the ALR mode will result in the child
restraint not being properly secured. The
restraint could tip over or be loose and
cause injury to a child in a sudden stop or
collision. Also, it can change the operation
of the front passenger air bag. For addi-
tional information, see “Front passenger
air bag and status light” (P. 1-52). For additional information, see “Child safety”
(P. 1-20) and “Child restraints” (P. 1-22) be-
fore installing a child restraint.
Do not use the lower anchors if the combined
weight of the child and the child restraint
exceeds 65 lbs. (29.5 kg). If the combined
weight of the child and the child restraint is
greater than 65 lbs. (29.5 kg), use the vehi-
cle's seat belt (not the lower anchors) to in-
stall the child restraint. Be sure to follow the
child restraint manufacturer's instructions for
installation. Follow these steps to install a forward-
facing child restraint using the vehicle seat
belt in the rear seats or in the front passenger
seat:
1.
If you must install a child restraint in the
front seat, it should be placed in a
forward-facing direction only. Move the
seat to the rearmost position. Child re-
straints for infants must be used in the
rear-facing direction and, therefore,
must not be used in the front seat.
2. Position the child restraint on the seat. Always follow the child restraint manu-
facturer’s instructions.
The back of the child restraint should be
secured against the vehicle seatback.
If necessary, adjust or remove the head
restraint/headrest to obtain the correct
child restraint fit. If the head restraint/
headrest is removed, store it in a secure
place. Be sure to reinstall the head
restraint/headrest when the child re-
straint is removed. For additional infor-
mation, see “Head restraints/headrests”
(P. 1-7).
WRS0699
Forward-facing (front passenger seat) – step 1
1-34Safety-Seats, seat belts and supplemental restraint system
