AUTOMATIC DRIVE POSITIONER
SE-41
C
D
E
F
G
H
J
K
L
MA
B
SE
Revision: August 20072004 QX56
ACTIVE TEST
CAUTION:
During vehicle driving, do not perform active test.
NOTE:
If active test is performed, reset seat memory and key fob interlock drive positioner after performing work.
DISPLAY ITEM LIST
CAN Communication Inspection Using CONSULT-II (Self-Diagnosis)EIS002YH
1. SELF-DIAGNOSTIC RESULT CHECK
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carry out CAN communication.
1. Connect to CONSULT-II, and select “AUTO DRIVE POS.” on the “SELECT DIAG SYSTEM” screen.
2. Select “SELF-DIAG RESULTS” on "SELECT DIAG MODE" screen.
3. Check display content in self-diagnostic results.
Contents displayed
No malfunction>>Inspection End.
Malfunction in CAN communication system>>After printing the monitor items, go to “CAN System”. Refer to
LAN-3, "
Precautions When Using CONSULT-II" .
Symptom ChartEIS002YI
MIR/SEN LH U–D “V” Voltage output from LH door mirror sensor (UP/DOWN) is displayed.
PEDAL SEN “V”The pedal position (voltage) judged from the pedal adjust sensor signal is dis-
played. Monitor item [OPERATION or UNIT] Contents
Test item Description
SEAT SLIDE The sliding motor is activated by receiving the drive signal.
SEAT RECLINING The reclining motor is activated by receiving the drive signal.
SEAT LIFTER FR The lifting motor (front) is activated by receiving the drive signal.
SEAT LIFTER RR The lifting motor (rear) is activated by receiving the drive signal.
PEDAL MOTOR The pedal adjust motor is activated by receiving the drive signal.
MEMORY SW INDCTR The memory switch indicator is lit by receiving the drive signal.
MIRROR MOTOR RHThe RH mirror motor moves the mirror UP/DOWN and LEFT/RIGHT by receiving the drive
signal.
MIRROR MOTOR LHThe LH mirror motor moves the mirror UP/DOWN and LEFT/RIGHT by receiving the drive
signal.
CONSULT-II display code Diagnosis item
U1000INITIAL DIAG
TRANSMIT DIAG
BSM
METER/M&A
ECM
SymptomDiagnoses / service procedure Refer to
page
Only setting change function cannot be set with display.1. Preliminary checkSE-34
2. CAN communication inspection using CONSULT-II (self-
diagnosis)SE-41
3. If the above systems are normal, check display systemAV- 6 1

SRS-22
TROUBLE DIAGNOSIS
Revision: August 20072004 QX56
Trouble Diagnosis With CONSULT-IIEHS000WH
DIAGNOSTIC PROCEDURE 2
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunction might be detected
in self-diagnosis depending on control unit which carries out CAN communication.
1. Turn ignition switch OFF.
2. Connect CONSULT-II and CONSULT-II CONVERTER to the
data link connector.
3. Turn ignition switch ON.
4. Touch “START (NISSAN BASED VHCL)”.
5. Touch “AIR BAG”.
If "AIR BAG" is not indicated, refer to GI-39, "
CONSULT-II Data
Link Connector (DLC) Circuit" .
6. Touch "SELF-DIAG [CURRENT]".
BBIA0369E
BCIA0029E
BCIA0030E
BCIA0031E

SRS-28
TROUBLE DIAGNOSIS
Revision: August 20072004 QX56
DIAGNOSTIC PROCEDURE 3
Final Check of SRS Using CONSULT-II—Diagnosis Mode
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunction might be detected
in self-diagnosis depending on control unit which carries out CAN communication.
1. After repairing SRS, connect both battery cables.
2. Connect CONSULT-II and CONSULT-II CONVERTER to data
link connector.
3. Turn ignition switch ON.
4. Touch “START (NISSAN BASED VHCL)”.
5. Touch “AIR BAG”.
If "AIR BAG" is not indicated, refer to GI-39, "
CONSULT-II Data
Link Connector (DLC) Circuit" .
6. Touch “SELF-DIAG [CURRENT]”.
BBIA0369E
BCIA0029E
BCIA0030E
BCIA0031E

SRS-30
TROUBLE DIAGNOSIS
Revision: August 20072004 QX56
DIAGNOSTIC PROCEDURE 4 (CONTINUED FROM DIAGNOSTIC PROCEDURE 2)
Check SRS Repair History
1. CONSIDER POSSIBILITY THAT SELF-DIAGNOSTIC RESULT WAS NOT ERASED AFTER REPAIR
Check repair history of the SRS.
Have any previous repairs been made to the SRS?
Yes >> Self-diagnostic result “SELF-DIAG [PAST]” (previously stored in the memory) might not be erased
after repair. Go to SRS-28, "
DIAGNOSTIC PROCEDURE 3" .
No >> Go to SRS-22, "
DIAGNOSTIC PROCEDURE 2" .
DIAGNOSTIC PROCEDURE 5
Check SRS Intermittent Malfunction Using CONSULT-II—Diagnosis Mode
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunction might be detected
in self-diagnosis depending on control unit which carries out CAN communication.
1. Turn ignition switch OFF.
2. Connect CONSULT-II and CONSULT-II CONVERTER to data
link connector.
3. Turn ignition switch ON.
4. Touch “START (NISSAN BASED VHCL)”.
5. Touch “AIR BAG”.
If "AIR BAG" is not indicated, refer to GI-39, "
CONSULT-II Data
Link Connector (DLC) Circuit" .
BBIA0369E
BCIA0029E
BCIA0030E

TF-1
TRANSFER
D DRIVELINE/AXLE
CONTENTS
C
E
F
G
H
I
J
K
L
M
SECTION TF
A
B
TF
Revision: August 20072004 QX56 PREPARATION ........................................................... 4
Special Service Tools ............................................... 4
Commercial Service Tools ........................................ 7
PRECAUTIONS .......................................................... 8
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 8
Precautions .............................................................. 8
Service Notice .......................................................... 9
Wiring Diagrams and Trouble Diagnosis .................. 9
ALL-MODE 4WD SYSTEM ...................................... 10
Cross-sectional View .............................................. 10
Control System ........................................................11
ALL-MODE 4WD TRANSFER BASIC CONTROL
... 12
HYDRAULIC CONTROL CIRCUITS ................... 12
OUTLINE ............................................................. 12
CONTROL SYSTEM DIAGRAM ......................... 13
INDICATIONS OF 4WD WARNING LAMP ......... 13
CAN Communication .............................................. 13
SYSTEM DESCRIPTION .................................... 13
Location of Electrical Parts ..................................... 14
Description of Electrical Parts ................................ 15
TRANSFER MOTOR .......................................... 15
WAIT DETECTION SWITCH .............................. 15
2-4WD SHIFT SOLENOID VALVE ...................... 15
LINE PRESSURE SWITCH ................................ 16
Circuit Diagram for Quick Pinpoint Check .............. 17
Wiring Diagram — T/F — ....................................... 18
ON BOARD DIAGNOSTIC SYSTEM DESCRIP-
TION .......................................................................... 27
Trouble Diagnosis without CONSULT-II ................. 27
DESCRIPTION .................................................... 27
SELF-DIAGNOSTIC PROCEDURE .................... 28
INDICATIONS OF 4WD WARNING LAMP ......... 28CONSULT-II Function (ALL MODE AWD/4WD) ..... 31
Trouble Diagnosis with CONSULT-II ...................... 31
SELF-DIAGNOSIS .............................................. 31
SELF-DIAGNOSTIC ITEMS ................................ 32
DATA MONITOR ................................................. 34
DATA MONITOR ITEMS ..................................... 35
REFERENCE VALUE IN DATA MONITOR MODE
... 38
WORK SUPPORT ............................................... 41
CLUTCH FORCE RELEASE LIMIT ADJUST-
MENT .................................................................. 42
TROUBLE DIAGNOSIS — INTRODUCTION ........... 44
Introduction ............................................................. 44
DESCRIPTION .................................................... 44
DIAGNOSTIC WORKSHEET .............................. 44
Work Flow ............................................................... 46
HOW TO PERFORM TROUBLE DIAGNOSES
FOR QUICK AND ACCURATE REPAIR ............. 46
TROUBLE DIAGNOSIS — BASIC INSPECTION .... 47
Listen to Customer Complaints .............................. 47
Transfer Fluid Check .............................................. 47
Road Test ............................................................... 47
PREPARATION FOR ROAD TEST ..................... 47
1. CHECK BEFORE ENGINE IS STARTED ....... 48
2. CHECK AT IDLE .............................................. 49
3. CRUISE TEST ................................................. 53
TROUBLE DIAGNOSIS — GENERAL DESCRIP-
TION .......................................................................... 55
Transfer Control Unit Terminals and Reference
Value ....................................................................... 55
TRANSFER CONTROL UNIT HARNESS CON-
NECTOR LAYOUT .............................................. 55
TRANSFER CONTROL UNIT INSPECTION
TABLE ................................................................. 55
DTC U1000, U1001 CAN COMMUNICATION LINE ... 59
CAN Communication System Inspection ................ 59
4WD SOLENOID VALVE .......................................... 60
Diagnostic Procedure ............................................. 60
2-4WD SHIFT SOLENOID VALVE AND 4WD SHIFT

ALL-MODE 4WD SYSTEM
TF-13
C
E
F
G
H
I
J
K
L
MA
B
TF
Revision: August 20072004 QX56
CONTROL SYSTEM DIAGRAM
INDICATIONS OF 4WD WARNING LAMP
*: When 4WD warning lamp is ON, all the 4WD shift indicator lamps turn OFF.
CAN CommunicationEDS0017P
SYSTEM DESCRIPTION
Refer to LAN-5, "CAN COMMUNICATION" .
WDIA0075E
Condition Content 4WD warning lamp
During self-diagnosis Indicates the malfunction position by number of flickers. Flickers at malfunction mode.
Lamp check*Checks the lamp by turning ON during engine starting. After
engine starts, it turns OFF if there are no malfunctions.ON
Malfunction in 4WD system*Turns ON to indicate malfunction. When ignition switch is
turned to “OFF” or the malfunction is corrected, it turns OFF.ON
When vehicle is driven with different
diameters of front and rear tiresFlickers once every 2 seconds.
Turns OFF when ignition switch is “OFF”.Flickers once every 2 sec-
onds.
High fluid temperature in transfer unitWhen fluid temperature is high or fluid temperature sensor cir-
cuit is shorted, it flickers twice every second.
It turns OFF when fluid temperature becomes normal.Flickers twice a second.
Other than above (System is nor-
mal.)Lamp is OFF. OFF

ON BOARD DIAGNOSTIC SYSTEM DESCRIPTION
TF-29
C
E
F
G
H
I
J
K
L
MA
B
TF
Revision: August 20072004 QX56
Flickering pattern or flick-
ering conditionMalfunction Check items
2 Rear revolution sensor circuit is shorted or open.Refer to AT- 11 2 , "
DTC P0720 VEHI-
CLE SPEED SENSOR A/T (REVO-
LUTION SENSOR)" .
3 4WD solenoid valve circuit is shorted or open.Refer to TF-60, "
Diagnostic Proce-
dure" .
42-4WD shift solenoid valve circuit is shorted or 2WD switch of
4WD shift switch is shorted.Refer to TF-62, "
Diagnostic Proce-
dure" .
5 Transfer motor relay circuit is shorted or open.Refer to TF-64, "
Diagnostic Proce-
dure" .
6If unexpected signal is detected because of ABS wheel sensor
malfunction or communications error within the vehicle.Refer to BRC-38, "
Wheel Sensor
System Inspection" .
7 When malfunction in CAN communication system is detected.Refer to LAN-5, "
CAN COMMUNICA-
TION" .
8 A/D converter of transfer control unit functions improperly.Refer to EC-351, "
DTC P0605 ECM"
.
9 Transfer fluid temperature sensor circuit is open.Refer to TF-66, "
Diagnostic Proce-
dure" .
10 Neutral-4LO switch circuit is shorted or open.Refer to TF-69, "
Diagnostic Proce-
dure" .
112-4WD shift solenoid valve circuit, 2WD switch of 4WD shift
switch circuit or clutch pressure switch circuit is shorted or open.Refer to TF-62, "
Diagnostic Proce-
dure" or TF-72, "Diagnostic Proce-
dure" .
12 Line pressure switch circuit is shorted or open.Refer to TF-74, "
Diagnostic Proce-
dure" .
13 Engine speed signal circuit is shorted or open.Refer to AT- 11 5 , "
DTC P0725
ENGINE SPEED SIGNAL" .
14 Throttle position sensor circuit is shorted or open.Refer to EC-351, "
DTC P0605 ECM"
.
15 Malfunction in power supply circuit of transfer control unit. Power supply of transfer control unit
16 4WD shift switch circuit is shorted.Refer to TF-62, "
Diagnostic Proce-
dure" .
17 ABS operation signal circuit is shorted.Refer to BRC-54, "
CAN Communica-
tion System Inspection" .
18ATP switch, wait detection switch or neutral-4LO switch circuit is
shorted or open.Refer to TF-69, "
Diagnostic Proce-
dure" .
19Transfer control device actuator motor is malfunctioning. (Mal-
functions are detected when actuator motor fails to operate while
shifting from “4H” to “4LO” or vice versa.)Refer to TF-77, "
Diagnostic Proce-
dure" or TF-82, "Diagnostic Proce-
dure" .
20Transfer control device actuator motor arm position sensing
switch is malfunctioning.Refer to TF-80, "
Diagnostic Proce-
dure" or TF-82, "Diagnostic Proce-
dure" .
21Transfer control device actuator circuit is shorted or open. (Mal-
functions are detected when motor relay circuit is open/shorted or
relay monitor circuit is open/shorted.)Refer to TF-77, "
Diagnostic Proce-
dure" , TF-80, "Diagnostic Proce-
dure" or TF-82, "Diagnostic
Procedure" .
22If VDC operation signal is being input because of VDC malfunc-
tion or communication error within the vehicle.Refer to BRC-40, "
ABS/TCS/VDC
Control Unit Inspection" .
23If TCS operation signal is being input because of TCS malfunction
or communication error within the vehicle.Refer to BRC-40, "
ABS/TCS/VDC
Control Unit Inspection" .
24If unexpected signal is input because of AT PNP switch circuit or
communication error within the vehicle.Refer to AT- 1 0 9 , "
DTC P0705 PARK/
NEUTRAL POSITION SWITCH" .
Repeats flickering every
2 to 5 sec.Circuits that the self-diagnosis covers have no malfunction. —

ON BOARD DIAGNOSTIC SYSTEM DESCRIPTION
TF-31
C
E
F
G
H
I
J
K
L
MA
B
TF
Revision: August 20072004 QX56
CONSULT-II Function (ALL MODE AWD/4WD)EDS002G7
CONSULT-II can display each diagnostic item using the diagnostic test modes shown following.
Trouble Diagnosis with CONSULT-IIEDS0017V
SELF-DIAGNOSIS
CONSULT-II Setting Procedure
1. Turn ignition switch to “OFF” position.
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carry out CAN communication.
2. Connect CONSULT-II and CONSULT-II CONVERTER to data
link connector.
3. Start engine.
4. On CONSULT-II screen, touch “START (NISSAN BASED
VHCL)”.
5. Touch “ALL MODE AWD/4WD” on SELECT SYSTEM screen.
If "ALL MODE AWD/4WD" is not indicated, refer to GI-39,
"CONSULT-II Data Link Connector (DLC) Circuit" .
ALL MODE AWD/4WD diag-
nostic modeDescription
SELF-DIAG RESULTS Displays transfer control unit self-diagnosis results.
DATA MONITOR Displays transfer control unit input/output data in real time.
WORK SUPPORTSupports inspections and adjustments. Commands are transmitted to the transfer control unit for set-
ting the status suitable for required operation, input/output signals are received from the transfer con-
trol unit and received data is displayed.
CAN DIAG SUPPORT
MNTRThe results of transmit/receive diagnosis of CAN communication can be read.
ECU PART NUMBER Transfer control unit part number can be read.
BBIA0369E
BCIA0029E
BCIA0030E

ON BOARD DIAGNOSTIC SYSTEM DESCRIPTION
TF-33
C
E
F
G
H
I
J
K
L
MA
B
TF
Revision: August 20072004 QX56
Note 1: When a malfunction occurs, it is only displayed and not stored in the memory.
Note 2: When the wait detection switch has been properly fixed, malfunction information is erased from the memory.
Note 3: If 4WD shift switch is left between 4H and 4LO for a while, this indication may be displayed.
(*1): If the malfunction is detected only while driving in reverse, check the continuity of “R” position on A/T PNP switch. When there is
nothing wrong with the electrical system, check the hydraulic system.
(*2): If a revolution sensor malfunction is detected at the same time, check the revolution sensor circuit first.
Note 4: When this malfunction is detected with the ABS warning lamp off, first check for disconnection or shorting in the harness
between the transfer control unit and the ABS control unit.
Note 5: When several systems including CAN communication system indicate malfunctions, perform diagnosis of the CAN communica-
tion first.Shift actuator abnormal
(SHIFT ACT)Transfer control device actuator motor is malfunctioning.
(Malfunctions are detected when actuator motor fails to
operate while shifting from “4H” to “4LO” or vice versa.) Refer to TF-77, "
Diagnostic Proce-
dure" or TF-82, "Diagnostic Pro-
cedure" .
Shift actuator position switch
abnormal
(SHIFT ACT P/S)Transfer control device actuator motor arm position sens-
ing switch is malfunctioning.Refer to TF-80, "
Diagnostic Proce-
dure" or TF-82, "Diagnostic Pro-
cedure" .
Shift actuator circuit abnormal
(SHIFT ACT CIR)Transfer control device actuator circuit is shorted or open.
(Malfunctions are detected when motor relay circuit is
open/shorted or relay monitor circuit is open/shorted.)Refer to TF-77, "
Diagnostic Proce-
dure" , TF-80, "Diagnostic Proce-
dure"TF-82, "Diagnostic
Procedure" .
Memory power supply stop

Due to removal of battery which cuts off power supply to
transfer control unit, self-diagnosis memory function is
suspended.Refer to TF-76, "Diagnostic Proce-
dure" .
Transfer control unit (RAM)
[CONTROL UNIT (RAM)]

Malfunction is detected in the memory (RAM) system of
transfer control unit.—
Transfer control unit (ROM)
[CONTROL UNIT (ROM)]

Malfunction is detected in the memory (ROM) system of
transfer control unit.—
Transfer control unit (EEPROM)
[CONTROL UNIT (EEPROM)]

Malfunction is detected in the memory (EEPROM) sys-
tem of transfer control unit.—
Longitudinal G-sensor Displayed, but do not use. —
ABS VHL SPD SEN

ABS vehicle speed sensor signal is not input due to an
open circuit.

An unexpected signal is input when vehicle is being
driven.Refer to ABS vehicle speed sensor
diagnosis.
STEERING ANGLE SENSOR Displayed, but do not use. —
VDC OPER SIGIf VDC operation signal is being input because of VDC
malfunction or communication error within the vehicle.Refer to BRC-40, "
ABS/TCS/VDC
Control Unit Inspection" .
TCS OPER SIGIf TCS operation signal is being input because of TCS mal-
function or communication error within the vehicle.Refer to BRC-40, "
ABS/TCS/VDC
Control Unit Inspection" .
CAN COMM (Note 5) Malfunction is detected in CAN communication.Refer to LAN-5, "
CAN COMMUNI-
CATION" .
A/T POSITION SIGNALWhen AT PNP switch circuit is malfunction or communica-
tion error between the vehiclesRefer to AT-109, "
DTC P0705
PARK/NEUTRAL POSITION
SWITCH" . Detected items
(Screen terms for CONSULT-II,
“SELF-DIAG RESULT” mode)Malfunction is detected when... Check items

TF-34
ON BOARD DIAGNOSTIC SYSTEM DESCRIPTION
Revision: August 20072004 QX56
DATA MONITOR
CONSULT-II Setting Procedure
1. Turn ignition switch to “OFF” position.
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CON-
VERTER, malfunctions might be detected in self-diagnosis
depending on control unit which carry out CAN communication.
2. Connect CONSULT-II and CONSULT-II CONVERTER to data
link connector.
3. Turn ignition switch to ON position.
4. Touch “START (NISSAN BASED VHCL)”.
5. Touch “ALL MODE AWD/4WD”.
If "ALL MODE AWD/4WD" is not indicated, refer to GI-39,
"CONSULT-II Data Link Connector (DLC) Circuit" .
6. Touch “DATA MONITOR”.
BBIA0369E
BCIA0029E
BCIA0030E
BCIA0031E
