Body INFINITI QX56 2004 Factory Owner's Guide

BCS-16
BCM (BODY CONTROL MODULE)
Revision: August 20072004 QX56
WRITE CONFIGURATION PROCEDURE
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carries out CAN communication.
1. With ignition switch OFF, connect CONSULT-II and CONSULT-II
CONVERTER to data link connector and turn ignition switch ON.
2. Touch “START (NISSAN BASED VHCL)”.
3. Touch “BCM” on “SELECT SYSTEM” screen.
If "BCM" is not indicated, go to GI-39, "
CONSULT-II Data Link
Connector (DLC) Circuit" .
4. Touch “BCM” on “SELECT TEST ITEM” screen.
BBIA0369E
BCIA0029E
BCIA0030E
LKIA0183E

BCM (BODY CONTROL MODULE)
BCS-17
C
D
E
F
G
H
I
J
L
MA
B
BCS
Revision: August 20072004 QX56
5. Touch “CONFIGURATION” on “SELECT DIAG MODE” screen.
6. Touch “JA60” and "OK" on “VEHICLE SELECT” screen. For
canceling, touch "CANCEL" on "VEHICLE SELECT" screen.
NOTE:
Confirm vehicle model. Refer to GI-46, "
Model Variation" in GI
section.
7. Touch “WRITE CONFIGURATION” on “SELECT CONFIG
ITEM” screen.
8. Touch YES”.
For canceling, touch "NO".
9. Touch “WITH” or "WITHOUT" on "WRITE CONFIGURATION" screen based on the following ITEM LIST.

Depending on CONSULT-II software version being used, some or all of the write configuration items
shown in the following configuration lists may be displayed. If an item does not appear on the CON-
SULT-II "WRITE CONFIGURATION" screen(s), then it is an auto setting item and it cannot be manually
set or changed.
NOTE:
Confirm vehicle model. Refer to GI-46, "
Model Variation" in GI section.
BCIA0031E
LKIA0606E
LKIA0547E
LKIA0175E
ITEM SET VAL
DTRL WITH ⇔ WITHOUT

BCS-18
BCM (BODY CONTROL MODULE)
Revision: August 20072004 QX56
10. Touch "CHNG SETTING" on "WRITE CONFIGURATION" screen.
CAUTION:
Make sure to touch "CHNG SETTING" even if the indicated configuration of new BCM is same as
the desirable configuration.
If not, configuration which is set automatically by selecting vehicle model cannot be memorized.
11. Touch “OK” on "WRITE CONFIGURATION" screen.
If "CANCEL" is touched, it will return to previous screen.
12. Wait until the next screen during setting.
13. WRITE CONFIGURATION results are printed out automatically.
Confirm "WRITE CONFIGURATION" is correctly executed by
comparing sheet automatically printed out with applicable con-
figuration list shown in step 9.
LKIA0397E
LKIA0398E
LKIA0509E

BCM (BODY CONTROL MODULE)
BCS-19
C
D
E
F
G
H
I
J
L
MA
B
BCS
Revision: August 20072004 QX56
14. Touch "OK" on "WRITE CONFIGURATION" screen.
WRITE CONFIGURATION is completed.
Removal and Installation of BCMEKS007GK
REMOVAL
NOTE:
If possible, before removing BCM, retrieve current BCM configuration to use for reference when configuring
brand-new BCM after installation. Refer to BCS-13, "
Configuration" .
1. Disconnect negative battery cable.
2. Remove lower knee protector LH. Refer to IP-10, "
INSTRUMENT PANEL ASSEMBLY" .
3. Remove screw and release BCM.
4. Disconnect connectors and then remove BCM.
INSTALLATION
Installation is in the reverse order of removal.
NOTE:

When replacing BCM, it must be configured. Refer to BCS-13, "Configuration" .

When replacing BCM, perform initialization of NATS system and registration of all NATS ignition key IDs.
Refer to BL-138, "
IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-NATS)" .

When replacing BCM, perform ID registration procedure of low tire pressure warning system. Refer to
WT-13, "
ID Registration Procedure" .
LKIA0400E
LEIA0068E

BCS-20
BCM (BODY CONTROL MODULE)
Revision: August 20072004 QX56

BL-1
BODY, LOCK & SECURITY SYSTEM
I BODY
CONTENTS
C
D
E
F
G
H
J
K
L
M
SECTION BL
A
B
BL
Revision: August 20072004 QX56 PRECAUTIONS .......................................................... 4
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 4
Precautions for work ................................................ 4
Wiring Diagnosis and Trouble Diagnosis ................. 4
PREPARATION ........................................................... 5
Special service tool .................................................. 5
Commercial Service Tool ......................................... 5
SQUEAK AND RATTLE TROUBLE DIAGNOSIS ...... 6
Work Flow ................................................................ 6
CUSTOMER INTERVIEW ..................................... 6
DUPLICATE THE NOISE AND TEST DRIVE ....... 7
CHECK RELATED SERVICE BULLETINS ........... 7
LOCATE THE NOISE AND IDENTIFY THE
ROOT CAUSE ...................................................... 7
REPAIR THE CAUSE ........................................... 7
CONFIRM THE REPAIR ....................................... 8
Generic Squeak and Rattle Troubleshooting ........... 8
INSTRUMENT PANEL .......................................... 8
CENTER CONSOLE ............................................. 8
DOORS ................................................................. 8
BACK DOOR ......................................................... 9
SUNROOF/HEADLINER ....................................... 9
OVERHEAD CONSOLE (FRONT AND REAR) ..... 9
SEATS ................................................................... 9
UNDERHOOD ....................................................... 9
Diagnostic Worksheet ............................................ 10
HOOD ....................................................................... 12
Fitting Adjustment .................................................. 12
CLEARANCE AND SURFACE HEIGHT
ADJUSTMENT .................................................... 13
HOOD LOCK ADJUSTMENT ............................. 13
Removal and Installation of Hood Assembly .......... 13
Removal and Installation of Hood Lock Control ..... 14
REMOVAL ........................................................... 14
INSTALLATION ................................................... 15
Hood Lock Control Inspection ................................ 15
POWER DOOR LOCK SYSTEM .............................. 16
Component Parts and Harness Connector Location ... 16System Description ................................................. 17
OUTLINE ............................................................. 18
Schematic ............................................................... 19
Wiring Diagram — D/LOCK — ............................... 20
Terminals and Reference Value for BCM ............... 25
Work Flow ............................................................... 25
CONSULT–II Function (BCM) ................................ 26
CONSULT–II INSPECTION PROCEDURE ......... 26
DATA MONITOR ................................................. 27
ACTIVE TEST ..................................................... 28
Trouble Diagnoses Symptom Chart ....................... 29
BCM Power Supply and Ground Circuit Check ...... 29
Door Switch Check ................................................. 31
Key Switch (Insert) Check ...................................... 33
Door Lock/Unlock Switch Check ............................ 34
Glass Hatch Switch Circuit Inspection .................... 36
Front Door Lock Assembly LH (Actuator) Check .... 37
Front Door Lock Actuator RH Check ...................... 39
Rear Door Lock Actuator RH/LH Check ................. 40
Glass Hatch Lock Actuator Check .......................... 41
Front Door Lock Assembly LH (Key Cylinder Switch)
Check ..................................................................... 42
REMOTE KEYLESS ENTRY SYSTEM ..................... 44
Component Parts and Harness Connector Location ... 44
System Description ................................................. 45
INPUTS ............................................................... 45
OPERATING PROCEDURE ................................ 46
CAN Communication System Description .............. 48
Schematic ............................................................... 49
Wiring Diagram — KEYLES — ............................... 50
............................................................................ 50
............................................................................ 51
............................................................................ 52
Terminals and Reference Value for BCM ............... 53
Terminals and Reference Value for IPDM E/R ....... 54
CONSULT-II Function (BCM) ................................. 55
CONSULT-II Inspection Procedure ......................... 55
“MULTI REMOTE ENT” ....................................... 55
CONSULT-II Application Items ............................... 56
“MULTI REMOTE ENT” ....................................... 56

BL-3
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: August 20072004 QX56 Terminals and Reference Value for BCM ............. 142
CONSULT-II ......................................................... 142
CONSULT-II INSPECTION PROCEDURE ....... 142
CONSULT-II DIAGNOSTIC TEST MODE FUNC-
TION .................................................................. 143
HOW TO READ SELF-DIAGNOSTIC RESULTS . 144
IVIS (NATS) SELF-DIAGNOSTIC RESULTS
ITEM CHART .................................................... 144
Work Flow ............................................................ 145
Trouble Diagnoses ............................................... 146
SYMPTOM MATRIX CHART 1 ......................... 146
SYMPTOM MATRIX CHART 2 ......................... 147
DIAGNOSTIC SYSTEM DIAGRAM .................. 147
Diagnostic Procedure 1 ........................................ 148
Diagnostic Procedure 2 ........................................ 149
Diagnostic Procedure 3 ........................................ 150
Diagnostic Procedure 4 ........................................ 151
Diagnostic Procedure 5 ........................................ 152
Diagnostic Procedure 6 ........................................ 155
How to Replace NATS Antenna Amp. .................. 156
HOMELINK UNIVERSAL TRANSCEIVER ............. 157
Wiring Diagram — TRNSCV — ........................... 157
Trouble Diagnoses ............................................... 158
DIAGNOSTIC PROCEDURE ............................ 158
CAB AND REAR BODY ......................................... 159
Body Mounting ..................................................... 159
BODY REPAIR ........................................................ 160
Body Exterior Paint Color ..................................... 160
Body Component Parts ........................................ 161
UNDERBODY COMPONENT PARTS .............. 161
BODY COMPONENT PARTS ........................... 163
FRAME COMPONENT PARTS ......................... 165
Corrosion Protection ............................................ 167
DESCRIPTION .................................................. 167ANTI-CORROSIVE WAX ..................................168
UNDERCOATING ..............................................169
Body Sealing ........................................................170
DESCRIPTION ..................................................170
Body Construction ................................................173
BODY CONSTRUCTION ..................................173
Body Alignment ....................................................174
BODY CENTER MARKS ...................................174
PANEL PARTS MATCHING MARKS .................175
DESCRIPTION ..................................................176
ENGINE COMPARTMENT ................................177
UNDERBODY ...................................................179
PASSENGER COMPARTMENT .......................182
REAR BODY .....................................................187
Handling Precautions for Plastics .........................189
HANDLING PRECAUTIONS FOR PLASTICS ..189
LOCATION OF PLASTIC PARTS ......................190
Precautions in Repairing High Strength Steel .......192
HIGH STRENGTH STEEL (HSS) USED IN NIS-
SAN VEHICLES ................................................192
Foam Repair .........................................................194
URETHANE FOAM APPLICATIONS ................194
FILL PROCEDURES .........................................194
Replacement Operations ......................................195
DESCRIPTION ..................................................195
HOODLEDGE ...................................................198
FRONT PILLAR .................................................199
CENTER PILLAR ..............................................202
OUTER SILL .....................................................204
REAR FENDER .................................................205
REAR SIDE MEMBER ......................................207
REAR FLOOR REAR ........................................208
CRUSH HORN ..................................................209

SQUEAK AND RATTLE TROUBLE DIAGNOSIS
BL-7
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: August 20072004 QX56
DUPLICATE THE NOISE AND TEST DRIVE
If possible, drive the vehicle with the customer until the noise is duplicated. Note any additional information on
the Diagnostic Worksheet regarding the conditions or location of the noise. This information can be used to
duplicate the same conditions when you confirm the repair.
If the noise can be duplicated easily during the test drive, to help identify the source of the noise, try to dupli-
cate the noise with the vehicle stopped by doing one or all of the following:
1) Close a door.
2) Tap or push/pull around the area where the noise appears to be coming from.
3) Rev the engine.
4) Use a floor jack to recreate vehicle "twist".
5) At idle, apply engine load (electrical load, half-clutch on M/T model, drive position on A/T model).
6) Raise the vehicle on a hoist and hit a tire with a rubber hammer.

Drive the vehicle and attempt to duplicate the conditions the customer states exist when the noise occurs.

If it is difficult to duplicate the noise, drive the vehicle slowly on an undulating or rough road to stress the
vehicle body.
CHECK RELATED SERVICE BULLETINS
After verifying the customer concern or symptom, check ASIST for Technical Service Bulletins (TSBs) related
to that concern or symptom.
If a TSB relates to the symptom, follow the procedure to repair the noise.
LOCATE THE NOISE AND IDENTIFY THE ROOT CAUSE
1. Narrow down the noise to a general area. To help pinpoint the source of the noise, use a listening tool
(Chassis Ear: J-39570, Engine Ear: J-39565 and mechanic's stethoscope).
2. Narrow down the noise to a more specific area and identify the cause of the noise by:

removing the components in the area that you suspect the noise is coming from.
Do not use too much force when removing clips and fasteners, otherwise clips and fastener can be broken
or lost during the repair, resulting in the creation of new noise.

tapping or pushing/pulling the component that you suspect is causing the noise.
Do not tap or push/pull the component with excessive force, otherwise the noise will be eliminated only
temporarily.

feeling for a vibration with your hand by touching the component(s) that you suspect is (are) causing the
noise.

placing a piece of paper between components that you suspect are causing the noise.

looking for loose components and contact marks.
Refer to BL-8, "
Generic Squeak and Rattle Troubleshooting" .
REPAIR THE CAUSE

If the cause is a loose component, tighten the component securely.

If the cause is insufficient clearance between components:
–separate components by repositioning or loosening and retightening the component, if possible.
–insulate components with a suitable insulator such as urethane pads, foam blocks, felt cloth tape or ure-
thane tape. A Nissan Squeak and Rattle Kit (J-43980) is available through your authorized Nissan Parts
Department.
CAUTION:
Do not use excessive force as many components are constructed of plastic and may be damaged.
Always check with the Parts Department for the latest parts information.
The following materials are contained in the Nissan Squeak and Rattle Kit (J-43980). Each item can be
ordered separately as needed.
URETHANE PADS [1.5 mm (0.059 in) thick]
Insulates connectors, harness, etc.
76268-9E005: 100×135 mm (3.94×5.31 in)/76884-71L01: 60×85 mm (2.36×3.35 in)/76884-71L02: 15×25
mm (0.59×0.98 in)
INSULATOR (Foam blocks)
Insulates components from contact. Can be used to fill space behind a panel.
73982-9E000: 45 mm (1.77 in) thick, 50×50 mm (1.97×1.97 in)/73982-50Y00: 10 mm (0.39 in) thick,
50×50 mm (1.97×1.97 in)
INSULATOR (Light foam block)

HOOD
BL-13
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: August 20072004 QX56
CLEARANCE AND SURFACE HEIGHT ADJUSTMENT
1. Remove the hood lock assembly and adjust the height by rotating the bumper rubber until the hood clear-
ance of hood and fender becomes 1 mm (0.04 in) lower than fitting standard dimension.
2. Temporarily tighten the hood lock, and position it by engaging it with the hood striker. Check the lock and
striker for looseness, and tighten the lock bolts to the specified torque.
3. Adjust the clearance and surface height of hood and fender according to the fitting standard dimension by
rotating right and left bumper rubbers.
CAUTION:
Adjust right/left gap between hood and each part to the following specification.
HOOD LOCK ADJUSTMENT
1. Move the hood lock to the left or right so that striker center is vertically aligned with hood lock center
(when viewed from vehicle front).
2. Make sure the secondary latch is properly engaged with the sec-
ondary striker with hood's own weight by dropping it from
approx. 200 mm (7.87 in) height or by pressing it lightly approx.
3 kg (29 N, 7lb).
CAUTION:
Do not drop the hood from 300 mm (11.81 in) height or
higher.
3. After adjusting hood lock, tighten the lock bolts to the specified
torque.
Removal and Installation of Hood AssemblyEIS002R5
1. Support the hood striker with a proper material to prevent it from
falling.
WAR NIN G:
Body injury may occur if no supporting rod is holding the
hood open when removing the damper stay.
2. Remove the hinge nuts from the hood to remove the hood
assembly.
CAUTION:
Operate with two workers, because of its heavy weight.
Installation is in the reverse order of removal.Hood and headlamp (B–B) : Less than 2.0 mm
PIIA3806E
LIIA1443E

HOOD
BL-15
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: August 20072004 QX56
INSTALLATION
1. Pull the hood lock cable through the panel hole to the engine room.
Be careful not to bend the cable too much, keeping the radius
100mm (3.94 in) or more.
2. Make sure the cable is not offset from the grommet, and push
the grommet into the panel hole securely.
3. Apply sealant to the grommet (at * mark) properly.
4. Install the primary and secondary cables securely to the hood
lock.
5. Install the hood lock and the secondary hood lock release
assemblies.
6. Check the hood lock adjustment and hood opener operation.
Refer to BL-12, "
Fitting Adjustment" .
Hood Lock Control InspectionEIS002R7
CAUTION:
If the hood lock cable is bent or deformed, replace it.
1. Make sure the secondary latch is properly engaged with the sec-
ondary striker with hood's own weight by dropping it from
approx. 200 mm (7.87 in) height.
2. While operating the hood opener, carefully make sure the front
end of the hood is raised by approx. 20 mm (0.79 in). Also make
sure the hood opener returns to the original position.
3. Check the hood lock lubrication condition. If necessary, apply
“body grease” to the points shown in the figure.
PIIA0173E
PIIA0174E
PIIA1086E
PIIA0176E
