DVD ENTERTAINMENT SYSTEM
AV-53
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: August 20072004 QX56
System DescriptionEKS007LB
Refer to Owner's Manual for DVD entertainment system operating instructions.
Power is supplied at all times

through 20A fuse (No. 31, located in the fuse and fusible link box)

to DVD player terminal 16.
With the ignition switch in the ACC or ON position, power is supplied

through 10A fuse [No. 4, located in the fuse block (J/B)]

to DVD player terminal 15.
Power is also supplied

from DVD player terminals 31 and 32

to video monitor terminals 11 and 12.
Ground is supplied

to DVD player terminal 22

through body grounds M57, M61 and M79.
Audio signals are supplied

through DVD player terminals 1, 2, 3 and 4

to audio unit terminals 34, 35, 36 and 37.
Video signals are supplied

through DVD player terminals 23, 24, 28 and 29

to video monitor terminals 5, 6, 7 and 8.

AV-58
DVD ENTERTAINMENT SYSTEM
Revision: August 20072004 QX56
Trouble DiagnosisEKS007LE
Symptom Possible causes Repair order
DVD player inoperative1. Power supply
2. Ground circuit
3. Audio enable circuit
4. DVD enable signal
5. Audio enable signal
6. DVD player
7. Audio unit1. Refer to AV- 5 9 , "
Power Supply Circuit Inspection" .
2. Refer to AV- 5 9 , "
Power Supply Circuit Inspection" .
3. Check audio enable circuits for open or short between
audio unit terminals 39, 40 and DVD player terminals
11 , 9 .
4. Push power switch of DVD player and verify approx.
5V is present at terminal 39 of audio unit.
5. Push power switch of DVD player and verify approx.
5V is present at terminal 9 of DVD player.
6. Remove DVD player for repair.
7. Remove audio unit for repair.
No sound when playing
DVD1. Audio signal circuits
2. DVD player
3. Audio unit1. Check audio signal circuits for open or short between
DVD player terminals 1, 2, 3 and 4 and audio unit ter-
minals 34, 35, 36 and 37.
2. Remove DVD player for repair.
3. Remove audio unit for repair.
Video monitor is inopera-
tive/does not operate prop-
erly1. Power supply
2. Video monitor ground circuit
3. Video circuits
4. Data signal
5. Video monitor
6. DVD player1. Operate DVD player and verify battery positive voltage
is present at terminals 11 and 12 of video monitor. Ver-
ify approximately 5 volts is present at terminal 10 of
video monitor.
2. Check video monitor ground circuits between DVD
player terminals 19 and 27 and video monitor terminals
1 and 2.
3. Check video circuits between DVD player terminals 23
and 24 and video monitor terminals 7 and 8.
4. Check data signal circuit for open or short between
DVD player terminal 29 and video monitor terminal 5.
5. Remove video monitor for repair.
6. Remove DVD player for repair.
DVD remote control is
inoperative/does not oper-
ate properly1. Data signal
2. DVD player remote control batteries
3. DVD player remote control
4. Video monitor1. Check data signal circuit for open or short between
DVD player terminal 28 and video monitor terminal 6.
2. Replace DVD player remote control batteries.
3. Replace DVD player remote control.
4. Remove video monitor for repair.
Headphones inoperative 1. Headphone batteries
2. Headphones
3. Rear audio remote control unit1. Replace headphone batteries.
2. Replace headphones.
3. Replace rear audio remote control unit.
Snowy video/poor audio 1. Harness or connectors
2. DVD player1. Check harness and connectors for open or short.
2. Check DVD player.
Snowy video (audio OK) 1. Harness or connectors
2. DVD player1. Check harness and connectors for open or short.
2. Check DVD player.
No video (audio OK) 1. Harness or connectors
2. DVD player
3. Video monitor1. Check harness and connectors for open or short.
2. Check DVD player.
3. Check video monitor.
Dim video (audio OK) 1. Harness or connectors
2. DVD player
3. Video monitor1. Check harness and connectors for open or short.
2. Check DVD player.
3. Check video monitor.

AV-90
NAVIGATION SYSTEM
Revision: August 20072004 QX56
Terminals and Reference Value for NAVI Control unitEKS007LO
Te r m i n a l N o .
(Wire color)
ItemSignal
input/
outputCondition
Vo l ta g e
(Approx.)Example of
symptom
+–Igni-
tion
switchOperation
1 (B) Ground Ground – ON – 0 V –
2 (Y)
GroundBattery
powerInput OFF – Battery voltageSystem does not
work properly.
3 (Y)
4 (B) Ground Ground – ON – 0 V –
6 (O) Ground ACC signal Input ACC – Battery voltageSystem does not
work properly.
7 (B) 8 (W)Voice guide
signalOutput ONPress the “GUIDE/
VOICE” button.Only route guide
and operation
guide are not
heard.
9–Shield
ground–– – –Audio noise
interference.
14 –Shield
ground–– – –Video display
interference.
15 (B) 17RGB signal
(B: blue)Output ONSelect “Display
Diagnosis (NAVI)” of
CONFIRMATION/
ADJUSTMENT
function.NAVI screen
looks yellowish.
16 (W) 14RGB syn-
chronizing
signalOutput ONPress the “MAP”
button.NAVI screen is
rolling.
17 –Shield
ground–– – –Video display
interference.
18 (R) 17RGB signal
(R: red)Output ONSelect “Display
Diagnosis (NAVI)” of
CONFIRMATION/
ADJUSTMENT
function.NAVI screen
looks bluish.
21 (R/W) 17RGB signal
(G: green)Output ONSelect “Display
Diagnosis (NAVI)” of
CONFIRMATION/
ADJUSTMENT
function.NAVI screen
looks reddish.
SKIA0171J
SKIA4979E
SKIA0164E
SKIA4977E
SKIA4978E

NAVIGATION SYSTEM
AV-93
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: August 20072004 QX56
30 (LG) GroundCommunica-
tion signal (–)Input/
outputON –System does not
work properly.
32 (L) GroundCommunica-
tion signal (+)Input/
outputON –System does not
work properly.
33 –Shield
ground–– – – –
34 (P) GroundCommunica-
tion signal (–)Input/
outputON –System does not
work properly.
36 (B/W) 37Display Com-
munication
signal
(DCU-DSP)Output ONPress the “TRIP”
button.Though a screen
is displayed, it is
impossible to
adjust bright-
ness.
37 –Shield
ground–– – – –
38 (L) 37Display Com-
munication
signal
(DSP-DCU)Input ONPress the “TRIP”
button.Though a screen
is displayed, it is
impossible to
adjust bright-
ness.
39 –Shield
ground–– – – –
40 (O/L) GroundAudio TX
Communica-
tion signalOutput ONOperate audio
volume.Audio does not
operate properly. Terminal No.
(Wire color)
ItemSignal
input/
outputCondition
Vo ltag e
(Approx.)Example of
symptom
+–Igni-
tion
switchOperation
SKIA0176E
SKIA0175E
SKIA0176E
SKIA4364E
SKIA4363E
SKIA4402E

AV-94
NAVIGATION SYSTEM
Revision: August 20072004 QX56
41 –Shield
ground–– – – –
42 (W/L) GroundAudio RX
communica-
tion signalInput ONOperate audio
volume.Audio does not
operate properly.
43 (W) 41RGB syn-
chronizing
signalInput ONPress the “MAP”
button.NAVI screen is
rolling.
44 (R/L) 45RGB signal
(R: red)Input ONSelect “Display
Diagnosis (NAVI)” of
CONFIRMATION/
ADJUSTMENT
function.NAVI screen
looks bluish.
45 –Shield
ground–– – – –
46 (R/W) 45RGB signal
(G: green)Input ONSelect “Display
Diagnosis (NAVI)” of
CONFIRMATION/
ADJUSTMENT
function.NAVI screen
looks reddish.
47 –Shield
ground–– – – –
48 (B) 45RGB signal
(B: blue)Input ONSelect “Display
Diagnosis (NAVI)” of
CONFIRMATION/
ADJUSTMENT
function.NAVI screen
looks yellowish.
49 –Shield
ground–– – – –
50 (R/L) 47RGB signal
(R: red)Output ONSelect “Display
Diagnosis (DCU)” of
CONFIRMATION/
ADJUSTMENT
function.NAVI screen
looks bluish. Terminal No.
(Wire color)
ItemSignal
input/
outputCondition
Voltage
(Approx.)Example of
symptom
+–Igni-
tion
switchOperation
SKIA4403E
SKIA0164E
SKIA4977E
SKIA4978E
SKIA4979E
SKIA4980E

NAVIGATION SYSTEM
AV-95
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: August 20072004 QX56
51 (B) 49RGB area
(YS) signalOutput ONPress the“TRIP”
button.RGB screen is
not shown.
52 (R/W) 47RGB signal
(G: green)Output ONSelect “Display
Diagnosis (DCU)” of
CONFIRMATION/
ADJUSTMENT
function.Screen looks
reddish.
53 (W) 49Vertical syn-
chronizing
(VP) signalInput ON –Operating
screen for audio
and A/C is not
displayed when
showing NAVI
screen.
54 (B) 47RGB signal
(B: blue)Output ONSelect “Display
Diagnosis (DCU)” of
CONFIRMATION/
ADJUSTMENT
function.Screen looks
yellowish.
55 (R) 49Horizontal
synchroniz-
ing (HP) sig-
nalInput ON –Operating
screen for audio
and A/C is not
displayed when
showing NAVI
screen.
56 (G) 49RGB syn-
chronizing
signalOutput ONPress the “TRIP”
button.NAVI screen is
rolling. Terminal No.
(Wire color)
ItemSignal
input/
outputCondition
Vo ltag e
(Approx.)Example of
symptom
+–Igni-
tion
switchOperation
SKIA0162E
SKIA4981E
SKIA4983E
SKIA4982E
SKIA4983E
SKIA0164E

AV-96
NAVIGATION SYSTEM
Revision: August 20072004 QX56
Terminals and Reference Value for Display unitEKS007LQ
Terminal No. (Wire
color)
ItemSignal
input/
outputCondition
Vo ltag e
(Approx.)Example of
symptom
+–Igni-
tion
switchOperation
1 (B) Ground Ground – ON – 0 V –
2 (L/W) GroundPower sup-
ply (Inverter) Input ON – 9 VScreen is not
shown.
3 (L/R) GroundPower sup-
ply (Signal) Input ON – 9 VScreen is not
shown.
6 (R/W) 7RGB signal
(G: green)Input ONSelect “Display
Diagnosis (DCU)” of
CONFIRMATION/
ADJUSTMENT
function.Screen looks
reddish.
7–Shield
ground–– – – –
8 (R) 21Horizontal
synchroniz-
ing (HP) sig-
nalOutput ON –Operating
screen for audio
and A/C is not
displayed when
showing NAVI
screen.
9 (B) 21RGB area
(YS) signalInput ONPress the “TRIP”
button.RGB screen is
not shown.
11 (B/W) 23Display com-
munication
signal
(DCU-DSP)Input ON –Though a screen
is displayed, it is
impossible to
adjust bright-
ness.
13 (P) Ground(Inverter)
Ground –ON – 0 V –
14 (P/L) Ground(Signal)
Ground –ON – 0 V –
17 (R/L) 7RGB signal
(R: red)Input ONSelect “Display
Diagnosis (DCU)” of
CONFIRMATION/
ADJUSTMENT
function.Screen looks
bluish.
SKIA4981E
SKIA4983E
SKIA0162E
SKIA4364E
SKIA4980E

NAVIGATION SYSTEM
AV-97
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: August 20072004 QX56
18 (B) 7RGB signal
(B: blue)Input ONSelect “Display
Diagnosis (DCU)” of
CONFIRMATION/
ADJUSTMENT
function.Screen looks
yellowish.
19 (G) 21RGB syn-
chronizing
signalInput ONPress the “TRIP”
button.NAVI screen is
rolling.
20 (W) 21Vertical syn-
chronizing
(VP) signalOutput ON –Operating
screen for audio
and A/C is not
displayed when
showing NAVI
screen.
21 –Shield
ground–– – – –
22 (L) 23Display com-
munication
signal
(DSP-DCU)Output ON –Though a screen
is displayed, it is
impossible to
adjust bright-
ness.
23 –Shield
ground–– – – – Terminal No. (Wire
color)
ItemSignal
input/
outputCondition
Vo l ta g e
(Approx.)Example of
symptom
+–Igni-
tion
switchOperation
SKIA4982E
SKIA0164E
SKIA4983E
SKIA4363E

AV-98
NAVIGATION SYSTEM
Revision: August 20072004 QX56
Terminals and Reference Value for AV SwitchEKS007LR
Te r m i n a l N o .
(Wire color)
ItemSignal
input/
outputCondition
Voltage
(Approx.)Example of
symptom
+–Ignition
switchOperation
1 (Y) GroundBattery
powerInput OFF - Battery voltageSystem does not
work properly.
2 (V) Ground ACC signal Input ACC - Battery voltageSystem does not
work properly.
3 (R/L) GroundIllumination
signalInput OFFLighting switch is
ON (position 1).Battery voltageAV switch illumi-
nation does not
come on when
lighting switch is
ON (position 1). Turn lighting switch
OFF.3.0V or less
4 (BR) GroundIllumination
control signalInput ONIllumination control
switch is operated
by lighting switch in
1st position.Changes between 0 and 12V.AV switch illumi-
nation cannot be
controlled.
5 (B) Ground Ground - ON - 0V -
6 (V) GroundCommunica-
tion signal (+)Input/
outputON -System does not
work properly.
7-Shield
ground-- - - -
8 (LG) GroundCommunica-
tion signal (-)Input/
outputON -System does not
work properly.
12 (R) GroundRemote con-
trol AInput ONPress MODE
switch 0V
Steering wheel
audio controls
do not function. Press SEEK UP
switch0.75V
Press VOL UP
switch2V
Except for above 5V
13 (G) GroundRemote con-
trol BInput ONPress POWER
switch 0V
Steering wheel
audio controls
do not function. Press SEEK
DOWN switch0.75V
Press VOL DOWN
switch2V
Except for above 5V
14 (L) -Remote con-
trol ground-- - -Steering wheel
audio controls
do not function.
SKIA0175E
SKIA0176E
