FUEL INJECTOR AND FUEL TUBE
EM-29
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: August 20072004 QX56
FUEL INJECTOR AND FUEL TUBEPFP:16600
Removal and InstallationEBS00ILK
CAUTION:
Do not remove or disassemble parts unless instructed as shown.
REMOVAL
1. Remove the engine room cover using power tool. Refer to EM-11, "REMOVAL" .
2. Release the fuel pressure. Refer to EC-46, "
FUEL PRESSURE RELEASE" .
3. Disconnect the negative battery terminal.
4. Disconnect the fuel injector harness connectors.
5. Disconnect the fuel hose assembly from the fuel tubes (right bank and left bank).
CAUTION:
Plug the fuel hoses to prevent fuel from draining.
Do not separate the fuel connector and fuel hose.
6. Remove the fuel injectors with the fuel tube assembly.
1. Fuel tube (right bank) 2. Cap 3. Fuel damper
4. O-ring 5. O-ring (Blue) 6. Fuel injector
7. Clip 8. O-ring (Brown) 9. O-ring
10. Fuel hose assembly 11. Fuel tube (left bank)
KBIA2472E
Page 1913 of 3371
EM-30Revision: August 2007
FUEL INJECTOR AND FUEL TUBE
2004 QX56
7. Remove the fuel injector from the fuel tube using the following
steps.
a. Spread open and remove the clip.
b. Remove the fuel injector from the fuel tube by pulling straight
out.
CAUTION:
Be careful with remaining fuel that may leak out from fuel
tube.
Do not damage injector nozzles during removal.
Do not bump or drop fuel injectors.
Do not disassemble fuel injectors.
8. Remove the fuel damper from each fuel tube.
INSTALLATION
1. Install the fuel damper to each fuel tube using the following
steps.
a. Apply engine oil to the new O-ring and set it into the cap of the
fuel tube.
CAUTION:
Handle O-ring with bare hands. Never wear gloves.
Lubricate new O-ring with new engine oil.
Do not clean O-ring with solvent.
Make sure that O-ring and its mating part are free of for-
eign material.
When installing O-ring, do not scratch it with tool or fin-
gernails.
Do not twist or stretch the O-ring.
b. Make sure that the backup spacer is in the O-ring connecting surface of the fuel damper.
NOTE:
The backup spacer is part of the fuel damper assembly.
c. Insert the fuel damper until it seats on the fuel tube.
CAUTION:
Insert straight, making sure that the axis is lined up.
Do not pressure-fit with excessive force.
d. Install the cap, and then tighten the bolts evenly.
After tightening the bolts, make sure that there is no gap between the cap and fuel tube.
2. Install new O-rings to the fuel injector paying attention to the items below.
CAUTION:
Upper and lower O-ring are different.
KBIA2506E
Reference value :130 N (13.3 kg, 29.2 lb)
KBIA2473E
Page 1914 of 3371
FUEL INJECTOR AND FUEL TUBE
EM-31
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: August 20072004 QX56
Handle O-ring with bare hands. Never wear gloves.
Lubricate O-ring with new engine oil.
Do not clean O-ring with solvent.
Make sure that O-ring and its mating part are free of foreign material.
When installing O-ring, be careful not to scratch it with tool or fingernails. Also be careful not to
twist or stretch O-ring. If O-ring was stretched while it was being attached, do not insert it
quickly into fuel tube.
Insert O-ring straight into fuel tube. Do not angle or twist it.
3. Install the fuel injector to the fuel tube using the following steps.
a. Insert new clip into clip mounting groove on the fuel injector.
Insert clip so that lug “A” of fuel injector matches notch “A” of
the clip.
CAUTION:
Do not reuse clip. Replace it with a new one.
Do not allow the clip to interfere with the O-ring. If
interference occurs, replace the O-ring.
b. Insert the fuel injector into the fuel tube with the clip attached.
Insert it while matching it to the axial center.
Insert fuel injector so that lug “B” of fuel tube matches notch
“B” of the clip.
Make sure that the fuel tube flange is securely fixed in the
flange fixing groove on the clip.
c. Make sure that installation is complete by checking that fuel
injector does not rotate or come off.
Make sure that the protrusions of the fuel injectors are aligned
with the cutouts of the clips after installation.
4. Install the fuel tube and fuel injector assembly to the intake manifold.
CAUTION:
Do not let the tip of the injector nozzle come in contact with other parts.
Tighten fuel tube assembly bolts “a” to “b” in illustration in two
steps.
5. Install the fuel hose assembly.
Insert connectors straight, making sure that the axis is lined up with fuel tube side to prevent O-ring
from being damaged.
Tighten the bolts evenly in several steps.
Make sure that there is no gap between the flange and fuel tube after tightening the bolts.
CAUTION:
Handle O-ring with bare hands. Do not wear gloves.Fuel tube side : Blue
Nozzle side : Brown
KBIA2507E
1st step : 12.8 N·m (1.3 kg-m, 9 ft-lb)
2nd step : 24.5 N·m (2.5 kg-m, 18 ft-lb)
KBIA2474E
Page 1915 of 3371
EM-32Revision: August 2007
FUEL INJECTOR AND FUEL TUBE
2004 QX56
Lubricate O-ring with new engine oil.
Do not clean O-ring with solvent.
Make sure that O-ring and its mating part are free of foreign material.
When installing O-ring, be careful not to scratch it with tool or fingernails. Also be careful not to
twist or stretch O-ring. If O-ring was stretched while it was being attached, do not insert it
quickly into fuel tube.
Insert new O-ring straight into fuel tube. Do not twist it.
6. Installation of the remaining components is in the reverse order of removal.
INSPECTION AFTER INSTALLATION
After installing the fuel tubes, make sure there are no fuel leaks at the connections using the following steps.
1. Apply fuel pressure to the fuel lines by turning the ignition switch ON (with engine stopped). Then check
for fuel leaks at the connections.
NOTE:
Use mirrors for checking on hidden points.
2. Start the engine and rev it up and check for fuel leaks at connections.
CAUTION:
Do not touch the engine immediately after stopping, as engine becomes extremely hot.
Page 1916 of 3371
ROCKER COVER
EM-33
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: August 20072004 QX56
ROCKER COVERPFP:13264
Removal and InstallationEBS00ILL
REMOVAL
1. Remove the engine room cover using power tool. Refer to EM-11, "REMOVAL" .
2. Remove the air duct and resonator assembly. Refer to EM-14, "
REMOVAL" (for left bank only) .
3. Move the harness on the upper rocker cover and its peripheral aside.
4. Remove the electric throttle control actuator, loosening bolts diagonally (for left bank only).
5. Remove the ignition coil. Refer to EM-26, "
REMOVAL" .
6. Remove the PCV hose from the PCV control valve.
7. Loosen the bolts in reverse order shown using power tool.
CAUTION:
Do not hold the rocker cover by the oil filler neck (right
bank).
1. Rocker cover (left bank) 2. PCV control valve 3. O-ring
4. Rocker cover gasket (left bank) 5. Rocker cover (right bank) 6. PCV control valve
7. O-ring 8. Oil filler cap 9. Rocker cover gasket (right bank)
KBIA2508E
KBIA2509E
Page 1919 of 3371
EM-36Revision: August 2007
TIMING CHAIN
2004 QX56
NOTE:
To remove timing chain and associated parts, start with those on the left bank. The procedure for remov-
ing parts on the right bank is omitted because it is the same as that for removal on the left bank.
To install timing chain and associated parts, start with those on the right bank. The procedure for installing
parts on the left bank is omitted because it is the same as that for installation on the right bank.
REMOVAL
1. Remove the engine assembly from the vehicle. Refer to EM-70, "REMOVAL" .
2. Remove the following components and related parts:
Drive belt auto tensioner and idler pulley. Refer to EM-12, "DRIVE BELTS" .
Thermostat housing and water hose. Refer to CO-17, "Removal of Thermostat Housing, Water Outlet
and Heater Pipe" .
Power steering pump bracket. Refer to PS-26, "REMOVAL" .
Oil pan (lower), (upper) and oil strainer. Refer to EM-22, "OIL PAN AND OIL STRAINER" .
Ignition coil. Refer to EM-26, "IGNITION COIL" .
Rocker cover. Refer to EM-33, "ROCKER COVER" .
3. Remove the chain case cover (right bank) and (left bank).
a. Loosen and remove the bolts in the reverse order shown.
b. Cut the liquid gasket to remove covers using Tool.
CAUTION:
Do not damage mating surfaces.
4. Obtain compression TDC of No. 1 cylinder as follows:
a. Turn crankshaft pulley clockwise to align the TDC identification
notch (without paint mark) with timing indicator on front cover.
1. Camshaft sprocket (left bank EXH) 2. Camshaft sprocket (left bank INT) 3. Camshaft sprocket (right bank INT)
4. Camshaft sprocket (right bank EXH) 5. Front cover 6. Chain case cover (right bank)
7. Chain case cover (left bank) 8. Crankshaft pulley bolt 9. Crankshaft pulley
10. Chain tensioner cover 11. Front oil seal 12. Oil pump drive spacer
13. Oil pump assembly 14. Crankshaft sprocket 15. Bracket
16. O-ring 17. Timing chain tension guide (right
bank)18. Timing chain slack guide (right bank)
19. Timing chain (right bank) 20. Timing chain (left bank) 21. Chain tensioner (right bank)
22. Timing chain slack guide (left bank) 23. Timing chain tension guide (left
bank)24. Chain tensioner (left bank)
Tool number: KV10111100 (J-37228)
KBIA2475E
KBIA2476E
Page 1923 of 3371
EM-40Revision: August 2007
TIMING CHAIN
2004 QX56
2. Install camshaft sprockets.
Install intake and exhaust camshaft sprocket by selectively
using the groove of dowel pin according to the bank (common
part used for both banks).
Lock the hexagonal part of camshaft in the same way as for
removal, and tighten bolts.
3. Install crankshaft sprockets for both banks.
Install each crankshaft sprocket so that its flange side (the
larger diameter side without teeth) faces in the direction as
shown.
NOTE:
The same parts are used but facing directions are different.
4. Install timing chains and associated parts.
Align the mating mark on each sprocket and the timing chain for installation.
CAUTION:
Before installing chain tensioner, it is possible to change the position of mating mark on tim-
ing chain and each sprocket. After the mating marks are aligned, keep them aligned by hold-
ing them by hand.
Install slack guides and tension guides onto correct side by checking with identification mark on sur-
face.
Install chain tensioner with plunger locked in with stopper pin.
CAUTION:
Before and after the installation of chain tensioner, make sure that the mating mark on timing
chain is not out of alignment.
After installing chain tensioner, remove the stopper pin to release tensioner. Make sure ten-
sioner is released.
To avoid chain-link skipping of timing chain, never move crankshaft or camshafts until front
cover is installed.
5. In the same way as for right bank, install the timing chain and associated parts on the left side.
6. Install the oil pump.
7. Install the oil pump drive spacer as follows:
Install so that the front mark on the front edge of oil pump
drive spacer faces the front of the engine.
Insert oil pump drive spacer according to the directions of the
crankshaft key and the two flat surfaces of oil pump inner
rotor.
If the positional relationship does not allow the insertion,
rotate oil pump inner rotor to allow the oil pump drive spacer
to be inserted.
KBIA2480E
KBIA2515E
KBIA2490E
Page 1925 of 3371
EM-42Revision: August 2007
TIMING CHAIN
2004 QX56
d. Install bolts in the numerical order shown.
e. Tighten to the specified torque.
CAUTION:
Be sure to wipe off any excessive liquid gasket leaking onto
surface mating with oil pan.
11. Install chain case cover (right bank) and (left bank) as follows:
a. Apply liquid gasket as shown.
Use Genuine RTV Silicone Sealant or equivalent. Refer to
GI-45, "
Recommended Chemical Products and Sealants".
CAUTION:
Both the start and end of application of liquid gasket should
be crossed at an invisible position after attaching the chain
case cover.
b. Install bolts in the numerical order shown.
12. Install the crankshaft pulley.
Install the key of the crankshaft.
Insert the pulley by lightly tapping it.
CAUTION:
Do not tap pulley on the side surface where belt is installed (outer circumference).
13. Tighten the crankshaft pulley bolt.
Lock crankshaft using suitable tool, then tighten the bolt.
Perform the following steps for angular tightening:
a. Apply engine oil onto threaded parts of bolt and seating area.
b. Select one most visible notch of the four on bolt flange. Corre-
sponding to the selected notch, put a mating mark (such as
paint) on crankshaft pulley.
14. Rotate crankshaft pulley in normal direction (clockwise when
viewed from engine front) to check for parts interference.
15. Installation of the remaining components is in the reverse order
of removal.M6 × 50 mm (1.97 in) : No. 1, 20, 25, 26, 27
M6 × 80 mm (3.15 in) : No. 4, 5, 7
M6 × 20 mm (0.79 in) : Except the above
KBIA2478E
KBIA2481E
WBIA0468E
Crankshaft pulley bolt torque
Step 1 : 93.1 N·m (9.5 kg-m, 69 ft-lb)
Step 2 : additional 90° (angle tightening)
KBIA2519E
Page 1935 of 3371
EM-52Revision: August 2007
CAMSHAFT
2004 QX56
Install intake and exhaust side camshaft sprocket by selec-
tively using the groove of dowel pin according to the bank.
(Common part used for both banks.)
b. Lock the hexagonal part of camshaft in the same way as for
removal, and tighten bolts.
c. Check again that the timing mating mark on timing chain and on
each sprocket are aligned.
6. Install chain tensioner with the following procedure:
NOTE:
Left bank is shown.
a. Install chain tensioner.
Compress plunger and hold it with a stopper pin when install-
ing.
Loosen the slack guide side timing chain by rotating camshaft
hexagonal part if mounting space is small.
b. Remove stopper pin and release plunger, and then apply ten-
sion to timing chain.
c. Install chain tensioner cover onto front cover. (RH bank)
Apply liquid gasket as shown.
Use Genuine RTV Silicone Sealant or equivalent. Refer to
GI-45, "
Recommended Chemical Products and Seal-
ants" .
7. Check and adjust valve clearances. Refer to EM-52, "
Va l v e
Clearance" .
8. Installation of the remaining components is in the reverse order
of removal.
Va lv e C le a ra n c eEBS00ILO
INSPECTION
NOTE:
Perform inspection as follows after removal, installation or replacement of camshaft or valve-related parts, or if
there are unusual engine conditions due to changes in valve clearance over time (starting, idling, and/or
noise).
1. Warm up engine. Then stop engine.
2. Remove engine cover, battery cover and air duct. Refer to EM-11, "
Removal and Installation" , SC-9,
"REMOVAL" and EM-14, "Removal and Installation" .
3. Remove right bank and left bank rocker covers using power tool. Refer to EM-33, "
Removal and Installa-
tion" .
KBIA2480E
Chain tensioner bolts : 6.9 N·m (0.70 kg-m, 61 in-lb)
Tensioner cover bolts : 9.0 N·m (0.92 kg-m, 80 in-lb)KBIA2479E
KBIA2547E
Page 1936 of 3371
CAMSHAFT
EM-53
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: August 20072004 QX56
4. Turn crankshaft pulley in normal direction (clockwise when
viewed from engine front) to align TDC identification notch (with-
out paint mark) with timing indicator.
5. At this time, make sure both the intake and exhaust cam noses
of No. 1 cylinder (top front on left bank) face outside.
If they do not face outside, turn crankshaft pulley once more.
6. Measure valve clearances at locations marked “×” as shown in
the table below (locations indicated with black arrow) using suit-
able tool.
NOTE:
Firing order 1-8-7-3-6-5-4-2
No. 1 cylinder compression TDC
Measure valve clearance using suitable tool.
KBIA2476E
KBIA0400J
Measuring position (RH bank) No. 2 CYL No. 4 CYL No. 6 CYL No. 8 CYL
No. 1 cylinder at TDC EXH ×
INT××
Measuring position (LH bank) No. 1 CYL No. 3 CYL No. 5 CYL No. 7 CYL
No. 1 cylinder at TDCINT××
EXH××
KBIA2526E
Valve clearance standard:
Hot*
Intake : 0.304 - 0.416 mm (0.012 - 0.016 in)
Exhaust : 0.308 - 0.432 mm (0.012 - 0.017 in)
Cold
Intake : 0.26 - 0.34 mm (0.010 - 0.013 in)
Exhaust : 0.29 - 0.37 mm (0.011 - 0.015 in)
* : Approximately 80°C (176°F)
KBIA0185E
